LogiCO2 MK10 User manual

User’s Manual
MK10
CO2Safety System
Connected to
Central Unit
English

I Safety..................................................................................................................................3
The purpose of CO2 detection
II General Description...................................................................................................... 4-8
Product description, performance and intended use
Temperature surveillance
The function of the Central Unit
The function of the CO2 Sensor
III Installation ....................................................................................................................9-11
IV Connection Diagrams.....................................................................................................12
V Function/Installation check...................................................................................... 13-15
VI Ordering Service and Parts............................................................................................16
Service and maintenance
Ordering parts or service
VII Specifications............................................................................................................ 17-19
Table of contents
Please note that whenever installing or
disconnecting a system, refer to this manual first!

The purpose of CO2 detection
CO2 is a colorless, odorless gas which normally
exists at a concentration of about 0.04% in the air
we breathe. CO2 gas does not support life and in
concentrations above 4% it has dangerous effects
(IDLH). The equipment that stores and uses CO2 is
designed for normal safe operation when properly
maintained. But leaks may cause High concentrations
of CO2 creating unsafe conditions.
The equipment that stores and uses CO2 is designed
for normal safe operation when properly maintained.
Leaks may cause High concentrations of CO2
creating unsafe conditions. CO2 is 1 ½ times heavier
than air. It will concentrate in low areas posing a risk
of asphyxiation/suffocation to anyone in or entering
those areas. The quantity of gas in relation to the size
of a room or space is what defines if an area is to be
considered a confined area.
The CO2 Safety System continuously monitors
CO2. The system is designed to monitor CO2 gas
concentration and to provide an alarm at four pre-set
elevated levels.
CO2 concentration levels (%) and
effects
(%) Effect
20.0 Death within a few seconds.
10.0 Convulsion, Unconsciousness, Death.
7.0 Dizziness, Vomiting, Headache, Reduced
blood supply to brain.
4.0 IDLH -Immediate Danger to Life and Health.
3.0 Normal exhale concentration; increased
breath and pulse rates.
1.0 Shortness of breath possible.
0.5 Maximum for working conditions (TWA 8 hr.
PEL).
0.1-0.2 Recommended max value in public areas.
0.04 Fresh air.
TWA (Time Weighted Average)
In most countries the Hygienic Limit Value over 8
hours/day is 0,5% or 5000 ppm. It is considered
unhealthy to be exposed to more than this value
during an 8-hour working day. In Europe there is EU
Legislation regarding TWA. (Patented measuring
method).
Safety I
IMPORTANT
All persons responsible for the use and maintenance of this equipment must read and understand the
safety and operating information contained in this guide. Installation and service of this equipment
should be performed only by professionals. The function of the equipment will be impaired if it is not
properly installed.
LogiCO2 bears no legal responsibility for the functionality of the CO2 Safety System if installed by a
company that has not been certified by LogiCO2.
3
US Safety Codes and Norms
Notification level CO2 Concentration or
fault indicator Reference regulatory code
1 Awareness Alert 5000 ppm (0.5%) 2015 International fire code
2 Alert 5000 ppm (0.5%) 8-hour
Time Weighted Average National fire protection association 55 and OSHA
3 Pre-Alarm 15000 ppm (1.5%) National board inspection code part 1 supplement 3
4 Full Alarm 30000 ppm (3.0%) National board inspection code part 1 supplement 3 and
short term exposure limit defined by ACGIH and NIOSH

