ASSEMBLY INSTRUCTIONS
LUCA PANEL/BUNK/DAYBED TRUNDLE
SKU: 314671
314583
314627
1
15 min
ITEM NO: Y2103W-348
Y2103B-348
Y2103G-348
x 2 x 1 x 1

PART SKU# IMAGE DESCRIPTION QTY
AFront 1
2
BBack rail 1
CSide rails 2
DSlats 1
1996-A-W: (White)
1996-A-B: (Blue)
1996-A-G: (Grey)
1996-B-W: (White)
1996-B-B: (Blue)
1996-B-G: (Grey)
1996-C-W: (White)
1996-C-B: (Blue)
1996-C-G: (Grey)
1996-D
Part list

1
2
Part IMAGE DESCRIPTION QTY
3
Hardware List of Luca Trundle
SKU#
THE HARDWARE IS LOCATED IN THE PACKING ITEM
NOTE: MUST TIGHTEN SCREWS PERIODIACLLY. WITH USE SCREW
MAY ENCOME LOOSE CHECK TIGHTNESS OF ALL SCREWS EVERY 6-8
WEEKS.
CLEANING INSTRUCTIONS:
After assembly, clean and polish the completed parts if necessary with
soft cloth and industrial recognized furniture polish.
3
4
5
6
Bolt and nut M8*70mm 8
Bolts M4*20mm 2
Dowel Ø8*40mm 4
Screws 8#*30mm 14
Allen key 60*22*4mm 1
Handle 1
1996-1(8)
1996-2(2)
1996-3(4)
1996-4(14)
1996-5(1)
1996-6(1)
Note: Screwdriver will be prepared by yourshelf.

Detail view
B
D
4
A
C
C

STEP 1:
- Firstly, please locate Side Rail (C) to Front (A), Back (B)
by dowel (3) .
- Fasten Side Rail (C) by (Bolt+nut) (1).
5
1=8 Pcs
3=4 Pcs
A
BC
C
6
4
D
3
3
3
3
STEP 2: Please fasten slats (D) by screw (4) into corresponding holes.
4=14 Pcs
Before assembly:
Move the nut out
1
1
1
1
1
1
1
1

STEP 3: Assemble the handle (5) into Front (A)
6
2=2 Pcs
5=1 Pc
5
2
A
That's it ! You've finished
assembling your item. Thank you!

ASSEMBLY INSTRUCTIONS
LUCA FULL-FULL BUNK BED
ITEM NO: Y2103W-345/343/346
Y2103B-345/343/346
Y2103G-345/343/346
SKU: 314668/314666/314669
314580/314578/314581
314624/314622/314625
1
30 min
x 2 x 1 x 1

PLEASE TAKE TIME TO READ ALL INSTRUCTIONS AND
WARNINGS BEFORE BEGINNING ASSEMBLY!
SAFETY WARNING
Our Bunk Beds have been tested by an Independent Laboratory and are certified to be in
compliance with:
ASTM F-1427, “Standard Consumer Safety Specification for Bunk Beds” and U.S. Government
specifications 16 Code of Federal Regulations, parts 1213 and 1513.
SAFETY WARNINGS
1. Follow the information on the warnings attached to the upper bunk end structure and on the
carton. Do not remove this label.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the
likelihood of entrapment or falls.
3. Top surface of mattress must be at least five inches (127mm) below the upper edge of top
guard rails.
4. Do not allow children less than six years of age to use the upper bunk.
5. Periodically, check and ensure that the guardrail, ladder and other components are in their
proper position, free from damage and that all connectors are tight.
6. Do not allow horseplay on or under the bed and prohibit jumping on the bed and ladder.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder or Stairway Chest for entering and leaving the upper bunk (as page 3).
9. Do not use substitute parts. Contact Living Spaces for replacement parts.
10. Use of a night-light may provide added safety precautions for a child using the upper Bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed
should be placed against the wall to prevent entrapment between the bed and the wall. (This applies
only to bunk beds without two full-length guardrails.)
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is expressly prohibited.
14. Keep these instructions for future reference.
STRANGULATION HAZARD
15. Never attach or hang items to any part of the bunk bed that are not designed for use with the
bed for example, but not limited to hooks, belts and jump ropes.
SIZE OF MATTRESS AND FOUNDATION
- Use only mattress which is 75'' long and 53- 53.5” wide on upper bunk, lower bunk of Full
bed.
- Ensure thickness of mattress does not exceed 6" and mattress is at least 5" below upper edge
of guardrails.
- Ensure thickness of mattress does not exceed 6" for lower bunk.
REPLACEMENT PARTS
Replacement parts, including additional guardrails, may be requested from Living Spaces, usually
at a cost.
2

Always use the ladder or Stairway Chest for
entering and leaving the upper bunk.
You will buy ladder/Stairway
as options.
3

