Logik L60CHDS12 User manual

60cm Chimney Hood
L60CHDB12 (Black)
L60CHDS12 (Silver)
Instruction / Installation Manual
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 1 7/3/16 12:08 pm

L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 2 7/3/16 12:08 pm

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 8
Product Overview......................................................................................................................... 9
Modes of Operation ................................................................................................................... 10
Air Extraction........................................................................................................................................................... 10
Air Recirculation.....................................................................................................................................................10
Operation .................................................................................................................................... 10
To Select the Fan Motor Speed.........................................................................................................................10
Hob Lighting ...........................................................................................................................................................10
Cleaning and Maintenance........................................................................................................ 11
Grease Filters........................................................................................................................................................... 11
Cleaning the Grease Filters by Hand ..............................................................................................................12
Cleaning the Grease Filters in the Dishwasher ...........................................................................................12
Carbon Filter Usage ..............................................................................................................................................13
Replacing Carbon Filters.....................................................................................................................................13
Changing the Lamps............................................................................................................................................ 13
Hints and Tips ............................................................................................................................. 14
If Cooker Hood Does Not Operate ..................................................................................................................14
Technical Specications............................................................................................................. 15
Installation .................................................................................................................................. 16
Product Overview.................................................................................................................................................. 16
Safety Distance Between Hob and Cooker Hood ......................................................................................18
Connection for Air Extraction ...........................................................................................................................19
Mounting the Cooker Hood ..............................................................................................................................20
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 3 7/3/16 12:08 pm

4
• Thisappliancecomplieswithallrelevantlocalandnationalsafetyrequirements.Inappropriateuse
can,however,leadtopersonalinjuryanddamagetoproperty.
• Toavoidtheriskofaccidentsanddamagetotheappliance,pleasereadtheseinstructionscarefully
beforeusingitforthersttime.Theycontainimportantinformationonthesafety,installation,use
andmaintenanceoftheappliance.
• Keeptheseinstructionsinasafeplaceandensurethatallusersarefamiliarwiththecontents.Pass
themontoanyfutureowneroftheappliance.
Correct Application
• Thisapplianceisnotdesignedforcommercialuse.Itisintendedforuseindomestichouseholds.
• Itmustonlybeusedasadomesticappliancetoextractvapoursandremoveodoursfromcooking.
• Anyotherusageisnotsupportedbythemanufacturerandcouldbedangerous.
Themanufacturercannotbeheldliablefordamageresultingfromincorrectorimproperuseor
operationoftheappliance.
• Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreduced
physical,sensoryormentalcapabilitiesorlackofexperienceandknowledgeiftheyhavebeen
givensupervisionorinstructionconcerninguseoftheapplianceinasafewayandunderstandthe
hazardsinvolved.Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshall
notbemadebychildrenwithoutsupervision.
• Accessiblepartsmaybecomehotwhenusedwithcookingappliances.
• Ifthesuppliedmainscableisdamaged,itmustbereplacedbythemanufacturer,itsserviceagent
orsimilarlyqualiedpersonsinordertoavoidahazard.
Safety with children
• Thisapplianceisonlyintendedforusebyadultswhohavereadtheseinstructions.
• Thisapplianceisnotatoy!Toavoidtheriskofinjury,keepchildrenwellawayanddonotallow
themtoplaywithitortousethecontrols.Theywillnotunderstandthepotentialdangersposedby
it.Theyshouldbesupervisedwheneveryouareworkinginthekitchen.
• Olderchildrenmayusethecookerhoodonlywhenitsoperationhasbeenclearlyexplainedtothem
andtheyareabletouseitsafely,recognisingthedangersofmisuse.
Correct Use
• Neveruseanopenamebeneaththecookerhood.Toavoidthedangerofre,donotambéor
grilloveranopenameunderthecookerhood.
Whenswitchedon,thecookerhoodcoulddrawamesintothelter.Fatparticlesdrawnintothe
cookerhoodpresentarehazard.
• Whenusingthecookerhoodoveragashob,ensurethatanyburnersinusearealwayscoveredbya
pan.Switchthecookingzoneowhenapanisremoved,evenforashorttime.
Safety Warnings
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 4 7/3/16 12:08 pm

