Logik L60CHDB17 Parts list manual

60cm/90cm Black T-box
Chimney Hood
L60CHDB17 / L90CHDB17
Instruction / Installation Manual
L60CHDB17
L90CHDB17
L60_90CHDB17_IB_RC_180906_grace.indd 1 6/9/18 12:29 pm

L60_90CHDB17_IB_RC_180906_grace.indd 2 6/9/18 12:29 pm

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 8
Product Overview......................................................................................................................... 9
Control Panel..............................................................................................................................................................9
Modes of Operation ................................................................................................................... 10
Air Extraction........................................................................................................................................................... 10
Air Recirculation.....................................................................................................................................................10
Operation .................................................................................................................................... 10
To Select the Fan Motor Speed.........................................................................................................................10
Hob Lighting ...........................................................................................................................................................10
Cleaning and Maintenance........................................................................................................ 11
Grease Filters........................................................................................................................................................... 11
Cleaning the Grease Filters by Hand ..............................................................................................................12
Cleaning the Grease Filters in the Dishwasher ...........................................................................................12
Carbon Filter Usage ..............................................................................................................................................13
Replacing Carbon Filters.....................................................................................................................................13
Changing the Lamps............................................................................................................................................ 13
Hints and Tips ............................................................................................................................. 14
If Cooker Hood Does Not Operate ..................................................................................................................14
Technical Specications............................................................................................................. 15
Product Fiche .............................................................................................................................. 15
Installation .................................................................................................................................. 17
Product Overview.................................................................................................................................................. 17
Safety Distance Between Hob and Cooker Hood ......................................................................................19
Connection for Air Extraction ...........................................................................................................................20
Mounting the Cooker Hood ..............................................................................................................................21
L60_90CHDB17_IB_RC_180906_grace.indd 3 6/9/18 12:29 pm

4
• Thisappliancecomplieswithallrelevantlocalandnationalsafetyrequirements.Inappropriateuse
can,however,leadtopersonalinjuryanddamagetoproperty.
• Toavoidtheriskofaccidentsanddamagetotheappliance,pleasereadtheseinstructionscarefully
beforeusingitforthersttime.Theycontainimportantinformationonthesafety,installation,use
andmaintenanceoftheappliance.
• Keeptheseinstructionsinasafeplaceandensurethatallusersarefamiliarwiththecontents.Pass
themontoanyfutureowneroftheappliance.
Correct Application
• Thisapplianceisnotdesignedforcommercialuse.Itisintendedforuseindomestichouseholds.
• Itmustonlybeusedasadomesticappliancetoextractvapoursandremoveodoursfromcooking.
• Anyotherusageisnotsupportedbythemanufacturerandcouldbedangerous.
Themanufacturercannotbeheldliablefordamageresultingfromincorrectorimproperuseor
operationoftheappliance.
• Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreduced
physical,sensoryormentalcapabilitiesorlackofexperienceandknowledgeiftheyhavebeen
givensupervisionorinstructionconcerninguseoftheapplianceinasafewayandunderstandthe
hazardsinvolved.Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshall
notbemadebychildrenwithoutsupervision.
• Accessiblepartsmaybecomehotwhenusedwithcookingappliances.
• Ifthesuppliedmainscableisdamaged,itmustbereplacedbythemanufacturer,itsserviceagent
orsimilarlyqualiedpersonsinordertoavoidahazard.
Safety with children
• Thisapplianceisonlyintendedforusebyadultswhohavereadtheseinstructions.
• Thisapplianceisnotatoy!Toavoidtheriskofinjury,keepchildrenwellawayanddonotallow
themtoplaywithitortousethecontrols.Theywillnotunderstandthepotentialdangersposedby
it.Theyshouldbesupervisedwheneveryouareworkinginthekitchen.
• Olderchildrenmayusethecookerhoodonlywhenitsoperationhasbeenclearlyexplainedtothem
andtheyareabletouseitsafely,recognisingthedangersofmisuse.
Correct Use
• Neveruseanopenamebeneaththecookerhood.Toavoidthedangerofre,donotambéor
grilloveranopenameunderthecookerhood.
Whenswitchedon,thecookerhoodcoulddrawamesintothelter.Fatparticlesdrawnintothe
cookerhoodpresentarehazard.
• Whenusingthecookerhoodoveragashob,ensurethatanyburnersinusearealwayscoveredbya
pan.Switchthecookingzoneowhenapanisremoved,evenforashorttime.
Safety Warnings
L60_90CHDB17_IB_RC_180906_grace.indd 4 6/9/18 12:29 pm

