Logitech ZONE VIBE 100 User manual

ZONE VIBE 100
Setup Guide
Guide d'installation

CONTENTS
English . . . . . . . . . . . . . . . . . . . 3
Deutsch . . . . . . . . . . . . . . . . . . 11
Français . . . . . . . . . . . . . . . . . .19
Italiano . . . . . . . . . . . . . . . . . . 27
Español . . . . . . . . . . . . . . . . . . 35
Português . . . . . . . . . . . . . . . . 43
Nederlands . . . . . . . . . . . . . . . . .51
Svenska. . . . . . . . . . . . . . . . . . 59
Dansk. . . . . . . . . . . . . . . . . . . 67
Norsk . . . . . . . . . . . . . . . . . . . 75
Suomi. . . . . . . . . . . . . . . . . . . 83
Ελληνικά . . . . . . . . . . . . . . . . . . .91
По-русски . . . . . . . . . . . . . . . . . 99
Po polsku . . . . . . . . . . . . . . . . . 107
Magyar . . . . . . . . . . . . . . . . . . 115
Česká verze. . . . . . . . . . . . . . . .123
Slovenčina . . . . . . . . . . . . . . . . 131
Українська. . . . . . . . . . . . . . . . .139
Eesti . . . . . . . . . . . . . . . . . . . 147
Latviski . . . . . . . . . . . . . . . . . . 155
Lietuvių . . . . . . . . . . . . . . . . . .163
Български . . . . . . . . . . . . . . . . . 171
Hrvatski . . . . . . . . . . . . . . . . . 179
Srpski . . . . . . . . . . . . . . . . . . .187
Slovenščina. . . . . . . . . . . . . . . .195
Română . . . . . . . . . . . . . . . . .203
Türkçe . . . . . . . . . . . . . . . . . . 211
219 . . . . . . . . . . . . . . . . . . . 
227 . . . . . . . . . . . . . . . . . . . 

KNOW YOUR PRODUCT
Front view:
Back view:
Microphone boom
Music controlbutton
(play/pause/
nexttrack)
USB-A receiver
Call button
(answer/end/reject calls)
Volume up/down
3English

Bottom view:
3-position switch
(power/Bluetooth®
pairing)
Mute button
USB-C port
LED light
4English

USB-C USB-C
BOX CONTENT
1. Zone Vibe 100 wireless headphones
2. Charging cable
3. Travel bag
4. User documentation
POWER ON/OFF
1. Slide the switch in the arrow’s direction
tothemiddle to power on the headphones.
2. Once powered on, the LED light will slightly
turnwhite.
3. There will be a voice prompt that tells you
thebattery status.
1
2
5English

LOGI Zone Vibe 100
2 sec.
CONNECT YOUR HEADPHONES
Connect via BLUETOOTH®
1. Slide the switch to the bottom in the arrow’s
direction for 2 seconds to initiate pairing.
2. The LED light will ash white rapidly.
3. Open Bluetooth®settings on your device.
4. Select Logi Zone Vibe 100 in discoverable devices.
5. Once successfully paired, the LED light will turn
solid white.
ADJUSTING HEADPHONES
1. Adjust the headphones by sliding earcups up
anddown the extended part of the headband.
2. It may be easier to adjust the headphones
on your head. Slide the earcups up and down
theheadband until they sit comfortably on
yourears.
6English

HEADPHONES CONTROLS
Note:
- Media control functionality depends on the type of application.
- Call activities are always the rst priority. When two Bluetooth®devices are connected,
the last active device will override the other.
Tip: Music EQ controls available on Logi Tune.
For UC controls:
Usage Button Action
Call controls Answer / End call Call button Short press
Reject call 2 sec. press
Music controls Play / Pause Music control button Short press
Track forward Double press
Volume Volume up "+" Short press
Volume down "-"
Connectivity Bluetooth®pairing Power button 2 sec. press
L L L
Voice notications indicate
when the microphone is on/
o mute.
Mute
"Mute on"
"Mute o"
MUTE
There are 2 ways to mute your microphone.
Press the button to mute. Flip up or down the mic
boom to mute or unmute.
7English

HEADPHONES LIGHT INDICATOR
Note:
- User-triggered behaviors, such as Bluetooth®pairing or link lost, will be prioritized then revert back to its previous status
once the behavior is completed.
Category Status Light
White
Power
Power ON Turn solid white and then dim
Battery charging Breathing
Battery fully charged Solid
Connectivity
Bluetooth®pairing Fast blinking
Bluetooth®connected Turn solid white and then dim
Link lost Dim white
Calls Active call Solid
Incoming call Slow blinking
Red Calls Mute Solid
Power Low battery (< 10%) Slow blinking
Factory reset Fast blink from red to white for
three times then LED turn o
CHARGING
To conserve battery life, headphones
automatically power o after 30 minutes
without usage.
Sleep timer could be adjusted in Logi Tune.
The LED light on the headphones will blink slowly
in RED when the battery is low.
Charging via USB cable
1. Plug one end of the cable to the USB-C port
onthebottom of the earcup and the other end
into the USB-C charging port on your computer.
2. The LED light will start breathing white when
charging.
3. The LED light will turn solid white when
fullycharged.
–2 hours will fully charge the battery.
– 5 minutes will give you 1 hour of playback.
4. The headphones can be used with Bluetooth®
paired while charging.
8English

LOGI TUNE
Logi Tune helps boost your headphones performance
withperiodic software and rmware updates.
It is recommended to update your headphones.
Todoso, download Logi Tune from
www.logitech.com/tune
www.logitech.com/tune
Logi Tune
ADJUSTING SIDETONE
Sidetone lets you hear your own voice during
conversations so you are aware of how loud
youaretalking. In Logi Tune, select the sidetone
feature, andadjust the dial accordingly.
 A higher number means you hear more
externalsound.
 A lower number means you hear less
externalsound.
AUTO SLEEP TIMER
By default, your headphones will automatically
power o when not in use for 30 minutes.
Adjustthe sleep timer in Logi Tune. To wake up
yourheadphones, try sliding o/on the power
switch again.
RESET YOUR HEADPHONES
1. Power the headphones on.
2. Press and hold the call button and volume ’–’
button for 5 seconds.
3. The LED light will quickly blink from red
towhite for 3 times and then turns o when
yourheadphones are successfully reset.
4. The headphones will turn o after reset.
9English

Headphones:
Height x Width x Depth: 183.03 x 169.68 x 73 mm
Weight: 0.185 Kg
Earpad:
Height x Width x Depth: 98.6 x 75.44 x 19.3 mm
DIMENSIONS
Works with common calling applications across almost all platforms and operating
systems.
Works with Windows®, Mac, or Chrome™ based computer via Bluetooth®and iOS
orAndroid™ Bluetooth®enabled devices.
SYSTEM REQUIREMENTS
Microphone Type: Dual omni-directional MEMS mics with directional beamforming
and DSP
Frequency response (Speaker): 20-20kHz (music mode), 100-8kHz (talk mode)
Frequency response (Microphone): 100-8kHz
Talk time up to 18 hrs
Listen time up to 20 hrs
Bluetooth®version: 5.2
Wireless range: Up to 30 m/100 ft (open eld line of sight)
Cable length (USB-C charging cable): 4.9 ft (1.5 m)
TECHNICAL SPECIFICATIONS
www.logitech.com/support/zonevibe100