BOX 1- FL/FL UPPER ENDS/SLATS BUNK BED
AUpper Ends 2
Slats 1
I
BOX 2- TW /FL + FL/FL LOWER ENDS/SLATS BUNK BED
BLower Ends 2
Slats 1
I
4
1987FF-A-W:(White)
1987FF-A-B:(Blue)
1987FF-A-G:(Grey)
1987FF-B-W:(White)
1987FF-B-B:(Blue)
1987FF-B-G:(Grey)
1987FF-I
PART SKU# IMAGE DESCRIPTION QTY
PART SKU# IMAGE DESCRIPTION QTY
1987FF-I
B(L) B(R)

BOX 3- FL/FL SIDE/GUARD RAILS/SLAT SUPPORT BUNK BED
CUpper Rails 2
Guard rails 4
D
EGuard rail
supports 2
HSlat supports 2
FLower
back rail 1
GLower
Front Rail 1
5
1987FF-C-W:(White)
1987FF-C-B:(Blue)
1987FF-C-G:(Grey)
1987FF-D-W:(White)
1987FF-D-B:(Blue)
1987FF-D-G:(Grey)
1987FF-E-W:(White)
1987FF-E-B:(Blue)
1987FF-E-G:(Grey)
1987FF-F-W:(White)
1987FF-F-B:(Blue)
1987FF-F-G:(Grey)
1987FF-G-W:(White)
1987FF-G-B:(Blue)
1987FF-G-G:(Grey)
1987FF-H
PART SKU# IMAGE DESCRIPTION QTY

Allen key 60*22*4mm
1
2
Dowel Ø8*40mm
Screws 8#*30mm
Screws Ø6.5*83mm
Bolt and nut M8*90mm 16
6
Part IMAGE DESCRIPTION QTY
3
4
5
6
7
8
28
1
4
Metal dowel Ø10*100mm
Bolts M8*35mm
16
Hardware List of Luca Full-Full Bunk Bed
SKU#
THE HARDWARE IS LOCATED IN THE PACKING ITEM
NOTE: MUST TIGHTEN SCREWS PERIODIACLLY. WITH USE SCREW
MAY ENCOME LOOSE CHECK TIGHTNESS OF ALL SCREWS EVERY 6-8
WEEKS.
CLEANING INSTRUCTIONS:
After assembly, clean and polish the completed parts if necessary with
soft cloth and industrial recognized furniture polish.
6
1987FF-1(16)
1987FF-2(6)
1987FF-3(8)
1987FF-4(16)
1987FF-5(28)
1987FF-6(4)
1987FF-7(1)
8
Note: Screwdriver will be prepared by yourshelf.
1987FF-8(6) Stickers 6

Detail view
D
C
A
A
E
E
I
I
G
H
7
F
B(L)
B(R)

A
A
D
C
C
1
1
4
7
3
1
1
2
7
E
4=12Pcs
1=8Pcs
3=8Pcs
2=6Pcs
3
8
1
3
STEP 1:
* Assembly Rail (C):
Please locate two rails (C) to Ends (A) by Dowel (4) firstly, and then fasten gradually by
Bolt+nut (1) BUT NO TIGHTEN.
* Assembly Guard Rail (D):
Please locate Guard rails (D) to Ends (A) by Dowel (4) firstly, and then fasten
gradually by Bolt (3).
Pay attention to rail orientation.
STEP 2:
Assemble the Guard Rail Supports (E) to Upper bed frame by Bolt (2).
Before assembly:
Move the nut out
1

STEP 3: Place the slat support (H) to Upper bunk
5
I
H
STEP 4: Please fasten slats (I) by screw (5) into corresponding holes.
5=14 Pcs
9

7
4
G
F
1
STEP 6: Place the slat
support (H) to Lower bunk
H
STEP 5: Assembly Rail (F), (G):
Please locate two rails (F) , (G) to Ends (B) by Dowel (4) firstly, and
then fasten gradually by Bolt+nut (1) .
4=4 Pcs
1=8 Pcs
10
1
1
1
1
Pay attention to rail orientation.
Distinguishing Back Rail (F)
and Front Rail (G)!
B(L)
B(R)

5
I
STEP 7:Please fasten
slats (I) by screw (5) into
corresponding holes.
6
STEP 8:
Assemble the
upper bunk to
lower bunk by
Metal dowel
(6).
5=14 Pcs
6=4 Pcs
11

Combining with Ladder ( Option 1).
12
Notice:
8
8=6 Pcs
Using the color stickers (8) to fill
the empty holes on frames.
Attaching the ladder to Guard rail
by Screw and to Lower
Side Rail by bolt (these hardware are included in Ladder box).

Combining with Stairway Chest ( Option 2).
13
Please attach the Stairway Chest to Bunkbed
by metal bracket and screw ( these hardware
are included in Stairway box).
Please place Stairway Chest
is next to Bunkbed Side and
wall.

Option 1:
Option 2:
14
That's it ! You've finished
assembling your item. Thank you!