5
• Regulatetheamesothatitdoesnotburnupthesidesofthepan.
• Donotallowthepanstooverheatexcessively(e.g.whenusingawok).
• Thecookerhoodcanbecomedamagedwhenexposedtoexcessiveheat.
• Alwaysswitchthecookerhoodonwhenacookingzoneisinuse,otherwisecondensationmay
collectinthehood,whichcouldcausecorrosion.
• Whencookingwithoilorfat,chippansanddeepfatfryersetc,donotleavethepansunattended.
Neverleaveanopengrillunattendedwhengrilling.Overheatedoilandfatcanigniteandcouldset
thecookerhoodonre.
• Donotusethecookerhoodwithouttheltersinplace.Thiswayyouwillavoidtheriskofgrease
anddirtgettingintotheapplianceandhinderingitssmoothoperation.
• Theltersshouldberegularlycleanedorchangedasappropriate.Saturatedltersarearehazard.
See"CleaningandMaintenance".
• Thecookerhoodcangetveryhotduringcookingduetoheatrisingfromthehob.
Donottouchthehousingorthegreaseltersuntilthecookerhoodhascooleddown.
• Donotuseasteam-cleanertocleanthisappliance.Steamcouldreachtheelectricalcomponents
andcauseashortcircuit.
Technical safety
• Beforeinstallation,checkthecookerhoodforvisiblesignsofdamage.Undernocircumstances
shouldyouuseadamagedappliance.Itcouldbedangerous.
• Beforeconnectingtheappliancetothemainssupply,makesurethatthevoltageandfrequency
detailsgivenonthedataplatecorrespondwiththeon-siteelectricitysupply,otherwisethe
appliancecouldbedamaged.Consultaqualiedelectricianifinanydoubt.
• Theelectricalsafetyofthisappliancecanonlybeguaranteedwhencontinuityiscompletebetween
theapplianceandaneectiveearthingsystemcomplieswiththecurrentlocalandnationalsafety
regulations.Itismostimportantthatthisbasicsafetyrequirementispresentandtestedregularly,
andwherethereisanydoubt,thehouseholdwiringsystemshouldbeinspectedbyaqualied
electrician.Themanufacturercannotbeheldliablefortheconsequencesofaninadequateearthing
system(e.g.electricshock).
• Forsafetyreasons,thisappliancemayonlybeusedwhenithasbeenfullyinstalled.
• Onlyopenthehousingasdescribedintheinstructions.Undernocircumstancesshouldany
otherpartsofthehousingbeopened.Tamperingwithelectricalconnectionsorcomponentsand
mechanicalpartsishighlydangeroustotheuser,andcancauseoperationalfaults.
• Installation,maintenanceandrepairsmayonlybecarriedoutbyanauthorisedpersonin
accordancewiththecurrentnationalandlocalsafetyregulations.Repairsandotherworkby
unqualiedpersonscouldbedangerous.Themanufacturercannotbeheldliableforunauthorised
work.
• Faultycomponentsmustonlybereplacedbygenuineoriginalparts.
L60_90CHDB17_IB_RC_180906_grace.indd 5 6/9/18 12:29 pm

