Livpure Glitz+ User manual

USER MANUAL
USER MANUAL
Absolute purity.
No Compromise
on features

01
Contents
01) Welcome to Livpure Family 02
02) Know your Livpure Water Purifier 03
03) Water Flow Diagram 04
04) How your Livpure Water Purifier works 05
05) Installation Instructions 06-07
06) Important Instructions 08
07) Technical Specifications 09
08) FAQ’s 10-11
09) Trouble Shooting 11
10) Warranty Card 12
11) Warranty Terms & Conditions 13
12) Key Features 14
13) Intellectual Property Rights 15
14) Installation Report 16

02
Dear Customer,
We thank you for the trust you have shown in Livpure Water Purifier and its technology.
Livpure is a “state-of-the-art” water purifier with the most advanced purification system. It is specially
designed, keeping in mind the changing water quality & your lifestyle.
It conforms to the most advanced drinking water quality standards for purity & safety.
Please go through these simple & easy to understand instructions to get the most out of your Livpure
water purifier.
Any queries & suggestions, please call us at 1800-419-9399.
We once again thank you for choosing “Livpure” and look forward to a long and fruitful association with
you.
Welcome to Livpure Family

03
Know your Livpure Water Purifier
1
2
3
Socket Board
Power Supply
(SMPS)
Input Water
Input Power
4
Reject Water
Two way tap
for purified water
dispensing
5
6
Power ON
Indication
Purification
Process
Indication
7 8
Tank Full
Indication

04
Water Flow Diagram
ANTI-SCALANT FILTER
RO MEMBRANE FILTER
PRE ACTIVATED CARBON FILTER
FLOW RESTRICTOR
REJECT
WATER
3 WAY CONNECTOR
SEDIMENT FILTER
BOOSTER
PUMP
SOLENOID
VALVE
SS BALL VALVE
TANK
FLOAT VALVE
POST CARBON
FILTER
UF FILTER

05
How your Livpure Water Purifier works
1. Antiscalant Cartridge
The Antiscalant Cartridge chelates scale causing salts in water to prevent scaling on membrane
layers. It results in improved purification capacity and increased life of membrane.
2. Sediment Filter
Sediment Filter removes coarse and fine suspended dirt impurities from water and makes water clean.
3. Pre Activated Carbon Filter
It adsorbs residual chlorine and hazardous impurities like pesticides, herbicides, THM’s etc. from
water. It also adsorbs bad taste, color and odor causing organic compounds from water.
4. Reverse Osmosis (RO) Membrane
The water is passed through RO membrane at high pressure, RO Membrane removes Bacteria, Virus
and Protozoa and reduces Dissolved Salts, Hardness, Pesticides and heavy metals from water like
Arsenic.
5. Ultra Filtration Cartridge
Eectively removes Bacteria, Cysts like Giardia and Cryptosporidium etc. from water. It also makes
water sparkling clear by removing fine suspended impurities.
6. Silver Impregnated Post Carbon Cartridge
It enhances the taste and quality of purified water by removing volatile organic impurities.
PURIFICATION STAGES

06
• Open the box and check availability of below accessories required for installation
- SS Ball Value and 3 Way connector
- Wall Mounting Plate
- Insert & Screw for Wall Mounting Plate
- PL4 Pipe White and Blue
- User Manual cum Warranty Card
- Power Adaptor
• Choose an appropriate water connection point.
• Please note water purifier unit should be connected to normal temperature water supply only. Hot water
supply is not recommended for water purifier connection.
• Fix 3 Way connector & SS Ball valve with the help of a pipe wrench at this water point to separate water
supply for water purifier Keep Ball Valve in Lock condition.
• Fix Mounting Plate at a suitable place on the wall near to Input Water Connection.
• Kindly ensure Fixing of Mounting plate is not inclined. On a inclined mounting plate unit will be hanged
inclined and it may result in float valve malfunctioning/water overflow from unit.
• Hang the unit on Mounting plate
• Connect Input Water pipe (White) at the inlet connector in the unit. Cut the excess pipe length; do not
fold/round it.
• Now Fix the Power Adaptor into a 3 Pin, 5A230VAC electrical socket.
Installation Instructions

