1
OUTDOOR FIREPIT
ITEM # IVY221-LB
SKU # 247211270 / 248211271
INSTALLATIONAND USER’S INSTRUCTIONS

2
PACKAGE CONTENTS
PART
DESCRIPTION
QTY
A
FIREPIT TABLETOP
1
B
FIREPIT BASE
1
C
BURNER COVER
1
D
1/4”*18 BOLTS
4
E
HEX BOLT DRIVER
1
F
WASHERS
4
G
BOLT COVERS
4
H
ROUND BRAZIER
1
I
GLASS BEADS
1
J
FOOT LEVELER
FACTORY ASSEMBLY
4

3
SAFETY INFORMATION
DANGER
FIRE OR EXPLOSION HAZARD
lf you smell gas:
·Shut off gas to the appliance.
·Extinguish any open flame.
·If odor continues,leave the area immediately.
·After leaving the area,call your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion, which could cause property
damage, personal injury, or death.
WARNING
Do not store or use gasoline,or other flammable vapors and liquids, in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
WARNING: For Outdoor Use Only.
Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in this manual is not followed exactly,a fire or explosion may
result causing property damage, personal injury, or loss of life.
DANGER CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper, tent,
car or home.
！
！
！
！
！

4
SAFETY INFORMATION
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate or install this
appliance.
The installation must conform to local codes or in the absence of local codes, to the National Fuel Gas
Code. ANSI Z223.1 • NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation
Code,CSA B149.1; or Propane Storage and Handling Code, CSA B149.2.This manual contains
important information about the assembly, operation and maintenance of this patio heater. General
safety information is presented in the first few pages and is also located throughout this manual. Keep
this manual for future reference and to educate new users of this appliance. This manual should be
read in conjunction with the labeling on the appliance. Safety precautions are essential when any
mechanical or propane fueled equipment is involved. These precautions are necessary when using,
storing, and servicing. Using this appliance with the respect and caution demanded will reduce the
possibilities of personal injury or property damage. The following symbols shown below are used
extensively throughout this manual. Always heed these precautions, as they are essential when using
any mechanical or propane fueled equipment.
DANGER
DANGER indicates an imminently hazardous
situation which, is not avoided, will result in
death or serious injury.
DANGER
Failure to comply with the precautions and
instructions provided with this fire pit can
result in death, serious bodily injury and
property loss or damage from hazards of fire,
explosion, burn asphyxiation, and/or carbon
monoxide poisoning. Only persons who can
understand and follow the instructions should
use or service this fire pit.
Solid fuels shall not be burned with this
appliance.

5
SAFETY INFORMATION
DANGER
EXPLOSION FIRE HAZARD
Keep solid combustibles, such as building
materials, paper or cardboard, a safe distance
away from the fire pit as recommended by the
instructions.
Provide adequate clearances around air
openings into the combustion chamber.
Never use the fire pit in spaces which do or
may contain volatile or airborne combustibles,
or products such a gasoline, solvents, paint
thinner, dust particles or unknown chemicals.
During operation, this product can be a
source of ignition. Keep fire pit area clear and
free from combustible materials, gasoline,
paint thinner, cleaning solvents and other
flammable vapors and liquids. Do not use fire
pit in areas with high dust content. Minimum
fire pit clearances from combustible materials:
two (2) feet from the sides & two (2) feet from
the rear, 6fet from ceiling.
DANGER
EXPLOSION FIRE HAZARD
Never store propane near high heat, open
flames, pilot lights, direct sunlight, other
ignition sources or where temperatures
exceed 120 degrees F (49℃).
Propane vapors are heavier than air and can
accumulate in low places. If you smell gas,
leave the area immediately.
Never install or remove propane cylinder
while fire pit is lighted, near flame, pilot lights,
other ignition sources or while fire pit is hot to
touch.
This fire pit is red hot during use and can
ignite flammables too close to the burner.
Keep flammables at least 2 feet from sides &
2feet from rear, 6 feet from ceiling. Keep
gasoline and other flammable liquids and
vapors well away from fire pit.
Store the propane cylinder outdoors in a well
ventilated space out of reach of children.
Never store the propane cylinder in an
enclosed area (house, garage, etc.). If fire pit
is to be stored indoors, disconnect the
propane cylinder for outdoor storage.
DANGER
CARBON MONOXIDE HAZARD
This fire pit is a combustion appliance. All
combustion appliances produce carbon
monoxide (CO) during the combustion
process. This product is designed to produce
extremely minute, non-hazardous amounts of
CO if used and maintained in accordance with
all warnings and instructions. Do not block air
flow into or out of the fire pit.
Carbon monoxide (CO) poisoning produces
flu-like symptoms, watery eyes, headaches,
dizziness, fatigue and possibly death. You
can’t see it and you can’t smell it. It’s an
invisible killer. If these symptoms are present
during operation of this product get fresh air
immediately!
For outdoor use only.
Never use inside house, or other unventilated
or enclosed areas.
This fire pit consumes air (oxygen). Do not
use in unventilated or enclosed areas to avoid
endangering your life.
WARNING
WARNING indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, injury or death. Read the installation,
operation and maintenance instructions
thoroughly before installing or servicing this
equipment.

