Living Spaces Eloise Queen User manual

CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning：do not move bed after final assembly as it may result in damages to floor and/or bed.~
Hardware included in side rails carton .
1
Step#1
Loosen Bolts (B) and Washers (E), which are pre-fitted into edges of headboard and
footboard, clip side rail bracket over the bolt and re-tighten using Wrench (I).
A
D
F
I
J
L
N
Φ10 MM
Φ6 MM
H=20CM
Φ8*70 MM
H=22.5CM
Φ10 MM
4PCS
3PCS
4PCS
1PC
3PCS
4PCS
13PCS
M
O
P
Q
Y
Z
Φ6*40 MM
Φ10 MM
3PCS
1PC
26 PCS
26 PCS
1 PC
4 PCS
Eloise Queen Assembly Instructions
*Bolt B and Washer E
are factory installed*

CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning：do not move bed after final assembly as it may result in damages to floor and/or bed.~
2
Step#2
Attach wooden legs to the angle bracket using Nut (Z) ,Washer (L) and Spring washer
(A) .Tighten/secure Nut (Z) using Wrench (Y) until snug.
3
Step#3
Remove Bolt (B) & Washer (E), attach center support rail (O) to the headboard and
footboard using Bolt (B) and Washer (E).
Attach center support legs (J) to the center support rail (O) using Wrench (I), Bolt (M) and
Washer (D).
Eloise Queen Assembly Instructions

CONGRATULATIONS ON YOUR NEW BED PURCHASE
~Warning：do not move bed after final assembly as it may result in damages to floor and/or bed.~
4
Step#4
Move/place bed into final position in bedroom.
Attach curved slats support system to full length steel side rail support cleats.please put slats
into end clip (Q) first，then connect with center clip (N),verify the slats are inserted properly
into center clip (N) and end clip (Q).
Verify the center support legs are perpendicular to the floor for full support.
Eloise Queen Assembly Instructions
*Clip(Q) are factory installed*