5
• Regulatetheamesothatitdoesnotburnupthesidesofthepan.
• Donotallowthepanstooverheatexcessively(e.g.whenusingawok).
• Thecookerhoodcanbecomedamagedwhenexposedtoexcessiveheat.
• Alwaysswitchthecookerhoodonwhenacookingzoneisinuse,otherwisecondensationmay
collectinthehood,whichcouldcausecorrosion.
• Whencookingwithoilorfat,chippansanddeepfatfryersetc,donotleavethepansunattended.
Neverleaveanopengrillunattendedwhengrilling.Overheatedoilandfatcanigniteandcouldset
thecookerhoodonre.
• Donotusethecookerhoodwithouttheltersinplace.Thiswayyouwillavoidtheriskofgrease
anddirtgettingintotheapplianceandhinderingitssmoothoperation.
• Theltersshouldberegularlycleanedorchangedasappropriate.Saturatedltersarearehazard.
See"CleaningandMaintenance".
• Thecookerhoodcangetveryhotduringcookingduetoheatrisingfromthehob.
Donottouchthehousingorthegreaseltersuntilthecookerhoodhascooleddown.
• Donotuseasteam-cleanertocleanthisappliance.Steamcouldreachtheelectricalcomponents
andcauseashortcircuit.
Technical safety
• Beforeinstallation,checkthecookerhoodforvisiblesignsofdamage.Undernocircumstances
shouldyouuseadamagedappliance.Itcouldbedangerous.
• Beforeconnectingtheappliancetothemainssupply,makesurethatthevoltageandfrequency
detailsgivenonthedataplatecorrespondwiththeon-siteelectricitysupply,otherwisethe
appliancecouldbedamaged.Consultaqualiedelectricianifinanydoubt.
• Theelectricalsafetyofthisappliancecanonlybeguaranteedwhencontinuityiscompletebetween
theapplianceandaneectiveearthingsystemcomplieswiththecurrentlocalandnationalsafety
regulations.Itismostimportantthatthisbasicsafetyrequirementispresentandtestedregularly,
andwherethereisanydoubt,thehouseholdwiringsystemshouldbeinspectedbyaqualied
electrician.Themanufacturercannotbeheldliablefortheconsequencesofaninadequateearthing
system(e.g.electricshock).
• Forsafetyreasons,thisappliancemayonlybeusedwhenithasbeenfullyinstalled.
• Onlyopenthehousingasdescribedintheinstructions.Undernocircumstancesshouldany
otherpartsofthehousingbeopened.Tamperingwithelectricalconnectionsorcomponentsand
mechanicalpartsishighlydangeroustotheuser,andcancauseoperationalfaults.
• Installation,maintenanceandrepairsmayonlybecarriedoutbyanauthorisedpersonin
accordancewiththecurrentnationalandlocalsafetyregulations.Repairsandotherworkby
unqualiedpersonscouldbedangerous.Themanufacturercannotbeheldliableforunauthorised
work.
• Faultycomponentsmustonlybereplacedbygenuineoriginalparts.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 5 7/3/16 12:08 pm

6
sameroomorareaofthehouseasanotherheatingappliancewhichdependsontheairinthe
room.Suchappliancesincludegas,oil,woodorcoal-redboilersandheaters,continuousowor
otherwaterheaters,gashobs,cookersorovenswhichdrawairinfromtheroomandductexhaust
gasesoutthroughachimneyorextractionducting.
• Whenusedinextractionmode,theappliancedrawsairinfromtheroominwhichitisinstalled
andfromneighbouringrooms.
• Ifthereisinsucientair,anunderpressurewilloccur.Theheatingappliancemaybestarvedof
oxygen,impairingcombustion.
• Harmfulgasescouldbedrawnoutofthechimneyorextractionductingbackintotheroom,with
potentiallyfatalconsequences.
• Inordertoensuresafeoperation,andtopreventgasesgivenobytheheatingappliances
frombeingdrawnbackintotheroomwhenthecookerhoodandtheheaterareinoperation
simultaneously,anunderpressureof0.04mbar(4pa)isthemaximumpermissibleintheroom.
• Ventilationcanbemaintainedbyairinlets
whichmustnotbeblocked,inwindows,
doorsandoutsidewallvents,orbyother
technicalmeasures,suchasensuringthat
thecookerhoodcanonlybeswitchedon
whentheheatingapplianceisswitchedo
orviceversa.Aventilationbrickaloneisnot
generallysucienttoensuresafeventilation.
Using at the same time as other heating
appliances that depend on the air from
the same room.
• Greatcareshouldbetakenwhenusingthe
cookerhoodatthesametimeandinthe
• Duringinstallation,maintenanceandrepairwork,theappliancemustbedisconnectedfromthe
mainselectricitysupply.Itisonlycompletelyisolatedfromtheelectricitysupplywhen:
a)itisswitchedoattheisolator,or
b)themainsfuseisdisconnected,or
c)itisswitchedoatthewallsocketandtheplugwithdrawn,or
d)thefuseofthefusedspurconnectionunitiswithdrawn.
• Donotconnecttheappliancetothemainselectricitysupplybyamulti-socketunitoranextension
lead.Thesedonotguaranteetherequiredsafetyoftheappliance(e.g.dangerofoverheating).This
appliancemayonlybeusedinmobileinstallationsifariskassessmentoftheinstallationhasbeen
carriedoutbyasuitablyqualiedengineer.
• Inareaswhichmaybesubjecttoinfestationbycockroachesorothervermin,payparticular
attentiontokeepingtheapplianceanditssurroundingsinacleanconditionatalltimes.
WARNING:Dangeroftoxicfumes.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 6 7/3/16 12:08 pm