6
SAFETY INFORMATION
WARNING
We cannot foresee every use which may be
made of our fire pit.
Check with your local fire safety authority if
you have questions about fire pit use.
Other standards govern the use of fuel gases
and heat producing products for specific uses.
Your local authorities can advise you about
these.
If no local codes exist, follow National Fuel
Gas Code, ANSI Z223.1. In Canada,
installation must conform to local codes. If no
local codes exist, follow the current National
standards of CANADA CAN/CGA-B 149.2.
WARNING
California Proposition 65
Combustion by-products produced when
using this product contain chemicals known
to the State of California to cause cancer, birth
defects, and other reproductive harm.
WARNING
BURN HAZARD
Never leave fire pit unattended when hot or in
use. Keep out of reach of children.
CAUTION
CAUTION indicates an imminently hazardous
situation which, if not avoided, may result in
minor or moderate personal injury, or
property damage.
CAUTION
SERVICE SAFETY
Keep all connections and fittings clean. Make
sure propane cylinder valve outlet is clean.
During set up, check all connections and
fittings for leaks using soapy water. Never use
a flame.
Use as a heating appliance only. Never alter in
any way or use with any device.
WARNING
Certain materials or items, when stored under
the fire pit, will be subjected to radiant heat
and could be seriously damaged.
WARNING
This product is fueled by propane gas.
Propane gas is invisible, odor less, and
flammable. An odorant is normally added to
help detect leaks and can be described as a
“rotten egg” smell. The odorant can fade over
time so leaking gas is not always detectable
by smell alone.
Propane gas is heavier than air and leaking
propane will sink to the lowest level possible.
It can ignite by ignition sources including
matches, lighters, sparks or open flames of
any kind many feet away from the original leak.
Use only propane gas set up for vapor
withdrawal.
Store or use propane gas in compliance with
local ordinances and codes or with
ANSI/NFPA 58. Turn off propane when not in
use.
WARNING
Alert children and adults to the hazards of
high surface temperatures. Stay away from
these surfaces to avoid burning skin or
igniting clothing.
Carefully supervise young children when in
the vicinity of the fire pit.
Do not hang clothing or any other flammable
materials from the fire pit, or place on or near
the fire pit.
Replace any guard or protective device
removed for servicing the appliance prior to
placing back in service.
Installation and repair should be done by a
qualified service person. The fire pit should be
inspected before use and annually by a
qualified service person. More frequent
cleaning may be required as necessary. It is
imperative that the control compartment,
burners, and circulating air passageway of the
appliance be kept clean.

