Logik LS474W User manual

LS474W/LS474WN
GB

This manual contains sections of Safety
Instructions,Operating Instructions,
Installation Instructions and Troubleshooting
Tips etc. Carefully reading it before using the
dishwasher will help you to use and maintain
the dishwasher properly.
To review the section on Troubleshooting Tips
will help you to solve some common problems
by yourself and not need to ask for the help of
professional technicians.
ControlPanel........................2
DishwasherFeatures................. 2
WashCycleTable.................... 3
TurningOntheAppliance..............3
WaterSoftener...................... 4
Detergent...........................5
RinseAid......................... 5,6
Loading the Dishwasher Rack . . . . . . . .6~8
FilteringSystem..................... 9
CaringfortheDishwasher.............10
Beforecallingforservice..........21,22
........................ 22Fault codes
..................1
The manufacturer, following a policy of constant
development and up-dating of the product, may
make modifications without giving prior notice.
This product has been wet tested to ensure
correct operation. As a result some water
can remain inside the unit. This is normal
and safe. Please remove any water droplets
from the exterior if necessary.
Thank You!

This appliance must be grounded. In the event
of a malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a
path of least resistance of electric current. This
appliance is equipped with a cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate
outlet that is installed and grounded in accordance
with all local codes and ordinances.
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service representative if you
are in doubt whether the appliance is
properly grounded. Do not modify the plug
provided with the appliance; If it is not fit
for the outlet. Have a proper outlet installed
by a qualified electrician.

Under certain conditions, Hydrogen gas may be produced in a hot-water system that has not been
used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.
If the hot-water system has not been used for such a period, before using the dishwasher turn on all
hot-water faucets and let the water flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this
time.
1

Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren

Do not abuse, sit on, or stand on the door or dish
rack of the dishwasher.

Do not touch the heating element during or
immediately after use.

Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic
items not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives designed
for an automatic dishwasher. Never use soap,
laundry detergent, or hand washing detergent
in your dishwasher. Keep these products out of
the reach of children.


During installation, the power supply must not
be excessively or dangerously bent or flattened.
The door should not be left in the open position
since this could present a tripping hazards.


Do not tamper with controls.


Do not place any heavy objects of stand on the door
when it is open. The appliance could tip forward.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal;
2) Load sharp knives with the handles up to reduce
the risk of cut-type injuries.
3 Warning:Knives and other utensils with sharp points
must be loaded in the basket with their points down
or placed in a horizontal position.
)

When using your dishwasher, you should prevent
plastic item from contacting with heating element.

If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a
similarly qualified person in order to avoid a
hazard.

Please dispose of packing materials properly.


Use the dishwasher only for its intended function.

Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
The appliance is not intended for use by young
children or infirm persons without supervision.
Dishwasher detergents are strongly alkaline,they
can be extremely dangerous if swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Young children should be supervised to ensure that
they do not play with the appliance.
Check that the detergent receptable is empty after
completion of the wash cycle.




Other means for disconnection from the supply must
be incorprated in the fixed wiring with at least 3mm
contact separation in all poles.

The appliance is to be connected to the water mains
using new hose sets and that old hose-sets should
not be reused.

The maximum number of place settings to be washed
is 8.

The maximum permissible inlet water pressure is 1Mpa.

The minimum permissible inlet water pressure is 0.04Mpa.

Do not operate your dishwasher unless all
enclosure panels are properly inplace. Open
thedoorverycarefullyifthedishwasheris
operating, there is a risk of water squirting out.

To get the best performance from your dishwasher,read all operating instructions before using it for the
first time.
Strong Normal Eco Rinse GlassAuto RapidDelay
On
Off
11 12
Back View
Front view
1
2
3
4
5
6
7
8
9
10
2
1234
Upper Basket
Spray Arms
Lower Basket
Water Softener
Detergent Dispenser
Silverware Basket
Main Filter
Cup Shelf
5
6
7
8
Rinse Aid Dispenser
Coarse Filter
Drain pipe connector
Inlet pipe connector
9
10
12
11
3
2
14
1
2
3
4
ON/OFF Button: To turn on/off the power supply.
Program button : To select washing program
when press the button.
Delayed Start Button: Press this button to set the
delayed hours for washing. You can delay the start
of washing up to 24 hours. One press on this
button delays the start of washing by one hour.
Display Window: Program remaining time, delay time,
fault codes and etc.
Salt Warning Light : To come on when the softener
needs to be refilled.
Rinse Aid Warning Light : To come on when the
rinse aid dispenser needs to be refilled.