07
Installation Instructions
• Switch ON the Main Switch. After switching ON the switch, LED in power adaptor will glow and unit
will start working.
• Allow water to Flush/Drain from all filters by removing the outlet pipe of each filter.
• While flushing filters kindly ensure water is not spilled onto any Electrical/Electronic part to avoid
failure. If so then switch OFF the Mains and soak the water with the help of a cloth from
Electrical/Electronic Part and allow it to dry.
• Check for any leakage from piping & fittings/loose fittings. If any pipe is found loose then reinsert it
into the connector to avoid leakage later.
• Take front cover and connect the Display PCB connector and fix it.
• Check the function of Display PCB. It should be in working condition.
• Allow water storage tank to fill completely and discard the first fill. You may use this water for
Floor/Utensils Cleaning and Gardening of Plants instead of draining.
1. Antiscalant Cartridge
The Antiscalant Cartridge chelates scale causing salts in water to prevent scaling on membrane
layers. It results in improved purification capacity and increased life of membrane.
2. Sediment Filter
Sediment Filter removes coarse and fine suspended dirt impurities from water and makes water clean.
3. Pre Activated Carbon Filter
It adsorbs residual chlorine and hazardous impurities like pesticides, herbicides, THM’s etc. from
water. It also adsorbs bad taste, color and odor causing organic compounds from water.
4. Reverse Osmosis (RO) Membrane
The water is passed through RO membrane at high pressure, RO Membrane removes Bacteria, Virus
and Protozoa and reduces Dissolved Salts, Hardness, Pesticides and heavy metals from water like
Arsenic.
5. Ultra Filtration Cartridge
Eectively removes Bacteria, Cysts like Giardia and Cryptosporidium etc. from water. It also makes
water sparkling clear by removing fine suspended impurities.
6. Silver Impregnated Post Carbon Cartridge
It enhances the taste and quality of purified water by removing volatile organic impurities.

08
Important Instructions
Avoid exposure to direct sunlight and
installation in damp areas
X
Avoid exposure to direct sunlight and
installation in damp areas
Make sure that the purifier is
connected to normal water supply
only. Hot water supply is not
recommended for RO connection.
X
GEYSER
Make sure the reject water pipe is
not placed at a level higher from the
purifier otherwise reject water may
flow backward into the purifier.
X
Avoid sharp bends in the pipe. Do not
bend or block the water pipe.
X
The maximum distance between
the water source and the purifier
should not be more than 1.5 meters
X
Water Source
Water in
1.5 M
Do not confine the purifier in a
closed cabinet.
X
Do not try to service the purifier on
your own. Instead, call service
engineer for help.
In case of not using the purifier for more than
two days, kindly switch of the power supply
and drain the storage tank.
Reject Water
X
X
In case of not using the purifier for more than
Avoid sharp bends in the pipe. Do not
bend or block the water pipe.
Make sure that the purifier is
connected to normal water supply
only
recommended for RO connection.
Reject Water

09
Technical Specifications#
NOTE -
1. Use a Pre filter cartridge if water contains more than 10 NTU turbidity.
2. Input Raw Water temperature should be between 10°C to 45°C.
3. Total Dissolved Solids in input raw water should not exceed 1500 ppm.
4. Raw Water should be free from oil & grease.
5. Permissible Iron content in Input Raw water is 0.3 mg/L (max).
6. Total Hardness in Input Raw Water should not exceed 600 mg/L (max).
* If input water pressure is below 0.3 kg/Sq.cm, use of Booster Pump attachment is recommended to increase input water pressure and proper functioning of the unit. Flow rate depends on the input water
pressure and condition of the filters.
** If input water pressure is above 3.0 kg/Sq.cm, use of pressure reducing valve is recommended for Leak proof and smooth functioning of the unit.
#Manufacturer reserves the right to change/replace/upgrade any part of component in pursuit of providing continuous improvement in the quality of the products to its esteemed customers.
RO + UF
Upto 12 litres/hour
Upto 75 litres/day
7 Litres (approx)
75 GPD (Gallons Per Day)
Anti Scalant Cartridge, Sediment Filter, Pre Activated Carbon Filter
RO Membrane, Ultra Filtration (UF) Cartridge,
Silver Impregnated Post Carbon Cartridge
0.3 Kg/Sq.cm*
3 Kg/Sq.cm**
140-300 V AC / 50 Hz
24 V DC
Purification Technology
Purification Capacity
Max. Duty Cycle
Storage Tank Capacity
RO Membrane
Purification Cartridges
Min. Inlet Pressure
Max. Inlet Pressure
Input Voltage
Operating Voltage