7
Theoverallventilationconditionofthedwellingmustbetakenintoaccount.Ifinany
doubt,theadviceofacompetentbuilderor,forgas,aqualifiedgasfitter(GasSafe
registeredintheUK)mustbesought.
Ifinanydoubt,theadviceofaqualifiedbuilder,gasfitter(GasSaferegisteredintheUK)or
electricianmustbesought.
• Iftheonlywayofensuringadequateventilationisviaanopenwindow,awindowcontactswitch
shouldbettedtoensurethatthecookerhoodcanonlyoperatewhenthewindowisopened
suciently.Awindowcontactswitchkitisavailablefromgoodbuilders'merchants.Takecare
whenventilatingtheroomthroughanopenwindowthatventilationisnotimpairedbyaclosed
blindorcurtain.Ifthehoodisbeingoperatedinrecirculationmode,theaboverestrictionsdonot
apply.
Correct Installation
• Refertothecookerorhobmanufacturer'sinstructionsastowhetheracookerhoodmaybe
operatedabovethecooker/hob.
• Theminimumsafedistancesbetweenthetopofthecookerorhobandthebottomofthecooker
hoodgivenintheInstallationsectionofthisbookletmustbemaintained,unlessthehob/cooker
manufacturerstatesthatagreatersafedistanceisrequired.
• Ifmorethanoneapplianceisttedbeneaththecookerhood,andtheyhavedierentminimum
safedistancestothecookerhood,selectthegreaterdistance.
• Safetyregulationsprohibitthettingofacookerhoodoversolidfuelstoves.
• Allducting,pipeworkandttingsmustbeofnon-ammablematerial.Thesecanbeobtainedfrom
builders'merchants.
• Theappliancemustnotbeconnectedtoachimneyorventuewhichisinuse.Neithershoulditbe
connectedtoductingwhichventilatesroomswithreplaces.
• Ifexhaustairistobeextractedintoachimneyorventilationductnolongerusedforother
purposes,seekprofessionaladvice.
Accessories
• Onlyusegenuineoriginalsparepartsandaccessorieswiththisappliance.
Themanufacturercannotbeheldliablefordamagecausedbynon-compliancewiththese
WarningandSafetyinstructions.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 7 7/3/16 12:08 pm

8
Unpacking
Remove all items from the packaging. If you dispose of it, please do so according to local regulations. The
following items are included:
Main Unit
4 x 8mm Screws X 4Internal Chimney X 1
External Chimney X 1 Ø8 x 40mm
Plastic Wall Plug X 9
Hanging Plate
(for mounting product on the wall)
External Chimney Connection Plate
(for xing external chimney on the wall)
Internal Chimney Connection Plate
(for xing internal chimney on the wall)
4 x 30mm Screws X 2 4 x 40mm Screws X 7 Drill Template Instruction Manual
Thank you on the purchase of your new Logik Cooker Hood.
We recommend that you spend some time to read this manual in order to fully understand
how to install and operate it correctly.
Read all the safety warnings carefully before use and keep this manual for future reference.
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
Adapter X 1
(for reducing outlet diameter from 150-120mm)
3503C1
5-Ø8
Outlet Flap X 2
Instruction
Manual
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 8 7/3/16 12:08 pm

