Logjam Chameleon User manual

1
Logjam Chameleon®
Operaon Manual

2
Contents
3Front Panel Diagram
4Out Of The Box—Chameleon overview
5Quick Start Guide—Get stomping in minutes
6Chameleon Flow Diagram—Menu Structure
7Chameleon Channel Overview
8Channel 1 (internal) instrucons
9Channel 2 (AUX) instrucons
10 Channel 3 (Login) instrucons
11 Global Sengs
12 General Informaon
13 Mute Funcon
14 Baery Indicator / Charging
15 Glossary Of Terms

3
SD
Made In England
AUX
M
e
n
u
/ S
e
l
e
c
t
Logjam Chameleon Instrucons
Front Panel
6 5 4 3 2 1
1) Power Buon (Hold to power on. Hold to power o and conrm on menu select buon)
2) Auxiliary input (mini jack socket). (Channel 2)
3) Selector Switch (Turn to select funcon & push to change & save sengs)
4) Micro SD Card slot. Any capacity. Max speed recommended. Please note that the SD card MUST be
placed upside down, with the contacts facing upwards and the label facing downwards.
5) USB slot for powering and/or charging unit. (Use standard Android phone charger) Can also be used
for data input.
Login
LogOut
Side panels
7 8
7) Login - 6.35mm (1/4”) jack socket (Channel 3)
8) Logout - Neutrik combo XLR & 6.35mm (1/4”) jack socket (Audio Out)

4
Out Of The Box!
Thank you for buying one of our Chameleons! Before you take it out and perform with
it ‘in the wild’, we wanted to explain a few things so please bear with us. We know
reading instrucon manuals can be a chore.
We know you might want to get started with this straight away, so we have adjusted
the default sengs accordingly. This means that, using the ‘Quick Start Guide’ (in the
box and also available online either in our Complete Instrucons or separately), you
can be stomping within minutes using the percussion surface, either with your foot or
hand.
One of the best things about the Chameleon is that it can be as adaptable as you need
it to be and the more you learn about it, the more you can do.
It is a 3 channel device. This means you can play sounds using the touch sensive
surface, plug in an external stomper to the mono jack socket (AUX) in order to trigger
sounds this way, and use the (Login) 3rd input to add in an external instrument—this
could be your guitar or even another stomper.
You can load your own sound samples (including drum loops or backing tracks) onto a
micro SD card by transferring your sounds from your computer using a card reader.
Want a simple, plug-and-play kick-ass stomper that adds amazing thud and bass beats
to your music? No problem. Want to use your faithful old Logarhythm footdrum whilst
the Chameleon plays your snare sample and mix your guitar through Login? Easily
done. Don’t have enough inputs on your amp and want a 3-piece drum kit? The
Chameleon’s got your back. It’s even got a rechargeable baery which will last you
approximately 24 hours, so you don’t have to worry about doing outdoor gigs where
power sources may be limited.
However you want to get started, it’s OK. Scan through the Quick Start Guide and get
stomping. Take a seat and read through the Complete Instrucon Manual in depth
and learn all the secrets in one go… that’s ne, too. It’s shorter than War and Peace. Or
print o the Chameleon Menu Structure , pin it up on the wall and study it instead of
watching TV. That’s what the Chameleon is all about, at the end of the day— doing it
YOUR WAY.
Have fun! And if you want to get in touch with us, call ([phone]), email
([email protected]t) or send a carrier pigeon. We are always pleased to hear from our
customers with comments, suggesons or quesons.

Chameleon® Quick Start Guide Guide
Turn down volume on amp / mixer
Power switch ON then turn right, push to select Channel 1
Trigger ON
Select a sample drum sound
Set volume to approx. 50
Set retrigger delay to approx. 50ms
Set peak threshold to approx. 10
Set max peak value to between 100
Set pre amp gain to 4
Bring up amp/mixer to a moderate level and hit the
percussion surface with your hand or foot
If necessary, adjust the sengs referring to the instrucons on the PDF which you can download
from our website at www.logjam.net. These will also give you a proper understanding of all of your
Chameleon’s many funcons.
5

