Loewe Individual 32 Compose Sound LED User manual

Operating instructions
Individual
TV
Individual 32 Compose Sound LED
Individual 32 Selection Sound LED
233–34654.023

- 2
english
Colour key function during radio operation
Red button: On/Off screen
Yellow button: Last selecting station
Button functions
Call MediaPortal,
select operating mode or function.
(e.g. Index)
with on-screen display: Info display,
info text appropriate to the content that can assist you
further, should you have any questions about your TV
device;
without on-screen display: Access status display,
with status display open and repeatedly pressing
programme information (if available)
Open DR archive/Video archive (2 / Timer list
Press button twice in quick succession:
Show / hide time permanently
Adjust picture format
On/Off PIP (picture in picture)
On/Off EPG (Electronic Programme Guide)
On/Off teletext/MediaText (1
Call TV menu,
carry out settings
With opened menu: Exit menu;
Terminate inserts
Set operating mode
TV operation
Radio operation (standard assignment)
The assignment of the AUDIO button can be changed
(see page 129).
On/Off of the television set
On/Off device in standby
(Main switch must be turned on)
Selecting stations
OK Call station overview and with
Select station
or
P+/P– Next/ previous channel
or
Select station with numeric buttons
Sound
V+/V– Increase/ reduce volume
Sound on/off
Colour key function during TV operation
Red button: Freeze on/off.
Start HbbTV (1 or interactive data service,
if this is available.
Green button: Teletext functions
Yellow button: Last selected station
Blue button: Programme information
Overview of the most important functions
(1
Depending on the corresponding settings (see from page 82).
(2
Only for TV sets that contain an integrated hard disc (DR+), a connected external hard
disc (USB Recording) or that have an archive available on the network (DR streaming).

3 -
english
1
Sound off/on ...........................................................................................................(page 36)
2
LED display for current operating mode................................................................(page 129)
3
Switch over to TV mode..................................................................................(page 20; 129)
4
Switch over to operate recorder (2 .........................................................................(page 129)
5
DR archive/Video archive(1 / Timer list on/off...........................................................(page 98)
6
Set picture format....................................................................................................(page 39)
7
Electronic Programme Guide on/off ........................................................................(page 52)
8
Teletext/MediaText (3 on/off................................................................................(page 54; 82)
9
Menu on/off............................................................................................................(page 12)
10
V+/V– Increase/ reduce volume...............................................................................(page 36)
11
Station list on...........................................................................................................(page 34)
in the menu: Confirm/call........................................................................................(page 12)
12
Green button: Teletext functions.............................................................................(page 40)
13
Red button: Freeze on/off / Start HbbTV or interactive data service (3 .....................(page 82)
14
Select station down / Jump (1 / Rewind (1..................................................... (page 34; 90; 99)
15
Direct recording (1.....................................................................................................(page 92)
16
Still frame on/off / Interrupt timeshift television(1 ....................................................(page 90)
17
Still frame on / End timeshift(1 .................................................................................(page 90)
18
Select station up / Jump (1 / Fast forward(1.................................................. (page 34; 90; 99)
19
Still frame off / Continue timeshift television(1 / Highlights (1..............................(page 90; 91)
20
Blue button: Programme info on/off.......................................................................(page 40)
21
Yellow button: Switch to the last viewed channel...................................................(page 40)
22
In the menu / Lists: Select/Set..................................................................................(page 12)
23
P+/P– Select Station up/down.................................................................................(page 34)
24
Close all displays ......................................................................................................(page 12)
25
Status display on/off / in the menu: context-relevant Info on/off......................(page 42; 15)
26
PIP on/off (picture in picture) ...................................................................................(page 50)
27
MediaPortal on/off ............................................................................................(page 14; 64)
28
AV selection.............................................................................................................(page 35)
29
Select station directly; in the menu: Enter numbers or letters..................................(page 34)
30
Set sound mode ......................................................................................................(page 36)
31
Switch over to operate DVD player (2 .....................................................................(page 129)
32
Switch over to radio mode(2..................................................................... (page 21; 56; 129)
33
Switch on/off to standby mode...............................................................................(page 21)
The key assignment displayed here is valid for the main menu level of the TV set. The key assignment
may vary in certain operating modes (see the corresponding chapter in this operating manual).
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
18
19
20
21
22
23
24
25
26
27
28
29
30
31
33
17
Remote control – TV functions
(1 For equipment with integrated hard disc (DR+) or connected
external hard disc, see the Digital Recorder chapter from page
85 onwards.
(2
The assignment of these buttons can be changed (see page 129).
The description refers to the standard setting.
(3 Depending on the corresponding settings (see from page 82).

