Living Spaces 7030-01155 KIT User manual

BOX 1: 4653 Summit Bookcase Bed Twin Headboard
Part # Description Quantity
4653 Summit Bookcase Bed Twin Headboard
1
BOX 2: 4652 Summit Bookcase Bed Twin Footboard
Part # Description Quantity
S0178END Summit Bookcase Bed Twin Footboard
1
BOX 3: 4650 Summit Bookcase Bed Twin Frame Rails
Part # Description Quantity
S1001SRL 5/4 x 6x 75 Mattress Rail
2
149383/40 Twin Individual Slat 3
5040-43183 7MM x 100MM Decorative Lag Bolt 8
5040-35410 #6 x 1 1/4 Phil Flat Slat Scew 10
ALNWR 4MM Allen Wrench 1
PWRDD 4MM Power Drill Driver 1
COMPLETED ASSEMBLY
7030-01155 KIT
4650 Frame Rails/4653 Heaboard/4654 Footboard
Summit Collection: Twin Bookcase Bed
PARTS LIST
(Scan for
instructional
video)

ASSEMBLY INSTRUCTIONS
4653
S0178END
S1001SRL
5040-43183

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
Diagram 1 Diagram 2
Scan Code for Instructional video

Mateo/Summit Collections: Knob and Pull Installation
7030-01195 KIT
1. Locate the box containing your knobs and/or pulls in the bottom drawer of your case
good.
2. Identify which of the screw sizes is correct for your drawers/doors. The screw should
protrude no more than 1/4" when pushed through the pre-drilled holes on your
drawers/doors.
3. Push the screw through the back of the pre-drilled hole on the drawer/door and line it
up with the thread on the back of the knob/pull.
4. Tighten the screw into the back of the knob/pull until the knob/pull is tight against the
front of your drawer/door.
**You can tighten your screws with either a phillips screwrdiver,
a drill with a phillips bit, or your hand**
(Scan code for
instructional
video)