3
CH.1 (Chameleon)
push to select
Set volume
push to select /turn to exit
to next menu item.
Save to SD card
push to save, push to con-
rm /turn to exit
CH. 2 (AUX)
push to select
CH. 3 (LOGIN)
push to select
Global Sengs
(save/reset)
Reset to defaults
push to reset, push to con-
rm and exit
Set impedance
push to select /turn to exit
to next menu item.
Volume (0-63) = XX
turn to select volume level
then push to conrm & exit
Impedance= low / high
turn to select impedance
then push to conrm & exit
Trigger on/o
push to select / turn to exit
to next menu item.
Select sample
push to select / turn to exit
to next menu item.
Set sample volume
push to select / turn to exit
to next menu item.
Retrigger delay
push to select / turn to exit
to next menu item.
Peak threshold
push to select / turn to exit
to next menu item.
Max peak value
push to select / turn to exit
to next menu item.
Preamp Gain
push to select / turn to exit
to next menu item.
Select sample
push to select / turn to exit
to next menu item.
Set sample volume
push to select / turn to exit
to next menu item.
Retrigger delay
push to select / turn to exit
to next menu item.
Peak threshold
push to select / turn to exit
to next menu item.
Max peak value
push to select / turn to exit
to next menu item.
Preamp Gain
push to select / turn to exit
to next menu item.
Volume (0-63) = XX
turn to select sample volume level then push to
conrm & exit
Bass / Treble (Tone Control)
push to select /turn to exit
to next menu item.
Treble / Bass
turn to select then push to
connue
Treble (+/- 50) = XX
turn to select then push to
conrm & exit
Bass (+/- 50) = XX
turn to select then push to
conrm & exit
Select sample
turn to select,sample , push twice to conrm /
turn to exit
Select sample
turn to select sample, push twice to conrm /
turn to exit
(0-20) = XX
turn to select preamp gain level then push to
conrm & exit
(1-1000ms) = XX
turn to select retrigger delay me then push to
conrm & exit
Range (1-100) = XX
turn to select peak threshold range then push to
conrm & exit
(1-100) = XX
turn to select max peak value level then push to
conrm & exit
Volume (0-63) = XX
turn to select sample volume level then push to
conrm & exit
(0-20) = XX
turn to select preamp gain level then push to
conrm & exit
(1-1000ms) = XX
turn to select trigger delay me then push to
conrm & exit
Range (1-100) = XX
turn to select peak threshold range then push to
conrm & exit
(1-100) = XX
turn to select max peak value level then push to
conrm & exit
Trigger ON-
push to
select / turn to
exit
Trigger OFF
Switch o for
audio input
Set impedance
push to select /turn to exit
to next menu item
Impedance= low / high
turn to select impedance then push to conrm
& exit
Set volume
push to select / turn to exit
exit to next menu item
Volume (0-63) = XX
turn to select volume level then push to conrm
& exit
Chameleon (home screen)
push to select channel
NB: Push menu/select knob for 3 seconds at ANY me to
return to main menu.
On / O
Turn to select, push
to conrm and exit
Logjam Chameleon Menu Structure

7
Logjam Chameleon Channel Overview
The Chameleon is a 3 channel device. Please refer to the ow diagram on page 6, and
to the brief descripon below:
Channel 1 (internal) is set up for you to play samples using the touch-sensive
percussion surface of the unit itself.
Channel 2 or “AUX” is set up for you to trigger sounds from an external stomper via
the 3.5mm mono jack socket. You may need to use a cable with a 6.35 mm jack at
one end and a 3.5mm at the other end (you can purchase these on our website).
Channel 3 or (Login) allows you to mix in an external instrument. You could, if you
want, put another stomper through this input but you could equally put a guitar
through this jack. This input has a tone control so that you can adjust the tone of
your instrument on this channel.
All three channels access the same balanced Neutrik combo “LogOut” socket. This
allows you to use either a standard guitar cable or a balanced XLR cable. You will
need a male to male adapter if you want to use an XLR cable.. (These cables are
available on our website: www.logjam.net).
We will now show you how to use the unit. In order to make things simple we will
give you separate instrucons for each channel and for the global sengs. Upon
turning the unit o, your sengs will automacally be saved. If there are any terms
that you are unfamiliar with (such as impedance), please refer to the glossary on
page 15.
To switch on, hold and press the power buon ( to switch o hold the buon and
conrm on the menu select buon)
Now please turn to the next page ...
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