4
II General Description
Product description, performance
and intended use
The Carbon Dioxide (CO2) Safety System is
designed to measure CO2 concentration in a
confined space environment. It is designed to provide
an alarm in the event that a CO2 level exceeds the
preset alarm levels.
The basic Mk 9 CO2 Safety System is a precision
instrument comprising one central unit (with a digital
display), one (up to eight) sensor unit/s, warning
lamp/s and horn/s. A separate power supply (100-240
VAC) supplies power to the system. Please observe
that you have to connect the appropriate plug adaptor
to the power supply depending on which country you
are in. The sensor uses infrared analysis for detecting
CO2. The system provides visible indication of CO2
levels in the area where the sensor is located.
When installed properly, the CO2 Safety System
will continuously monitor the CO2 concentration
where a sensor unit is located. A green light emitting
diode (LED) on the central unit indicates normal safe
conditions. If ambient conditions at the sensor unit
reach a CO2 concentration level of 1.5% (preset
low alarm), the central unit will emit an intermittent
audible tone and the « low alarm » red LED will blink
and a remote warning lamp will be activated. This
will also happen if the TWA for 8 hours also reaches
5000 ppm. The difference can be acknowledged on
the display.
A properly connected system will begin to operate
immediately after a Self-diagnostics program has
been made by the System, when plugged into to a
(100-240V AC) power outlet. No additional start-up
procedure or adjustment is necessary.
In the event of a system fault, the yellow « error »
LED is activated and a beeping tone will be made by
the Central Unit. The error will be described in the
display until the fault has been rectified and cleared/
reset on the central unit.
In case of Alarm, the buzzer in the Central Unit may
be muted by pressing the reset button shortly.
The alarm can only be totally cleared/reset when the
CO2 level drops below 1.5% (the low alarm). At a
Low Alarm, one person, supervised by another, may
check for the leakage cause.
If ambient conditions at the Sensor reach a
concentration level of 3% or more, the Central Unit’s
High Alarm will activate a constant sound signal, the
red LED will light continuously and the digital display
will show ALARM. The room in which the sensor
is located must not be entered when the CO2
concentration is over 3%!
Emergency services must be contacted!
Temperature monitoring
Selectable Temperature Alarm
The Sensor Unit has a temperature alarm function
that can be activated via the DIP-switches on the
Sensor. If activated, the current temperature at the
Sensor will be shown on both the Central Unit and
the Sensor. The temperature alarm is activated if
the temperature at the Sensor is lower or higher
than +1°C to +10°C / +34°F to +50°F. For more
information, see the CO2 Sensor section.
The functions of the Central Unit
The Central Unit is multi-lingual. The measurements
from the sensor(s) and alarm indications are shown
on the display. An information text for all Alarm and
Error conditions is also shown on the display. If
more sensors are connected their values are also
displayed, indicating which sensor the value is from.
On the right side of the display, there is a sound
mute/reset and test button .
The Central Unit also has an alarm memory that
remembers and reactivates any alarm after a power
interruption.
LED (Light Emitting Diode) indications
Red: CO2 concentration Alarm
Yellow: Error
Green: The system is active

5
General Description II
Internal buzzer
The built-in buzzer has two different sounds:
1. Beeping sound indicates Low Alarm (warning) and
Error.
2. Continuous sound indicates High Alarm (danger)
Reset button
A short push on the reset button mutes the internal
buzzer during an alarm situation. Push and hold the
reset button for approximately 4 seconds to clear/
reset an alarm. “Alarm Cleared!” is shown in the
display.
To test all alarm indications (horn/strobe/LED/buzzer),
push and hold the reset button for approx. 10
seconds. “Testing system...” is shown in the display.
Changing the display language
Disconnect the power. Push and hold the Reset
button, connect the power and keep the Reset button
pushed for approximately 5 seconds. The display
shows now: “Language” and blinking “English”,
which is the default language. Push the Reset button
shortly to browse through the different languages. To
select a language, wait approximately 3 seconds, the
display will switch to the standard view. Finished.
Language
English
g
E
E
h
h
Internal layout
2
3
4
1
5
6
7
8 9
ON 1 2 3 4 5 6 7 8
Central Unit Function/Indication
1. DIP-switch Setting number of connected
CO2 Sensors
2. LED yellow Fault
3. LED red Blinking: Low Alarm –
Fixed: High Alarm
4. LED green Power ON
5. Buzzer Alarm
6. Display Measurement and alarm
information
7. Mute/Reset/Test button Mute/Reset/Test button
8. RJ45 input connector Power and communication
9. RJ45 output connector Power and communication
DIP-switch settings
All DIP-switches are set to OFF as default.
Default functions/settings:
- Connection to one CO2 Sensor
The number of connected CO2 Sensors is set on dip-
switch 1-3. Dip-switch 4-8 are not used and must be
in position OFF.
1 2 3 4 5 6 7 8
ON