6
sameroomorareaofthehouseasanotherheatingappliancewhichdependsontheairinthe
room.Suchappliancesincludegas,oil,woodorcoal-redboilersandheaters,continuousowor
otherwaterheaters,gashobs,cookersorovenswhichdrawairinfromtheroomandductexhaust
gasesoutthroughachimneyorextractionducting.
• Whenusedinextractionmode,theappliancedrawsairinfromtheroominwhichitisinstalled
andfromneighbouringrooms.
• Ifthereisinsucientair,anunderpressurewilloccur.Theheatingappliancemaybestarvedof
oxygen,impairingcombustion.
• Harmfulgasescouldbedrawnoutofthechimneyorextractionductingbackintotheroom,with
potentiallyfatalconsequences.
• Inordertoensuresafeoperation,andtopreventgasesgivenobytheheatingappliances
frombeingdrawnbackintotheroomwhenthecookerhoodandtheheaterareinoperation
simultaneously,anunderpressureof0.04mbar(4pa)isthemaximumpermissibleintheroom.
• Ventilationcanbemaintainedbyairinlets
whichmustnotbeblocked,inwindows,
doorsandoutsidewallvents,orbyother
technicalmeasures,suchasensuringthat
thecookerhoodcanonlybeswitchedon
whentheheatingapplianceisswitchedo
orviceversa.Aventilationbrickaloneisnot
generallysucienttoensuresafeventilation.
Using at the same time as other heating
appliances that depend on the air from
the same room.
• Greatcareshouldbetakenwhenusingthe
cookerhoodatthesametimeandinthe
• Duringinstallation,maintenanceandrepairwork,theappliancemustbedisconnectedfromthe
mainselectricitysupply.Itisonlycompletelyisolatedfromtheelectricitysupplywhen:
a)itisswitchedoattheisolator,or
b)themainsfuseisdisconnected,or
c)itisswitchedoatthewallsocketandtheplugwithdrawn,or
d)thefuseofthefusedspurconnectionunitiswithdrawn.
• Donotconnecttheappliancetothemainselectricitysupplybyamulti-socketunitoranextension
lead.Thesedonotguaranteetherequiredsafetyoftheappliance(e.g.dangerofoverheating).This
appliancemayonlybeusedinmobileinstallationsifariskassessmentoftheinstallationhasbeen
carriedoutbyasuitablyqualiedengineer.
• Inareaswhichmaybesubjecttoinfestationbycockroachesorothervermin,payparticular
attentiontokeepingtheapplianceanditssurroundingsinacleanconditionatalltimes.
WARNING:Dangeroftoxicfumes.
L60_90CHDB17_IB_RC_180906_grace.indd 6 6/9/18 12:29 pm

7
Theoverallventilationconditionofthedwellingmustbetakenintoaccount.Ifinany
doubt,theadviceofacompetentbuilderor,forgas,aqualifiedgasfitter(GasSafe
registeredintheUK)mustbesought.
Ifinanydoubt,theadviceofaqualifiedbuilder,gasfitter(GasSaferegisteredintheUK)or
electricianmustbesought.
• Iftheonlywayofensuringadequateventilationisviaanopenwindow,awindowcontactswitch
shouldbettedtoensurethatthecookerhoodcanonlyoperatewhenthewindowisopened
suciently.Awindowcontactswitchkitisavailablefromgoodbuilders'merchants.Takecare
whenventilatingtheroomthroughanopenwindowthatventilationisnotimpairedbyaclosed
blindorcurtain.Ifthehoodisbeingoperatedinrecirculationmode,theaboverestrictionsdonot
apply.
Correct Installation
• Refertothecookerorhobmanufacturer'sinstructionsastowhetheracookerhoodmaybe
operatedabovethecooker/hob.
• Theminimumsafedistancesbetweenthetopofthecookerorhobandthebottomofthecooker
hoodgivenintheInstallationsectionofthisbookletmustbemaintained,unlessthehob/cooker
manufacturerstatesthatagreatersafedistanceisrequired.
• Ifmorethanoneapplianceisttedbeneaththecookerhood,andtheyhavedierentminimum
safedistancestothecookerhood,selectthegreaterdistance.
• Safetyregulationsprohibitthettingofacookerhoodoversolidfuelstoves.
• Allducting,pipeworkandttingsmustbeofnon-ammablematerial.Thesecanbeobtainedfrom
builders'merchants.
• Theappliancemustnotbeconnectedtoachimneyorventuewhichisinuse.Neithershoulditbe
connectedtoductingwhichventilatesroomswithreplaces.
• Ifexhaustairistobeextractedintoachimneyorventilationductnolongerusedforother
purposes,seekprofessionaladvice.
Accessories
• Onlyusegenuineoriginalsparepartsandaccessorieswiththisappliance.
Themanufacturercannotbeheldliablefordamagecausedbynon-compliancewiththese
WarningandSafetyinstructions.
L60_90CHDB17_IB_RC_180906_grace.indd 7 6/9/18 12:29 pm

8
Unpacking
Remove all items from the packaging. If you dispose of it, please do so according to local regulations. The
following items are included:
Main Unit
(L60CHDB17)
4 x 8mm Screws X 4Internal Chimney X 1
External Chimney X 1 Ø8 x 40mm
Plastic Wall Plug X 9
Hanging Plate
(for mounting product on the wall)
External Chimney Connection Plate
(for xing external chimney on the wall)
Internal Chimney Connection Plate
(for xing internal chimney on the wall)
4 x 30mm Screws X 2 4 x 40mm Screws X 7 Drill Template Instruction Manual
Thank you on the purchase of your new Logik Cooker Hood.
We recommend that you spend some time to read this manual in order to fully understand
how to install and operate it correctly.
Read all the safety warnings carefully before use and keep this manual for future reference.
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
Adapter X 1
(for reducing outlet diameter from 150-120mm)
Drill
Template
Instruction
Manual
Main Unit
(L90CHDB17)
L60_90CHDB17_IB_RC_180906_grace.indd 8 6/9/18 12:29 pm