8
Channel 1 (Internal) Instrucons
1) Trigger On/O : This determines whether the touch sensive surface of the
unit will be switched on or o. Push to select then turn for on/o. Push again
to conrm and exit. Turn for next menu item.
2) Select Sample : This allows you to select from a menu of preset samples and
also those you may have programmed into a micro SD card. Push to select item
then turn to select samples. Push twice to conrm your choice . Turn for next
menu item
3) Set Volume: This determines the channel 1 volume. The graphic image shows
minimum to maximum from boom to top of the display. Push to select item.
Turn to select the desired volume then push again to conrm and exit. Turn for
next menu item.
4) Retrigger Delay: This determines the me it takes in milliseconds before you are
able to trigger the selected sample again. A typical useful value would be 50
ms. Push to select item, turn to select value then push again to conrm and
exit. Turn for next menu item.
5) Peak Threshold: This determines the level below which the unit will not trigger
a sample. This is necessary to avoid samples being triggered by background
noise. The level has a seng between 1-100. Push to select item, turn to select
value then push again to conrm and exit. Turn for next menu item.
6) Max Peak Value: This seng limits the peak volume of the sample selected. It is
handy in order to avoid feeding too high a signal into your amp/mixer. This
seng has a range of 1-100. Push to select item, turn to select value then push
again to conrm and exit. Turn for next menu item.
7) Preamp Gain: This seng is similar to the gain seng on a mixer or amp. It
determines the signal level fed into the internal electronics. Push to select item,
turn to select value then push again to conrm and exit. Turn for next menu
item.
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

9
Channel 2 (AUX) Instrucons
1) Impedance High/Low : This determines whether the input impedance is “HIGH”
or “LOW”. Push to select item, turn to select then push again to conrm and
exit. Turn for next menu item.
2) Set Volume: This determines the channel 2 volume. The graphic image shows
minimum to maximum from boom to top of the display. Push to select item,
turn to select the desired volume then push again to conrm and exit. Turn
for next menu item.
3) Trigger On/O, This determines whether the channel 2 input can be used to
trigger samples (ON) or alternavely to be used as an audio input (OFF). Push to
select item, turn to select “On” or “O”, then push again to conrm and exit.
Turn for next menu item.
4) Select Sample : This allows you to select from a menu of preset samples and
also from those you have programmed into a micro SD card. Push to select the
item, then turn to run through the list of samples. Push twice to conrm your
choice .Turn for next menu item.
5) Set Sample Volume: This selects the individual volume of the chosen sample.
Push to select the item, turn to select the desired volume then push again to
conrm and exit. Turn for next menu item.
6) Retrigger Delay: This determines the me it takes in milliseconds before you are
able to trigger the selected sample again. A typical useful value would be 50 ms.
Push to select item, turn to select value then push again to conrm and exit.
Turn for next menu item.
7) Peak Threshold: This determines the level below which the unit will not trigger
a sample. This is necessary to avoid samples being triggered by background
noise. The level has a seng between 1-100. The lower the level, the more
sensive the unit is; for example a small shue of your foot or a sound in the
background. Push to select, turn to select value then push again to conrm and
exit. Turn for next menu item.
8) Max Peak Value: This seng limits the peak volume of the sample selected. It’s
handy in order to avoid feeding too high a signal into your amp/mixer. This
seng has a range of 1-100. Push to select item, turn to select value then push
again to conrm and exit. Turn for next menu item.
9) Preamp Gain: This seng is similar to the gain seng on a mixer or amp. It
determines the signal level fed into the internal electronics. Push to select item,
turn to select value then push again to conrm and exit. Turn for next menu
item.

10
1) Impedance High/Low : This determines whether the input impedance is “HIGH”
or “LOW”. Push to select item, turn to select your choice, then push again to
conrm and exit. Turn for next menu item.
2) Set Volume: This determines the channel 3 (Login) volume. The graphic image
shows minimum to maximum from the boom to top of the display. Push to
select item, turn to select the desired volume then push again to conrm and
exit. Turn for next menu item.
3) Select Bass/Treble (Tone) : This allows you to control the tone of the instrument
connected to the “Login” socket. Push to select item. Turn to select tone control
choice (bass or treble) ,push to conrm then turn to adjust the tone (-50-+50).
Push again to conrm and exit. Turn to go to next menu item.
Channel 3 (Login) Instrucons
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