6
II General Description
Number of
sensors Dip1 Dip2 Dip3 Dip4-8
Not used
1 OFF OFF OFF
2ONOFFOFF
3OFFONOFF
4ONONOFF
5OFFOFFON
6ONOFFON
7 OFF ON ON
8ONONON
Display information during start-up:
Software version Cycle/Start-up
LogiCO2 Central unit
FW:1420* ID CO2 TWA TEMP
1 Heating…
*FW = Firmware version
Normal display information:
One CO2-sensor is attached
ID CO2 TWA*1 TEMP*2
10.04% 400 5°C
*1TWA (Time Weighted Average): Average CO2 exposure over 8
hours.
*2Temperature measurement is only shown when temperature
alarm is enabled on the CO2 sensor.
Display information during CO2 alarm mode:
CO2 Alarm CO2 concentration is
shown in highlighted text
ID CO2 TWA
1 ALARM 440ppm
Information text…*
ID CO2 TWA
1 3,14% 440ppm
Information text…*
* Information text is only shown during alarm or error situations.
Display information at CO2 alarm levels over 6%
CO2:
CO2 concentrations that exceed the CO2 Sensors
measuring range gives the following display
indications, together with continuous red LED and
internal buzzer.
CO2 Alarm CO2 Sensor display
ID CO2 TWA
1 ALARM over 6% CO2
TWA ALARM CO2%
K,
HighAlarm
Display information during TWA Alarm:
CO2 TWA Alarm CO2 TWA concentration
shows in highlighted text
ID CO2 TWA
1 0,14% ALARM
Information text…*
ID CO2 TWA
1 0,14% 5444PPM
Information text…*
* Information text is only shown during alarm or error situations.
Alternating display information during
temperature alarm mode:
Temperature alarm Temperature shows in
highlighted text
ID CO2 TWA TEMP*
10.04% 400 ALARM ID CO2 TWA TEMP* 1 0.04% 400 21°C
* Temperature measurement is only shown when temperature
alarm is enabled on the CO2 sensor.
Display information during Error alarm mode:
CO2 Central display together with blinking yellow
LED and intermittent internal buzzer.
Fault in the CO2 Sensor measuring device
Information text…*
ID CO2 TWA
1 Out of range
* Information text is only shown during alarm or error situations.
Error codes:
Fault message Measures
Out of range CO2-measuring fault. Check CO2-Sensor.
Exchange CO2-Sensor.
Sensor error Internal fault in CO2-Sensor. Check CO2-
Sensor. Exchange CO2-Sensor.
No sensor found Communication error. Check communication
cabling. Check CO2-Sensor. ID number.

7
General Description II
The functions of the CO2 Sensor
The measured values from the MK10 sensor are
displayed on the Central Unit.
0,5%
1,5%
3%
5000ppm
Default Alarm/settings: -
CO2 Awareness Alert -
CO2 Low Alarm
- CO2 High Alarm
- CO2 TWA Alarm
Communication address/ID1 (Can be changed from 1-8)
The CO2 Awareness Indication activates the flash
light of the sensor itself
Low alarm activates the strobe and high alarm
activates the horn.
CO2 TWA alarm is classified as Low Alarm.
CO2 “Awareness Alert” (>5000 ppm CO2) is
activated by default. To deactivate: set switch no. 4
on DIP in ON-position. CO2 “Awareness Alert” is
indicated by one blink every 5 sec.
The CO2 Alert MK10 has 2 red diodes on the side
marked with L1 and L2. When starting the sensor,
both diodes L1 and L2 go ON. This is a self
testing mode, after a few seconds, L2 remains
ON and L1 goes OFF
Alarm Functionnality

8
II General Description
DIP-switch settings
All DIP-switches are set to OFF as default.
Communication adress / ID configuration
Sensor ID is configured using switch 1, 2 and 3 of the
DIP on the sensor board
ID 1
1 : OFF, 2 : OFF, 3 :OFF
ID 2
1 : ON, 2 : OFF, 3 :OFF
ID 3
1 : OFF, 2 : ON, 3 :OFF
ID 4
1 : ON, 2 : ON, 3 :OFF
ID 5
1 : OFF, 2 : OFF, 3 :ON
ID 6
1 : ON, 2 : OFF, 3 :ON
ID 7
1 : OFF, 2 : ON, 3 :ON
ID 8
1 : ON, 2 : ON, 3 :ON
CO2 Awareness Indication configuration
Sensor ID is configured using switch 4 of the DIP on the
sensor board
Switch 4 OFF : CO2 Awareness Indication activated
(default)
Switch 4 on : CO2 Awareness Indication NOT activated
CO2 Awareness
Indication Activated
CO2 Awareness
Indication NOT Activated

