Living Spaces LOGAN BED QUEEN 54003076 User manual

AX 1
BX 1
CX 2
DX 2
EX 14
F
X 20
X 20
X 20
X 1
X 2
ASSEMBLY REQUIRES 30 MINUTE KEEP INSTRUCTIONS
TWO PEOPLE ASSEMBLY TIME FOR FUTURE USE
54003076
LOGAN BED QUEEN
Assembly Instructions
Parts and Tools
54003076
LOGAN BED QUEEN
54003076-A
54003076-B
54003076-C
54003076-D
54003076-E
54003076-F
F
G
H
I
J
Page 1 of 3

1
Stand both Headboard (A) and Footboard (B) to assemble the two Side rails (C) using Open Wrench (I) to tighten Bolts (F)
Spring Washers (G) and Washers (H). Adjust levelers as needed.
2
Assemble the Center Support Rails (D) into both Headboard and Footboard using Open Wrench (I) to tighten Bolts (F)
Spring Washers (G) and Washers (H).
3
Install the Slats (E) correctly in between joints.
LOGAN BED QUEEN
54003076
Assembly Instructions
Page 2 of 3

4
Secure the middle slat by using a screwdriver to fasten Screws (J) through the predrilled holes at the two ends of the slat into the side
rails.
5
Completed item
Assembly Instructions
LOGAN BED QUEEN
54003076
Page 3 of 3