- 4
english
Acknowledgements
Loewe Technologies GmbH
Industriestraße 11
D-96317 Kronach
www.loewe.tv
Date of issue 01/12-6.0 TB
© Loewe Technologies GmbH, Kronach
ID: 7.5.0
All rights including translation, technical modifications and errors reserved.

5 -
english
Contents
Overview of the most important functions ............................................. 2
Remote control – TV functions ................................................................ 3
Acknowledgements.................................................................................. 4
Welcome................................................................................................... 7
Scope of delivery..................................................................................... 7
About this operating manual .................................................................. 7
For your safety ......................................................................................... 8
Control unit front side of the device ..................................................... 10
Connections rear side of the device ...................................................... 11
Operating convenience .......................................................................... 12
General information on menu operation.............................................. 12
Operating convenience with wizards.................................................... 13
Overview of wizards.............................................................................. 13
MediaPortal........................................................................................... 14
The index in the TV set.......................................................................... 15
The info display ..................................................................................... 15
TV menu – Overview diagram............................................................... 16
Radio menu – Overview diagram.......................................................... 17
Other menus– Overview diagram ......................................................... 17
Initial installation................................................................................... 18
Installing the TV set............................................................................... 18
Set covers.............................................................................................. 18
Connecting the TV Set .......................................................................... 18
Bundling the Cables .............................................................................. 20
Preparing the remote control unit......................................................... 20
Turning the set on/off............................................................................ 21
First installation wizard .......................................................................... 22
TV set as a monitor ............................................................................... 33
Positioning/aligning DVB-T antenna ...................................................... 33
Daily operation ...................................................................................... 34
Select station......................................................................................... 34
Selecting audio/video source................................................................. 35
Adjusting the sound.............................................................................. 36
Adjusting the picture............................................................................. 38
Daily operation (continuation)............................................................... 40
Button functions ................................................................................... 40
Operation without remote control........................................................ 41
Status display......................................................................................... 42
Managing stations ................................................................................. 44
TV stations............................................................................................. 44
Put together / change favourites lists .................................................... 49
Picture in Picture.................................................................................... 50
Picture in Picture (PIP)............................................................................ 50
iPIP ........................................................................................................ 50
Standard PIP .......................................................................................... 50
Configure Picture in Picture (PIP) mode ................................................. 51
Electronic Programme Guide ................................................................. 52
Electronic Programme Guide – EPG ...................................................... 52
Configuring EPG.................................................................................... 53
Teletext................................................................................................... 54
Teletext.................................................................................................. 54
Teletext menu........................................................................................ 55
Digital radio ........................................................................................... 56
Radio mode (DVB radio)........................................................................ 56
EPG – Electronic Programme Guide (radio) ........................................... 57
Radio mode (Internet radio) .................................................................. 58
Audio playback from external devices................................................... 59
Other settings ........................................................................................ 60
Parental lock.......................................................................................... 60
Timer functions ..................................................................................... 61
Language .............................................................................................. 61
On-screen displays ................................................................................ 62
Time and date....................................................................................... 62
Coded Stations....................................................................................... 63
Conditional Access module (CA module).............................................. 63

- 6
english
Media+.................................................................................................. 64
General information on Media+........................................................... 64
Connecting the TV set to your network................................................ 64
MediaNet .............................................................................................. 64
Help for configuration problems........................................................... 64
MediaUpdate - additional functions...................................................... 64
Accessing your media ........................................................................... 65
Media menu.......................................................................................... 66
MediaHome.......................................................................................... 70
MediaNet .............................................................................................. 73
MediaMusic .......................................................................................... 78
MediaPhoto .......................................................................................... 79
MediaVideo........................................................................................... 80
Interactive data services........................................................................ 82
HbbTV / MediaText................................................................................ 82
MHEG-5 ................................................................................................ 84
Digital Recorder ..................................................................................... 85
About the Digital Recorder system........................................................ 85
Settings ................................................................................................. 88
TV viewing with time shift..................................................................... 90
Archive recording – Direct recording..................................................... 92
Archive playback ................................................................................... 98
DR+ Streaming .................................................................................... 106
External devices ................................................................................... 112
Connections menu.............................................................................. 112
Gaming mode..................................................................................... 113
Devices to the connections AV/AVS .................................................... 114
Devices to the HDMI connections....................................................... 116
Digital Link HD .................................................................................... 117
Devices to the PC IN connection......................................................... 118
Sound components wizard ................................................................. 119
Connecting Loewe sound system ....................................................... 120
Connecting active loudspeakers.......................................................... 121
Adjusting the speaker system.............................................................. 121
Connecting audio amplifiers ............................................................... 124
Assignment of the digital audio input................................................. 125
Audio connection in HDMI/DVI devices.............................................. 125
Serial interface RS-232C (RJ12)............................................................ 125
External devices (continuation) ........................................................... 126
The direct way to record ..................................................................... 126
Timer recording with external devices................................................. 128
Operating Loewe equipment.............................................................. 129
Software update .................................................................................. 130
Basic information ................................................................................ 130
USB stick.............................................................................................. 130
Software download for updates over USB.......................................... 130
Software update via USB storage device............................................. 131
Software update via the internet......................................................... 132
Input of characters............................................................................... 134
USB keyboard...................................................................................... 134
Button combinations........................................................................... 134
Character table.................................................................................... 135
Rotating the TV set .............................................................................. 136
Troubleshooting ................................................................................... 137
Technical data ...................................................................................... 140
General data........................................................................................ 140
Electrical data ...................................................................................... 141
Signals via PC IN / HDMI ..................................................................... 141
Connections (max. equipment)........................................................... 142
MediaHome........................................................................................ 143
Accessories........................................................................................... 144
Upgrade kits / conversion kits / cables................................................. 145
Equipment variants.............................................................................. 146
TV set equipment................................................................................ 146
Setup possibilities ................................................................................ 147
Environment......................................................................................... 148
Legal notes........................................................................................... 149
Glossary................................................................................................ 150
EC Declaration of Conformity .............................................................. 155
Index .................................................................................................... 158
Service.................................................................................................. 161
Contents

