Lonking CDM835EV.00I User manual

1
PREFACE
Thank you for purchasing LONKING’s wheel loader!
This Manual briefly describes the safety, operational and maintenance requirements of
CDM835E Ⅴ.00I/CDM835E Ⅹ.00I wheel loaders for the use and reference by operators,
maintenance and technical management personnel.
Operation Manual is a guide for proper use and maintenance of this machine. Please
carefully read and understand the contents of this Manual before operating this machine.
Please put this Manual in driver’s cab for convenience of reference at any moment. If you
lose this Manual, please contact our sales department for buying a new one.
Many failures arise as a result of operator’s failure to carefully read this Manual and other
human reasons. A high sense of safety and good maintenance enable the safe and
efficient operation of this machine, thus bringing you more benefits. Therefore, please
read and understand safety instructions before operating this machine and fully comply
with them. Improper operation, lubrication, maintenance and repair of this machine are
dangerous and may result in human casualties.
We will continue to increase the working efficiency of the machine by improving product
design and endeavoring to improve the comprehensive product performances. The
parameters and configurations of the machine in this Manual are subject to change
without notice. The technical parameters contained herein shall not serve as the basis for
any inspection or test.
In order to offer better services to you and improve product and service quality, you are
expected to timely inform us of any problem identified during your use of LONKING
products and this Manual, along with any corresponding improvement opinions.
This Manual is its first version (No. 60900003039).
Best wishes for your business!
LONKING Holdings Limited
September 2015
