Lofts & Ladders PODIUM User manual

This new unit is another solution to
working at low level.
Using a specially designed telescopic
guardrail frame, the user is able to use
this podium at both 1m & 1.2m platform
levels (3m & 3.2m working Heights)
The step platforms gain easy access to
and from the working platform.
Stabilizers are provided for extra
stability.
This unit has a folding mechanism that
allows it the fold flat, great for
transportation and storage.
DIMENSIONS: Platform: 0.6m x 0.67m
1m & 1.2m platform heights
3m & 3.2m working heights
SWL 250Kgs
The Step Fold Podium
STEP FOLD PODIUM
Manufactured To a TUV Certified ISO 9001:2008 Quality Control System
Anti Surf Option...
This unit is available as a mobile unit
complete with 4 Castors, or with the
option of 2 plates as shown to prevent
“surfing”
Other Extras include:
Kynol Decked Platforms
Toeboard Assembly

STEP FOLD PODIUM
Manufactured To a TUV Certified ISO 9001:2008 Quality Control System
The Step Fold Podium
Assembly Instructions
Ensure all parts are present and are not damaged before
assembling
Kit List
4 x 5” Castors / Base Plates
1 x Podium Base Unit
2 x Stabilizers (left & Right)
2 Horizontal Braces `
1 x Non Slip Ribbed Brace
2 x Step Platforms
1 x Main Platform
Step by step guide
Always work on the podium
with the knuckled gate
facing the work area.
When leaving the podium,
always descend, facing the
knuckled gate.
1. Open the unit
on a firm and
level base.
2. Lock the folding
gate at the back;
ensure that the
knuckle mechanisms
have engaged.
3. Fit the small
platforms on rung
1 & 2 to form the
steps up to the
platform.
4. Fit the working
platform on the 3rd
rung. Lock Castors.
5. Fit stabilizers,
left & right.
6. Ascend to the
platform using the
step platforms as
steps.
7. Once the platform
is accessed, close the
gate behind you;
ensure that the clips
are engaged.
8. To extend the unit.
whilst standing on the
platform, extend the
top frames & Fit 2
horizontal braces.
9. Unclip one side of
the front horizontal
brace and flip it to
the opposing side,
as shown.
10. When descending
from the platform,
use the step
platforms and face
the knuckle frame.
11. Move the
working
platform to
the 4th rung as
shown.
12. Fit the non slip
ribbed brace to the 1st
rung above the step
platform. (Hooks
facing outwards)
13. Access the
platform using
the step
platforms and
non slip ribbed
rung.
14. Once the platform is
accessed, close the gate
& swing the horizontal
brace back onto its
previous position and
begin work.
