Lockly Secure Link+ WIFI-RF User manual
USER MANUAL
PGH222
(53㧉⨚᧶
*$84*/607$9
'HVLJQHG᧶:DOWHU 'DWH᧶
㙞承広㢝᧶*$843*+
6075(9
+,803*+6L]H;PP
欄槱孔帱㦻᧨J兇᧨♛槱◤煠◿Ⓠ᧨5($&+3URS323V3$+V᧷
(5331᧶
5(9
.
Secure Link
+
WIFI-RF Hub
+
WWW.LOCKLYPRO.COM
FOR COMMERCIAL USE & PROFESSIONAL INSTALLATION
2
The Lockly Guard Secure
Link+
Wi-Fi Hub comes in two
parts. Each part of the Secure
Link+
is crucial to enable
voice assistant features and live monitoring and control of
your Lockly device.
The Wireless Door Sensor is optional but highly recommend-
ed as they provide the ability to verify that your door is
securely closed and not ajar.
Secure Link+Wi-Fi Hub
USB 5V 1A AC Adaptor* Wireless Door Sensor
PART A PART B
* You may plug the USB Secure
Link+
Wi-Fi Hub into any UL
Certified 5V 1A USB outlet, however we recommend using
ours for best performance. Power adaptor supplied in this
box is based on standard power plug and socket used by
country.
3
1. Setting up the Secure Link+WIFI-RF Hub
You should install the Secure Link+WIFI-RF Hub after
you have successfully finished installation and set up
of your Lockly Smart Lock. Refer to your appropriate
Lockly Smart Lock Installation Guide and User Manual
that came with the lock for reference.
For best connectivity, choose an appropriate
location
for the Wi-Fi Hub for optimum
performance (see below).
30 Feet (9 Meters)
Distance Between
In order for your WIFI-RF Hub to connect to the internet,
you must have a Wi-Fi network with a radio signal
emitting 2.4 GHz. All modern Wi-Fi devices support 2.4
GHz connections while some equipment supports both
2.4 GHz and 5 GHz. Please check with your network
administrator or internet provider if you’re unsure what
kind of network you have.
Proceed to the next page to read how to finish set up of
your
Wi-Fi Hub
.
4
Plug the Secure Link
+
Hub into the 5V 1A USB AC adapter
and plug the AC adapter to your wall socket.
USA Outlet Shown
A RED LED indicator light
will
flash slowly to indicate
that the
Wi-Fi Hub is ready to
connect.
LED Indicator is located
next to the Setup Button
Once you have confirmed that your
Hub is ready
to
connect to your lock, open the
LocklyPro
app to get
started.
In case you have not downloaded our
app, you can scan the QR code to the
left or visit https://LocklyPro.com/app
Make sure you have already created an account and
setup your Lockly device to the LocklyPro app to continue.
Before you continue the Hub set up
on your app,
proceed to the next page to learn more
about using
the Hub and best practices
for connectivity.
5
2. Using the Secure Link
+
WIFI-RF Hub
During the setup process position yourself between the
lock and
the Wi-Fi Hub—ideally no more than 30 feet (9
meters)
apart. Ensure your iOS or Android™device has
both Bluetooth and Wi-Fi enabled.
30 Feet (9 Meters)
Distance Between
Ingress Smart
Access Control
Secure
Link+
WIFI-RF
Hub
Part A Shown
Above
as reference only
You
Using an iOS or Android
™
Device with Bluetooth &
Wi-Fi enabled
TIP: The Secure Link
+
requires a strong wireless signal
for optimal
performance. Make sure the Secure
Link+
will be installed in a location with a strong 2.4 Ghz
wireless signal. Sometimes distances between Wi-Fi
hub and lock can vary due to circumstances. If you are
having
difficulty setting up optimal range of 30/ft or
less, we’re here to
help.
Call our customer care
team: (669) 500 8835,
or visit
LocklyPro.com/support
for suggestions and troubleshooting tips.
6
Secure Link+Installation Checklist.
You have a Lockly Smart Lock already, and
now adding the Wi-Fi Hub.
The Secure Link
+
WIFI-RF Hub is installed within
30 feet (9 meters) from your Lockly Smart Lock.
You have the LocklyPro App installed on your
iOS or Android™device.
You are standing between your smart lock and
the Secure Link+WIFI-RF Hub.
Your Secure Link+WIFI-RF Hub is located in a
location with a strong Wi-Fi signal.
You are currently connected to a 2.4 GHz Wi-Fi
Network (802.11 B/G/N) on your iOS or Android
™
device.
Be sure you check off the above 8 boxes before
proceeding. If any of the boxes are not checked, you
may experience intermittent or delayed response time
in notifications.