7 -
english
Thank you
for choosing a Loewe TV set!
Loewe stands for the highest demands in technology, design and user
friendliness. This applies equally for TV, video and accessories.
In addition to the elegant design and the many different possible colour
combinations and installation possibilities, your Loewe TV set also offers
many technological options.
Loewe Image+
State-of-the-art Full-HD-LCD-displays with LED-Backlight Technology. The
advantage of the LED-Backlight is in the reduced energy consumption and
high contrast values.
24p films played by a connected HDMI unit can be displayed optimally.
Loewe Sound+
Loewe Sound+contains sound processors that are optimally calibrated
to the TV set and boasts a closed coverage construction type for the
integrated loudspeakers.
Many Loewe TV sets are fitted with a digital multi-channel audio decoder
for impressive 5.1 surround sound.
Loewe Media+
You can reach the MediaPortal via the MEDIA button on your remote control,
giving you access to all multimedia functions of your TV set.
Loewe DR+
If the hard disc recorder DR+(1 is integrated into your TV set, you can
record TV programmes simply at the press of a button. Programmes
currently being watched can be interrupted, rewound and played back
from the desired point if needed.
Scope of delivery
nLCD TV set
nMains cable
nAntenna cable
nVelcro cable ties
nRemote control Assist with two batteries
nTV quick guide
About this operating manual
For best results regarding safety and the longevity of the set, we recom-
mend you read the chapter For your Safety (page 8) before switching
it on for the first time.
The functions of the Loewe TV set are largely self-explanatory. However,
should you have any questions, the integrated index and the info display
(see page 15) can assist you further.
The index/glossary from page 150 onwards gives explanations of certain
terms used in the TV set and the operating manual.
Paragraphs which begin with the symbol ➠indicate important instruc-
tions, tips or conditions for the following settings.
Terms which you will find in the menus or printed on the remote control
or TV set are written in bold type.
The necessary control elements are shown in the descriptions to the left
of the text containing the instructions for action.
In addition to the remote control, a PC keyboard can be connected to
one of the USB ports on your TV and then used to control your TV set
(see also page 134).
In the operating manual, this symbol indicates places in
which the use of a keyboard is particularly advantageous.
Depending on the connected accessory equipment the menus in the TV
set can differ from those described here.
All the station names, programme contents, the illustrated photos, titles,
albums and album covers in this operating manual are examples.
The operating instructions for your TV set are updated at irregular
intervals. We recommend checking now and then, especially after a
software update.
Interactive data services
In some countries the stations also broadcast interactive data services
with their programmes, leading to the functions of individual buttons
not being available or only so to a limited extent. You can find out more
about this from page 82 onwards.
Welcome
(1 Depending on the type of TV set. (equipment and upgrade options, see page 146.

