LK Systems PAL Multi 16-32 Al User manual

1 (2)
The following components should
be included in the LK Bending Tool
packaging:
Main unit with handle and lever, 1 pc.
Crossbars, 4 pcs.
Variable matrices in aluminium, 4 pcs.
• 14-16 mm is for dimension LK PAL 16
• 18-20 mm is for dimension LK PAL 20
• 26 mm is for dimension LK PAL 25
• 32 mm is for dimension LK PAL 32
Tool assembly
Take the crossbar for the pipe dimension to be bent
and mount this on the tool by screwing on the
wingnuts on the underside of the tool.
Mount the aluminium matrices for the same
dimension of pipe selected for the crossbar on the
tool by pressing onto the stud bolt.
Description
The LK Bending Tool is designed to provide a con-
trolled bend of LK PAL Universal Pipe. The bend
angle can be adapted up to 90°. The LK Bending
Tool is intended for use with PAL pipe with an
outer dimension of 16-32 mm.
LK Bending Tool PAL Multi 16-32 Al (Art. No. 188 25 11)
EN.29.C.42.1904
Assembly instruction | LK Bending Tool PAL Multi 16-32 Al

2 (2)
EN.29.C.42.1904
Assembly instruction | LK Bending Tool PAL Multi 16-32 Al
Once the pipe has been bent, hold the tool with
one hand and pull the lever away from the handle
to release the pipe from the matrices.
NOTE!
1. Mind your ngers when using the tool
to avoid being clamped between moving
parts.
2. Make sure that you use the right matrix for
each pipe dimension. The correct dimension
is specied on each matrix.
3. The LK Bending Tool is designed for LKPAL
Universal Pipe and is not constructed to
bend metal pipes.
Bending the pipe
Turn the variable matrices into the correct position
for the pipes outer diameter, see dimension on the
top of the loose matrix. Place the pipe between the
two xed and the loose matrix.
To begin bending, press the lever towards the
handle repeatedly until the pipe has reached the
desired angle.
