Lonpoo LP-700 User manual

USER MANUAL
LP-700
MINI BLUETOOTH SOUND BAR

Instruct ions
Important safety information
· Product size:500MM(Length)*50MM(Depth)*50MM(Height)
Driver Unit:40MM*4·
Output power:10W·
SNR:>95db·
Power supply:USB DC 5V·
Impedance:4Ω·
Distortion Factor:THD+No.1%·
Frequency Response:80Hz-20KHz·
Specifications
· Read and follow all these instructions.
· The device must not be exposed to drips or splashes. No object filled
with liquid, such as a vase, should be placed on the device.
· No naked flame, such as a lighted candle, should be placed on the
device.
· Keep the device away from sunlight, naked flames and any heat
sources.
· Never remove the casing from this product.
· Never place the product on any other electrical equipment.

①. Earphone output
-3.5mm stereo earphone output
②. Mic output
③. Remote control receive window.
④. Knob
-Power on/of (Press and hold for 2 seconds to turn on
or turn off)
-Volume adjustment(Turn up and down to adjust volume)
-Bluetooth/AUX (Short press to choose Bluetooth
or AUX mode)
Operation chart
2
13
4

·On Bluetooth output mode, skip to the previous or next songs.
(Note: Only bluetooth status use.)
⑥
Remote control
LED Indicator Instruction
· The white LED is on lit, it means the unit is on AUX input mode.
· The Blue LED twinkles quickly, it means the unit bluetooth function
turns on and enter into match status.
· The Blue LED stops twinkling and keeps being on lit all the time,
it means the bluetooth connection is successful, and ready for
playing music.
①②
③
④
⑥
③
④
⑥
⑤
①
②
③
⑤
·Play/pause
④
·Volume up/down
·BLUETOOTH
·AUX Input
SOURCE
·Mute on/off
Power Switch
·Turn on/turn off to
standby mode

USING
1、 Bluetooth:
· Press and hold "Knob" for 2seconds to turn on the bluetooth soundbar,
the blue LED twinkles quickly it indicates that the speaker is on matching
status. Turn on your bluetooth player device and search until it search out"
LP-700", and then connect the speaker immediately. When a "hint"sound
comes out, and the Blue LED stops twinkling and keeps being on lit all the
time, it means you can play the music now.
2、 Aux:
· Short press "Knob", the blue LED turn into white LED, connect AUX
cable to your devices.
NOTE: USE WITH A TV
· Please checked the TV whether supports BLUETOOTH or AUX OUT
（if your TV is only with AUX IN, then our device don't support） funciton
firstly.

Use with a computer
3、Turn the central wheel on the sound bar to the right to switch on the
device and adjust the volume.

Use with a TV equipped with RCA outputs
1、 Insert the USB plug into the mains adapter supplied.
2、 Insert the green audio input plug (2) into the RCA adapter supplied(1).
3、 Insert the red and white plugs of the RCA adapter into the
"Audio OUT" TV sockets, matching colour to colour.
4、 Turn the central wheel on the sound bar to the right to switch on the
device and adjust the volume.

Use with a TV that is not equipped with RCA outputs
1、 Insert the USB plug into the mains adapter supplied.
2、 Insert the audio input plug (green plug) into the headphone jack of
your TV
3、 Turn the central wheel on the sound bar to the right to switch on the
device and adjust the volume. Technical characteristics
Dimensions: 50*6.5*6.5 cm
Power: 10 W
Technical characteristics
The separate collection and recycling of electrical and electronic
equipment became mandatory for all electrical or electronic equipment
sold in the European Union market after August 13, 2005. The use of the
"crossed rubbish bin" symbol means that this product must not be
disposed of along with unsorted domestic refuse. By making sure that this
product is properly disposed of at a suitable collection point for the
recovery and recycling of waste, you will be contributing to the
preservation of the environment and the protection of human health.
Information for users on the recycling of
waste from electrical or electronic appliances
MADE BY SHENZHEN LONGPING ELECTRONICS CO., LTD
Email:[e-mail]
