Loewe Connect ID 55 User manual

Product information
Loewe Connect ID
55 DR+/ 55
Page 1
Model Article no. EAN Code
Black+High
Gloss Black
55 DR+51465 W 44 4011880141581
55 51465 W 84 4011880141598
White + High
Gloss Black
55 DR+51465 Y 44 4011880141604
55 51465 Y 84 4011880141611
Silver + High
Gloss Black
55 DR+51465 T 44 4011880141536
55 51465 T 84 4011880141659
Beige + High
Gloss Black
55 DR+51465 V 44 4011880141567
55 51465 V 84 4011880141574
Green + High
Gloss Black
55 DR+51465 G 44 4011880141420
55 51465 G 84 4011880141444
Orange + High
Gloss Black
55 DR+51465 I 44 4011880141475
55 51465 I 84 4011880141482
Black + High
Gloss White
55 DR+51465 Z 44 4011880141628
55 51465 Z 84 4011880141635
White + High
Gloss White
55 DR+51465 U 44 4011880141543
55 51465 U 84 4011880141550
Silver + High
Gloss White
55 DR+51465 F 44 4011880141642
55 51465 F 84 4011880141413
Beige + High
Gloss White
55 DR+51465 P 44 4011880141512
55 51465 P 84 4011880141529
Green + High
Gloss White
55 DR+51465 H 44 4011880141451
55 51465 H 84 4011880141468
Orange + High
Gloss White
55 DR+51465 J 44 4011880141499
55 51465 J 84 4011880141505
Loewe Connect ID
55 DR+/ 55
Set-up options
TV
Versions
Wall Mount Isoflex1, Aluminium
W 125.8 / H 78.4 / PD 7.7 / TD 14.4 to 51.9
Flexible solution, folds flat, can be pulled out
straight, rotated and pivoted, adjustable incline
(+2° to 0°), intelligent cable management
Wall Mount Slim/ VESA Size 400, Chrome Silver
W 125.8 / H 78.4 / PD 7.7 / TD 9.9
Flat mounting
Wall Mount WM 62, Chrome Silver
W 125.8 / H 78.4 / PD 7.7 / TD 11.3
Convenient mounting, adjustable incline
(+2° or 0°)
Table Stand Connect ID Comfort, Aluminium
W 125.8 / H 81.1 / PD 7.7 / TD 32.0
Manually rotatable (+/ –20°), adjustable incline
(+1° to –5°)
Dimensions in cm: W = Width, H = Height, PD = Product Depth, TD = Total Depth, BP = Diameter/Dimensions of Base Plate.
1 Only in conjunction with VESA Size 400 adapter. 2 Only in conjunction with a corresponding adapter, to be ordered separately.
Contents: Assist 1 system remote control, aluminium, incl. batteries.
N.B. Set-up options are not included in ex-works delivery. Some products are
depicted with optional accessories.
Loewe Rack2
Different versions, sizes and colours available to
match Loewe TV, sound system and equipment

Product information
Loewe Connect ID
55 DR+/ 55
Page 2
Loewe Connect ID
55 DR+/ 55
Set-up options
Floor Stand Universal2,Aluminium Silver
W 125.8 / H 121.9 / PD 7.7 / BP 50.0
Manually rotatable (+/ –45°), adjustable incline
(+1° to –5°), concealed cable routing
Screen Lift Plus1,Brushed Aluminium
W 125.8 / H 300.0 / PD 7.7 / TD 22.6
Manually rotatable (+/ –90°), adjustable incline
(0° to –5°), concealed cable routing
Technical features
Floor Stand Connect ID, Aluminium
W 125.8 / H 122.3 / PD 7.7 / BP 53.0
Manually rotatable (360°), adjustable incline
(0° to –2.5°), concealed cable routing
Floor Stand Connect ID with Equipment board,
Aluminium, Glass, W 125.8 / H 122.3 / PD 7.7 / BP 53.0
Manually rotatable (360°), adjustable incline
(0° to –2.5°), positioning of 2 equipment products,
concealed cable routing
Dimensions in cm: W = Width, H = Height, PD = Product Depth, TD = Total Depth, BP = Diameter/Dimensions of Base Plate.
1 Only in conjunction with VESA Size 400 adapter. 2 Only in conjunction with a corresponding adapter, to be ordered separately.
Contents: Assist 1 system remote control, aluminium, incl. batteries.
N.B. Set-up options are not included in ex-works delivery. Some products are
depicted with optional accessories.

