Living Spaces SUMMIT 4674 User manual

MAS90: 5043-43250
SUMMIT BUNK FRAME HARDWARE
QTY: DESCRIPTION:
32 100MM DECORATIVE HEAD LAG BOLTS
14MM ALLEN WRENCH
41/2" X 3" FLUTED WOODEN DOWELS
20 6 X 1 1/4" PHIL FLAT PARTICLE BOARD SCREW
14MM DRIVER FOR POWER DRILL
7030-00449 KIT
ASSEMBLY: 2 PERSONS AND 60 MINUTES
TOOLS:
1) 4mm Allen Wrench (INCLUDED)
2) 4mm Allen Drill Bit (Be sure to FULLY SEAT bit into bolt head before turning)
3) Phillips head Screwdriver or Drill with Phillips Bit
*We recommend using a power driver with the drill bit if available*
BE SURE THAT LAG BOLTS ARE STARTED INTO THE HOLES ON THE FRAME RAILS DURING
ASSEMBLY. DO NOT FULLY TIGHTEN UNTIL ASSEMBLY IS COMPLETE

4674/4675 SUMMIT FULL/FULL BUNK BED
7030-00449
PARTS LIST:
A) 32 - 100mm Decorative Head Lag Bolts
B) 1 - 4mm Allen Wrench
C) 2 - Top End Assemblies
D) 2 - Bottom End Assemblies
E) 4 - 5" x 75" Mattress Rails w/Support Cleats
F) 4 - 3 1/4" x 75" Guard Rails
G) 4 - 1/2" x 3" Wooden Dowels
H) 6 - 3 1/2" x 53 3/4" Loose Slats
I) 20 - 1 1/4" Wood Screws
J) 1 - 4mm Driver for Power Drill
ASSEMBLY INSTRUCTIONS:
Make sure you have all parts before beginning assembly. If you need a part, contact the dealer where you
purchased your bed.
1) Attach two mattress rails(E) to two bottom end assemblies(D) with 8 lag bolts and tighten.
2) Attach two mattress rails(E) and two guard rails(F) to top end assembly with 24 lag bolts and tighten.
3) Place four wooden dowels in the four holes in top edge of bottom bunk assembly.
4) Place the top bunk assembly on the bottom bunk assembly, ensuring that the dowels are inserted in holes in the top bunk
assembly.
5) Spread Slat roll out across bed frame from end to end. Place wood screws in 4 outside corners with slat pushed tightly up
against the bed ends. Place 3 loose slats into gaps in slat roll, and screw down with wood screws. See slat installation
information on following pages.
6) Add the proper thickness innerspring bunk mattresses. See dealer for details.
BE SURE THAT LAG BOLTS ARE STARTED INTO THE
HOLES ON THE FRAME RAILS DURING ASSEMBLY. START
LAG BOLTS INTO ALL RAILS BEFORE TIGHTENING.

00500
SAFETY WARNING
Summit Bunk Beds have been tested by an Independent Laboratoryand are certified to be in compliance
with: ASTM F-1427, “Standard Consumer Safety Specification for Bunk Beds” and U.S. Government
specifications 16 Code of Federal Regulations, parts 1213 and 1513.
SAFETY WARNINGS
1. Follow the information on the warnings attached to the upper bunk end structure and on the carton. Do
not remove this label.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the
likelihood of entrapment or falls.
3. Surface of mattress must be at least five inches(127mm) below the upper edge of guardrails.
4. Do not allow children less than six years of age to use the upper bunk.
5. Periodically, check and ensure that the guardrail, ladder and other components are in their proper
position, free from damage and that all connectors are tight.
6. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder or bed end for entering and leaving the upper bunk.
9. Do not use substitute parts. Contact manufacturer or dealer for replacement parts.
10. Use of a night-light may provide added safety precautions for a child using the upper bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be
placed against the wall to prevent entrapment between the bed and the wall. (This applies only to bunk
beds without two full-length guardrails.)
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is prohibited.
14. Keep these instructions for future reference.
STRANGULATION HAZARD
15. Never attach or hang items to any part of the bunk bed that are not designed for use with the bed for
example, but not limited to hooks, belts and jump ropes.
SIZE OF MATTRESS AND FOUNDATION
Your Twin bed is designed to use a mattress 37”-39” in width and 74” - 75” in length.
Your Full bed is designed to use a mattress 52”- 54” in width and 74” - 75” in length.
The total thickness of mattress and foundation (slat kit, bunk board, etc.) combined must not exceed 10”.
Note: There must be at least 5” from mattress sleeping surface to top edge of guardrail.
REPLACEMENT PARTS
Replacement parts, including additional guardrails, maybe obtained from your Furniture dealer.
A FOUNDATION IS REQUIRED WITH 3 SLAT CONFIGURATION

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