- 8
english
For your own safety and to prevent unnecessary damage to your device,
read and comply with the following safety instructions:
Proper use and environmental conditions
This TV set is designed exclusively for reception and reproduction of
video and audio signals and is designed for living rooms or office facilities,
and should not be operated in rooms with high humidity, such as a
bathroom, or sauna, or where there is a high concentration of dust (e.g.
workshops). The manufacturer‘s warranty is only valid for use in the specified
permissible environment.
If the set is used outdoors ensure that it is protected against moisture
(rain, splashing water, or dew). High humidity and dust concentrations
cause leak currents in the device, which can cause a shock hazard if the
device is touched, or a fire.
If you have brought the set into a
warm environment from the cold,
then wait for about 1 hour before
switching it on to avoid formation of
condensation.
Do not place any objects filled with
liquids on top of the appliance. Pro-
tect the appliance against dripping
and splashing water.
Candles or naked flames must be kept
away from the appliance at all times
to prevent it from catching fire.
Never place the TV set in a position where it is exposed to vibrations. This
can lead to material overload.
Transporting
Only transport the device in vertical position. Grasp the device on the
upper and lower edges of the housing.
If the set has to be put down during packing/unpacking, place the TV
set with the entire front surface lying flat on a soft underlay such as a
blanket or the felt from the packing material.
The LCD screen is made of glass or plastic and can break if not handled
properly.
Always wear rubber gloves to carry the TV set if the LCD screen is dam-
aged and liquid crystal might be leaking out. In the case of skin contact
immediately wash thoroughly with water.
Power supply
The wrong voltage can damage the set. This equipment must only be
connected to a mains power supply which has the same voltage and
frequency as that specified on the rating plate; use the mains cable
provided. The mains plug of the TV set must be easily accessible so that
the device can be disconnected from the mains at any time. When you
unplug the mains plug, do not pull on the cable rather pull on the plug
housing. The cable in the mains plug could be damaged and cause a
short circuit the next time it is plugged in.
Lay out the mains cable in such a manner that it cannot be damaged.
The mains cable must not be kinked or laid over sharp edges, stepped
on or exposed to chemicals; The latter also applies for the entire equip-
ment. A mains cable with damaged insulation can cause electrical shock
and is a fire hazard.
Air circulation and high temperatures
The vent slots on the rear panel of the set must always be kept free.
Please do not place newspapers or cloths on/over the TV.
Ensure that there is at least 10
cm free space on the sides and
above the set for air circulation,
if the set is placed in a cabinet
or on a shelf.
Like any electronic device, your
TV set requires air for cooling.
Obstruction of the air circula-
tion can cause fires.
Prevent metal items, needles,
paper clips, liquids, wax, or
similar items, from getting into the interior of the device through the
vent slots in the rear panel. Such objects can cause short circuits in the
set, which could possibly cause a fire.
If something should get into the interior of the set then immediately
unplug the mains plug of the device and contact customer service for
more information.
Automatic shutdown (only in Home Mode)
If the TV is not operated for 4 hours (adjustment of volume, programme
change, etc.) the TV will automatically switch to stand-by mode to save
energy. A prompt to terminate this shutdown process appears one min-
ute before expiry of the 4 hours. The automatic shutdown is only active
in the energy efficiency mode Home Mode. Automatic shutdown does
not occur when using the radio without screen display (screen off).
For your safety
10 cm 10 cm 10 cm

9 -
english
Note on the LCD screen
The TV set you have purchased with LCD screen satisfies the most rigor-
ous quality requirements and has been inspected relative to pixel errors.
Despite our thorough care when manufacturing the display, it cannot be
100% guaranteed that no subpixel defects will be present due to techni-
cal reasons. Please understand that these types of effects, as long as they
are within the standard of specified limits, cannot be considered as a
device defect in terms of the guarantee.
Avoid displaying still images for long periods of time. It is possible that
a copy of the image may remain.
Cleaning and care
➠ Switch off the TV set at the main switch before cleaning.
Clean the TV set, the screen, and the remote control unit with a soft,
moist, and clean cloth only, without any aggressive or scouring cleaning
agents.
Sets with glass screens may be cleaned with a conventional glass cleaner.
Installation
The set is suitable for different installation solutions. See the instructions
for assembly for the different installation solutions.
Stand the TV set with the table or floor stand only on a level, sturdy,
horizontal base. Particularly ensure that the set does not protrude to the
front when placed in or on pieces of furniture.
Place the TV set in a normal position for use. The TV set may only be
used in an upright horizontal position. It may not be tilted by more than
10 degrees. The TV set must never be operated vertically, lying flat or
hanging overhead from the ceiling.
Set up the device where it is not exposed to direct sunlight and where it
is not exposed to additional warming through heating elements.
Repairs and accessories
Never remove the back of the TV set yourself. Only have your TV device
repaired or serviced by authorised television technicians.
Only use original accessories such as Loewe stands if possible (see Acces-
sories on page 144.
Supervision
Do not allow children to use the TV set without supervision or to play in
the immediate vicinity of the TV set. The set could tip over, be pushed
off or pulled down from the stand surface and injure someone.
Do not allow the switched-on TV set to run unattended.
Volume
Loud music can lead to ear damage. Avoid extreme volume especially
over long periods and when using headphones.
Thunder storms
Pull out the mains plug and all connected antenna cables from the TV
set in a thunderstorm. Overvoltage caused by lightning can damage the
set via the antenna system, as well as via the mains. The mains plug and
all connected antenna cables should also be pulled out during long pe-
riods of absence.
For your safety
±10°
D