10
FAQ’s
1) What does TDS (total dissolved solids) mean?
Total Dissolved Solids is a measure of dissolved
inorganic substances in water
2) How much time it takes to purify water by
Livpure Glitz+Water Purifier ?
Livpure Glitz+Water Purifier can purify water @12 litres
per hour. However, the time taken to purify depends on
the impurities present in water, input water pressure
and life of filters.
3) What is the storage capacity of Livpure Glitz+
Water Purifier?
Livpure Glitz+ Water Purifier has a storage tank capacity
of 7 litres (approx.)The process of filling the storage
tank is fully automatic and when you take water out of
the tank, the purification process starts automatically
and refills the storage tank.
4) How will I get service/ spare parts for my Livpure
Glitz+ Water Purifier?
During warranty period, two free preventive mainte-
nance services will be provided at an interval of 150
days & 300 days. Breakdown calls
will not be charged.
Any consumables like carbon filter, sediment filter, UF
Cartridge will
be on chargeable basis .You need to call
our customer care help line number which is printed on
the back page of user's manual. Post warranty of the
machine
you have two choices for service contracts
ACMC
(Annual Comprehensive Maintenance Contract)
AMC (Annual Maintenance Contract ). Under ACMC all
the spares including the consumables are replaced free
of cost on as when required and in AMC only visit of
customer care representative is free and spares are
charged extra.
5) Is water from first purification cycle fit to drink?
No. it is recommended to drain the first cycle of water
that is filled in the storage tank when the new Livpure
Glitz+Water Purifier is installed, and also whenever
cartridges are changed.
6) What should I do if there is no water in the storage tank?
In case there is no water in the storage tank we suggest
following preliminary checks by customer
a) Check if there is water supply
b) Check if there is power supply
If answers to both cases are true, please call Livpure
customer support center
7) Can I service on my own?
It is not recommended to open your Livpure Glitz+ Water
Purifier and service it by individual. Call our Livpure
customer support center for any issues related to
service & opening the machine.
8) What should I do if there is a leakage from the
purifier?
In case of leakage from the purifier switch o the
purifier. Check for any visual improper fitment like tap or
connection to purifier. Call our Livpure customer support
number and register for a service request.
9) How long the water in Livpure Glitz+Water
Purifier can be used for drinking?
You can use stored water for upto 48 hrs. If it is not
used for 48 hours we advise you to discard that water,
refill and consume.

11
1) What does TDS (total dissolved solids) mean?
Total Dissolved Solids is a measure of dissolved
inorganic substances in water
2) How much time it takes to purify water by
Livpure Glitz+Water Purifier ?
Livpure Glitz+Water Purifier can purify water @12 litres
per hour. However, the time taken to purify depends on
the impurities present in water, input water pressure
and life of filters.
3) What is the storage capacity of Livpure Glitz+
Water Purifier?
Livpure Glitz+ Water Purifier has a storage tank capacity
of 7 litres (approx.)The process of filling the storage
tank is fully automatic and when you take water out of
the tank, the purification process starts automatically
and refills the storage tank.
4) How will I get service/ spare parts for my Livpure
Glitz+ Water Purifier?
During warranty period, two free preventive mainte-
nance services will be provided at an interval of 150
days & 300 days. Breakdown calls
will not be charged.
Any consumables like carbon filter, sediment filter, UF
Cartridge will
be on chargeable basis .You need to call
our customer care help line number which is printed on
the back page of user's manual. Post warranty of the
machine
you have two choices for service contracts
ACMC
(Annual Comprehensive Maintenance Contract)
AMC (Annual Maintenance Contract ). Under ACMC all
the spares including the consumables are replaced free
of cost on as when required and in AMC only visit of
customer care representative is free and spares are
charged extra.
5) Is water from first purification cycle fit to drink?
No. it is recommended to drain the first cycle of water
that is filled in the storage tank when the new Livpure
Glitz+Water Purifier is installed, and also whenever
cartridges are changed.
6) What should I do if there is no water in the storage tank?
In case there is no water in the storage tank we suggest
following preliminary checks by customer
a) Check if there is water supply
b) Check if there is power supply
If answers to both cases are true, please call Livpure
customer support center
7) Can I service on my own?
It is not recommended to open your Livpure Glitz+ Water
Purifier and service it by individual. Call our Livpure
customer support center for any issues related to
service & opening the machine.
FAQ’s
8) What should I do if there is a leakage from the
purifier?
In case of leakage from the purifier switch o the
purifier. Check for any visual improper fitment like tap or
connection to purifier. Call our Livpure customer support
number and register for a service request.
9) How long the water in Livpure Glitz+Water
Purifier can be used for drinking?
You can use stored water for upto 48 hrs. If it is not
used for 48 hours we advise you to discard that water,
refill and consume.
Trouble Shooting
S.No. Problem Reason Remedies
1.
The water from the purifier The water is stored too long in
the storage
Drain the stored water and fill fresh water
tastes unusual .
Call customer care and get the
purifier services.
The filters are choked
2. The purification is taking The ball valve may Please ensure the ball valve is open fully
more time not be opened fully
.
3. The storage tank is not Check the ball valve It should be in open condition.
getting filled
Check if there is any If there is any leakage then call the
customer care number
leakage from the purifier

12
Warranty Card
Serial No.:
For Service Contact:
Service Provider Name :
Service Provider Address:
_________________________________________________
_________________________________________________
_________________________________________________
_________________________________________________
Ph. No.:
___________________________________________
Customer Details:
Customer Name :
_______________________________
Customer Address:
_______________________________
__________________________________________________
__________________________________________________
Email:
___________________________________________
Customer Ph. No.:
________________________________
Warranty Details:
Invoice date: ______________ Invoice no. _____________
_______________________
Product : Livpure
Communication address : Luminous Water Technologies Pvt. Ltd. Plot No. 221, Udyog Vihar, Phase-I, Gurgaon-122016, Tel.: [phone],
Fax : [phone] Website : www.livpurewater.com, E-mail : [email protected]