9
Installation III
OBSERVE!
“All persons responsible for the operation and
maintenance of this equipment must read and
understand the safety and operating information
contained in this guide. Installation and service
of this equipment should be performed only by
professionals. The function of the equipment will be
impaired if it is not properly installed.”
Disconnection from supply source: When installing
the CO2 Safety System to the power net, please
ensure that the fuse that the system runs on is clearly
marked. This makes it easy to disconnect the power
to the system, if needed.
Plug the power supply into an electrical supply
outlet before carefully taking the components out of
the box, this to insure that it runs correctly before
installation. NOTE: Be aware of the very high
sound from the horn.
Notice that all LEDs on the Central Unit and the
Sensor will illuminate and the built-in buzzers
will beep during start-up, this is part of the Self-
diagnostics program. After approximately 3 seconds
all external horns and/or strobes (connected to
the Sensor) will be activated for approximately 5
seconds.
Determine proper location for
system components
CO2 Sensor
• The CO2 sensor should be placed in the room
where CO2 equipment is being used/distributed
and/or where CO2 is likely to accumulate in the
event of leak. Please observe that this does not
necessarily have to be where the CO2 is stored,
for example when the CO2 is stored outside.
NOTE: CO2 is a heavy gas that will collect in
low areas and in confined spaces.
One sensor unit will monitor an area up to about
5 meters from the place that it is mounted,
therefore it is important/essential to place the
sensors in the correct places.
It is VERY IMPORTANT to be aware that the
danger is always in relationship to how much
CO2 is used (stored) in relationship to the volume
of the room in question.
It does NOT have to be BULK CO2 STORAGE
CONTAINERS to be dangerous!!!
NOTE: If a room only has mechanical
ventilation, it should have a sensor, since the
ventilation can be turned of.
The sensor should be mounted 12” / 30 cm
from the floor to the bottom of the sensor. It
should be installed horizontally on a wall with
the cable outlets pointing downwards, so it
has clear exposure to room air but is mounted
away from ventilation inlets or outlets. Its digital
display should be clearly visible. Try to position
the Sensor where it will be out of the way of
moving objects. Use the supplied screws and wall
anchors.
• A warning Horn/Strobe, must be located where it
is clearly visible at any entrance to the area being
monitored. This may require more than one Horn/
Strobe.
A Horn/Strobe should also be mounted on the
wall above the sensor.
Central Unit
Place the Central Unit horizontally on a wall with the
cable outlets pointing downwards, in a dry location.
It should be placed at a height where it can be easily
seen but where it is least likely to be damaged by
items such as mop handles or boxes being moved.
Use the supplied screws and wall anchors.
• The Central Unit must be placed outside the
area or room being monitored, preferably in the
manager’s office. If the Central Unit is placed in
the manager’s office it is recommendable that a
Horn/Strobe is mounted outside the door to make
the personnel observant that there is an alarm
situation.
NOTE: The Central Unit and Sensor(s) are
connected to each other by cables that may need
to be disconnected for purposes of cable routing
or installing a longer cable. When reconnecting
cables make sure they are properly
reconnected to their proper connectors. Refer
to the connection diagram on page 12 for
assistance.
Try to route all conductor cables in cable conduits for
a neat and safe installation.
• Be sure the reset button can be pushed without
obstructions.

10
III Installation
• Mount the Plug-lock so that the power supply
cannot be disconnected without the use of
mechanical tools.
• Make sure the Central Unit is not placed in the
risk area that is being monitored!
Removal of the cover
If the cover of the Central Unit or Sensor Unit needs
to be removed please observe the following order of
screw reassembling.
1
23
45
Installation suggestion
Route the cables in the cable channels on the back
of the enclosure.
Horn/Strobe
The CO2 Safety System is equipped with a pre-wired
Horn/Strobe. Its power cord has a blue connector
at the end terminal that is connected to the splitter,
marked with a blue dot.
1. Mount the horn/strobe in a proper location above
the CO2 sensor. Refer to the description and
diagram on page 12.
Warning Beacon (Optional US)
The CO2 Safety System is equipped with an optional
prewired warning beacon. Its power cord has a blue
connector at the end terminal that is connected to the
splitter, marked with a blue dot.
1. Separate the beacon from its mounting base
using a counter clockwise twist.
2. Mount the base in a proper location using screws
through the knockouts on the « back » of the
base. Refer to the following description and
diagram on page 12.
3. Attach the beacon to its base using a clockwise
twist.
An additional beacon can be added, if necessary,
at another entrance to the room being monitored.
Simply add a 1-2 splitter and connect the second
unit.
To ensure proper operation, the combined
distance between (farthest) Warning Beacon,
Horn/Strobe, Sensor Unit, and Central Unit,
should not exceed 300 m (980 feet).