9
Control Panel
1. OFF button
2. Motor speed buttons
3. Lamp button
1
12 3
2
3
4
5
6
Product Overview
1. Recirculation Vents
2. Internal Chimney
3. External Chimney
4. Control Panel
5. Illumination
6. Aluminium Filter
L60CHDB17
L90CHDB17
L60_90CHDB17_IB_RC_180906_grace.indd 9 6/9/18 12:29 pm

10
Modes of Operation
The cooker hood works with
Air Extraction
The air is drawn in and cleaned by the grease filters and directed outside.
When the cooker hood is switched on, the non-return flap opens for the cooking
vapours to be ducted away.
Ensure there is adequate ventilation in the room when the cooker hood is used at the same time as
other appliances burning gas or other fuels.
• Carbon filters are available as an optional extra, see rear page for ordering details.
• Before using the cooker hood in recirculation mode, ensure that the carbon filters are in place.
See “Cleaning and Maintenance”
Air Recirculation
The air is drawn in and cleaned first by the grease filters and then by a carbon filter. The
cleaned air is then recirculated back into the kitchen through the recirculation vents in
the top of the cooker hood chimney.
Operation
To Select the Fan Motor Speed
1. The unit has 3 motor speeds “1” , “2” and “3”.
2. For short periods of cooking food with intensive vapours and a strong aroma, e.g. when searing meat, you
may wish to select the highest setting “3”.
3. To turn the motor fan off, press the OFF button.
• Do not flambe under the cooker hood.
• Accessible parts may become hot when used with cooking appliances.
Hob Lighting
The hob lighting can be switched on and off independently of the fan by pressing the LAMP button.
L60_90CHDB17_IB_RC_180906_grace.indd 10 6/9/18 12:29 pm

11
• All external surfaces and controls can be cleaned using a little washing-up liquid applied with a damp soft
sponge or cloth.
Grease Filters
The re-usable metal grease filters in the appliance remove solid particles (grease, dust, etc.) from the kitchen
vapours, preventing soiling of the cooker hood.
The grease filters should be cleaned regularly (at least every 3-4 weeks) to avoid a build-up of grease.
1. To take out the grease filter, press the plastic catch.
2. Pull the aluminium filter downwards.
Cleaning and Maintenance
• Before any cleaning or maintenance work is carried out, disconnect the cooker hood from the mains
power supply. Ensure that it is switched off at the wall socket and the plug is withdrawn.
• The surfaces and controls are susceptible to scratches and abrasions. Please observe the following
cleaning instructions.
Do not use:
• Cleaning agents containing soda, acids, chlorides or solvents.
• Abrasive cleaning agents, e.g. powder cleaners or cream cleaners and abrasive sponges, as well as
pot scourers or sponges which have been used previously with abrasive cleaning agents as these
will damage the surface material.
Only use a damp cloth as water could get into the unit and cause damage.
Dirty filters are a fire hazard.
To avoid damaging the filters or the hob
below, make sure you hold the filters
securely at all times when handling them.
• Wipe dry using a soft cloth.
2
1
L60_90CHDB17_IB_RC_180906_grace.indd 11 6/9/18 12:29 pm

12
Cleaning the Grease Filters by Hand
• Clean the filters with a soft nylon brush in a mild solution of hot water and a little washing-up liquid.
Cleaning the Grease Filters in the Dishwasher
• Place the filters as upright as possible in the lower basket, with the short sides upright. Wash using
a 65°C programme, ensuring the spray arm is not obstructed.
• Use a mild dishwasher detergent.
Do not use:
• Cleaning agents containing descaling agents.
• Powder cleaners, cream cleaners or abrasive all-purpose cleaners.
• Oven cleaners.
Depending on the cleaning agent used, cleaning the filters in a dishwasher
can cause permanent discolouration to the surface. However, this will not
affect the functioning of the filters in any way.
• After cleaning, leave the filters to dry on an absorbent surface before replacing them.
• When removing the filters for cleaning, also clean off any residues of oil or fat from the now accessible housing
to prevent the risk of these catching fire.
When putting the grease filters back in position, ensure that the locking clips are facing down towards
the hob.
L60_90CHDB17_IB_RC_180906_grace.indd 12 6/9/18 12:29 pm