- 10
english
Control unit front side of the device
Functions of the operating elements
1Mains switch:
The mains switch is located on the bottom of the set.
Always return the TV set to Standby mode before switching it off
with the main switch.
2 On/Off button:
Switch on from the standby mode
Switch off to the standby mode
3 Display:
red = Standby
green = Operation
orange = Operation without on-screen display
(Radio, EPG data capture, timer recording, software
update or archive recording via USB (1 ).
4 Display DR+(2:
white = Digital Recorder inactive
(no recording, no playback)
green = Digital Recorder active (offset TV viewing or
archive playback)
red = Digital Recorder active
(archive recording)
5 Button M:
Call the menu
in the menu: up/down 
6 Button R:
Radio on/off (back to TV mode)
Switch on the radio from the standby mode
in the menu: down 
7 Button +:
Station up
in the menu: to the right 
8 Button – :
Station down
in the menu: to the left 
(1 USB recording is only possible for devices without DR+(integrated hard disc recorder).
(2 Only for devices with DR+ (integrated hard disc recorder).
DR+
M
R
+
-
3 1
5
7
8
2
4
6

11 -
english
(1 Equipment and upgrade options, see page 146.
(2 The position of the aerial sockets depends on the tuner equipment.
Connections rear side of the device
1
HDMI 1 - HDMI input 1
2
HDMI 2 - HDMI input 2
3
PC IN - VGA/XGA input
4
AV - Euro-AV socket
5
LAN - Network connection
6
USB - USB connection
7
AUDIO IN - Audio input (analogue)
8
AUDIO DIGITAL OUT - Digital audio output
9
AUDIO DIGITAL IN - Digital audio input
10
CENTER IN - Centre audio input (analogue)
11
SERVICE - Service socket
12
ANT-TV - Antenna/cable analogue/digital (1 (2
12
ANT SAT - Satellite antenna (Sat tuner 1) (1 (2
12
ANT SAT 2 - Satellite antenna (Sat tuner 2) (1 (2
13
AUDIO LINK - Surround audio outputs (analogue)
14
CI-COMMON INTERFACE - Common Interface 1 (CI slot 1)
15
CI-COMMON INTERFACE - Common Interface 2 (CI slot 2)
16
HDMI 3 - HDMI input 3
17
USB - USB connection
18
- Headphones connection
19
AUDIO IN L - Audio in left (AVS)
20
AUDIO IN R - Audio in right (AVS)
21
VIDEO IN - Video in (AVS)
22
AVS - S-Video connection (AVS)
23
220-240V~ 50/60Hz – Mains connection
24
IR LINK - Infrared transmitter connection
25
CONTROL - Rotating stand control
26
RS-232C - Serial interface
1 2
11
9
10
12 13
26
15
4 5
23
3
24
8
19
20
22
21
18
25
6 7
14
17
16

- 12
english
Menu operation (example: TV menu)
Menus for the individual modes (TV, Radio, PIP, EPG, Teletext, MediaPortal
and DR archive/Video archive (1) are called with the MENU button.
The menus are displayed at the bottom of the screen. At the top you get
additional information about the selected menu item (see info display on
page 15).
➠ In normal TV mode, without other displays.
MENU: Call TV menu.
Select Picture,
go to the menu line below.
Select Brightness,
go to the menu line below.
Set Brightness.
Return to the Brightness menu line
to make other picture settings.
Select more ... ,
OK call more ... functions.
Select Auto format,
go to the menu line below.
Select on / off.
END: Exit settings and close all on-screen displays.
Menu structure
You can find a diagram of the menu structure in the overview diagrams,
page 16 and after.
General information on menu operation
The operation can be divided basically into two areas: The operation of
dropdown lists (e.g. station list, favourites list, EPG etc.) and the menu
operation (TV menu etc.) for configuring your TV set.
➠ If any questions arise during the operation of your TV set, an appro-
priate info screen can be accessed to help you by pressing the INFO
button (see also info display on page 15).
Selection list (example: Station list)
You move the cursor by pressing the ring (up,
down, left, right).
P+/P– If more selection options are available than will fit
on one screen page page ܬis displayed. You can
scroll the pages with P+/P–.
OK The OK button calls the selection or confirms the
setting.
With the coloured buttons you can select different op-
tions depending on the application. The assignment of
the coloured keys is shown at the bottom of the screen.
INFO: Additional information about the screen page.
END: Close/exit dropdown list.
Inputs with the numeric buttons
Letters have to be entered for specific functions. When
using the remote control, press the numeric buttons just
as on a mobile phone keypad (0-9) until the desired
symbol is displayed. The available letters are printed on
the individual numeric buttons.
See page 135 for a detailed overview of the available
characters.
OK
az
-
P+
P–
STATIONLIST
21:00-21:45 Urlaubsparadies - Toskana
HDMI3
HDMI2
HDMI1
PC IN
AVS
AV
0 VIDEO
 'DV(UVWH۽
 =')۽
 :'5.¸OQ   ۽
  %D\HULVFKHV)6 ۽
KUIHUQVHKHQ   ۽
  3KRHQL[ ۽
  %5DOSKD۽
VDW۽
  (LQV([WUD۽
  (LQV)HVWLYDO۽
(LQV3OXV۽
  =')LQIRNDQDO   ۽
  =')GRNXNDQDO  ۽
  =')WKHDWHUNDQ  ۽
  DUWH۽
.LND۽
OK
Scan stations
Change stations
Sort alphabetically
Switch to ...
Select station
Favourites3DJHܬ
Sound Recording Connections Settings G
Here you can adjust among other things: Contrast, colour, brightness,
picture adjustment, sharpness, picture format.
TV MENU
Picture adjustment ...
Operating convenience
(1
Only for TV sets that contain an integrated hard disc (DR+), a connected external hard
disc (USB recording) or that have an archive available on the network (DR streaming).