For normally soiled loads,
such as pots, plates,glasses
and lightly soiled pans.
standard daily cycle.
For lightly soiled loads,such
as plates,glasses,bowls and
lightly soiled pans.
For the heaviest soiled loads,
such as pots,pans,casserole
dishes and dishes that have
been sitting with dried food
on them for a while.
A shorter wash for lightly
soiled loads that do not
need drying.
For dishes that need to be
rinsed and dried only.
Normal
Eco
Strong
Rapid
Rinse
For lightly soiled loads, such
as glasses, crystal and fine
china.
For all soiled loads, such as
pots,pans,casserole dishes
and dishes that have been
sitting with driedfood on them
for a while.
150
105
175
30
90
110
Pre-wash 40
Autowash 50-60
Rinse
Rinse 70
Drying.
（℃）
（℃）
（℃）
Pre-wash（50 ）
-wash
Wash (60 ℃)
Rinse
Rinse (70 ℃)
Drying
℃
Pre
Rinse
Pre-wash
Pre-wash
Wash (50 ℃)
Rinse (65 ℃)
Drying
Pre-wash
Wash (45 ℃)
Rinse (60 ℃)
Drying
Wash(45 )
℃
Rinse (70 ℃)
Drying
Pre-wash
Wash (40 ℃)
Rinse (70 ℃)
Drying
Wash (40 ℃)
Rinse (45 ℃)
4/20g
4/20 g.
4/20 g.
20 g.
15 g.
15 g.
0.8~1.2
1.35
0.74
0.65
0.75
0.75
0.40
9~12
17.5
10.4
10.4
7.7
10.4
6.7
3
/
/
3
4
5
6
7
8
1
Draw out the lower and upper basket, load the dishes and
push them back. It is commended that loading the lower
basket first, then the upper one (see the section entitled
" Loading the Dishwasher " ).
Press the ON/OFF button
Turn the knob located on the right of the control panel in
the clockwise direction until the number or the symbol
for the cycle
Press the button to start the washing.
Start/Reset
When the washing is over, you can shut off the swtich by
pressing on/off button.
With a little force to ensure the door is properly closed.
NOTE: A click could be heard when the door is closed
perfectly.
2
Pour in the detergent(see the section entitled,
" Salt, Detergent and Rinse Aid " ).
Insert the plug into the socket.
The power supply is 220-240VAC 50HZ, the specification
of the socket is 12A 250 VAC, Make sure that the water
supply is turned on to full pressure.
Premise : A cycle that is underway can only be modified if it
has only been running for a short time. Otherwise, the detergent
may have already been released, and the appliance may have
already drained the wash water. I this case, the detergent
dispenser must be refilled (see the paragraph entitled " Loading
the Detergent " ).
n
*AUTOWashCycle
If select program AUTO, the dishwasher will automatically evaluate the turbidity of the dishes, then optimizing water temperature and running time to
getyourdishescleanasquicklyaspossible.
Note: Running time will vary to the display due to the automatic system.
1.
2
3
Press current program button more than 3
seconds to cancel the program, then you can
change the program to the desired cycle setting
(seethesectionentitled"Startingawashcycle...").
.Press the Program Button to select a desired
Wash cycle, After 3 seconds, the machine will work.
.Press the delay button more than 3 seconds to
re-edit delay time.
NOTE: If you open the door when washing, the machine
will pause. The program light will stop blinking and the
buzzer will moo every minute unless you close the door.
After you close the door, the machine will keep on working
after 10 seconds.
The Display window shows the state of the dishwasher:
a) Display window shows "--:--" --> stand by;
b) Display window shows "H:MM" and not blinking --> pause;
c) Display window shows "H:MM" and blinking --> run.
If display window shows fault codes (see the section entitled Fault codes ), that indicates the machine is out of order, please turn
off the main power and water supply before calling a service.
""