11
1) Reset to defaults: This seng takes you back to the factory defaults. Push to
select item, push again to save or turn to exit.
2) Save to memory: This allows you to save your sengs so that the unit will boot up
next me you switch on with your saved parameters. Push to save and push again to
conrm or turn to exit.
This funcon is in addion to the fact that the unit will automacally save your
sengs on shutdown.
Global Sengs
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

12
General Informaon
Power & Charging
The Chameleon takes an 18650 Li-ion baery . These are readily available but you
can also purchase them from our website. The unit can also run from a standard
Android phone charger which aaches to the micro USB socket on the front panel.
This is also used to charge the baery.
Micro SD Card & Samples
The unit comes with 10 preset 16 bit samples (44.1 khz) which are in the internal
memory . These are idened on the display with 2 underscore lines. These drum
samples have been especially created by experienced UK session drummer Terl
Bryant. We also have a micro SD card available with a large range of samples (also
created by Terl Bryant) which is available from our site.
You can record your own samples and loops, of course. These should be at 44.1 khz
and 16 bit.
Care of Your Chameleon
The Chameleon is made from high-quality Sapele wood. When it gets to be a lile
worn you can lightly sand the wooden area and renish with Linseed oil applied
sparingly with a so cloth. Be careful not to get any oil on any other area of the unit.
We would also recommend that you always transport your Chameleon in the
provided gigbag as this will help to prevent any possible damage.
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

13
Mute Funcon
We have installed a mute feature on the Chameleon which is a useful on-stage
funcon that will prevent any signal going to the amp or mixing desk at all. To use
this feature, scroll through the main menu past Global to Mute. To turn the mute
funcon either on or o, simply press once to toggle (either on or o) and then push
again to conrm. You can then exit the mute menu by scrolling out of it or a long
push will return you to the Chameleon default screen.
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

14
Baery Indicator / Charging
Your Chameleon has an operaon mer which is the vercal line on the le hand
side of the display. This is a 24 hour mer which counts down 24 hours of the unit
being on. This will gradually get smaller over me. When the Chameleon has been
running for nearing 24 hours, this bar will begin to ash and upon reaching the 24
hour mark, will disappear completely. You may have baery life le aer this mer
has disappeared, but to ensure you have 24 hours’ worth of use, you may wish to
charge your unit at this me.
If the baery becomes crically low, your Chameleon will display the following
messages on the screen:
WARNING
LOW BATTERY
SAVING STATE
Followed by:
WARNING
POWERING DOWN
STATE SAVED
20 sec.. (counng down)
This countdown will start at 20 and when it reaches 0, will turn the Chameleon o
automacally. If, during this countdown, or low baery alert, you plug in the unit to
charge, the warning will disappear and the unit will begin to charge. You may
connue to use the unit whilst it is charging. When you charge the unit, the
operaon mer will ash on and o to indicate that it is successfully charging. When
the Chameleon is fully charged, the operaon mer will stop ashing. The operaon
mer is NOT a baery level indicator.
NB: Push menu/select knob for approximately 3 seconds at ANY me to
return to main menu.

15
Glossary of terms
Channel 1 - This is the internal channel of the Chameleon and allows you to play
samples using the touch-sensive surface of the Chameleon itself.
Channel 2 - (AUX) allows you to trigger sounds from an external stomper via the 3.5mm
mono jack socket.
Channel 3 - (Login) allows an external instrument to be plugged in to your Chameleon.
Gain - Gain is the level of the signal that is being fed into the internal electronics. If you
increase the gain, you will increase the signal you feed in, and vice versa.
Impedance - Audio devices are either high or low impedance, guitars typically are high
impedance whereas a dynamic microphone will be low impedance. However, if you are
unsure of the impedance of the instrument you are plugging in to the Chameleon you
can try experimenng with the other impedance seng. Also, if you nd that you are
geng too weak a signal or alternavely too high a signal, you can try toggling the
impedance to see if there is an improvement.
Neutrik Combo Socket—This is a high quality socket made by Neutrik. The advantage of
this is you can plug in a standard guitar cable (1/4” 6.35mm) or alternavely, an XLR
cable. An XLR cable is a 3 pin cable and the advantage of this is that it is a balanced low
noise cable and will help to get rid of any extraneous noise. If you wish to use the XLR
opon you will need a XLR male to male adaptor (available to buy from our website at
logjam.net)