11
The warning signs provided with the CO2 Safety System
All signs must be mounted in a secure, permanent way to eliminate any risk that they fall down.
Sign 1: ”CO2 Safety System - What to do” should be placed next to the Central Unit.
Sign 2: ”WARNING” should be placed next to the Horn/Strobe.
Alarm functionality: CO2 Awareness Indication 5000 ppm (0.5%): Local warning on Sensor only.
TWA 5000 ppm: White Horn/Strobe flashes - Call service.
Low Alarm 1.5%: White Horn/Strobe flashes - Call service.
High Alarm 3.0%: White Horn/Strobe sounds - Evacuate area. Call the fire department.
Installation III
HFE1060 EN
CO2 Safety System – MK10
What to do in case of an ALARM?
1. Keep Calm!
2. Turn off the sounding alarm on the Central Unit by pressing the RESET button on the front.
3. Check the type of alarm and which Sensor is giving the alarm by following the instructions below.
INDICATION CAUSE ACTION
Central Unit:
xThe red diode is ON
xConstant sound signal
Display:
xSensor number, alternating
ALARM and CO2 %
HIGH-ALARM
!
TAKE PRECAUTIONS
High concentration of CO2
DO NOT ENTER
the risk zone.
Evacuate the area.
Call the fire department.
Central Unit:
xThe red diode is blinking
xBeeping sound signal
Display:
xSensor number, alternating
ALARM and CO2 %
LOW-ALARM
High concentration of CO2
A service technician should
only enter the room under the
supervision of another person.
Open the doors and the windows
as much as possible.
Central Unit:
xThe red diode is blinking
xBeeping sound signal
Display:
xSensor number, alternating
ALARM and CO2 ppm value
TWA-ALARM
There is a small CO2 leak
that has lasted for over
8 hours
Open the doors and the windows
as much as possible.
Find and stop the leakage, if not
found, call service.
Phone: …………………………….
CO2-Sensor:
xBeeping sound signal every
5 seconds
Display:
xHigh and CO2 %
CO2 AWARENESS
INDICATION Be aware that the CO2
concentration is over 5000 ppm.
There is no danger.
Central Unit:
xThe yellow diode is blinking
xBeeping sound signal
Display:
xSensor number, (Fault
information)
SYSTEM FAULT Check the manual, communication
cables and CO2-Sensor.
If no fault is found, call service.
Phone: ….…………………………
After an alarm, always reset the
system. ALARM RESET Press reset button until "Alarm cleared!" is shown in the display.
Toinsure that communication,
warning lamps and sounders
function.
ALARM TEST Press reset button until "Testing
system…" is shown in the display.
Sensor Place
1
2
3
4
5
6
7
8
WARNING
! !
CO2ALERT
CARBON DIOXIDE GAS
DO NOT ENTER THIS AREA WHEN SIREN
IS SOUNDING AND LIGHT IS FLASHING!
Emergency Actions
(YDFXDWHWKH$UHD,PPHGLDWHO\
&DOOWKH)LUH'HSDUWPHQWIURP
RXWVLGH RIWKHEXLOGQLQJ
Non-Emergency Action
,IOLJKWRQO\LVIODVKLQJ
FDOO&226HUYLFHDW
HFE1061 EN

