Living Spaces SEDONA 4710 User manual

MAS90: 5043-43190
7109TWR WRANGLER/HIGH SIERRA
QTY: DESCRIPTION:
24 1/4 X 4 HEX LAG BLK
24 3/16 USS FL WASHER BLK
20 6 X 1 1/4 PHIL FLAT PARTICLE BOARD SCREW
41/2 X 3 FLUTED DOWEL
7030-00355 KIT

4710/4711
SEDONA TWIN/TWIN BUNK BED
w/ TRUNDLE/MATTRESS AND
STAIRWAY CHEST 00355
PARTS LIST:
A) 24-4 1/4" Lag Bolts
B) 24-Black Steel Washers
C) 2 -Bottom End Assemblies
D) 2 -Top End Assemblies
E) 4 -7" x 75" Mattress Rails w/Support Cleats
F) 2 -5" x 75" Guard Rails
G) 4 -1/2" x 3" Wooden Dowels
H) 6 -3 1/2" x 38 1/2" Mattress Supports
I) 20-1 1/4" Wood Screws
TOOLS REQUIRED:
1) 7/16" Wrench or Socket Wrench
2) Phillips Head Screwdriver
Recommended: Electric driver with 7/16” socket
Make sure you have all parts before beginning assembly. If you need a part, contact Living Spaces
1) Attach two mattress rails(E) to two bottom end assemblies(C) with 8 lag bolts and 8 washers, and tighten.
Be sure that the holes in the posts (legs) are UP for this step!
2)Attach two mattress rails(E) and two guard rails(F) to top end assembly(D) with 16 lag bolts and 16
washers, and tighten. Be sure the holes in the posts (legs) are DOWN for this step!
3) Roll out Slat kit across bed surface stretching slats from bed end to bed end. Secure the two outermost slats
on the ends with 4 wood screws, one at each corner of the bed. Center 3 individual slats in the 3 gaps built
into the slat kit, and secure with 6 wood screws, one at each end of the individual slat.
4) Repeat step 3 for the other bed assembly.
5) Place four wooden dowels in the four holes in top edge of bottom bunk assembly.
6) Lift the top bunk assembly onto the bottom bunk assembly, ensuring that the dowels are inserted in holes in
the top bunk assembly.
7) Attach knobs to Trundle front
8) Add amattress not to exceed 7" in thickness and sleep well!
A FOUNDATION IS REQUIRED WITH 3 SLAT CONFIGURATION

00700
SAFETY WARNING
Our Bunk Beds have been tested by an Independent Laboratory and are certified to be in compliance with: ASTM F-1427,
“Standard Consumer Safety Specification for Bunk Beds” and U.S. Government specifications 16 Code of Federal
Regulations, parts 1213 and 1513.
SAFETY WARNINGS
1. Follow the information on the warnings attached to the upper bunk end structure and on the carton. Do not remove this
label.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment or
falls.
3. Surface of mattress must be at least five inches(127mm) below the upper edge of guardrails.
4. Do not allow children less than six years of age to use the upper bunk.
5. Periodically, check and ensure that the guardrail, ladder and other components are in their proper position, free from
damage and that all connectors are tight.
6. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder or bed end for entering and leaving the upper bunk.
9. Do not use substitute parts. Contact manufacturer or dealer for replacement parts.
10.Use of a night-light may provide added safety precautions for a child using the upper bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be placed against the
wall to prevent entrapment between the bed and the wall. (This applies only to bunk beds without two full-length
guardrails.)
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is prohibited.
14. Keep these instructions for future reference.
STRANGULATION HAZARD
15. Never attach or hang items to any part of the bunk bed that are not designed for use with the bed for example, but not
limited to hooks, belts and jump ropes.
SIZE OF UPPER AND LOWER MATTRESS AND FOUNDATION
Your Twin bed is designed to use a mattress 37”-39” in width and 74” - 75” in length.
Your Full bed is designed to use a mattress 52”-54” in width and 74” - 75” in length.
The total thickness of mattress and foundation (slat kit, bunk board, etc.) combined must not exceed 7”.
Note: There must be at least 5” from mattress sleeping surface to top edge of guardrail.
REPLACEMENT PARTS
Replacement parts, including additional guardrails, may be obtained from your Furniture dealer.
* A FOUNDATION IS REQUIRED WITH 3 SLAT CONFIGURATION *

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat

MAS90: 5043-43381
TRUNDLE BED HARDWARE
QTY: DESCRIPTION:
4CASTERS WITH INSERT
7030-00205 KIT
4 - Antique Brass Knobs 4 - 1 1/2" Screws
4
4
ANTIQUE BRASS KNOBS
1 1/2" SCREWS

TRUNDLE BED
4466 SEDONA
28 7/8" 28 7/8"
1/2"
39"
PARTS LIST:
A) Assembled Caster Frame
B) Bunkie Mattress
C) 4 Casters w/ Metal Stem
D) 4 Black Plastic Caster Inserts
TOOLS REQUIRED:
Phillips Screwdriver
ASSEMBLY INSTRUCTIONS:
NOTE:
Make sure you have all parts before beginning assembly. If you need a part, contact the dealer where you
purchased your bed.
1.) Push the 4 caster inserts into the pre-drilled holes on the bottom of the bed. Make sure the inserts sit
flush with the holes and do not protrude.
*Do no attempt to complete step 1 with the caster stems attached to the caster inserts*
7030-00335
2.) Once all 4 caster inserts are in place, install the caster wheels by pushing the stems of the caster wheels
into the inserts and locking them into place.
3.) Attach 4 metal knobs to trundle front with the 1 1/2" screws provided. Lay Bunkie mattress in place, and
slide under bed or lower bunk.

7030-00420
STAIRWAY CHEST WITH BUNK BED
 


 



 
 

 
44 5 3
