Lorex ACSOL2 Series User manual

Solar Panel
Quick Start Guide
ACSOL2 Series
lorex.com
En

Package contents
User-supplied tools
• Solar panel with 10ft (3m) power cable
• Wall mount
• Wall mount template
• Wall mount screws & anchors (×4)
• Adjustment ring screws (x2)
• 1/4” (6mm) Drill bit for cement and wood
• Cable guides, screws & anchors (×3)
• Velcro cable tie
• Drill
• Phillips screwdriver
1

Dimensions
4.7"
120mm
4.5"
115mm
5.4"
137mm
2
7”
178mm
6.1”
156mm
1”
25mm
2.9”
73mm
Solar panel
Front and side panel
Wall mount
Front and side view

Position the solar panel
• The solar panel produces power only when exposed
to sunlight. You will need to choose a location with
plenty of direct sunlight.
• To achieve the best charging performance, angle
the solar panel towards the sun. The optimal
angle varies throughout the year, depending on the
seasons and your location. As a general guideline,
the solar panel should be facing the equator; in the
northern hemisphere, the solar panel faces south
and in the southern hemisphere, the solar panel
faces north.
• Make sure the red LED indicator on the back of
the solar panel turns on (see Figure 1). If the LED
turns on, the solar panel is receiving enough light to
maintain the camera battery pack’s charge.
3
Figure 1:
Back panel
3WattSolar Panel
ModelNo.:ACSOL2-CT
Power: 3.00 W
Voltage: 5.10 V
LOREXTEC HNOLOGYINC.
www.lorex.com
20181200001 Made in China
Red LED indicator
Tip: Periodically clean the solar panel with a soft
cloth and warm water to keep the surface clear.

Select your installation method
Install your wire-free camera directly
onto the solar panel, see pages 8-11.
4
Install your wire-free camera and solar
panel separate from each other, see
pages 5-7.
Option A (recommended):
Installing the solar panel separately
Option B:
Installing the solar panel and
camera together
ATTENTION: For option B, the camera
and solar panel should be installed facing the
residence. If the camera is installed backing
onto the residence, the wall mount may block
the wireless signal.

4
Option A - Installing the solar panel separately
1. The solar panel is designed
to maintain the camera
battery pack’s charge. Make
sure to rst charge the
battery pack using the micro
USB cable.
2. Stick the wall mount
template in the desired
mounting position.
3. Drill into the wall mount
template’s marked holes
using the 1/4” (6mm) drill bit.
If attaching to masonry,
gently tap four anchors into
the holes.
4. Secure the wall mount using
four screws (see Figure 1).
5
Figure 1

6
5. Loosen the wall mount’s adjustment
ring by turning it counterclockwise
(see Figure 2).
6. Angle the rotating adjustment screw
45° away from the mounting surface
(see Figure 2).
7. Twist the solar panel onto the wall
mount. Be careful not to hit the
mounting surface.
8. Adjust the angle of the solar panel to
receive direct sunlight, then tighten
the adjustment ring.
9. Use a Phillips screwdriver and the
adjustment ring screw to secure the
adjustment ring from underneath the
wall mount (see Figure 2).
Adjustment ring
Figure 2
Option A - Installing the solar panel separately

7
10. Run the solar panel’s power cable along
the cable guide on the wall mount arm
(see Figure 3).
11. Pull up the power port cover on the back
of your camera.
12. Use the solar panel’s power cable to
connect to the power port (see Figure 3).
Option A - Installing the solar panel separately
Figure 3
Figure 4
Optional cable management:
• Use the adjustable Velcro cable tie to
secure cords and organize any clutter.
• Secure the solar panel’s 10ft (3m) power
cable to the wall using the cable guides,
screws, and anchors as needed
(see Figure 4).

Option B - Installing the solar panel and camera together
1. The solar panel is designed to
maintain the camera battery pack’s
charge. Make sure to rst charge the
battery pack using the micro USB
cable.
2. Stick the wall mount template in the
desired mounting position.
3. Drill into the wall mount template’s
marked holes using the 1/4” (6mm)
drill bit. If attaching to masonry,
gently tap four anchors into the holes.
4. Secure the wall mount using four
screws (see Figure 1). 8
ATTENTION: The camera can be installed onto the solar panel only if the camera is
facing the residence. If the camera is installed backing onto the residence, the wall mount may
block the wireless signal. We recommend installing the solar panel and camera separately, see
pages 5-7.
Figure 1