12
Connection diagram
Please OBSERVE! The hard wire option is not intended for the US market.
OBSERVE!
- The CO2 Alert Mk9 is compatible with the earlier MkVII (Mk7) system.
- The MK9 CO2 Sensor can also be connected to the system.
Important!
The sensor shall be
mounted 12" / 30 cm
from the floor to the
bottom of the sensor.
5 m 10 m 5 m
2 m
2 m
Option
RCB
Connection box for
external signal.
Package incl.
1-4 split.
US Option
FLASH-24-R
1 m 1 m1 m
CO2Alert!
If Light is Flashing,
Call Service at:
CAUTION
!
Open doors to ventilate
Hard wired
Option
Plug mounting
IV Connection Diagrams
HFE1060EN
CO2 Safety System – MK10
What to do in case of an ALARM?
1. Keep Calm!
2. Turn off the sounding alarm on the Central Unit by pressing the RESET button on the front.
3. Check the type of alarm and which Sensor is giving the alarm by following the instructions below.
INDICATION CAUSE ACTION
Central Unit:
xThe red diode is ON
xConstant sound signal
Display:
xSensor number, alternating
ALARM and CO2 %
HIGH-ALARM
!
TAKE PRECAUTIONS
High concentration of CO2
DO NOT ENTER
the risk zone.
Evacuate the area.
Call the fire department.
Central Unit:
xThe red diode is blinking
xBeeping sound signal
Display:
xSensor number, alternating
ALARM and CO2 %
LOW-ALARM
High concentration of CO2
A service technician should
only enter the room under the
supervision of another person.
Open the doors and the windows
as much as possible.
Central Unit:
xThe red diode is blinking
xBeeping sound signal
Display:
xSensor number, alternating
ALARM and CO2 ppm value
TWA-ALARM
There is a small CO2 leak
that has lasted for over
8 hours
Open the doors and the windows
as much as possible.
Find and stop the leakage, if not
found, call service.
Phone: …………………………….
CO2-Sensor:
xBeeping sound signal every
5 seconds
Display:
xHigh and CO2 %
CO2 AWARENESS
INDICATION Be aware that the CO2
concentration is over 5000 ppm.
There is no danger.
Central Unit:
xThe yellow diode is blinking
xBeeping sound signal
Display:
xSensor number, (Fault
information)
SYSTEM FAULT Checkthe manual, communication
cables and CO2-Sensor.
If no fault is found, call service.
Phone: ….…………………………
After an alarm, always reset the
system. ALARM RESET Press reset button until "Alarm cleared!" is shown in the display.
Toinsure that communication,
warning lamps and sounders
function.
ALARM TEST Press reset button until "Testing
system…" is shown in the display.
Sensor Place
1
2
3
4
5
6
7
8
WARNING
! !
CO
2
ALERT
CARBON DIOXIDE GAS
DO NOT ENTER THIS AREA WHEN SIREN
IS SOUNDING AND LIGHT IS FLASHING!
Emergency Actions
(YDFXDWHWKH$UHD,PPHGLDWHO\
&DOOWKH)LUH'HSDUWPHQWIURP
RXWVLGH RIWKHEXLOGQLQJ
Non-Emergency Action
,IOLJKWRQO\LVIODVKLQJ
FDOO&226HUYLFHDW
HFE1061EN

13
Function/Installation check V
Function and installation check for the MK10 CO2 Safety System
Store Name (Store Number)
Address
City
State / Region
Zip Code
Country
Date of inspection
Service Provider’s Company Name
Repair Company Name (if different)
Power supply control
If a plug-in power supply is used, make sure that the Plug-lock is
mounted in a way to eliminate the risk for the power supply to be
un-plugged.
YES NO
Is it a hardwired power-supply (directly connected to the
power network without any plug, OBSERVE not for the
US)?
Is it a plug-in power supply?
If it is a plug-in power supply, is the plug-lock securely
mounted (or any other mechanical system that eliminates
the risk for the power supply to be un-plugged)?
Central Unit
The Central Unit must be mounted at a height and where it is easily
reachable (to control/reset the system and to read the values/messages).
The sign “What to do” must be mounted in a permanent manner (NOT
TAPE) next to the Central Unit so that the personnel can easily read it.
Phone number of the Service Provider responsible if there is a CO2
Leak should be registered on the “what to do sign”.
When the Central Unit is running properly, the green diode (ON) is ON,
and the screen should display the CO2 levels of the CO2 Sensor or
Sensors that are connected.
YES NO
Is the Central Unit mounted in a way that makes it easy to read?
Is the “What to do” sign mounted next to the Central Unit and is it easily readable?
Is the “What to do” sign mounted in a permanent way?
Is the phone number of the Service Provider which is responsible if there is a CO2 leak written on the
“What to do” sign?
Is the green diode ON?
Is the yellow diode (Error) ON?
Is the red diode (Alarm/Alert) ON?
Is any Error Message displayed? if yes, what is it: ……………………..