13
Carbon Filter Usage
Your product is compatible with one type of carbon filter (carbon filters are not provided).
• Before installing or replacing the carbon filters, you should switch off and disconnect the electricity supply.
• The carbon filters should never be washed.
• The grease filters should be installed on the product even when carbon filters are not being used.
Do not use your product without the grease filters.
Replacing Carbon Filters
• It is necessary to install 2 carbon filters in your product.
• Open all the grease filters, see page 7 for details.
• To attach the carbon filters, place them on the connection
channels on the motor and turn the left hand filter
anticlockwise and the right hand filter clockwise.
• In order to remove the carbon filters, turn the left hand
filter clockwise and the right hand filter anticlockwise.
• Replace the carbon filters when they no
longer absorb kitchen odours effectively.
They should, however, be replaced at least
every 3 months to prevent a risk of fire.
• Used carbon filters can be disposed of with
the normal household waste.
• Replace all the grease filters to the main unit.
Changing the Lamps
1. Press the plastic catch and take out the grease
filter.
2. Unscrew the lamp cover.
3. Pull out the LED light box and you will find a
connection box.
4. Disassemble the connection box and disconnect
the LED light box.
5. Replace with a new LED light box.
6. Screw the lamp cover and replace the grease
filter.
L60_90CHDB17_IB_RC_180906_grace.indd 13 6/9/18 12:29 pm

14
Hints and Tips
Problem Solution
Cooker hood does not operate
• CheckElectricconnection.
(The supply voltage should be 220-240 V. The cooker hood must
be connected to an earthed socket)
• Checkmotorspeedselector.
(Motor speed selector should be in position I, II or III)
Lamp does not light
• CheckElectricconnection.
(The supply voltage should be 220-240 V. The cooker hood must
be connected to an earthed socket)
• Checklampswitch.
(Lamp switch should be in the on position)
• Checklightbulbs.
Air suction of cooker hood is weak
• Checkaluminiumfilters.
(Aluminium grease filters should be washed once a month under
normal conditions)
• Checkairoutletchimney.
(Air outlet chimney should be open)
• Checkcarbonfilters.
(If the unit operates with carbon filters, they should be replaced
quarterly)
If Cooker Hood Does Not Operate
Before Contacting Service:
Be sure that the mains plug is connected to the mains socket and the fuse in the installation is in good condition.
Check your cooker hood according to the above table. If the problem continues, contact your retailer or an
authorised service agent.
L60_90CHDB17_IB_RC_180906_grace.indd 14 6/9/18 12:29 pm

15
Technical Specications
Model no. L60CHDB17 L90CHDB17
Extraction Rate (m3/h) 526.7 526.7
Voltage (V) 220 – 240 ~ 220 – 240 ~
Frequency (Hz) 50 50
Total Power (W) 102.5 105
Lamp 1 x 2.5 W 2 x 2.5 W
Features and specifications are subject to change without prior notice.
Product Fiche
Model no.: L60CHDB17
Symbol Value Unit
Annual Energy Consumption AEChood 56.9 kWh/a
Time increase factor f 1.7
Fluid Dynamic Efficiency FDEhood 8.7
Fluid Dynamic Efficiency class E
Energy Efficiency Index EEIhood 86.9
Energy Efficiency class D
Measured airflow rate at the best efficiency QBEP 306.6 m3/h
Measured air pressure at best efficiency point PBEP 91 Pa
Maximum airflow Qmax 526.7 m3/h
Air flow at working point (highest setting) 474.6 m3/h
Air flow at working point (lowest setting) 381 m3/h
Measured electric power input at best efficiency point WBEP 88.7 W
Nominal power of the lighting system WL2.5 W
Average illumination of the lighting system on the cooking surface Emiddle 99 lux
Lighting Efficiency LEhood 39.4 lux/w
Lighting efficiency class A
Grease Filtering Efficiency (%) GFEhood 79.2
Grease Filtering Efficiency (GFE hood ) class C
Measured power consumption on standby mode PS- W
Measured power consumption on off mode PO0 W
Sound power level LWA 58 dB
The above table indicate the information for the cooker hood. The test result is done as per the relevant
requirement of EU No 65/2014 and EU No 66 / 2014.
L60_90CHDB17_IB_RC_180906_grace.indd 15 6/9/18 12:29 pm