13 -
english
Operating convenience with wizards
For many settings your TV set has user guidance with wizards which
guide you through the settings step by step.
Overview of wizards
Initial installation
The initial installation wizard helps you with the initial installation and
connection of any existing equipment (see page 22).
Setting up the antenna
You enter in the antenna wizard which antenna signals are available to
you. The antenna wizard is called in initial installation (see page 22).
You can also call the antenna wizard in the TV menu under Connections
טAntenna DVB טAntenna DVB-S (1 or Antenna DVB-T.
Search wizard
If you want to search for new stations after the initial installation, or if you
have set up your antenna for the first time, then you can handle this task
with the help of the search wizard (see page 44).
You will find the search
wizard in the TV menu under Settings
טStations טSearch wizard.
Connecting sound components
The sound component wizard ensures that the components which re-
produce the TV sound are correctly registered, connected and set. It is
started automatically at the end of the initial installation wizard but can
also be called separately (see page 119). You will find the sound com-
ponents wizard in the TV menu under Connections טSound components.
Programming and managing recordings
The recording wizard helps you when programming a recording using
video, DVD or digital recorder (DR+for devices with an integrated hard
disc or USB recording for those without it) see page 126 onwards).
Software update
You can download the latest software for your TV set from the Loewe
Service site and update using a USB stick (see page 130).
Operating convenience
(1 Equipment and upgrade options, see page 146.

- 14
english
MediaPortal
The MediaPortal is the central overview page for your TV set‘s functions.
From here you can gain access to TV channels, local and online media,
digital radio and to the archive of the Digital Recorder (1.
Call MediaPortal
MEDIA: Call MediaPortal.
The individual media and various functions are organised
in the MediaPortal.
The number of selectable items varies depending on the
TV equipment, network connection, available media/
media servers and connected appliances.
Select menu item,
OK call.
Description of the individual functions:
TV: Here you call the TV mode of your TV set.
See page 34 for further information.
DVB radio: Use this to open the DVB radio mode of your TV set
to listen to digital radio stations over DVB.
See page 56 for further information.
Internet radio: Use this to open the Internet radio mode of your TV
set to listen to digital radio stations over the Internet.
The menu item only appears if an Internet connection
is available.
See page 58 for further information.
DR archive (1 / Using the DR archive, you have access to the recorded
Video archive: programmes on the integrated hard disc (for TV sets
with DR+) or to the recordings on a storage device
connected via USB. If the TV set does not have an
integrated hard disc or a storage device connected via
USB, the menu item Video archive will only appear if a
network connection to a Loewe TV set with a shared
DR archive is available.
See page 85 for further information.
MediaHome: Here you have access to your personal memory media,
e.g. to all memory media connected via USB or to
networks with which your TV set is connected.
See page 64 onwards for further information.
DR+ Streaming (1: Here, you can switch off the TV set in the advanced
standby mode for DR+Streaming.
The menu item only appears if the TV set is equipped
with an integrated hard disc (DR+) and the DR archive
is being shared with other TV sets.
See page 106 for further information.
Index: Here you have access to the index integrated in the TV
set.
See page 15 for further information.
MediaNet: Here you have access to multimedia content in the
Internet as well as a high-quality web browser.
See page 64 onwards for further information.
MEDIA PORTAL
TV
DR+ StreamingMediaHome
DVB radio DR archive
MediaNet
Index
Internet radio
Operating convenience
(1 Depending upon which equipment the TV set has.