14
V Function/Installation check
CO2 Values displayed on the Central Unit
When the System is running properly, the CO2 level measured by each sensor is displayed in % (actual value)
and in ppm (Time Weighted Average over 8 hours). The values are displayed sequentially on the second line of
the display. The first character displayed is the Sensor ID, the value is displayed after.
Value in % Value in ppm
Sensor 1
Sensor 2
Sensor 3
Sensor 4
Sensor 5
Sensor 6
Sensor 7
Sensor 8
CO2 Sensor check
Each Sensor should be mounted not higher than 30cm/12 inches from
the floor in the lowest part of the room. The Sensor should be mounted
within 5 m from the potential CO2 Leak Source. The Warning Lamp
should be mounted so that it can easily be seen by the restaurant
personnel without entering the zone at risk. If there is a door leading to
a lower area, for example, a basement, then a sensor is also needed in
this area, to insure CO2 Safety in that area. Under normal conditions the
CO2 value displayed, should read between 0.03% and 0.2%.
Sensor 1
Sensor serial number (normally written on a sticker on the side of the
Sensor housing ).
CO2 Value on Sensor %
CO2 TWA on Sensor ppm
YES NO
Is the green diode ON
Is the yellow diode ON
Is the red diode ON
Is the Horn/Strobe or Warning Lamp mounted at a height of 2.1-2.5 m/6.9-8.2 ft so that the staff can see it
without any obstructions in the way?
Is there a CO2 Warning Sign mounted next to the Horn/Strobe or Warning Lamp, with a telephone number to
the service provider?
Is the CO2 Warning Sign next to the Horn/Strobe or Warning Lamp mounted in a permanent way?
Is a Horn/Strobe installed above the Sensor at a height of 2.1-2.5 m/6.9-8.2 ft?
Is there a CO2 Warning Sign mounted next to the Horn/Strobe?
Is this CO2 Warning Sign, next to the Horn/Strobe, mounted in a permanent way?

15
Function/Installation check V
Horn/Strobe with sign Warning Lamp with sign
Sensor 2
Sensor serial number (normally written on a sticker on the side of the
Sensor housing ).
CO2 Value on Sensor %
CO2 TWA on Sensor ppm
YES NO
Is the green diode ON
Is the yellow diode ON
Is the red diode ON
Is the Horn/Strobe or Warning Lamp mounted at a height of 2.1-2.5 m/6.9-8.2 ft so that the staff can see it
without any obstructions in the way?
Is there a CO2 Warning Sign mounted next to the Horn/Strobe or Warning Lamp, with a telephone number to
the service provider?
Is the CO2 Warning Sign next to the Horn/Strobe or Warning Lamp mounted in a permanent way?
Is a Horn/Strobe installed above the Sensor at a height of 2.1-2.5 m/6.9-8.2 ft?
Is there a CO2 Warning Sign mounted next to the Horn/Strobe?
Is this CO2 Warning Sign, next to the Horn/Strobe, mounted in a permanent way?

16
Service and maintenance
1. Should be performed only by authorized professional service agents who are familiar with the CO2 Safety
System and all pertinent safety and service procedures. Contact your representative for the name of the
authorized service agent(s) in your area.
2. Since this is a Safety Product we recommend that a function check be performed on the CO2 Safety System
by a qualified professional service agent at least once every year.
3. The CO2 Safety System has no user serviceable parts. All service work should be performed by an authorized
professional agent.
4. NOTE: Any attempt to service the equipment by unauthorized persons or to perform unauthorized
modifications will void the warranty.
5. The Sensor and Central Unit housing must NEVER be opened by unauthorized personnel.
6. Cleaning is done by use of water on a moistened cloth.
Ordering parts or service
Description Itemcode
CO2MK10 Detector SET 4 A 2049
CO2 MK10 Detector SET 4 A consists of:
CO2 Central Unit MK10
Cable red 5m
CO2 Sensor MK10
Cable red 10m
Cable blue 5m
Horn/Strobe LED with 1mcable
RJ45 1-1 split
RJ45 1-2 split
Transformer 1A
Plug-UL for transformer
Plug-CE for transformer
Plug-AU for transformer
Plug-UK for transformer
Plug-lock
Bag with 6 screws and plug Sign
CO2 Safety System MK10 Sign
Horn/strobe Mk9/10 Installation
manual MK10 Quick-guide MK10
One stainless steel protection bar
For parts or service contact your local authorized supplier or equipment service agent.
VI Ordering Service and Parts

17
Environmental conditions for system
a) For indoor use.
b) Calibrated for altitude up to 2 000 m.
c) Ambient temperature 0 °C to +40 °C.
d) Maximum relative humidity 95 % (non condensing).
e) MAINS supply voltage fluctuations up to ±10 % of the nominal voltage.
f) TRANSIENT OVERVOLTAGES up to the levels of OVERVOLTAGE CATEGORY II.
NOTE 1 These levels of transient overvoltage are typical for equipment supplied from the building wiring.
g) Pollution degree 2.
Ingress protection
CO2 Sensor IP54 (TÜV) IP44 (UL)
CO2 Central Unit IP54 (TÜV) IP44 (UL)
Warning lamp IP54 (CE)
Horn/Strobe IPX0
Symbol explanations
Please note that whenever installing or disconnecting a system, refer to this manual first!
Double insulation protected equipment may also be called “Class 2”.
Symbol for the marking of electrical and electronic equipment.
(The symbol indicating separate collection for electrical and electronic equipment).
Specifications VII

