Logik S105CG11 User manual

Installation Guide
Clear Glass TV Stand
S105CG11

3
CUSTOMER HELPLINE (UK Customers Only)
0844 561 1234
MAX
42”
MAX LOAD
50 kg
KG
• Suitable for at screen TVs with screen sizes up to 42”
• Maximum TV Load: 50 kg
• 3 Shelves
• Cable management
ATTENTION - Please note before assembling your TV stand
• Check that you have all the parts and familarise yourself with this installation
guide.
• Make sure you have enough space to layout all the parts. Keep children and
pets away from the work area, small parts could choke them if swallowed.
• Assemble the TV stand on a soft level surface as close to its nal position as
possible.
WARNING
• We do not recommend the use of power drills. Only use hand screwdrivers
and do not overtighten the components unnecessarily.
• Do not stand or sit on the TV stand, this could cause damage.
• Only use this product when fully assembled.
• Do not place very hot or cold items on any part of the TV stand unless
adequately thick table mats are used.
• When cleaning the TV stand use a damp cloth with washing-up liquid or soap.
Do not use washing powder or any other substances containing abrasives.
• Do not place TV near to the front of the tv stand.
• Always site the TV stand on rm level ground and ensure that the base is fully
in contact with the ground.
2 people are required to lift the unit during assembly.

4
1050 x 420 x 4mm1050 x 450 x 8mm
Installation
Guide
Ø50 x 103mm Ø50 x 18mm
Ø20 x 2.5mm
M6 x 6mm
120 x 350mm
Ø50 x 181mm
M6 x 25mm
M6 1050 x 450 x 4mm Ø50 x 174mm
Ax 1 Bx 1
Cx 4
Gx 2
Ex 4
Ix 2
Fx 2
Jx 1
Dx 4
Hx 4
Kx 1 Lx 1 Mx 4
M6 x 463mm

5
1
3
5
2
4
6
A
H
H
H
H
M
M M
M
J
F F
BC
C
C
C

6
7
9
11
8
10
12
L
D
D
D
D
K
G G
I I
E
E
E
E

13
15
14

DSG Retail Ltd. (co. no. 504877)
Maylands Avenue, Hemel Hempstead, Herts., HP2 7TG, UK
IB-S105CG13-140215V2
