Logitech ZONE VIBE WIRELESS User manual

ZONE VIBE WIRELESS
Setup Guide

CONTENTS
English . . . . . . . . . . . . . . . . . 3
Deutsch . . . . . . . . . . . . . . . . 11
Français . . . . . . . . . . . . . . . . 19
Italiano. . . . . . . . . . . . . . . . .27
Español. . . . . . . . . . . . . . . . .35
Português . . . . . . . . . . . . . . .43
Nederlands . . . . . . . . . . . . . . 51
Svenska . . . . . . . . . . . . . . . .59
Dansk . . . . . . . . . . . . . . . . . 67
Norsk. . . . . . . . . . . . . . . . . .75
Suomi . . . . . . . . . . . . . . . . .83
Ελληνικά. . . . . . . . . . . . . . . . .91
По-русски. . . . . . . . . . . . . . . .99
Po polsku. . . . . . . . . . . . . . . 107
Magyar. . . . . . . . . . . . . . . . 115
Česká verze . . . . . . . . . . . . . 123
Slovenčina . . . . . . . . . . . . . . 131
. . . . . . . . . . . . . . 139
Eesti . . . . . . . . . . . . . . . . . 147
Latviski . . . . . . . . . . . . . . . . 155
Lietuvių. . . . . . . . . . . . . . . . 163
Български. . . . . . . . . . . . . . . .171
Hrvatski . . . . . . . . . . . . . . . 179
Srpski. . . . . . . . . . . . . . . . . 187
Slovenščina . . . . . . . . . . . . . 195
Română . . . . . . . . . . . . . . . 203
Türkçe . . . . . . . . . . . . . . . . 211
219 . . . . . . . . . . . . . . . . . ةيبرعلا
227 . . . . . . . . . . . . . . . . . תירבע

KNOW YOUR PRODUCT
Front view:
Back view:
Microphone boom
Music control button
(play/ pause/
nexttrack)
Volume up / down
Teams/ Call button
3English

Bottom view:
3-position switch (power /
Bluetooth®pairing) USB-C port
LED light
Mute button
4English

USB-C USB-C
BOX CONTENT
1. Zone Vibe Wireless
2. Charging cable
3. Travel bag
4. User documentation
POWER ON / OFF
1. Slide the switch in the arrow’s direction to
the middle to power on the headphones.
1
2
2. Once powered on, the LED light will slightly
turn white.
3. There will be a voice prompt that tells you
the battery status.
5English

CONNECT YOUR HEADPHONES
a. Connect via BLUETOOTH®
1. Slide the switch to the bottom in the arrow’s
direction for 2 seconds to initiate pairing.
2. The LED light will ash white rapidly.
3. Open Bluetooth®settings on your device.
4. Select Logi Zone Vibe Wireless in
discoverable devices.
5. Once successfully paired, the LED light will
turn solid white.
TROUBLESHOOTING:
1. If you encounter audio issues aer connecting
your headphones to your device, please slide
the switch in the Bluetooth®direction and
press the call bottom at the same time for
2 seconds.
2. Repeat the steps from 2-5 in the previous step.
3. If you have further connecting issues, please
reach out to www.logitech.com/prosupport/
zone-vibe-wireless
LOGI Zone Vibe
Wireless
LOGI Zone Vibe
Wireless
2 sec.
2 sec.
ADJUSTING HEADPHONES
1. Adjust the headphones by sliding
earcups up and down the extended
part of the headband.
2. It may be easier to adjust the
headphones on your head. Slide the
earcups up and down the headband
until they sit comfortably on your ears.
6English

