Living Spaces 4176 User manual

MAS90: 5043-43325
4176 BH TRIPLE BUNK HARDWARE KIT
QTY:
DESCRIPTION:
40 1/4 X 4 HEX LAG BLK
40 3/16 USS FL WASHER BLK
30 6 X 1 1/4 PHIL FLAT PARTICLE BOARD SCREW
4
1/2 X 3 FLUTED DOWEL
7030-00425 KIT

TRIPLE BUNK 4176/4177
7030-00425
1) 7/16" Wrench or Socket Wrench
2) Phillips Head Screwdriver
Recommended: Electric driver with 7/16” socket
Make sure you have all parts before beginning assembly. If you
need a part, contact Living Spaces
1)Attach four 5 1/4” Mattress Rails (E) to theposts of the Bottom ends (C) with 16 lag bolts and 16 washers and tighten.
Be sure the posts (legs) have the dowel holes UP for this step!
2) Attach two 5 1/4" Mattress Rails (E) and four 3 1/2" Guard Rails (F) to the Top Ends (D) with 24 lag screws and 16
washers and tighten. Be sure the posts (legs) have the dowel holes DOWN for this step!
3) Roll out Twin Slat Kit on Support Cleats of Mattress Rails on Top Bunk assembly, and stretch end to end. Secure with
4 Wood Screws at each end of the two outermost slats. One in each corner of the bed. Center the three individual slats
in the 3 built in gaps in the Slat Kit, and secure with 6 wood screws, at each end of the individual slats.
4) Repeat step for the bottom bunk, starting with the very bottom bed surface, at the floor.
5) Repeat step 3 for the middle bed surface.
6) Place the 4 Wood Dowels in the holes of the bottom bunk assembly, and lift the top assembly to stack. Be sure that the
dowels slide into the holes at the bottom of the Top end assembly.
7) Place a mattress not to exceed 7" thick in the bottom and middle bed surfaces, and not to exceed 10" in the top bed and
sleep well!
PARTS LIST:
A) 40 - 4 1/4" Lag Screws
B) 40 - Black Steel Washers
C) 2 - Triple Bunk Bottom Ends
D) 2 - Triple Bunk Top Ends
E) 6 - 5 1/4" x 75" Mattress Rails w/ Support Cleats
F) 4 - 3 1/2" x 75" Guard Rails
G) 9 - 3 1/2" x 38 3/4" Twin Mattress Supports
H) 30 - 1 1/4" Wood Screws
I) 4 - 1/2" x 3" Wooden Dowels
TOOLS REQUIRED:

00500
SAFETY WARNING
Our Bunk Beds have been tested by an Independent Laboratoryand are certified to be in compliance with: ASTM
F-1427, “Standard Consumer Safety Specification for Bunk Beds” and U.S. Government specifications 16 Code of
Federal Regulations, parts 1213 and 1513.
SAFETY WARNINGS
1. Follow the information on the warnings attached to the upper bunk end structure and on the carton. Do not remove
this label.
2. Always use the recommended size mattress or mattress support, or both, to help prevent the likelihood of entrapment
or falls.
3. Surface of mattress must be at least five inches(127mm) below the upper edge of guardrails.
4. Do not allow children less than six years of age to use the upper bunk.
5. Periodically, check and ensure that the guardrail, ladder and other components are in their proper position, free from
damage and that all connectors are tight.
6. Do not allow horseplay on or under the bed and prohibit jumping on the bed.
7. Prohibit more than one person on upper bunk.
8. Always use the ladder or bed end for entering and leaving the upper bunk.
9.Do not use substitute parts. Contact manufacturer or dealer for replacement parts.
10. Use of a night-light may provide added safety precautions for a child using the upper bunk.
11. If the bunk bed will be placed next to a wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and the wall. (This applies only to bunk beds without two full-length
guardrails.)
12. Always use guardrails on both long sides of the upper bunk.
13. The use of water or sleep flotation mattress is prohibited.
14. Keep these instructions for future reference.
STRANGULATION HAZARD
15. Never attach or hang items to any part of the bunk bed that are not designed for use with the bed for example, but not
limited to hooks, belts and jump ropes.
SIZE OF MATTRESS AND FOUNDATION
Your Twin bed is designed to use a mattress 37 ½”-38 ½” in width and 74” - 75” in length.
Your Full bed is designed to use a mattress 52”- 54” in width and 74” - 75” in length.
The total thickness of mattress and foundation (slat kit, bunk board, etc.) combined must not exceed 10”.
Note: There must be at least 5” from mattress sleeping surface to top edge of guardrail.
4137, 4145, 4151, 4175, 4270, 4738, 4797
4516,4517,4519, 4521, 4523, 4525, 4529 UPDATED: 04/19/2013
A FOUNDATION IS REQUIRED WITH 3 SLAT CONFIGURATION

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