15 -
english
Operating convenience
The index in the TV set
The index explains the TV functions and the terms that you may be con-
fronted with when operating the TV set. You can start all the assistants
and many of the operating functions directly from here.
Alphabetic sorting is preceded by the items Menu language, Energy ef-
ficiency, Integrated features and Repeat initial installation.
Call index
MEDIA: Call MediaPortal.
Select Index,
OK call.
You will see an info text for the highlighted keyword in
the info display.
If an OK symbol appears in the marked line, this function
can be called directly with OK.
Selecting a keyword
Enter initial letters with the numeric buttons like with a
mobile phone keypad (see page 12).
or go with:
to the preceding / next letters,
from line to line,
P+/P– Flip forwards or backwards through the pages.
Example: You want to have the TV set switch off automatically at
a specific time:
Select the keyword Switch off טAutomatic, with OK you can
activate the setting and with back again.
The info display
The info display provides an info text appropriate to the on-screen display
that can assist you further with the operation of your TV set. Together
with the index it makes for a comfortable operating system.
➠ An on-screen display is faded in.
The factory setting is that the info display is shown auto-
matically for each menu item. In this case you can tempo-
rarily hide the info texts with the INFO button.
The automatic info display can be hidden via a menu
setting. Then it can be displayed temporarily by pressing
the INFO button.
You will also be able to see that there is an info-text avail-
able from the displayed INFO symbol at the bottom right.
If an info text over several pages is available the number
of available pages and P+P– Page ܬis displayed in the
Info window. You can scroll through the individual info
pages with P+ and P–.
Permanently display or hide the automatic info display
Once you have become familiar with how to operate the TV set, you can
switch off the automatic info display.
➠ In normal TV mode, without other displays.
MENU: Call TV menu.
Select Settings,
go to the menu line below.
Select Miscellaneous,
go to the menu line below.
Select On-screen displays,
go to the menu line below.
Select Automatic info,
go to the menu line below: yes / no.
OK
az
-
OK
P+
P–
Activate Previous/next letter
6HOHFWOHWWHU3DJHܬ
INDEX
Menu language
Energy efficiency
Integrated features
Repeat initial installation
*
Access code
Automatic dimming - Room
Automatic station programming
You can select your language for operating the TV set.
Picture Sound Recording
SETTINGS
Here, you can search for stations automatically or manually as well as set
the menu language, timer functions, parental lock,
on-screen displays, etc.
TV MENU
Settings
Station ...
t
ions

- 16
english
TV menu – Overview diagram
(1 Menu items appear depending on the signal source currently selected (DVB or analogue) and/or at definite presettings in the relevant
menus. For individual details, see the corresponding chapter of the operating instructions.
(2 Menu item only appears if a foot with motor drive is used (see page 136).
(3 Menu item only appears if the audio commentary is activated and available (see page 43).
(4 Menu item can only be selected if a valid signal is present at the PC IN input.
(5 Menu item only available if a Decoder has been selected as Device at connection AV (see page 112).
(6 Menu item only appears in sets with DR+ (see page 85).
Operating convenience
Settings
TV menu
Picture Sound Connections
Recording
Recording wizard
Timer list
Pre-record time
Post record time
Sound components
Antenna DVB
AV connecting settings
Miscellaneous
Picture adjustment
Contrast
Colour intensity
Colour temperature
Brightness
Sharpness
Digital Noise Control (DNC)
more...
Image+ Active
Auto dimming - Room
Auto dimming - Video (VBD+)
Film quality improvement (DMM)
Auto format
Picture format
Move picture up/down (1
PC IN display (4
Search wizard
Manual adjustment
Change stations
Select/change favourites
Update station list
automatically
On-screen displays
Time and date
Software update
CA module: xxx (1
DVB settings
Rotate TV (2
HbbTV mode
Start behaviour
of HbbTV stations
Feature of the TEXT key
Check integrated
hard disk
(6
Menu language
Subtitles (DVB)
Audio (DVB)
Energy efficiency
Stations
Parental lock
Timer functions
Language
Miscellaneous
Digital Link Plus
Decoder stations (5
Remote TV switch on
via Digital Link
Assign digital audio input
Gaming mode Switch off once
Switch off daily
One-time alarm
Wake up Mon-Fri
Wake up Sat
Wake up Sun
Wake up with
Wake up signal volume
Sound mode
Dolby PLII mode (1
Sound adjustment
Audio commentary volume (3
Headphone volume
Loudness
Sound-picture synchronisation (1
more...
Loudspeaker sound (1
Headphone sound (1
Auto volume
AV output signal
Maximum volume
Max. switch on volume
Volume adjustment for
current station
Balance
Auto speech detection
Home Mode
Premium Mode
Shop Mode