13
1. The product is warranted against any manufacturing defects arising out of
any faulty or defective material on workmanship for a period of 12 months
from the date of final invoice to customer commitment shall be applicable.
2. The LWT responsibility under this warranty will confine to the first purchaser
only and will not apply or extend to any subsequent sale of the product by the
customer.
3. The LWT liability under this warranty shall remain valid if and only if the
product is duly installed by the company, its authorized dealer/s service
provider at the address specified in the invoice or where the installation is at
a place other than specified in the invoice. Such installation is undertaking
with the consent in writing of and by the company confined to cities where
company has service network.
4. Consumables such as sediment filter, carbon filter, reverse osmosis
membrane, anti scalant cartridge, UF membrane and post carbon filter which
are subject to normal wear & tear in the course of use are not covered by this
warranty.
5. During Warranty period, two free preventive maintenance services will be
provided at an interval of 150 days & 300 days.
6. Inspection & test report of the LWT oce/service center will be treated as
final & binding under the warranty for determining defect, repairs/alterations
required or carried out, or certifying working of the goods thereafter.
repairs/alterations required or carried out, or certifying working of the goods
thereafter.
7. The LWT liability under the warranty will be limited only to defect which occur
under condition normal operation and under proper use as defined in manual.
It excludes defects occurring because of abuse, faulty care or maintenance,
repairs/ alterations to goods or parts by others.
8. The consumer shall have no claim under this warranty in respect of
death/injury to any person or loss/damage to any property caused as a result
of equipment failure, breakdown or accident on utilization of goods not in
accordance with the inflections in this user's manual or any other
circumstance beyond the control of the LWT.
9. The LWT shall be entitled to retain any defective part replaced under
warranty.
10. Product returned to LWT or its authorized service provider for warranty
examination must be shipped freight pre-paid.
11. LWT reserves the right to make design and product changes or change
specifications at anytime without any contingent obligations to prospective
buyers or owners or products previously sold.
12. Any disagreement and obligations based upon purchase of LWT products and
thereby imposed on LWT or its authorized service providers shall be governed
and construed according to the laws of India and subject to jurisdiction of
Delhi courts only.
13. LWT or its authorized service provider assures no warranty liability in
connection with this water purifier other than that specified herein. This
warranty is in lieu of all other warranties of fitness for a particular purpose.
LWT or its authorized service provider does not authorize any person or
representative to assume for it any other obligations on the sale of goods.
This warranty becomes eective when the system is installed correctly and
successfully.
14.Under no circumstances the terms mentioned above are negotiable and no
employee of LWT or its authorized service provider has the authority to
supersede the terms mentioned above.
Warranty Terms & Conditions
Luminous Water Technologies Pvt. Ltd. (LWT) warrants all new products manufactured by it to be free from defects in material and
workmanship under normal usage and service from the date of installation as under :

14
Key Features
6 Stage purification process for
pure & healthy water Elegant and Sleek Design
Power On, Purification Process
and Tank Full Indication
Eectively removes Bacteria, Cysts
like Giardia and Cryptosporidium etc.
from water.
Wall mounted installation
Removes turbidity, Chlorine,
inorganics like Calcium, Magnesium
and a wide range of hazardous
organics like pesticides and THMs.
India's largest company- owned RO
service network.
Eective tank storage capacity
of 7 litres
365 days customer care support.
7
Litres
6
Stage
365
DAYS
Equipped with double protection
of RO & Ultra Filtration
RO+UF

15
Intellectual Property Rights
The following are covered under Luminous Water Technologies Pvt. Ltd. intellectual property rights :
Livpure Logo
Glitz+Logo
Livpure Glitz+
Product Design

16
0 0 M M Y Y
Product Model Serial No./Sticker
Invoice Date
Invoice No.
Dealer Name & Address
Installation Date Customer Name Customer Address Customer Contact Number Customer E-Mail ID
Installation Site Details
Tank Height in feet TDS of Raw Water
Distance of Electrical point from M/c in Feet
Source of Power in %
%
Water Supply Timing
Input Voltage
Mains Invertor Generator Mains Invertor Generator
% % V V V
Customer's Convenient time for Service
TDS of RO Water
0 0 M M Y Y Installation Time AM/PM
M/c Installed By Customer Signature & Feedback
Name Signature LWT/Service provider Add: Display
Demonstration of Main Features
Service Through Call Centre PM Frequency New Features
Installation Report

Website : www.livpure.in, E-mail : [email protected]
