ASSEMBLY INSTRUCTIONS
LUCA TWIN CORNER BOOKCASE BED
ITEM NO: Y2103W-352/353
Y2103B-352/353
Y2103G-352/353
SKU: 314675/314676
314585/314586
314629/314630
1
15 min
LUCA FULL CORNER BOOKCASE BED
ITEM NO: Y2103W-352/355
Y2103B-352/355
Y2103G-352/355
SKU: 314675/314677
314585/314587
314629/314631
x 2 x 1 x 1

ALong bookcase 1
2
1993TF-A-W: (White)
1993TF-A-B: (Blue)
1993TF-A-G: (Grey)
CRail 1
1993TF-C-W: (White)
1993TF-C-B: (Blue)
1993TF-C-G: (Grey)
BOX 1- TW /FL LONG HEADBOARD/RAILS CORNER BOOKCASE BED
PART SKU# IMAGE DESCRIPTION QTY
If your item is TWIN Corner bookcase bed:
Please help to check part list in page 2 and page 3
If your item is FULL Corner bookcase bed:
Please help to check part list in page 2 and page 4

DHeadboard 1
3
FSlat support 1
E1
GSlats 1
B1
1993T-B-W: (White)
1993T-B-B: (Blue)
1993T-B-G: (Grey)
Short bookcase
Footboard
1993T-D-W: (White)
1993T-D-B: (Blue)
1993T-D-G: (Grey)
1993T-E-W: (White)
1993T-E-B: (Blue)
1993T-E-G: (Grey)
1993T-F
1993T-G
PART SKU# IMAGE DESCRIPTION QTY
BOX 2-TWIN SHORT HEADBOARD/FOOTBOARD/SLATS CORNER
BOOKCASE BED

DHeadboard 1
4
FSlat support 1
E1
GSlats 1
B1
1993F-B-W: (White)
1993F-B-B: (Blue)
1993F-B-G: (Grey)
Short bookcase
Footboard
1993F-D-W: (White)
1993F-D-B: (Blue)
1993F-D-G: (Grey)
1993F-E-W: (White)
1993F-E-B: (Blue)
1993F-E-G: (Grey)
1993F-F
1993F-G
PART SKU# IMAGE DESCRIPTION QTY
BOX 2-FULL SHORT HEADBOARD/FOOTBOARD/SLATS CORNER
BOOKCASE BED

Detail view B
1
2
Part IMAGE DESCRIPTION QTY
3
Hardware List of Luca Twin/Full Corner Bookcase Bed
SKU#
THE HARDWARE IS LOCATED IN THE PACKING ITEM
NOTE: MUST TIGHTEN SCREWS PERIODIACLLY. WITH USE SCREW
MAY ENCOME LOOSE CHECK TIGHTNESS OF ALL SCREWS EVERY 6-8
WEEKS.
CLEANING INSTRUCTIONS:
After assembly, clean and polish the completed parts if necessary with
soft cloth and industrial recognized furniture polish.
5
A
4
5
Bolts M8*20mm 8
14
6
Hook 63*18*2mm 2
Allen key 60*22*4mm 1
1993TF-1(8)
1993TF-2(14)
1993TF-3(6)
1992TF-4(2)
1992TF-5(1)
Screws 8#*30mm
Screws 6#*15mm
C
D
E
F
G
Note: Screwdriver will be prepared by yourshelf.

STEP 1:
Attaching the hook (4) to pre-holes on Short bookcase (B) by
screw (3)
6
3=4 Pcs
4=2 Pcs
B
34
34

STEP 2:
Place the hook of (A) and (C) closes to Ends (D) and (E), then fasten by Bolt (1).
7
1=8 Pcs
5
A
C
E
D
Pay attention to rail orientation and must have two people assemble.
Distinguishing the (D) and (E) part.
1

STEP 3: Place the Slat support (F) to Bed Frame
8
F
2=14 Pcs
G
2
STEP 4:
Please fasten slats (G) by
screw (2) into corresponding
holes.

STEP 5:
Connecting the short bookcase
to bed frame and fix by screw
(3)
9
3=2 Pcs
3
That's it ! You've finished
assembling your item. Thank you!