16
Model no.: L90CHDB17
Symbol Value Unit
Annual Energy Consumption AEChood 58.7 kWh/a
Time increase factor f 1.7
Fluid Dynamic Efficiency FDEhood 8.7
Fluid Dynamic Efficiency class E
Energy Efficiency Index EEIhood 87.9
Energy Efficiency class D
Measured airflow rate at the best efficiency QBEP 306.6 m3/h
Measured air pressure at best efficiency point PBEP 91 Pa
Maximum airflow Qmax 526.7 m3/h
Air flow at working point (highest setting) 474.6 m3/h
Air flow at working point (lowest setting) 381 m3/h
Measured electric power input at best efficiency point WBEP 88.7 W
Nominal power of the lighting system WL5.0 W
Average illumination of the lighting system on the cooking surface Emiddle 143 lux
Lighting Efficiency LEhood 28.6 lux/w
Lighting efficiency class A
Grease Filtering Efficiency (%) GFEhood 81.6
Grease Filtering Efficiency (GFE hood ) class C
Measured power consumption on standby mode PS- W
Measured power consumption on off mode PO0 W
Sound power level LWA 58 dB
The above table indicate the information for the cooker hood. The test result is done as per the relevant
requirement of EU No 65/2014 and EU No 66 / 2014.
L60_90CHDB17_IB_RC_180906_grace.indd 16 6/9/18 12:29 pm

17
Installation
Product Overview
1
2
3 4
5
6
1. Grill For Air Outlet
2. Internal Chimney
3. External Chimney
4. Internal Chimney Connection Plate
5. External Chimney Connection Plate
6. Hanging Plate
L60_90CHDB17_IB_RC_180906_grace.indd 17 6/9/18 12:29 pm

18
All dimensions shown are in mm.
273/276
302/303
40
55
20
400
400
500
600/900
40/80
440-820/
480-860
L60_90CHDB17_IB_RC_180906_grace.indd 18 6/9/18 12:29 pm

19
Min.650 mm
Safety Distance Between Hob and Cooker Hood
When planning the installation height of your cooker hood, the minimum safe distance between the
top of a cooker or hob and the bottom of the cooker hood should be at least 650mm, unless a greater
distance is specified by the manufacturer of your cooking appliance.
• When deciding on the safe distance between the hob and cooker hood, please note that a distance greater
than 650mm above electric cookers/hobs may be preferable to give more working space under the hood.
• Account should also be taken of the height of the person who will be using the hood most often. The person
should have sufficient space to work comfortably at the hob, and also be able to reach the hood controls with
ease.
• Please be aware that if positioned too high, extraction will be inefficient.
• If you want the top of the cooker hood telescopic extension piece to be mounted flush with the ceiling, make
sure there is adequate space below the appliance for safe operation.
L60_90CHDB17_IB_RC_180906_grace.indd 19 6/9/18 12:29 pm

20
Connection for Air Extraction
Only use smooth pipes or flexible hoses made from non-flammable materials for the extraction ducting.
To achieve the greatest possible air extraction with the lowest noise level, please note the following:
• To ensure efficient air extraction, the diameter of the exhaust ducting should not be less than
120mm.
• If flat ducting is being used, the cross-sectional area must not be smaller than the cross sectional area of the
exhaust connection.
• All ducting, pipework and fittings must be made of non-flammable materials.
• The exhaust ducting should be as short and straight as possible.
• Only use wide radius bends.
• The exhaust ducting should not be kinked or compressed.
• Ensure that all connections are strong and airtight.
• Where ducting is horizontal, it must be laid to slope away at least 1 cm per metre. This is to ensure that
condensation cannot drain back into the cooker hood.
• If the exhaust air is to be ducted into the open air, the installation of a telescopic wall vent or roof vent is
recommended.
To avoid the danger of toxic fumes, please observe the Safety Warnings.
This is especially crucial when using the cooker hood at the same time as another heating appliance
which relies on air from the same room.
The cooker hood should be installed according to the local and national building regulations. Seek
approval from the building inspector where necessary.
If the exhaust ducting is to run through rooms, ceiling space etc. where there may be great variations
in temperature between the different areas, the problem of condensation will need to be addressed.
The exhaust ducting will need to be suitably insulated.
L60_90CHDB17_IB_RC_180906_grace.indd 20 6/9/18 12:29 pm