9
Control Panel
1. OFF button
2. Motor speed buttons
3. Lamp button
1
12 3
2
34
5
6
Product Overview
1. Recirculation Vents
2. Internal Chimney
3. External Chimney
4. Control Panel
5. Illumination
6. Aluminium Filter
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 9 7/3/16 12:08 pm

10
Modes of Operation
The cooker hood works with
Air Extraction
The air is drawn in and cleaned by the grease filters and directed outside.
When the cooker hood is switched on, the non-return flap opens for the cooking
vapours to be ducted away.
Ensure there is adequate ventilation in the room when the cooker hood is used at the same time as
other appliances burning gas or other fuels.
• Carbon filters are available as an optional extra, see rear page for ordering details.
• Before using the cooker hood in recirculation mode, ensure that the carbon filters are in place.
See “Cleaning and Maintenance”
Air Recirculation
The air is drawn in and cleaned first by the grease filters and then by a carbon filter. The
cleaned air is then recirculated back into the kitchen through the recirculation vents in
the top of the cooker hood chimney.
Operation
To Select the Fan Motor Speed
1. The unit has 3 motor speeds “1” , “2” and “3”.
2. For short periods of cooking food with intensive vapours and a strong aroma, e.g. when searing meat, you
may wish to select the highest setting “3”.
3. To turn the motor fan off, press the OFF button.
• Do not flambe under the cooker hood.
• Accessible parts may become hot when used with cooking appliances.
Hob Lighting
The hob lighting can be switched on and off independently of the fan by pressing the LAMP button.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 10 7/3/16 12:08 pm

11
• All external surfaces and controls can be cleaned using a little washing-up liquid applied with a damp soft
sponge or cloth.
Grease Filters
The re-usable metal grease filters in the appliance remove solid particles (grease, dust, etc.) from the kitchen
vapours, preventing soiling of the cooker hood.
The grease filters should be cleaned regularly (at least every 3-4 weeks) to avoid a build-up of grease.
1. To take out the grease filter, press the plastic catch.
2. Pull the aluminium filter downwards.
1
2
Cleaning and Maintenance
• Before any cleaning or maintenance work is carried out, disconnect the cooker hood from the mains
power supply. Ensure that:
– it is switched off at the isolator, or
– it is switched off at the wall socket and the plug is withdrawn, or
– the fuse from the fused spur connection unit is withdrawn, or
– the mains fuse is disconnected.
• The surfaces and controls are susceptible to scratches and abrasions. Please observe the following
cleaning instructions.
Do not use:
• Cleaning agents containing soda, acids, chlorides or solvents.
• Abrasive cleaning agents, e.g. powder cleaners or cream cleaners and abrasive sponges, as well as
pot scourers or sponges which have been used previously with abrasive cleaning agents as these
will damage the surface material.
Only use a damp cloth as water could get into the unit and cause damage.
Dirty filters are a fire hazard.
To avoid damaging the filters or the hob
below, make sure you hold the filters
securely at all times when handling them.
• Wipe dry using a soft cloth.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 11 7/3/16 12:08 pm

12
Cleaning the Grease Filters by Hand
• Clean the filters with a soft nylon brush in a mild solution of hot water and a little washing-up liquid.
Cleaning the Grease Filters in the Dishwasher
• Place the filters as upright as possible in the lower basket, with the short sides upright. Wash using
a 65°C programme, ensuring the spray arm is not obstructed.
• Use a mild dishwasher detergent.
Do not use:
• Cleaning agents containing descaling agents.
• Powder cleaners, cream cleaners or abrasive all-purpose cleaners.
• Oven cleaners.
Depending on the cleaning agent used, cleaning the filters in a dishwasher
can cause permanent discolouration to the surface. However, this will not
affect the functioning of the filters in any way.
• After cleaning, leave the filters to dry on an absorbent surface before replacing them.
• When removing the filters for cleaning, also clean off any residues of oil or fat from the now accessible housing
to prevent the risk of these catching fire.
When putting the grease filters back in position, ensure that the locking clips are facing down towards
the hob.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 12 7/3/16 12:08 pm