4
Always use salt intended for use with dishwashers.
The salt container is located beneath the lower rack and should be filled as follows:
Unscrew the cap from the salt container.
There is a ring on the container with an arrow on it (see Figure to the side), if
necessary, rotate the ring in the anticlockwise direction from the "-" Setting
toward the "+" sign, based on the hardness of the water being used.It is
recommended that adjustments should be made in accordance with the following
schema:
1
2
1.
2.
The salt container must be refilled when the salt warning light comes on. Though the salt container is filled
enough, the indicator light may not black out before the salt fully dissolve.
If there are spills of the salt, a soak program could be run to wipe them out.
The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes
and utensils.
The appliances is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the
water.
The dishwasher is designed to allow for adjusting the amount of salt consumed based on the hardness of the water used.
This is intended to optimize and customize the level of salt consumption so that the salt consumption could be set proceed as
follows:
There are two ways to reduce the hardness: one way is using water softener, the other is using
detergent.
water
Remove the lower basket and then unscrew and remove the cap from the salt
container.
If you are filling the container for the first time ,fill 2/3of its volume with water
(around 500ml).
Place the end of the funnel(supplied) into the hole and introduce about 1.2kg of
salt .It is normal for a small amount of water to come out of the salt container
Carefully screw the cap back on.
1
2
4
3
Usually, the salt warning light will be off in 2-6 days after the salt container be
filled with salt.
5
dH mmol/l
0~140~8 0~1.4 /0/
14~398~22 1.4~3.9 -20 60
39~8022~45 3.9~8 Mid 40 30
>80>45 >8 +60 20
fH
0~10
10~28
28~56
>56
Clark
°Clark: British degree
°fH : French degree
°dH : German degree
Note:1 °dH=1.25 °Clark=1.78 °fH=0.178mmol/l
WATER HARDNESS
Selector Position Salt consumption
(gram/cycle)
Auto nomy
(cycles/1.2kgs)
NOTE: After you open the door during washing, the unit will
pause for a few seconds before its restarting. This is normal.

5
Dishwasher detergent is corrosive! Take care to keep it out
of reach of children.
IF THE WATER ISN'T TOO HARD, YOU MAY ALSO PREVENT THE FORMATION OF DEPOSITS BY ADDING DETERGENT.
The amount of detergent needed can vary due to differences in water hardness. To determine the water hardness in your area,
contact your local water utility or area water softening company. The harder the water, the more detergent you may need.
Remember, you should adjust the amount of detergent you use by small amounts until you find the correct amount.
To remove hard water spots, try the following:
Run dishes through a normal wash program.
Remove all metal dishware, such as cutlery, pans, etc.,
from the dishwasher.
Do not add detergent.
Pour two cups of vinegar into a bowl and set the bowl face
up on the lower rack of the dishwasher.
Run the dishes through a normal wash program.
If this doesn't work, try the same process with 1 / 4 cup of
citric acid crystals instead of vinegar.
Use only detergent specifically made for use in dishwashers.
Keep your detergent fresh and dry. Don't put powder detergent
into the dispenser until you're ready to wash dishes.
The dispenser must be refilled before the start of each wash cycle following the instructions provided in the" Wash Cycle
Table". Your dishwashers than conventional dishwashers. Generally, only one tablespoon of
detergent is needed for a normal wash load. Also, more heavily soiled items need more detergent. Always add the detergent just
before starting dishwasher, otherwise it could get damp and will not dissolve properly.
use less detergent and rinse aid
To open the dispenser, turn the cap to the "open" (left)
arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to
overfill.
Replace the cap by inserting it aligned with "open" arrow
and turning it to the closed (right) arrow.
A measured amount of rinse aid is released during the final rinse. As with detergent, the amount
of rinse aid needed for your dishes depends on the hardness of the water in your area. Too much
rinse aid can result in lather of foaming and cause cloudiness or steaks on your dishes. If the
water in your area is very soft, you may not need rinse aid. If you do,you can dilute the rinse aid
with an equal amount of water.
The rinse aid dispenser has six settings. Always start with the dispenser set on " 2 ". If spots and
poor drying are problems, increase the amount of rinse aid dispensed by removing the dispenser
lid and rotating the dial to "3". If the dishes still are not drying properly or are spotted, adjust the
dial to the next higher number until your dishes are spot-free. We suggest you to set on "4" .
(Factory value is "4".)
The rinse aid is released during the final rinse to prevent water
from forming droplets on your dishes that can leave spots and
streaks. It also improves drying by allowing water to "sheet" off
the dishes.
Your dishwashers are designed to use liquid rinse aids. The
rinse aid dispenser is located inside the door next to the
detergent dispenser. To fill the dispenser, open the cap and
pour the rinse aid into the dispenser until the level indicator
turns completely black. The volume of the rinse aid container is
about 140ml.
Be careful not to overfill the dispenser, because this could
cause oversudsing. Wipe away any spills with a damp cloth.
Don't forget to replace the cap before you close the dishwasher
door.
If you have soft water, you may not need rinse aid for it may
cause a white film to develop on your dishes.