7
OPERATION CHECKLIST
Operation Checklist
For a safe and pleasurable heating experience, perform this check before each use.
Before Operating:
1. The max. inlet supply pressure: max. Gas supply 11 in w.c. (2.74kPa)
2. I am familiar with entire owner’s manual and understand all precautions noted.
3. All components are properly assembled, intact and operable.
4. No alterations have been made.
5. All gas connections are secure and do not leak.
6. Wind velocity is below 10 mph.
7. Unit will operate at reduced efficiency below 40 degrees F/4.44 C.
8. Fire pit is outdoors (outside any enclosure).
9. There is adequate fresh air ventilation. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the appliance and to replace any part of
the control system and gas control which has been under water.
10. Fire pit is away from gasoline or other flammable liquids or vapors.
11. Fire pit is away from windows, air intake openings, sprinklers and other water sources.
12. Fire pit is at least 48 in. on rear and at least 48 in. on sides from combustible materials.
13. Fire pit is on a hard and level surface.
14. There are no signs of spider or insect nests.
15. All burner passages are clear.
16. All air circulation passages are clear.
17. Children and adults should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition.
18. Young children should be carefully supervised when they are in the area of the fire pit.
19. Clothing or other protective material should not be hung from the fire pit, or placed on or near the fire
pit.
20. Any guard or other protective device removed for servicing the fire pit must be replaced prior to
operating the fire pit.
21. Installation and repair should be done by a qualified service person. The fire pit should be inspected
before use and at least annually by a qualified service person.
22. More frequent cleaning may be required as necessary. It is imperative that control compartment,
burner and circulating air passageways of the fire pit be kept clean.
After Operation
1. Gas control is in OFF position.
2. Gas Tank valve is OFF.
3. Disconnect Gas line.
4. After each use, replace cap on tank.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents above. If any part is missing or damaged, do not attempt to
assemble the product. Contact customer service for replacement parts.
Estimated AssemblyTime: 60 minutes
Tools Required Assembly (not included) : Leak Test Solution.

8
ASSEMBLY
NOTE: It is best to use TWO PEOPLE for assembly of this gas fire pit.
1. Carefully unpack all items from the box. Place the base in the final position. There must be a minimum of 48 in
/ 122 cm of clearance from the side of the table top to any combustible walls.
2. Place the tabletop on the base. Secure the tabletop to the firepit base using the bolts and washers that are
provided
3.Pour the lava rock into the burner pan completely covering the burner.
4. Connect the hose and regulator to the cylinder. The propane gas and cylinder are
sold separately. Use a standard 20 lb / 9.1kg. propane cylinder only. Use this fire pit
only with a propane vapor withdrawal supply system. See Chapter 5 of the standard
for storage and handling of liquefied petroleum gas, ANSI/NFPA 58. Your local
library or fire department should have this book. Storage of an appliance indoors is
permissible only if the cylinder is disconnected and removed from the appliance. A
cylinder must be stored outdoors in a well-ventilated area out of reach of children. A
disconnected cylinder must have dust caps tightly installed and must not be stored
in a building, garage or any other enclosed area. The maximum inlet gas supply
pressure: 250 psi..
The minimum hourly of 50000 Btu is required input rating for a fire pit at rating less
than full input rating. The pressure regulator and hose assembly supplied with the
appliance must be used. The installation must conform with local codes, or in the
absence of local codes, with national fuel gas code, ANSI Z223.1/NFPA54, natural
gas and propane Installation Code, CSA B149.1, or propane storage and handling
code, B149.2.

9
ASSEMBLY
A dented, rusted or damaged propane cylinder may be hazardous and should be
checked by your cylinder supplier. Never use a propane cylinder with a damaged
valve connection.
The propane cylinder must be constructed and marked in accordance with the
specifications for LP gas cylinders of the U.S. Department of Transportation
(DOT) or the standard for cylinders, spheres and tubes for transportation of
dangerous goods and commission, CAN/CSA-B339.
The cylinder must have a listed overfilling prevention device.
The LP gas tank must have a listed overfilling prevention device and a QCCI or
Type I (CGA791) LP gas tank connection.
The cylinder must have a connection device compatible with the connection for the appliance.
The cylinder used must include a collar to protect the cylinder valve.
Never connect an unregulated propane cylinder to the appliance. Attach regulator to cylinder. Complete
attachment. Install cylinder. Secure the propane cylinder with the cylinder screw by tightening the screw until it
comes in contact with the cylinder.
Do not store a spare LP-gas cylinder under or near this appliance;
Never fill the cylinder beyond 80 percent full;
Place the dust cap on the cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the
cylinder valve that is provided with the cylinder valve. Other type of caps or plugs mayresult in leakage of propane.
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE INTENDED FOR RESIDENTIAL USE ONLY.
Do not sit or stand on this table.
Keep children away during assembly, as this item contains small parts which can be swallowed by
children.
Do not use indoors or inside any enclosure.
Retain the assembly instructions for future reference. Installer –Please leave these instructions with the
owner.
The burning trace of the fire system is because the fire test must be carried out before leaving the factory,
which will not affect the use.