13
Carbon Filter Usage
Your product is compatible with one type of carbon filter (carbon filters are not provided).
• Before installing or replacing the carbon filters, you should switch off and disconnect the electricity supply.
• The carbon filters should never be washed.
• The grease filters should be installed on the product even when carbon filters are not being used.
Do not use your product without the grease filters.
Replacing Carbon Filters
• It is necessary to install 2 carbon filters in your product.
• Open all the grease filters, see page 7 for details.
• To attach the carbon filters, place them on the connection
channels on the motor and turn the left hand filter
anticlockwise and the right hand filter clockwise.
• In order to remove the carbon filters, turn the left hand
filter clockwise and the right hand filter anticlockwise.
• Replace the carbon filters when they no
longer absorb kitchen odours effectively.
They should, however, be replaced at least
every 3 months to prevent a risk of fire.
• Used carbon filters can be disposed of with
the normal household waste.
• Replace all the grease filters to the main unit.
Changing the Lamps
1. Disconnect the electricity supply.
2. Remove the aluminium grease filters.
3. Two candle lamps are located under the lamp
cover.
4. Replace with a 40W 240V (E14) candle lamp.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 13 7/3/16 12:08 pm

14
Hints and Tips
Problem Solution
Cooker hood does not operate
• CheckElectricconnection.
(The supply voltage should be 220-240 V. The cooker hood must
be connected to an earthed socket)
• Checkmotorspeedselector.
(Motor speed selector should be in position I, II or III)
Lamp does not light
• CheckElectricconnection.
(The supply voltage should be 220-240 V. The cooker hood must
be connected to an earthed socket)
• Checklampswitch.
(Lamp switch should be in the on position)
• Checklightbulbs.
Air suction of cooker hood is weak
• Checkaluminiumfilters.
(Aluminium grease filters should be washed once a month under
normal conditions)
• Checkairoutletchimney.
(Air outlet chimney should be open)
• Checkcarbonfilters.
(If the unit operates with carbon filters, they should be replaced
quarterly)
If Cooker Hood Does Not Operate
Before Contacting Service:
Be sure that the mains plug is connected to the mains socket and the fuse in the installation is in good condition.
Check your cooker hood according to the above table. If the problem continues, contact your retailer or an
authorised service agent.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 14 7/3/16 12:08 pm

15
Technical Specications
Model no. L60CHDS12 / L60CHDB12
Extraction Rate (m3/h) 450.0
Voltage (V) 220 – 240 ~
Frequency (Hz) 50
Total Power (W) 180
Lamp 2 × 40 W
Features and specifications are subject to change without prior notice.
Product Fiche
Symbol Value Unit
Annual Energy Consumption AEChood 114.0 kWh/a
Time increase factor f 1.7
Fluid Dynamic Efficiency FDEhood 9.1
Fluid Dynamic Efficiency class E
Energy Efficiency Index EEIhood 105.0
Energy Efficiency class E
Measured airflow rate at the best efficiency QBEP 321.0 m3/h
Measured air pressure at best efficiency point PBEP 92 Pa
Maximum airflow Qmax 546.1 m3/h
Air flow at working point (highest setting) 491.4 m3/h
Air flow at working point (lowest setting) 392.4 m3/h
Measured electric power input at best efficiency point WBEP 89.6 W
Nominal power of the lighting system WL80 W
Average illumination of the lighting system on the cooking surface Emiddle 85 lux
Lighting Efficiency LEhood 1.1 lux/w
Lighting efficiency class G
Grease Filtering Efficiency (%) GFEhood 74.2
Grease Filtering Efficiency (GFE hood ) class D
Measured power consumption on standby mode PS0 W
Measured power consumption on off mode PO- W
Sound power level LWA 58 dB
The above table indicate the information for the cooker hood. The test result is done as per the relevant
requirement of EU No 65/2014 and EU No 66 / 2014.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 15 7/3/16 12:08 pm

16
Installation
Product Overview
1
2
3 4
5
6
1. Grill For Air Outlet
2. Internal Chimney
3. External Chimney
4. Internal Chimney Connection Plate
5. External Chimney Connection Plate
6. Hanging Plate
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 16 7/3/16 12:08 pm

17
All dimensions shown are in mm.
273
302
40
55
20
400
400
500
600
40
440-820
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 17 7/3/16 12:08 pm