6
If there is no rinse aid warning light in the control panel, you can judge the amount of rinse aid by the following means. The
black dot on the rinse aid dispenser indicates the amount of rinse aid in the dispenser. As the rinse aid diminishes, the size of
the black dot decreases. You should never let the rinse aid get below 1 / 4 full.
As the rinse aid diminishes, the size of the black dot on the rinse
aid level indicator changes, as illustrated below.
Full
3/4full
1/2full
1 / 4 full - Should refill to eliminate spotting
Empty
The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cup and saucers, as well
as plates, small bowls and shallow pans(as long as they are not too dirty).
Position the dishes and cookware so that they do not get moved
by the spray of water.
The upper rack can be adjusted for height by putting wheels of
different height into the rails.
For the below placement method of Rack, the adjustment position
of Upper Rack must be as below shown on the illustration.
Scrape off any large amounts of left-over food. It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way
1.Items such as cups, glasses, pots/pans, etc. are stood upside down.
2.Curve items, or those with recesses, should be at a slant so that water can run off.
3.They are stacked securely and cannot tip over.
4.Theydo not prevent thespray arms from rotating while washing takes place.
Very small items should not be washed in the dishwasher as they could easily fall out of the racks
Removing the dishes
To prevent water dripping from the upper back onto the dishes in the lower back, we recommend that you empty the lower basket first
and then the upper back.
1
Cups
2
Small serving bowl
3
Large serving bowl
4 Glasses
Saucers
5
6
Dish
12
3
4
6
5

7
If required, the height of the upper rack can be adjusted in order to creat more space for large utensils either in the upper rack
or lower rack.
Lengthy items, serving cutlery, salad servers or knives should be placed on the shelf so that they do not obstruct the rotation of
the spray arms. The shelf can be folded back or removed when not required for use.
The upper rack can be adjusted for height by putting wheels of different height into the rails.
We recommend that you place large items which are most difficult to clean into the lower rack: pots, pans, lids,
serving dishes and bowls, as shown in the figure to the right.
It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the
top spray arm.
Pots, serving bowls, etc, must always be placed top down.
Deep pots should be slanted to allow water to flow out.
The bottom rack feature fold down tine rows so that larger or more pots and pans can be loaded.
To improve stacking of pots and pans, the spikes can be folded down.
1
Oval platter
3
Soup plates
Dessert dishes
4
2
Dinner plates
5
Silverware basket
2
3
4
1
5
4