17 -
english
Operating convenience
Radio menu – Overview diagram
Other menus– Overview diagram
Radio menu
Sound Stations Timer functions
Search wizard
Manual adjustment
Change stations
Select/change favourites
Switch off once
Switch off daily
One-time alarm
Wake up Mon-Fri
Wake up Sat
Wake up Sun
Wake up with
Wake up signal volume
EPG menu Teletext menu
Preview pages
Sub-title pages
Personal text pages
Character set
Station selection
Newsflash
Reveal
Recording wizard
Settings
Sound mode
Dolby PLII mode (1
Sound adjustment
Headphone volume
Loudness
more...
Auto volume
Maximum volume
Max. switch on volume
Volume adjustment for
current station
Balance
Auto speech detection
Media menu
Switch on TV when marked
off
on
Station selection
Data capture
no
yes
Sorting
corresponding to station list
chronologically
Photo settings
Music settings
Video settings
Network access
Other
Reset to factory settings
Network settings

- 18
english
Connecting the TV Set
Connecting to the mains
Remove the cover for the connections.
Connect the TV set to a 220-240V mains socket:
First plug the small plug of the power cable into the mains connection
on the back of the TV and then the large mains plug into a mains socket.
Connecting antennas
Cable (analogue) / DVB-C / DVB-T antenna:
Plug the antenna cable of antenna, cable system or room antenna into
the ANT TV socket.
If you want to use analogue cables / DVB-C connection and a DVB-T
antenna together, use an external antenna switch (available from your
dealer).
Satellite antenna DVB-S:
If the TV set is equipped with a Single or Twin satellite tuner (ex-factory or
means of upgrade kit / conversion kit), the ANT-SAT and ANT-SAT2 sockets
are available.
Depending on the used satellite system, connect a connecting cable from
the multi-switch or directly from the LNC to the ANT-SAT and ANT-SAT2
sockets of the TV set respectively.
When connecting the TV set to a single cable community antenna, con-
nect the ANT-SAT and ANT-SAT2 sockets directly to the appropriate SAT
antenna socket. Ask your dealer if required.
Installing the TV set
Installation options
Your TV set is delivered without installation options. This gives you the
option of choosing the installation solution tailored to your requirements
from your Loewe dealer. Only use Loewe installation solutions (e.g. wall
mounts, floor stand) that are included in the Accessories – Setup pos-
sibilities chapter on page 147.
After selecting an installation option, read the appropriate assembly
instructions.
Installation notes
Choose a place for installing your TV where no bright light or sunlight
shines directly onto the screen. This could cause reflections which impair
the picture.
3 times the screen diagonal can be taken as a guide value or the viewing
distance (e.g. for 32-inch set approx. 2,5m for SD signal). The viewing
distance can be reduced with an HD signal.
Set covers
Covers for rear and side connections
To remove the rear cable cover, pull the two recessed handles at the
bottom and drop down the cover.
To fit the cover, insert the lugs at the top edge of the cover into the corre-
sponding cut-outs in the rear panel and push up the cover until it snaps in.
The side cover of the TV set can also be completely removed. For this,
open it as far as it will go and gently pull on the open cover.
The cover detaches from the holder and gives free access to the con-
nection area. To replace the cover, simply push it until it latches back
into place.
DVB-T DVB-S an. cable /
DVB-C
Initial installation
R TV

19 -
english
Connecting the TV set to the home network
You can connect your TV set to the home network by a wired connection
(Ethernet, Powerline) or if available(1 by a wireless radio connection (WLAN).
Please contact your specialist dealer for more information on Powerline.
For the network adapter configuration, see page 67.
➠ Under no circumstances may the TV set be wired and at the same time
connected by a wireless connection to the same network, e.g. router.
This may cause severe operational faults.
Example for a wired connection
Connect the LAN socket of your TV set to the LAN switch/router of your
home network with a network cable (available from your dealer).
Example for a wireless connection (1
You can connect the TV set to your home network by a wireless radio
connection via the WLAN antenna inside the set.
Initial installation
LAN switch/router
Homeserver,
e.g. PC
TV set
Wi-Fi router
Homeserver,
e.g. PC
TV set
(1 Equipment and upgrade options, see page 146.

- 20
english
Preparing the remote control unit
Inserting or replacing batteries
Press on the embossed arrow whilst pushing the battery cover down.
Only use leak-proof micro-cells of the LR 03 (AAA) Alkali-Manganese type.
Do not use different types of batteries and old and new batteries together.
The batteries used must not be exposed to excessive heat such as sun-
light, fire or similar!
Pay attention to the correct polarity of + and – when inserting the bat-
teries.
If the batteries are too weak after longer use, the TV set prompts you
to change the batteries.
Dispose of used batteries in an environmentally friendly way (see page 148).
Push the cover back on from below after inserting the batteries.
Adjusting the remote control for operating the TV set
Press the TV button.
See page 129 for how to operate other Loewe appli-
ances and how to reprogramme the remote control
buttons.
AAA LR03
AAA LR03
Initial installation
Bundling the Cables
The cables connected to the TV set can be bundled and fixed to the back
of the housing using the Velcro cable tie provided.
Then fit the cover for the connections (see page 18).
