logika WL-ZOECNPW-B-01 User manual

© 2019 Logika Limited
Smart Doorbell
WL-ZOECNPW-B-01
Product Manual
Version 1.0

1
Logika Limited
E
-Centre, Massey University, Gate 5, Oaklands Road
Albany, Auckland 0632, New Zealand
www.logika.nz
·[e-mail]
Introduction
Thank you for choosing Logika. Please take a moment to carefully read through the manual to
ensure safe and proper installation and use.
•Before use, the product must be properly installed as described in this manual by a qualified
technician.
•The product should be used with the supplied accessories.
•Do not disassemble or modify the product.
•Logika is not responsible for any loss due to improper installation or use of this product.
•Please visit our official website at www.logika.nz for more information.
•You can also contact us at the following email address: [e-mail].

2
Device Layout
Status Indicator
System Indicator
Multi-Function
Key
Power Port
Front
Back

3
Features
•Communication Mode: IEEE 802.15.4 Zigbee.
•Used with doorbell button; Get prompts on phone.
•Can bind with other devices for expandability.
•Easy to install and operate.
•A variety of ring tones to select from.
Specifications
Communication Mode IEEE 802.15.4 Zigbee
Antenna Type Internal Antenna
Power 100 -240V AC, 50/60Hz
Standby Consumption 0.6 W
Max Power Consumption 2W
Alarm Decibel Adjustable
Overall Dimension (Diameter × Thickness) 98*45 (mm)
Material & Colour PC, White
Flame Retardant Rating UL94 V-0
Working Temperature -10°C - + 45°C
Working Humidity ≤95%RH (Noncondensing)
Installation Method Ceiling-Mounted
Net Weight 102(g)
Storage Temperature -20°C - +60°C

4
Installation Steps
Hardware Installation
There are 3 ways that the doorbell can be mounted on the ceiling or wall. Each option is described
below.
Note: The hole for the mains power is 10mm in diameter and the quick connector terminals will
accept 14-22 AWG cables.
Install Option 1
This install option is for the ceiling with a mounting hole between 68mm and 80mm in diameter. For
this option, you will need the main body of the Smart Doorbell and the Ceiling-Mounted Base.
1) Attach the Smart Doorbell to the Ceiling-Mounted Base by lining up the slots on the Smart
Doorbell to the Lock Plates on the Ceiling-Mounted Base unit. Turn clockwise to lock them
together.
2) Attach the power cable to the connector terminals.
Mounting Slots
Lock plates
Smart Doorbell Body
Ceiling-Mounted Base
Connect mains cable to terminals

5
3) Pull the Spring mounts up and push the unit through the hole in the ceiling.
Install Option 2
This install option is for mounting without the need for cutting large ceiling holes. For this, you will
need the Smart Doorbell, Wall-Mounted Base, wall plugs and screws (supplied).
1) Place the base onto the ceiling or wall and mark off where to drill.
2) Drill the holes (5mm) and insert the wall plugs.
3) Screw in the base to the ceiling, feeding the mains cable through the centre.

6
4) Connect the power cable to the Smart doorbell unit and attach to the Wall-Mounted Base
attached to the ceiling.
Install Option 3
This install option is similar to Install Option 2 but for situations where the cable can only be fed in
from the side (i.e. not through the ceiling). However, rather than using the Wall-Mounted Base, we
will be using the Ceiling-Mounted Base with the spring mounts removed.
1) Remove the spring mounts from the Ceiling-Mounted Base and place on the ceiling to mark
off the drill holes.
2) Drill the holes (5mm) and insert the wall plugs.
3) Screw in the base to the ceiling, feeding the mains cable through the side, as shown.
Original Location of Spring Mounts

7
4) Connect the power cable to the Smart Doorbell unit and attach to the base.
Adding the Device to the Smart Home Network
Use the Logika Smart Home app to add the device to the Smart Home system. Please refer to the
Logika Smart Mobile App user guide which will take you through the process of adding smart
devices to the system.
Refer to the information below to locate the device in the Device Add screen. Once selected, the app
will walk you through how to add the device to the system.
Device Category:
Security
Device Name:
Doorbell
Connect mains
cable to terminals

8
Device Functions
When the device is first powered on, it will normally automatically attempt to connect to the Zigbee
Smart Home network. The System Indicator light will flash as it’s searching for the network. If it
connects, the light will remain on for 2 seconds and then go out.
If this does not happen, you can manually connect via the mobile app and follow the instructions
below.
Join the Zigbee Network
Press the Multi-Function Button once. The System Indicator light will start flashing, signifying it’s
searching for the network.
When it successfully connects, the System Indicator light will stay solid for 2 seconds then go out.
System Indicator
Multi-Function Button

9
Binding the Doorbell to a Doorbell Button
1) Press the Multi-Function button 3 times in quick succession.
2) Press and hold the Smart Doorbell Button switch at the same time as tapping its Multi-
Function button 3 times in quick succession.
3) If the binding succeeds, the System Indicator on the Smart Doorbell and Smart Doorbell
Button will flash 3 times. On failure, it will flash 6 times.
Quit the Zigbee Network
Long press the Multi-Function Button for 6 seconds. The System Indicator light will flash 4 times and
go out. The device has now been successfully removed from the network.
Smart Doorbell Button
Multi-Function Button
