LOGICDATA HSD User manual
User Manual
HSD
Availability and specifications are subject to change without prior notice.
LOGICDATA assumes no liability for maloperation or improper use of
products.
LOGICDATA will at point of delivery replace/repair defective products
covered by the warranty.
No liability is assumed beyond such replacement/repair.
Please contact LOGICDATA directly on inquiries or custom requirements.
2007 LOGICDATA
Rev 2 – 08/2007
Seite 2 von 7
Table of Contents
Table of Contents ....................................................................................................... 2
1Installation and Starting up .................................................................................. 3
2Operation............................................................................................................. 4
2.1 Manual mode with Handset.......................................................................... 4
3Automatic mode .................................................................................................. 4
3.1 Memory mode .............................................................................................. 4
3.2 Up/Down mode............................................................................................. 5
4Manufacturer information..................................................................................... 7
Seite 3 von 7
1 Installation and Starting up
Shift the switch “HS/Off/Auto” to “Off”.
Plug-in the automatic handset into the handset socket of the motor control.
The system is operating as soon as the red LED for „Power“ is turned on.
For LOGICDATA CBX-motor controls an external supply (9VDC) has to be
connected.
Plug-in the handset into the 8-pin DIN socket „HS“.
Power-LED
Switch „HS/Off/Auto“
Seite 4 von 7
2 Operation
2.1 Manual mode with Handset
Shift the switch “HS/Off/Auto” to “HS”.
The green LED for “HS” is turned on.
Now all function of the LOGICDATA handsets can be carried out.
3 Automatic mode
The automatic handset has two different automatic modes:
3.1 Memory mode
With this function the desk will drive continously to the memory positions 1, 2, 3 and
4. The desired duty cycle can be set with the two knobs „Drive“ und „Break“.
Drive ....................determines, how long the desk will drive (1 – 60s)
Break ...................determines, how long the desk will wait between driving to
the certain positions (0 – 600s)
Switch „HS/Off/Auto“
Seite 5 von 7
Shift the switch “Mem Up/Down” to “Mem”.
The green LED for “Mem” is turned on.
Shift the switch “HS/Off/Auto” to “Auto”.
The green LED for “Auto” is turned on.
While driving to a memory position, one of the 4 yellow LEDs „M1, M2, M3
und M4“ is turned on. While the desk is waiting, the LED for „Break“ is
flashing.
3.2 Up/Down mode
With this function the desk will continously drive up and down. The desired duty cycle
can be set with the two knobs „Drive“ und „Break“.
Drive ....................determines, how long the desk will drive (1 – 60s)
Break ...................determines, how long the desk will wait between driving to
the certain positions (0 – 600s)
Switch „Mem Up/Down“
Knobs
Switch „HS/Off/Auto“
Seite 6 von 7
Shift the switch “Mem Up/Down” to “Up/Down”.
The green LED for “Up/Down” is turned on.
Shift the switch “HS/Off/Auto” to “Auto”.
The green LED for “Auto” is turned on.
While driving to the upper and lower desk position, the 4 yellow LEDs bs and bs are
turned on. While the desk is waiting, the LED for „Break“ is flashing.
Switch „Mem Up/Down“
Knobs
Switch „HS/Off/Auto“
Seite 7 von 7
Attention
Text
Attention
Text
4 Manufacturer information
LOGICDATA
Electronic & Software Entwicklungs GmbH
Wirtschaftspark 18
A-8530 Deutschlandsberg
Tel.: +43 (0)3462 5198 0
Fax: +43 (0)3462 5198 530
Email: office@logicdata.at
www.logicdata.at