8
Wooden cutlery and utensils-these will leach out and become unsightly.
Sensitive ornamental glasses, craft utensil and vases,special antique or irretrievable utensils.These ornaments are not
dishwasher-proof.
Plastic parts sensitive to hot water.
Copper and tin utensils.
Utensils which are soiled with ash,wax,lubricating grease or ink.
Absorbent materials such as sponges and cloths.
Aluninium and silver parts have a tendency to discolour and fade during the wash cycle. Even some types of glass may turn
cloudy after many wash cycles.
In future buy utensils which identified as dishwasher-proof.
Possible causes:
Type of glass or manufacturing process.
Chemical composition of detergent.
Water temperature and duration of dishwasher programme.
Suggested remedy:
Use glassware or porcelain dishes that have been marked "dishwasher-proof" by the manufacturer .
Use a mild detergent that is described as "kind to dishes". If necessary, seek further information from degergent manufacturers.
Select a programme with as low a temperature.
To prevent damage, take glass and cutlery out of the dishwasher as soon as possible after the programme has ended.
Silverware should be placed in the silverware basket with handles at the bottom: If the rack has side baskets, the spoon should
be loaded individually into the appropriate slots, especially long utensils should be placed in the horizontal position at the
front of the upper rack.
Do not let any item extend through bottom.
Teaspoons
4
Soup spoons
2
Forks
1
Serving fork
8
Serving spoon
6
Knife
5
3
Dessert spoons
7
Gravy ladle
1
1
1
1
1
4
7
8
1
1
1
6
2
2
2
2
2
2
2
2
5
5
5
5
5
5
5
5
3
3
3
6
4
4
4
4
4
4
4
3
3
3
3
3

9
The filter prevent larger remnants of food or other objects from getting inside the pump. This residue can
occasionally clog up the filters.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Main filter
Food and soil particles trapped by this filter are pulverized by a
special jet on the lower spray arm and washed down the
drain.
Coarse filter
Larger items, such as pieces of bone or glass, that could clog
the drain are trapped in the coarse filter. To remove an item
caught in this filter, gently squeeze the taps on the top of this
filter and lift it out.
Fine filter
This filter holds soil and food residue in the sump area and
prevents it from being redeposit on the dishes during a cycle.
- Inspect the filters for obstructions every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the
filters under running water.
1
2
3
2
3
1
2
3
Step１：Unscrew the C ,
and then gently lift it up
oarse filter
Step２：Gently lift the Main filter up
Step 3： Gently lift the Fine filter up
NOTE：
1
To install the filter system back, please do the following:
1. Gently insert the Fine filter back to the Filtering System.
2. Gently insert the Main Filter back to the Filtering System.
3. Gently insert the Coarse Filter back to the Filtering System, and screw back the Filter Cylinder securely.

10
Never run the dishwasher without the filters in place.
If your dishwasher is left in an unheated place during the winter, ask a service technician to:
Cut off electrical power to the dishwasher.
Turn off the water supply and disconnect the water
inlet pipe from the water valve.
Drain water from the inlet and water valve.pipe
(Useapantocatchthewater.)
Reconnect the water inlet to the
water valve.
pipe
Remove the filter in the tub the bottom
and use a sponge to soak up water
in sump.
5
4
3
2
1
It is necessary to clean the spray arms regularly for hard water chemicals will clog the
spray arm jets and bearings. To remove the spray arm, screw off the nut to takeoutthe
washer on top of the spray arm and remove the arm. Wash the arms in soapy and warm
water and use a soft brush to clean the jets. Replace them after rinsing them thoroughly.
Filter assembly
For best performance and results, the filter assembly must be cleaned.The filter efficiently removes food particles from the wash
water, allowing it to berecirculated during the cycle. For this reason, it is a good idea to remove the larger food particles trapped in
the filter after each wash cycle by rinsing the semicircular filter and cup under running water. To remove the filter assembly, pull
on the cuphandle in the upward direction. The entire filter assembly should be cleaned once a week.
To clean the coarse filter and the fine filter, use a cleaning brush. Then, reassemblethe filter parts as shown in the figures left and
reinsert the entire assembly in the dishwasher, positioning in its seat andpressingdownward.
The dishwasher must never be used without the filters. Improper replacement of the filter may reduce the performance level of the
appliance and damage dishes and utensils.
When cleaning the filters, don't knock on them. Otherwise, the filters could be contorted and the performance of dishwasher
could be debased.

