Lode Edan EC-12 EXPRESS Operator's manual

Interface sheet - Edan EC-12 EXPRESS - CPET treadmill
Service documentation
Lode BV
Zernikepark 16
NL 9747 AN Groningen
The Netherlands
t: [phone]
f: [phone]
@: [e-mail]
www.lode.nl
INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

33
33
44
4
4
5
66
6
7
7
88
1313
1717
1919
19
Table of contentsTable of contents
1 - List of symbols used1 - List of symbols used
2 - Validity2 - Validity
3 - Setup instructions Edan EC12 Express3 - Setup instructions Edan EC12 Express
3.1 - Cable selection
3.2 - Software Setup
3.3 - Ergometer setup
4 - Setting up the hardware4 - Setting up the hardware
4.1 - Connection overview
4.2 - Connecting with the usb cable
4.3 - Connecting with the RS232 cable
5 - Treadmill or ergometer with 3.5" touch screen unit5 - Treadmill or ergometer with 3.5" touch screen unit
6 - Treadmill or ergometer with 7" touch screen control unit6 - Treadmill or ergometer with 7" touch screen control unit
7 - Nummerical Control Unit - Treadmill only7 - Nummerical Control Unit - Treadmill only
8 - Treadmill or Bicycle without control unit8 - Treadmill or Bicycle without control unit
8.1 - Device without control unit

1 - List of symbols used1 - List of symbols used
Next
Previous
2 - Validity2 - Validity
This interface form covers
* All OEM treadmills manufactured by Lode B.V. with the part number 939900/01/02/07/08/09/10
starting from serial #939900-20090001;
* All Katana treadmills 9349XX-201X0001
* All Valiant treadmills starting with serial number 932900-20122XXX and 9329XX-20121XXX
* All Valiant 2 treadmill starting with serial number 9389xx-20140001
If your treadmill or ergometer is not covered by this interface form please contact Lode service
[e-mail]
3/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

3 - Setup instructions Edan EC12 Express3 - Setup instructions Edan EC12 Express
3.1 - Cable selection3.1 - Cable selection
You will need the RS-232 cable
(part no. MS1R- 107242,
provided by EDAN) Express to
establish communication
between the Lode Treadmill
Valiant and SE-12 Express.
Connect the RS232 cable to the
SE-12 (picture).
Connect the cable to the
ergometer as described in
chapter "Hardware setup".
3.2 - Software Setup3.2 - Software Setup
1. Switch on SE-12 Express and
start program.
2. Click on the General Info key
on the System Setup interface.
3. Select Treadmill in the Device
Type pull-down list.
4. Select TMX425 in the Device Model pull-down list.
5. Press the OK key.
The Edan ECG is now ready for communication with the Treadmill.
4/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

3.3 - Ergometer setup3.3 - Ergometer setup
The following protocol needs to be set in the Lode ergometer to communicate with the external
equipment.
Treadmill ergometer: Trackmaster
The next chapters describe the procedures to setup these protocols depending on the type of
ergometer.
5/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

4 - 4 - Setting up the hardwareSetting up the hardware
Lode ergometers have two ways of connecting external devices. The cable selection depends on the
connection possibilities of the external device. The previous chapter tells you which cable you need. This
can be a RS232 cable or a USB cable.
4.1 - 4.1 - Connection overviewConnection overview
Connect the cable to the USB
port if you are using a USB
cable.
Please note that you may have
to install the FTDI driver on the
external equipment. This
procedure is only needed if
windows fails to instal the driver
automatically.
You can find the driver on the
Lode website under the Services
tab.
Locations:
- For the Treadmill the communication ports are Located on the front side near the power switch.
- For the bicycle ergometer the communication ports are located on the bottom of the bicycle. Tilt the
ergometer on it's side to be able to acces these ports.
Communication Module:
Use the single RS232 port to connect the communication module to the external equipment.
Legacy communication card (picture above -> 1 * USB, 2 * RS232)
In case you are using a RS232 cable you must use the RS232 port closest
to the USB connector, on the picture indicated with RS232 (1).
6/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

4.2 - Connecting with the usb cable4.2 - Connecting with the usb cable
If there is no other connection available you can also use a USB cable to
connect.
1. You will need an USB A to B cable (Lode part no. 930916) to establish
communication between the Lode ergometer and your stress system or
ergospirometrysystem. See picture left.
2. Connect the cable to the Lode ergometer.
3. Connect the cable to the external device.
4.3 - Connecting with the RS232 cable4.3 - Connecting with the RS232 cable
Connecting with the RS232 cable
1. Depending on the external device you may need to use a straight
RS232 cable (Lode part no. 930911) or a cross linked cable. The cable
selection chapter specifies which cable is needed.
2. Connect the cable to the Lode ergometer.
3. Connect the cable to the external device.
7/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

5 - Treadmill or ergometer with 3.5" touch screen unit5 - Treadmill or ergometer with 3.5" touch screen unit
Start the Lode ergometer.
During start up information
about the ergometer, like the
kind of device, the serial
number and the connected
modules is displayed.
After initialisation the terminal
mode is automatically
displayed. Swipe with your
finger over the screen as
indicated with the red arrow in
the picture to go to the main
menu.
8/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

Select "Settings" to change
settings of the device.
You can choose your Language
in the "Language" menu. The
menu "Sleep Mode" sets a
screensaver. The menu
"Terminal Settings" lets you set
the communication settings for
external communication. The
menu "Service" is only intended
for service purposes to be
executed by factory trainend
personel.
Select "Terminal Settings" to
change the communication
protocol.
9/22INTERFACE SHEET - EDAN EC-12 EXPRESS - CPET TREADMILL / VERSION: 1.0 - 2015-10-22

Select the Communication
protocol as desribed in
"Ergometer setup" chapter.
Select "Default" for the
baudrate.
