Living Spaces DE-GCL201-NG User manual

ltem# 282920
FIRE OR EXPLOSION HAZARD
If you smell gas:
·Shut off gas to the appliance.
·Extinguish any open flame.
·If odor continues, leave the area immediately.
·After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance. An LP-cylinder not connected for use
shall not be stored in the vicinity of this or any
other appliance.
Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
:
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
CONCRETE TOP
SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG
CONCRETE TOP SQUARE FIREPIT

If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

1.Check that the control knob for the gas
supply system is turned to the "OFF" position before
starting any assembly.
2. Attach side panel (C) , front panel (E) ,back
panel (B) and door panel (D) using 8pcs of M6*20 bolt
(J) by screwdriver (not included).
3. Turn over the unit, then attach steel base to
the bottom part of the table top (A) using 4pcs of
M6*35 bolt (L) by screwdriver (not included).
CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

4.Attach the tank seat (F) to the front panel and back
panel using 4pcs of M6*25 bolt (K) by screwdriver
(not included).
5. Using 1pc of M6*35 bolt (L), 1pc of
∅6.5*∅16 Flat Washer (M) and 1pc of M6 Nut (N)
to fix the control box by screwdriver (not
included).
CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

8. Remove the rubber cap on the electronic igniter by
unscrewing and slide battery (P) into the battery slot.
Make sure the positive side of the battery faces
outwards. Screw the electronic igniter cap over the
battery tightly.
9. Pour the box of lava rocks into the firebowl, then
pave the lava rocks.
To ensure proper function, the guard on this burner
should be free of lava rocks at all times.
CONCRETE TOP SQUARE FIREPIT
LS SKU# 282920
MODEL # DE-GCL201-NG

1. Make sure the control knob is in the "off" position.
2. Remove door and slowly open the valve on the propane gas tank by turning the knob counterclockwise.
3. Replace the door on the body.
4. Push and hold in the electronic igniter to create sparks within the electrode, continue to hold.
5. Push in the control knob and turn to the "low" position. Keep holding down the control knob to allow gas
to flow for 45 seconds.
6. If ignition doesn't occur within a few seconds release the control knob and rotate to the "OFF" position.
Wait for 5 minutes for gas to clear and then repeat the above lighting instructions.
7. Once the fire product is lit, the flame intensity may be controlled by turning the control knob between the
"low" and "high" positions.
1. Turn control knob clockwise to the "low" position; let the knob pop up and continue turning
the control knob to the "off" position.
2. Close the cylinder valve on the propane gas tank if you don't intend to use it for a long time.