11
Never use a spray cleaner to clean the door panel for it could damage the door lock and electrical components. It is not allowed
to use the abrasive agent or some paper towel becauseof the risk of scratching or leaving spots on the stainless steel surface.
To clean the edge around the door, you should use only a soft warm, damp rag. Toprevent
penetration of water into the door lock and electrical components, do not use a spray cleaner
of any kind.
Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will
scratch the finish. Some papers towels can also scratch or leave marks on thesurface.
After every wash, turn off the water supply to the
appliance and leave the door slightly ajar so that
moisture and odors are not trapped inside.
Before cleaning or performing maintenance, always
remove the plug from the socket. Do not run risks.
To clean the exterior and rubber parts of the dishwasher,
do not use solvents or abrasive cleaning products.
Rather, use only a cloth and warm soapy water.
To remove spotsor stains fromthe surface of the
interior, use a cloth dampened with water and a little
white vinegar, or a cleaning product made specifically
for dishwashers.
When you go on holiday, it is recommened that you run a
wash cycle with the dishwasher empty and then remove
the plug from the socket, turn off the water supply and
leave the door of the appliance slightly ajar. This will help
the seals last longer and prevent odors from forming
within the appliance.
If the appliance must be moved, try to keep it in the vertical
position.If absolutely necessary, it can be positioned on
its back.
One of the factors that cause odors to form in the
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Please see the rating lable to know the rating voltage and connect the dishwasher to appropriate power supply,Use required fuse
12 amp. Fused electrical supply is required-copper wire only. Time delay fuse or circuit breaker recommended and provide
separate circuit serving only this appliance. Outlet should be placed in adjacent cabinet.
After making sure that the voltage and the frequency values for the current in the home
correspond to those on the rating plate and that the electrical system is sized for the
maximum voltage on the rating plate, insert the plug into an electrical socket which is
earthed properly. If the electrical socket to which the appliance must be connected is not
appropriate for the , replace the socket,rather than using a adaptors or thelikeas
they could cause overheating and burns.
plug

Remove the power cord plug from the wall receptacle.
Disconnect Unicouple from faucet adapter.
2
1
A hose that attaches to a sink spray can burst if it is installed on the same water line as the dishwasher. If your sink has one, it is
recommended thet the hose be disconnected and the hole plugged.
Pull The safety supply hoses completely out from storage compartment located at rear of dishwasher.
Turn water fully on before starting the dishwasher.
1
Tighter the screws of the safety supply hose to the faucet with thread 3/4 inch.
The safety supply hose consists of the double walls. The hose's system guarantees its intervention by blocking the flow of water
in case of the supply hose breaking and when the air space between the supply hose itself and the outer corrugated hose is full
of water.
Turn off the water.
Release the water pressure by depressing the pressure release button. This relieves water pressure and protects you, and the
room, from severe splashing.
Unscrew The safety supply hose from the faucet..
3
2
1
2
3
The appliance must be connected to the water mains using new hose-sets.
The old hose-sets should not be reused.
Water pressure must be between 0.04 MPa and 1 MPa. If the pressure is below theminimum
consult our Service Department for advice.
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place.
If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the
water is clear and free of impurities. If this precaution is not taken, there is a risk that the water inlet can get blocked and
damage the appliance.
The water supply to the appliance can also be connected to the house hot water line (centralized system, heating system),
as long as it does not exceed a temperature of 60℃. In this case, the wash cycle time will be shortened by about 15 minutes
and the wash efficiency slightly reduced.
The connection must be made to the hot water line following the same procedures as those for the connection to the
cold water line.
If the appliance stops operating, please check the water connection.The device connected at the water inlet is designed to
stop water flow in the event of a fault with the pipe.Please check the small window. If it is red then the pipe must be replaced.
If it is clear then please follow the trouble shooting guidelines within this manual.
NOTE：
12

13
Dimension: 450x580x850(mm)
Capacity: 8 Place setting
ater pressure: 0.04-1.0MPa
Power supply: 1930W
W
Rated voltage: 230V/50Hz
Once the appliance is positioned,adjust the feet (screwing them in or out) to adjust the
height of the dishwasher, making it level. In any cases , the appliance should not be inclined
more than 2 .
Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent
cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to the right or the left to
facilitate proper installation.
DIMENSIONS(mm) 450 580
850
1135
If the sink is 1000mm or higher from the floor, the excess water in hoses cannot
be drained directly into the sink. It will be necessary to drain excess
water from hoses into a bowl or suitable container that is held outside and lower
than the sink.
Insert the drain hose into a drain pipe with a minimum diameter of 40 mm, or let it run into the sink, making sure to avoid bending
or crimping it. Use the special plastic support that comes with the appliance. The free end of the hose must be at a height
between 400 and 1000mm and must not be immersed in water.
φ40mm