10

11
OPERATION INSTRUCTIONS
DANGER
•CARBON MONOXIDE HAZARD
•For outdoor use only. Never use inside house,
or other unventilated or enclosed areas. This fire
pit consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid
endangering your life.
WARNING
Very hot while in operation!
Never lean over the fireplace while in use.
Failure to comply with these instructions may
result in serious bodily injury.
Caution: Do not attempt to operate until you have read and understand all General Safety Information in
this manual and all assembly is complete and leak checks have been performed.
Before Turning Gas Supply ON:
1. Your fire pit was designed and approved for outdoor use only. Do NOT use it inside a building, garage,
or any other enclosed area.
2. Make sure surrounding areas are free of combustible materials, gasoline, and other flammable vapors
or liquids.
3. Ensure that there is no obstruction to air ventilation. Be sure all gas connections are tight and there
are no leaks.
4. Be sure the cylinder cover is clear of debris. Be sure any component removed during assembly or
servicing is replaced and fastened prior to starting.
Before Lighting:
1. Fire pit should be thoroughly inspected before each use, and by a qualified service person at least
annually. If relighting a hot fire pit, always wait at least 5 minutes.
2. Inspect the hose assembly for evidence of excessive abrasion, cuts, or wear. Suspected areas should
be leak tested. If the hose leaks, it must be replaced prior to operation. Only use the replacement hose
assembly specified by manufacturer. The burner must be replaced prior to the appliance being put into
operation if it is evident that the burner is damaged. The replacement burner should be specified by
manufacturer.
Lighting:
1) Turn the control knob to the “OFF” position (Figure a).
2) Fully open LP cylinder valve.
Note: For initial start or after any cylinder change, hold Control Knob IN for
2 minutes to purge air from gas lines before proceeding.
3) Push in gas control knob and turn counterclockwise to “IGNITE” (Figure b) to light the fire pit. If
needed, keep depressing and turning control knob counterclockwise until the heater lights (You should
hear a clicking sound).
4) After fire pit lights, release control knob. Push in and turn the control knob to the “HIGH”, then release
control knob. If you want a lower temperature, push in the control knob and turn counterclockwise to the
“LOW” (Figure c).
Note: If burner fails to remain lit, all valves should be closed and a waiting period of at least 5 minutes
should pass before attempting to light.
Figure a Figure b Figure c Normal Abnormal

12
OPERATION INSTRUCTIONS
WARNING
FOR YOUR SAFETY
Be careful when attempting to manually ignite this fire pit.
Holding in the control knob for more than 10 seconds
before igniting the gas will cause a ball of flame upon ignition.
When fire pit is ON:
Burner will display tongues of blue and yellow flame. These flames should not be yellow or produce
thick black smoke, which would indicate an obstruction of airflow through the burners. The flame
should be blue with straight yellow tops. If excessive yellow flame is detected, turn off heater and
consult “Troubleshooting” on page 13.
Re-lighting:
1. Turn control knob to OFF.
2. Repeat the "Lighting” steps on prior page.
WARNING
FOR YOUR SAFETY
Fire pit will be hot after use. Handle with extreme care.
Shut Down:
1. To extinguish burner depress control knob and continue to turn it clockwise to OFF.
2. Turn cylinder valve clockwise to OFF and disconnect regulator when heater is not in use.
CARE AND MAINTENANCE
WARNING
FOR YOUR SAFETY:
Do NOT touch or move fire pit for at least 45 minutes after use.
Bomer is hot to the touch.
Allow borner to cool before touching.
To enjoy years of outstanding performance from your fire pit, make sure you perform the following
maintenance activities on a regular basis:
Keep exterior surfaces clean.
1. Use warm soapy water for cleaning. Never use flammable or corrosive cleaning agents.
2. While cleaning your unit, be sure to keep the area around the burner dry at all times. Do not
submerge the control valve assembly. If the gas control is submerged in water, do NOT use it. It must
be replaced. a. Keep the appliance area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
b. Do not obstruct the flow of combustion and ventilation air.
c. Keep the ventilation opening(s) of the cylinder enclosure free and clear from debris.
3. Air flow must be unobstructed. Keep controls, burner, and circulating air passageways clean. Signs
of possible blockage include.