HEADPHONES CONTROLS
Note:
- Teams activities are only functional when Teams is running on an unlocked PC or Mac.
- Media control functionality depends on the type of application.
- Call activities are always the rst priority. When two Bluetooth®devices are connected, the last active device will
override the other.
Tip: Music EQ controls available on Logi Tune.
MSFT Teams:
Usage Button Action
Call controls
Answer / End call
Call button
Short press
Reject call 1.5 sec. press
Resume call Short press
Transfer active call to other device
Team activities Invoke Teams Call button Short press
Music controls Play / Pause Music control button Short press
Track forward Double press
Volume Volume up "+" Short press
Volume down "-"
Connectivity Bluetooth®pairing Power button 2 sec. press
Voice notications indicate
when the microphone is on /
o mute.
MUTE
There are 2 ways to mute your microphone.
Press the button to mute. Flip up or down the mic
boom to mute or unmute.
L L L
Mute
"Mute on"
"Mute o"
7English

HEADPHONES LIGHT INDICATOR
Note:
- User-triggered behaviors, such as Bluetooth®pairing, will be prioritized then revert back to its previous status once
thebehavior is completed.
Category Status Light
White
Power
Power ON Turn solid white and then dim
Battery charging Breathing
Battery fully charged Solid and then o
Connectivity Bluetooth®pairing Fast blinking
Bluetooth®Turn solid white and then dim
Calls Active call Solid
Incoming call Slow blinking
Red Calls Mute Solid
Power Low battery (< 10%) Slow blinking
Factory reset Fast blink from red to white for
three times then LED turn o
CHARGING
To conserve battery life, headphones
automatically power o aer 30 minutes
without usage.
Sleep timer can be adjusted in Logi Tune.
The headphones LED light will turn RED slow
blinking when the battery is lower than 10%.
Charging via USB cable
1. Plug one end of the cable to theUSB-C port
on the bottom of the earcup and the other
end into the USB-C charging port on
yourcomputer.
2. The LED light will start breathing white when
charging.
3. The LED light will turn solid white when
fullycharged.
– 2 hours will fully charge the battery.
– 5 minutes will give you 1 hour of playback.
Note:
Battery life may vary based on user, environment,
andcomputing conditions.
4. You can use the headphones while charging.
8English

LOGI TUNE
Logi Tune helps boost your headphones
performance withperiodic soware
andrmwareupdates.
It is recommended to update yourheadphones
to the latest version. To do so, download and view
soware compatibility from logi.com/tune.
www.logitech.com/tune
Logi Tune
ADJUSTING SIDETONE
Sidetone lets you hear your own voice during
conversations so you are aware of how loud
you are talking.
In Logi Tune, select the sidetone feature, and
slide the adjustment bar accordingly.
 A higher number means you hear more
external sound.
 A lower number means you hear less
external sound.
AUTO SLEEP TIMER
By default, your headphones will
automatically power o when not in use for
30 minutes. Adjust the sleep timer in Logi
Tune. To wake up your headphones, try sliding
o/on the power button again.
RESET YOUR HEADPHONES
1. Power the headphones on.
2. Press and hold the call button and volume ’–’ button for
5seconds.
3. The LED light will quickly blink from red to white for
3timesand then turns o when your headphones are
successfully reset.
4. The headphones will turn o aer reset.
9English

Headphones:
Height x Width x Depth: 183.03 x 169.68 x 73 mm
Weight: 0.185 Kg
Earpads:
Height x Width x Depth: 98.6 x 75.44 x 19.3 mm
DIMENSIONS
Works with common calling applications across almost all platforms and operating
systems via Bluetooth®and iOS or Android Bluetooth®enabled devices.
SYSTEM REQUIREMENTS
TECHNICAL SPECIFICATIONS
www.logitech.com/prosupport/zone-vibe-wireless
Microphone Type: Dual omni-directional MEMS mics with directional
beamforming and DSP
Frequency response (Speaker): 20-20kHz (music mode), 100-8kHz (talk mode)
Frequency response (Microphone): 100-8kHz
Talk time up to 18 hrs *
Listen time up to 20 hrs *
Bluetooth®version (headphones): 5.2
Wireless range: Up to 30 m / 100  (open eld line of sight)
Cable length (USB C to A charging cable): 4.9  (1.5 m)
* Battery life was measured from fully charged to automatic shut-o, utilizing50% volume
forbothtalk time and listening time.
