Logitech HD 200a User manual

Getting Started Guide
Logitech HD 200a Powerline Starter Kit
2 Network adapters
2 Ethernet cables
2 wall spacers
Documentation
Power-strip Warning!
Do NOT plug the network adapter into a surge protector or power strip as they
interfere with network communication. The network adapter(s) must be plugged
directly into your wall outlet. Surge protectors are built-in to the network adapter
and protect your devices.
1Logitech HD 200a Powerline Starter Kit
1) Plug one end of the Ethernet cable connector into the network adapter.
1a) Add the optional wall spacer.
1b) Plug the network adapter into the power outlet.
2) Connect the other end of the Ethernet cable connector into an open port on
your router.
21) Take the second network adapter and plug one end of the Ethernet cable
connector into the network adapter.
1a) Add the optional wall spacer.
1b) Plug the second network adapter into the power outlet by the device
you will be connecting to.
2) Connect the other end of the Ethernet cable connector into the ethernet
port of your device (i.e. gaming console, laptop, etc.).
3Turn the device on and test.
1
INTERNET
234
11b 2
*
Off
2
Welcome.
Thank you for purchasing Logitech HD Powerline products. With Logitech powerline
home products you can easily network devices in your home using your home’s
existing electrical wiring. No new wires to run, no networking hassles.
Logitech HD 200a Powerline Starter Kit
1a
11b
1a
Quick-start
guide
Logitech
HD Powerline 200a
Networking Starter Kit
Logitech
HD Powerline 200
Networking Adapter
System Requirements
& Support Guide
(not included)

Network Floor Plan
© 2010 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech
marks are owned by Logitech and may be registered. All other trademarks are the
property of their respective owners. Logitech® assumes no responsibility for any
errors that may appear in this manual. Information contained herein is subject to
change without notice.
620-003174.003
www.logitech.com
Software and advanced conguration
Logitech HD Powerline products come with 128 bit encryption to secure the power-
line network. To congure your network with advanced network security, please
download the Logitech Powerline Utility software at www.Logitech.com > Suppport >
Downloads.
Customer Support
1.888.469.4543 [U.S.]
LED Status Section
Network Adapter Diagnostic LEDs
What do these LEDs tell me?
Network Status LEDs
What do these LEDs tell me?
[Green] Trac and data is owing
[Yellow] Connection with Ethernet/LAN
[Green] Adapter getting power
[Blue] Network trac is owing
LED On/O Toggle Switch
How do I turn the LEDs o?
OFF ON
LED
Use the switch on the side of the network adapter to disable the diagnostic
and status LEDs.
Powerline adapters use
existing wall wiring
Logitech HD 200 Powerline Adapter
(sold separately)
Logitech HD 200 Powerline Adapter
(sold separately)
Logitech HD 200a Powerline Starter Kit
