Lorex VQ1732 User manual

VANDAL PROOF COLOR POLYCARBONATE
DOME CAMERA WITH 3 BOARD LENS
Owners Manual
Please read the manual thoroughly before operating this unit.
VQ1732

CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
!
CAUTION! TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF TWO SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of un-insulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance-
(servicing) instructions in the literature accompanying the appliance.
THE GRAPHIC SYMBOLS WITH SUPPLEMENTAL MARKING ARE ON THE BOTTOM OF
THE SYSTEM.
“WARNING – TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THE UNIT TO
RAIN OR MOSITURE”
IMPORTANT SAFETY INSTRUCTIONS
This wireless A/V equipment is provided with a polarized alternating-current line plug (a plug
having one blade wider than the other). This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing
the plug. If the plug still fail to fit, contact your electrician to replace your obsolete outlet. Do
not defeat the safety purpose of the polarized plug.
CONTENTS AND PARTS IDENTIFICATION:
This Package Contains:
!
1 – Vandal Proof Polycarbonate
Dome with 3 ¼” CCD Color
Cameras
12V DC Power Supply RCA/BNC Coupler
-1-

INTRODUCTION:
Congratulations on your purchase of this Vision Q Vandal Proof Color Dome Camera. This Dome camera comes with
a Polycarbonate construction to provide high impact protection. The heavy duty all metal base with swivel
bracket and tamper proof hardware adds extra protection against possible vandalism. This Dome camera can be
tilted 90° for optimum angle selection.
CONNECTING VISION Q CAMERA TO A 2 PAGE / 8 CHANNEL QUAD OBSERVATION SYSTEM
1. Mount the camera to the ceiling.
2. Connect the video extension cable (not included) from the camera to the monitor
3. Connect the power extension cable (not included) to the supplied power 12V DC adaptor
4. Attach the video extension cable to the monitor’s camera inputs (see diagram below)
5. Attach the supplied 12V DC power supply to the power extension cable and plug into an electrical outlet
6. Turn your monitor ON and select the desired channel to see the picture.
7. Repeat above procedures for connecting all 3 cameras to the monitor
CONNECTING CAMERA TO A SINGLE PAGE QUAD OBSERVATION SYSTEM
1. Mount the camera to the ceiling.
2. Connect the video extension cable (not included) from the camera to the monitor
3. Connect the power extension cable (not included) to the supplied power 12V DC adaptor
4. Attach the video extension cable to the monitor’s camera inputs (see diagram below)
5. Attach the supplied 12V DC power supply to the power extension cable and plug into an electrical outlet
6. Turn your monitor ON and select the desired channel to see the picture.
7. Repeat above procedures for connecting all 3 cameras to the monitor
BACK VIEW OF 2 PAGE 8 CHANNEL QUAD MONITOR
BNC INPUTS
VANDALPROOF
COLOR DOME CAMERA
VIDEO EXTENSION CABLE
(NOT INCLUDED)
CAMERA 1
CAMERA 2
CAMERA 3
BACK VIEW OF SINGLE PAGE QUAD MONITOR
BNC INPUTS
VANDALPROOF
COLOR DOME CAMERA
VIDEO EXTENSION CABLE
(NOT INCLUDED)
CAMERA 1
CAMERA 2
CAMERA 3
-2-

TROUBLE SHOOTING:
If the camera does not function properly, check the following points. If you continue to have problems, please call our
Toll Free Customer Support line for assistance.
PROBLEMS CAUSE AND REMEDIES
NO PICTURE DC ADAPTOR NOT PLUGGED IN
MONITOR NOT TURNED TO CORRECT
MODE OR CHANNEL
POOR PICTURE QUALITY CLEAN THE CAMERA LENS
ADJUST THE CONTRAST OR BRIGHTNESS CONTROL
OF YOUR MONITOR
FOR MORE INFORMATION
FOR MORE INFORMATION
OR TO SEE THE COMPLETE RANGE OF LOREX PRODUCTS
OR TO SEE THE COMPLETE RANGE OF LOREX PRODUCTS
PLEASE VISIT OUR WEBSITE:
PLEASE VISIT OUR WEBSITE:
WWW.STRATEGICVISTA.COM
WWW.STRATEGICVISTA.COM
TECHNICAL SPECIFICATIONS
Image Sensor ¼” CCD Color
Pixels 510 x 492
Scanning System Internal Sync
Resolution 330 lines
Min Illumination 1.0 lux
S/N Ratio More than 48 db
White Balance Auto White Balance
Electronic Shutter 1/60 – 1/100,000 sec
Lens 2.5mm
Power Consumption 12 V DC, 500mA
Operational Temp. -26°- 122°F
Dimensions 5 7/8” Dia x 4” H
Weight 29.2 oz
ALWAYS USE DISCRETION WHEN INSTALLING VIDEO AND/OR AUDIO SURVEILLANCE EQUIPMENT
WHEN THERE IS PERCEIVED PRIVACY. INQUIRE REGARDING FEDERAL, STATE AND/OR LOCAL
REGULATIONS APPLICABLE TO THE LAWFUL INSTALLATION OF VIDEO AND OR AUDIO RECORDING
OR SURVEILLANCE. PARTY CONSENT MAY BE REQUIRED.
BECAUSE OUR PRODUCTS ARE SUBJECT TO CONTINUOUS IMPROVEMEMT, SVC RESERVES THE RIGHT TO MAKE PRODUCT MODIFICATION
WITHOUT NOTICE AND WITHOUT INCURRING ANY OBLIGATION. E&OE