13
CARE AND MAINTENANCE
⚫Gas odor with extreme yellow tipping of flame. Fire pit does NOT reach the desired temperature.
Fire pit glow is excessively uneven.
⚫Fire pit makes popping noises.
⚫Spiders and insects can nest in burner or orifices. This dangerous condition can damage fire pit
and render it unsafe for use. Clean burner holes by using a heavy-duty pipe cleaner. Compressed
air may help clear away smaller particles.
⚫Carbon deposits may create a fire hazard. Clean burner with warm soapy water if any carbon
deposits develop.
Note: In a salt-air environment (such as near an ocean), corrosion occurs more quickly than normal.
Frequently check for corroded areas and repair them promptly.
TIP:
Use high-quality automobile wax to help maintain the appearance of your fire pit.
Apply to exterior surfaces only. Do not apply to borner..
Storage
Between uses:
⚫Turn Control Knob OFF.
⚫Disconnect LP source.
⚫Store fire pit upright in an area sheltered from direct contact with inclement weather (such as rain,
sleet, hail, snow, dust and debris).
⚫If desired, cover fire pit to protect exterior surfaces and to help prevent build-up in air passages.
Note: Wait until fire pit is cool before covering.
During periods of extended inactivity or when transporting:
⚫Turn Control Knob OFF.
⚫Disconnect LP source and move to a secure, well-ventilated location outdoors.
⚫Store fire pit upright in an area sheltered from direct contact with inclement weather (such as rain,
sleet, hail, snow, dust and debris).
⚫If desired, cover fire pit to protect exterior surfaces and to help prevent build-up in air passages.
Never leave LP cylinder exposed to direct sunlight or excessive heat.
Note: Wait until fire pit is cool before covering.
Service
Only a qualified service person should repair gas passages and associated components.
Caution: Always allow firepit to cool before attempting service.

14
TROUBLESHOOTING
PROBLEM
CAUSE
REMEDY
Burner won’t light
No Propane Gas at Burner
Check that gas tank valve is open. Turn control knob to
“ON” and push control knob in. Make sure tank has
propane gas.
No Spark at Electrode
Check that AAA battery is installed with negative (-) end
first and has a charge. Check that the wire is connected to
the ignition module. Check that the electrode is not
cracked or broken.
Lack of oxygen
Remove excess lava rocks or fire ices from around the
ignition well.
Burner won’t stay lit
after lighting
Thermocouple not in flame
Check that the tip of the thermocouple is even with the top
of the ignition well. Remove any fire ice from the igntion
well.
Thermocouple connection at the
main control valve is loose
Tighten the thermocouple nut at the back of the valve.
No Fire Ice on Burner
Cover the burner with fire ice per the instructions

15
1 YEAR LIMITED WARRANTY –Customers in the Continental US
All components are warranted for a period of 1 year after date of purchase by the original owner against defects in
materials and workmanship under normal use. This warranty does NOT cover normal wear and weathering, assembly
and/or maintenance OR use in a commercial application if model is not designated as a commercial model.
This warranty is extended only to the original purchaser. Proof of purchase will be required before warranty service is
rendered. The sales receipt is the only valid proof of purchase. This warranty only covers failures due to defects in
materials or workmanship which occur during normal use. Failures and/or damage which result from accident, negligence,
misuse, abuse, neglect, mishandling, alteration or modification, failure to maintain, improper assembly or maintenance,
service by unauthorized agency or use of unauthorized components or damage that is attributable to acts of God are NOT
covered.
***THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED ABOVE***
***PURCHASER ASSUMES ALL RISKS IN THE ASSEMBLY AND OPERATION OF THIS UNIT***
***FAILURE TO FOLLOW WARNINGS AND OPERATIONAL INSTRUCTIONS CONTAINED IN THIS MANUAL CAN
RESULT IN SEVERE PROPERTY DAMAGE AND/OR PERSONAL INJURY***
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO THE PURCHASER.
This limited warranty gives you specific legal rights and you may also have other rights which vary from jurisdiction to
jurisdiction. The provisions of the United Nations Convention on Contracts for the Sales of Goods shall not apply to this
limited warranty or the sale of products covered by this limited warranty.