18
Min.650 mm
Safety Distance Between Hob and Cooker Hood
When planning the installation height of your cooker hood, the minimum safe distance between the
top of a cooker or hob and the bottom of the cooker hood should be at least 650mm, unless a greater
distance is specified by the manufacturer of your cooking appliance.
• When deciding on the safe distance between the hob and cooker hood, please note that a distance greater
than 650mm above electric cookers/hobs may be preferable to give more working space under the hood.
• Account should also be taken of the height of the person who will be using the hood most often. The person
should have sufficient space to work comfortably at the hob, and also be able to reach the hood controls with
ease.
• Please be aware that if positioned too high, extraction will be inefficient.
• If you want the top of the cooker hood telescopic extension piece to be mounted flush with the ceiling, make
sure there is adequate space below the appliance for safe operation.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 18 7/3/16 12:08 pm

19
Connection for Air Extraction
Only use smooth pipes or flexible hoses made from non-flammable materials for the extraction ducting.
To achieve the greatest possible air extraction with the lowest noise level, please note the following:
• To ensure efficient air extraction, the diameter of the exhaust ducting should not be less than
120mm.
• If flat ducting is being used, the cross-sectional area must not be smaller than the cross sectional area of the
exhaust connection.
• All ducting, pipework and fittings must be made of non-flammable materials.
• The exhaust ducting should be as short and straight as possible.
• Only use wide radius bends.
• The exhaust ducting should not be kinked or compressed.
• Ensure that all connections are strong and airtight.
• Where ducting is horizontal, it must be laid to slope away at least 1 cm per metre. This is to ensure that
condensation cannot drain back into the cooker hood.
• If the exhaust air is to be ducted into the open air, the installation of a telescopic wall vent or roof vent is
recommended.
To avoid the danger of toxic fumes, please observe the Safety Warnings.
This is especially crucial when using the cooker hood at the same time as another heating appliance
which relies on air from the same room.
The cooker hood should be installed according to the local and national building regulations. Seek
approval from the building inspector where necessary.
If the exhaust ducting is to run through rooms, ceiling space etc. where there may be great variations
in temperature between the different areas, the problem of condensation will need to be addressed.
The exhaust ducting will need to be suitably insulated.
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 19 7/3/16 12:08 pm

20
Mounting the Cooker Hood
1. We recommend that for air extraction installations, a professional tradesperson is consulted prior to any
work being undertaken. A 150mm or 120mm hole will need to be provided for the aluminium flexible hose
(not supplied) to duct the extracted air to the outside. For recirculation operation, a competent layman
can follow the instructions below. If you are in any doubt, we recommend you consult a professional
tradesperson.
2. Ensure there is an available switched mains socket adjacent to the hood to power the appliance. If this
is not available, do not use extension leads. We recommend you consult a qualified electrician prior to
commencing any work.
3. The unit itself is with 150mm air outlet. Firstly; you need to install 2 pieces of Outlet Flap (OF150C3) onto the
air outlet. The 2 pieces of Outlet Flap are completely same. Take out one piece; make sure that the side with
protruding points is the upper side. Then; insert one end into the relative hole on air outlet which located
on the top of unit. Bend it a little and insert another end into the hole on the other end of air outlet. Do the
same of another Outlet Flap. If your kitchen is with 120mm hole; you need to mount Adaptor (AD) onto air
outlet before connecting the aluminium flexible hose.
4. You can either use the drill template to mark the position of the fixing screws or position the hood on the
wall and mark the position "A", "B", "C", "D" and "E" as shown.
5. Screw the External Chimney to the External Chimney Connection Plate by screwing 2 pcs of the 4 x 8mm
screws through the mounting holes at the top of External Chimney. Screw the Internal Chimney to the
Internal Chimney Connection Plate by screwing the other 2 pcs of 4 x 8mm screws through the mounting
holes at the top of Internal Chimney.
• We recommend professional tradespersons are consulted prior to the fitting of this appliance.
• Each installation is different and these instructions should be used as a guide only. If in doubt
consult professional tradespersons.
• Air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas
or other fuels.
Before drilling any holes, ensure there is no pipe work or wires buried in the wall.
230
300
A
C
F G
D
E B
256
243 250
L60CHDB12_LCHD60S12_IB_RC_160307_grace.indd 20 7/3/16 12:08 pm