14
Carefully read this manual before installation
Reading this manual will help to understand the connections of inlet, drain hoses and
power cord, and to find a optimal position for the dishwasher.
This product is exclusively available though Dixons stores group.In the unlikelyevertofa
problem with your product please return to the store where your purchase was made.
Notes
●
The installation of the pipes
and electrical equipment
should be made by a qualified
person.
Electrical Shock Hazard
Disconnect electrical power before
carrying out any re-wiring.
Failuretodosocanresultindeathor
electrical shock.
The installation position of the dishwasher should be near the existing inlet ,drain hoses and
power cord.
One side of the cabinet sink should be chosen to facilitate the connection ofdrainhosesof
the dishwasher.
Please carefully read the installation instruction.
Preparations should be made before moving the dishwasher to the installation place.
Choose a place near the sink to facilitate the installation of inlet and drain hoses
(see Figure 1).
If dishwasher is installed at the corner of the cabinet, there should be some space
(see Figure 2) when the door is opened.
2
1
Installation preparation
Installation instruction
Note: Please check the accompanying installation accessories are provided.
●
●

15
Minimum space when
thedoorisopened
【Figure 2】
Cabinet dimensions
【Figure 1】
Cabinet
Dishwasher
Door of
dishwasher
Minimum space of 50mm
Less than 5mm
between the top
of dishwasher and
cabinet and the
outerdooraligned
to cabinet.
90 °
90 °
450 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain and
water supply line
entrances

16
qualified plumber.
maximum of 10 bars.
Make sure your plumbing is suitable to install
your new dishwasher. If in doubt contact a
The water pressure coming from the water
mains supply must be a minimum of 0.4 and a
First connect water inlet hose to your
dishwasher Ensure black rubber seal is
in place.
Then connect the straight end to your water
mains supply Ensure black rubber seal is
in place.
Please turn on the tap and check for leakages
after connecting the hose.
Please ensure the tap is turned off when the
machine is not used.
If you only have one cold water
feed (For example for your
washing machine don't worry.
a Y adaptor will provide you with
the additional cold water feed
you need for your dishwasher.
Y adaptor is available from most
DIY stores.
max 100 cm
min40cm
min 4cm
Fit the drainage hose of your machine
tothedrainagepipewithoutbending.
washing process.
Secure your hose firmly to the waste
pipe to avoid it coming off during the
drainage system.
The waste pipe must only be connected
into the foul drains and not surface water
The hose should be placed between
40 cm and 100 cm from the floor level
and must not be extended otherwise the
machine may not empty the waste water.

17
Connection of drain hoses
●
Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it
run into the sink, making sure to avoid bending or crimping it. Use the speical
plastic support that comes with the appliance (Figure 3). The free end of thehose
must be at a height between 400 and 1000mm and must not be immersed in water
to avoid back flow . ATTENTION: The special plastic hose support must be tightly
fastened to the wall toprevent the drain hose from moving and allowing waterto
spill outside the drain.
Drain pipe connection
【Figure 3】
Drain hose hook
φ40mm

18
Dishwasher installation steps
●
.
.
1
2
4
6
7
Connect the inlet hose to the cold water supply
Connect the drain hose.
Connect the power cord
Put the dishwasher to slide rails
Add the condensation strip following instructions on the reverse side of the condensation strip
Place the dishwasher into position.
Level the dishwasher. The rear feet can be adjusted from the front of the dishwasher by turning
the screws on the left and right hand side of the cabinet (Figure 4A). To adjust the front feet,
use a spanner and turn the front feet until the dishwasher is level (Figure 4B).
The dishwasher must be secured in place. There are two ways to do this:
A. Normal work surface-secure to the work surface by using two woodscrews ensuring the
dishwasher weight is not being hit by the surface .
B. Marble or granite work top-secure the bracket to the side panel of the dishwasher and secure
the dishwasher to the furniture housing. Put the rubber cap over the screw (Figure 5).
3
5
8
.
.
4
2
3
RUBBER
SCREW
COVER
5
SCREW
CONE GEAR
4B
4A