18
VII Specifications
CO2 SENSOR
Power supply: 24V DC
Power consumption: No alarm status: 56 mA
Alarm status: 68 mA (external optional warning lamp not included)
Wiring connections: RJ 45
Digital interface: RS485 serial port – MODBUS
Display: LCD
Acoustic signal-strength: 76 dBa (1m) max.
Approval: Manufactured in accordance with DIN 6653-2.
The CO2 Safety System is tested by the German TÜV-Rheinland.
EN 50081-1 / EN 50082-2 /CE.
Certified by UL.
Operating principle: Non-dispersive infrared (NDIR) and thermistor
Temperature range: 0 to +40°C (+32°F to +102°F)
CO2 measuring range: 0-3 Vol.%
Extended CO2 range: 3-6,7 Vol.%
Gas sampling mode: Diffusion
TWA: Time Weighted Average (TWA) calculation 8 h time span (most recent)
with 2 min sample period. (Pat. Pend.)
Accuracy
Temperature: ±1°C (±1.8°F)
Resolution: 1°C (1.8°F)
CO2: ±5% of measured value up to 3% CO2. @ ambient temperature 15-30°C
The Accuracy is for altitudes under 2000 meters
Resolution: 0.01 Vol.%
Annual zero point drift: <0.01 Vol.% with automatic self calibration feature
Ambient temperature: 0-40°C (+32°F...102°F)
General performance
Compliance with: 2004/108/EG Sensor Life expectancy: > 15 years
Operating humidity range: 0 to 95% RH (non condensing)
Warm-up time (@ 22°C): 1 min.
Dimensions (LxWxD): 90 x 161 x 38 mm / 3.5” x 6.3” x 1.5”
Ingress protection: IP54 according to TÜV, IP44 according to UL
Overvoltage: Category II
Pollution degree: II
Please observe that since this is a safety product we recommend that a function control should be carried out
at least once a year.

19
CO2 CENTRAL UNIT
Supply: 24V DC
Current consumption: No alarm status: 21 mA
Alarm status: 32 mA
Communication: RS485, Modbus
Display: Graphical 128x64, backlit
Acoustic signal-strength: 80 dBa (1m) max.
Ambient temperature: 0 to +40°C (+32°F to +102°F)
Humidity: 0-90% non-condensing
Approval: CE: Emission tests according SS-EN 61000-6-3 and the immunity
tests according to SS-EN 61000-6-2.
Manufactured in accordance with DIN 6653-2.
The CO2 Safety System is tested by the German TÜV-Rheinland.
Certified by UL.
Dimensions (LxWxD): 90 x 161 x 38 mm / 3.5” x 6.3” x 1.5”
Ingress protection: IP54 according to TÜV, IP44 according to UL
WARNING LAMP (BEACON)
Nominal voltage: 10-26V DC
Average current: 100-130 mA @ 24V DC supply
Flash frequency: 150-180/min
Ambient temperature: -10°C to +60°C (+14°F to +140°F)
Dimensions: Ø 91 x Height 96 mm / Ø 3.6” x Height Ø 3.8”
Ingress protection: IP54
HORN/STROBE CE
Nominal voltage: 18-24V DC
Average current: 120 mA @ 24V DC supply
Decibel: 110 dB / 1 m
Flash intensity: 115 CD
Flash frequency: 65/min
Ambient temperature: -5°C to +50°C (+23°F to +122°F)
Dimensions (LxWxD): 134 x 115 x 61 mm / 5.3” x 4.5” x 2.4”
Ingress protection: IPX0
PLUG-IN POWER SUPPLY
Type: Model FJ-SW2401000N
Input voltage: 100-240V AC, 50/60 Hz, max 0.5 A. Output: 24V DC, max 1.0 A
Ambient temperature: 0-40°C (+32°F to +102°F)
Dimensions (LxWxD): 82.4 x 44.5 x 36.2 mm / 3.2” x 1.8” x 1.4” + input plug
Specifications VII

©2014-11-25 Rev. 2.2, LogiCO2 International
HFE1052 EN
Contact information
Sales and service contact:
For parts or service contact your local authorized supplier or equipment service agent.
Company:........................................................................................................................
Phone:.............................................................................................................................
Place company stamp or sticker here
Manufactured by:
LogiCO2 International AB
Box 4113
SE-426 04 Västra Frölunda, Sweden
E-mail: [email protected]
Web: www.logico2.com