Product information
Loewe Connect ID
55 DR+/ 55
Page 3
Technical information
Loewe Connect ID 55 incl. DR+55
Image+(Image)
Contrast filter panel / 3D glass panel / high gloss frames
Display technology
Screen diagonal (in cm) / screen diagonal (in inch)/ Picture format / Resolution (in pixels)
Brightness (in cd/m²) / Viewing angle (horizontal/vertical)
Contrast (static/dynamic)
Response time (in ms) /Picture repetition rate
Fully digitised signal processing / Image+Active / 24 p motion picture display
3D technology / 2D-3D conversion / Active Glasses 3D
Format options 1 16 : 9, 4 : 3, Panorama, Zoom
Video auto-dimming (VBD+) / Interior auto-dimming (OPC) / home Mode
h/h/i
Full-HD-LCD with E-LED backlight
140 / 55 / 16 : 9 / 1.920 x 1.080
400 / 178° / 178°
6,000:1 / 6,000,000:1
5 / 200Hz
i/i/i
i/i/y
i
i/i/i
h/h/i
Full-HD-LCD with E-LED backlight
140 / 55 / 16 : 9 / 1.920 x 1.080
400 / 178° / 178°
6,000:1 / 6,000,000:1
5 / 200Hz
i/i/i
i/i/y
i
i/i/i
Sound+(Audio)
Output in W (music/sine)
Closed 2-way speakers / DFW sound system2 / CRX®sound system
Individual bass and treble control / Volume / Sound effects
Automatic voice detection / Automatic Volume Control (AVC)
Dolby Digital Plus / dts / 5.1 Out / Two-channel
Audio out available: variable / fixed / Subwoofer
2 x 10 + 1 x 20 / 2 x 20 + 1 x 40
Open twin driver /i/h
i/i/i
i/i
i/i/i/i
i/i/i(via Audio Link)
2 x 10 + 1 x 20 / 2 x 20 + 1 x 40
Open twin driver /i/h
i/i/i
i/i
i/i/i/i
i/i/i(via Audio Link)
Digital+(Television standards)
DVB-T / DVB-T2 / DVB-C / DVB-S2 / Multistandard (analogue) / Dual Channel
A/V-Decoding: MPEG / MPEG2 / MPEG4 / integrated HDTV reception 3
Colour standard: PAL / Secam / NTSC / NTSC-V / PAL-V (60 Hz)
Audio standard: Two-channel FM / AM, Nicam
i/y12 /i/i/i/i
i/i/i/i
i/i/i/i/i
i/i
i/y12 /i/i/i/h
i/i/i/i
i/i/i/i/i
i/i
Assist+(Operation)
Automatic Channel Programming (ACP) / Channel recognition
Programme positions including AV and radio
Radio reception
Digital Link Plus / Digital Link HD
Video text Level 2.5 / TOP-Video text / FLOF-Video text / Page memory
Personalised Video text with direct access to favorites / bookmarked pages
PIP (AV) 4 / Full PIP 5 / iPIP / Splitscreen TV : Video text
Electronic Program Guide (EPG)
Parental Lock / Automatic turn-off / Timer
Electronic Instruction Manual / Menu languages 6
Index / Context Related Help
i/i
6,000
DVB radio
i/i
i/i/i/ 2,000
i/i
i/i/i/i
i
i/i/i
i/19
i/i
i/i
6,000
DVB radio
i/i
i/i/i/ 2,000
i/i
i/h /i/i
i
i/i/i
i/19
i/i
Media+(Multimedia functions)
DR+/ storage capacity in GB / USB recording
DR+Streaming server / client
MediaHome (photos, music and video via home network / USB)
MediaNet (Internet portal / browser / Internet radio / Internet video)
MediaText (HbbTV) / MediaUpdate
i/ 500 /i
i/i
i/i
i/i/i/i
i/i
h/ h/i
h/i
i/i
i/i/i/i
i/i
Connectivity+(Connectors)
HDMI with HDCP / USB / Component (YUV) In 7
Euro-AV (Scart) / S-VHS, Hi-8 / RGB
Copy function Front-AV to Euro-AV
Digital Audio-In (Cinch) / Digital Audio-Out (Cinch) / Analogue audio-out (L/R)
Analogue audio link (Loewe 5.1 System Out, Stereo Out, Sub Out, Center In)
VGA / RS 232 C (RJ12) / Motor control / IR-Link
Side AV Video-/S-VHS, Hi-8-ready / Headphone (jack 3.5 mm)
Common Interface CI / CI Plus certified 8
LAN network connection / integrated WLAN
3 (HDMI 1 with ARC) / 2 /y
Mini-Scart / 1 / 1
i
i/i/y13
i
i/y/y/y
i/i/i
2 /i
i/i
3 (HDMI 1 with ARC) / 2 /y
Mini-Scart / 1 / 1
i
i/i/y13
i
i/y/y/y
i/i/i
2 /i
i/i
Environment
EU energy efficiency class / Annual energy consumption (kWh) 9
Power consumption in stand-by mode / off (in W)
Power consumption „ON“ 10 (in W) / Peak luminance ratio in %
Mercury content in mg /contains lead 11
A+ / 128
0,35 / 0
92.0 / 67.0
0.0 / traces
A+ / 125
0,35 / 0
90.0 / 67.0
0.0 / traces
Miscellaneous
Weight in kg
Power switch / Mains voltages
VDE-safety standard (inspection seal)
28.5
i/220–240 V, 50/60 Hz
i
28.3
i/220–240 V, 50/ 60 Hz
i
i = included/installed y= upgradeable/optional
1Dependent on SD/HD input format.
2DFW: Down Firing Woofer. Subwoofer which emits sound downwards.
3Reception of digital channels may be limited by individual regulations from
the respective broadcaster/provider. UK models are Freeview HD compliant.
4On sets without DR+, AV-PIP is only available in combination with DVB-T/C/S.
5Not with MPEG4.
6D-GB-F-I-E-NL-CZ-GR-PL-H-FIN-SLO-SK-TR-S-DK-P-RUS-N
7Using VGA adapter (available from Loewe specialist retail partners).
8CI Plus is backwards compatible with CI.
Functionality is dependent on module availability from the supplier.
9On the basis of four hours of operation per day, 365 days a year.
Actual energy consumption depends on the purpose for
which the TV is used.
10 To EN 62087 : 2009.
11 Traces may occasionally be found in electronic components
(in compliance with the recast European RoHS directive).
12 For the UK, Denmark and Sweden: already included.
13 Connect ID via Audio Link adapter.