*Requires successful installation of the Wi-Fi Hub and
connected to a strong internet connection
Your smartphone Bluetooth connection is ON
and connected to your Lockly device.
7
3. Configuring Your Secure Link
+
WIFI-RF Hub
First, make sure the smartphone you are using to add
the Wi-Fi Hub
is connected to your 2.4 GHz Wi-Fi Network.
Next, open your
LocklyPro
App and select the main
menu
from the upper left corner. (Image shown with
iOS
demo). Once the menu opens go ahead select
“Set up a New Device”
Select the Secure
Link
+
WIFI-RF Hub
NEXT >
8
If you have never connected the Hub to your smart
lock, the Secure Link should have a slow flashing RED
LED Indicator. Press and hold the Setup
Button located
on the top of the Wi-Fi Hub for 3 seconds
until you see
the
GREEN
LED Indicator start to rapidly
flash.
I
f you don’t see anything appear with a Bluetooth icon
and a name starting with PGH222... simply click the
Refresh button on the upper right to rescan. Make
sure your Wi-Fi Hub is showing a flashing GREEN LED
indicator and the Hub is within the optimal distance
of
30 feet from your lock. Select the desired Wi-Fi Hub to
continue.
Connect to
Secure Link+
Minimum 2-3 Bars
Recommended
Press and Hold
3 Seconds
9
Enter your Wi-Fi password
in the next line next to the
icon, then click “Next
Step” to continue.
If you are already connected to a 2.4 GHz compatible
Wi-Fi network, it should display the network name. (See
example below)
Select if your Hub LED
Indicator light is ON
and
SOLID GREEN
.
Select if your Hub LED
is flashing green.
NOTE: If the LED is flashing RED, please check if your
WiFi network is properly working. Please check with your
network administrator or internet provider if you’re
unsure.
10
Congratulations! Your Secure Link+WIFI-RF
Hub is now set up.
Below are some quick information for troubleshooting.
No Indicator Light
Your Wi-Fi Hub has no power.
Check your the power supply.
Slow RED Light Flashing
Your Wi-Fi Hub has power. It’s
not connected to any wireless
network.
Rapid GREEN Light Flashing
Your Wi-Fi Hub is in setup mode.
Setup mode can be entered by
pressing the setup button for 2
seconds. Setup mode will last
approx 2 minutes.
Solid GREEN Light
Your Wi-Fi Hub is on and connect-
ed to an active 2.4 GHz wireless
network.
FCC Warning：
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
r
adio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
NOTE 2: Any changes or modifications to this unit not expressly
approved by the party responsible for compliance could void
the user's authority to operate the equipment.
FCC Radiation Exposure Statement
Lockly Guard Secure Link+WIFI-RF Hub complies with FCC
radiation exposure limits set forth for an uncontrolled
environment. It should be installed and operated with
minimum distance 20cm between the radiator & your body.
IC WARNING:
This device contains licence-exempt transmitter(s) that
comply with Innovation,Science and Economic Development
Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference.
IUMPGH22220220513
WARNING: This product can expose you to chemicals
including Lead, which is known to the State of
California to cause cancer. For more information go
to www.P65Warnings.ca.gov.
© Copyright 2022 Lockly All rights reserved
USA Patent No. US 9,881,146 B2 | USA Patent No. US 9,853,815
B2 | USA Patent No. US 9,875,350 B2 | USA Patent No. US
9,665,706 B2 | USA Patent No. US 11,010,463 B2 | AUS Patent
No. 2013403169 | AUS Patent No. 2014391959 | AUS Patent
No. 2016412123 | UK Patent No. EP3059689B1 | UK Patent No.
EP3176722B1 | Other Patents Pending
The Bluetooth
®
word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. , and any use
of such marks by Lockly is under license. Other trademarks
and trade names are those of their respective owners.
Google, Android, Google Play and Google Home are
trademarks of Google LLC. , Amazon, Alexa and all related
logos are trademarks of Amazon.com, Inc., or its affiliates.
(
2) This device must accept any interference, including
interference that may cause undesired operation of the
device.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation,
Sciences et Développement économique Canada applicables
aux appareils radio exempts de licence.
L’exploitation est
autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.
IC Radiation Exposure Statement
This equipment meets the exemption from the routine
evaluation limits in section 2.5 of RSS-102. It should be installed
and operated with a minimum distance of 20cm between the
radiator and any part of your body.
Cet équipement est conforme à l'exemption des limites
d'évaluation habituelle de la section 2.5 de la norme RSS-102.
Il doit être installé et utilisé à une distance minimale de 20 cm
entre le radiateur et toute partie de votre corps.