5. Loosen the wall mount’s
adjustment ring by turning it
counterclockwise (see Figure 2).
6. Angle the rotating adjustment
screw 45° away from the mounting
surface (see Figure 2).
7. Twist the solar panel onto the wall
mount. Be careful not to hit the
mounting surface.
8. Adjust the angle of the solar panel
to receive direct sunlight, then
tighten the adjustment ring.
9. Use a Phillips screwdriver and
the adjustment ring screw to
secure the adjustment ring from
underneath the wall mount
(see Figure 2).
9
Adjustment ring
Figure 2

Option B - Installing the solar panel and camera together
10
10. Use a Phillips screwdriver and two
screws to attach the camera’s
mounting plate to the wall mount
(see Figure 3).
11. Align the four tabs from the
camera’s bracket with the four
slots on the mounting plate
(see Figure 4).
12. Push down to lock the camera.
13. Run the solar panel’s power cable
along the cable guide on the wall
mount arm (see Figure 3).
Figure 3
Camera bracket Mounting plate
Cable guide

11
Figure 4
Optional cable management:
Use the adjustable Velcro
cable tie to secure cords and
organize any clutter.
14. Pull up the power port cover on the
back of the camera.
15. Use the solar panel’s power cable
to connect to the camera’s power
port (see Figure 3).

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
Copyright © 2021 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves the right to modify product design,
specications and prices, without notice and without incurring any obligation. E&OE. All rights reserved.
Need help?
Visit help.lorex.com for up-to-date information and resources:
• Register your product
• Download product guides
• Watch how-to-videos
• Find related troubleshooting tips & FAQs
ACSOL2_QSG_TRILINGUAL_R1
Please see our full Terms of Service and Limited Hardware Warranty Policy at
lorex.com/warranty.
Panneau solaire
Guide de démarrage rapide
SérieACSOL2
lorex.com

Panneau solaire
Guide de démarrage rapide
SérieACSOL2
lorex.com
Fr

Contenu de l’emballage
Outils à fournir par l’utilisateur
• Panneau solaire avec câble d’alimentation de 3m (10pi)
• Support mural
• Modèle de support mural
• 4vis et ancrages pour support mural
• 2vis de la bague de réglage
• Foret de 6mm (1/4po) pour ciment et bois
• 3guides de câble, vis et ancrages
• Attache de câble en velcro
• Une perceuse
• Tournevis Phillips
1

Dimensions
120mm
ou 4,7po
115mm
ou 4,5po
137mm
ou
5,4po
2
178mm
7po
156mm
ou 6,1po 25mm
ou 1po
73mm
ou 2,9po
Panneau solaire
Panneau avant et
panneau latéral
Support mural
Vue de face et
vue latérale

Placez le panneau solaire
• Le panneau solaire produit de l’énergie uniquement lorsqu’il
est exposé à la lumière du soleil. Vous devrez choisir un
endroit où la lumière directe du soleil est abondante.
• Pour obtenir des performances optimales en matière de
charge, orientez le panneau solaire vers le soleil. L’angle
optimal varie tout au long de l’année, en fonction des
saisons et de votre emplacement. Généralement, le panneau
solaire doit être orienté vers l’équateur; dans l’hémisphère
nord, le panneau solaire est orienté vers le sud et dans
l’hémisphère sud, le panneau solaire est orienté vers le nord.
• Assurez-vous que le voyant DEL rouge situé à l’arrière du
panneau solaire s’allume (voir gure1). Si la DEL s’allume,
cela signie que le panneau solaire reçoit susamment de
lumière pour maintenir la charge du bloc-piles de la caméra.
3
Figure1:
Panneau arrière
3WattSolar Panel
ModelNo.:ACSOL2-CT
Power: 3.00 W
Voltage: 5.10 V
LOREXTEC HNOLOGYINC.
www.lorex.com
20181200001 Made in China
Voyant DEL rouge
Conseil: Nettoyez régulièrement le panneau solaire à l’aide d’un
chiffon doux et d’eau chaude an de garder la surface propre.

Sélectionnez votre méthode d’installation
Installez votre caméra sans
l directement sur le panneau
solaire, voir pages8 à 11.
4
Installez votre caméra sans
l et votre panneau solaire
séparément, voir pages5 à 7.
OptionA (recommandée):
Installation du panneau solaire
séparément
OptionB:
Installation simultanée du
panneau solaire et de la caméra
ATTENTION: En ce qui concerne l’optionB,
la caméra et le panneau solaire doivent être installés
de sorte à faire face à la résidence. Si la caméra est
installée dos à la résidence, le support mural est
susceptible de bloquer le signal sans l.
