Lotus TPT-64G User manual

Translation of the original instructions
Installation and operating instructions
KITCHEN WITH OVEN FOR
PROFESSIONAL USE
TPT-64G TP4T-610G TPF4-610G TPF4-610GEM TPFM4-610GEM
Model LIBR.ISTR.TP60GNEW
Code 563014600
Review 1
Edition date 05/09/2019
Language English
LOTUS S.p.A.
Via Calmaor, 46
31020 San Vendemiano
[phone]
[phone]

Contents
Translation of the original instructions
2
Contents
1 INTRODUCTION......................................................................................................................... 3
1.1 Installation drawing...................................................................................................................... 3
1.2 Components................................................................................................................................. 5
2 GENERAL INFORMATION......................................................................................................... 15
2.1 Declaration of compliance............................................................................................................ 15
2.2 User information, RAEE Directive on waste electrical and electronic equipment ........................ 16
2.3 Technical data table..................................................................................................................... 16
3 INSTALLATION........................................................................................................................... 17
3.1 Delivery checks ............................................................................................................................ 17
3.2 Removing the packaging ............................................................................................................. 17
3.3 Mechanical installation ................................................................................................................. 17
3.4 Electrical/gas connections ........................................................................................................... 17
4 BURNERS TECHNICAL DATA TABLE (ITGB).......................................................................... 22
4.1 Burners technical data table ........................................................................................................ 22
5 INSTRUCTIONS FOR USE......................................................................................................... 23
5.1 General information ..................................................................................................................... 23
5.2 Lighting and adjusting the open rings.......................................................................................... 23
5.3 Starting the main burner and adjusting the temperature.............................................................. 23
5.4 Turning the appliance off.............................................................................................................. 23
5.5 Lighting and regulating gas oven burner...................................................................................... 23
5.6 Igniting the Grill burner................................................................................................................. 24
5.7 Oven lighting ............................................................................................................................... 25
5.8 Igniting and adjusting the static oven ........................................................................................... 25
5.9 Igniting and adjusting the multi-function electric oven ................................................................. 25
5.10 Cooking table for the fan oven ..................................................................................................... 27
5.11 Electric grill cooking table ............................................................................................................ 28
6 MAINTENANCE.......................................................................................................................... 29
6.1 Routine......................................................................................................................................... 29
6.2 Changing the open ring nozzles (fig. B) ....................................................................................... 29
6.3 Substituting the nozzle in the oven burner ................................................................................... 29
6.4 Replacing the grill burner nozzle.................................................................................................. 30
6.5 Replacing the nozzle for the whole plate burner .......................................................................... 30
6.6 Replacing the oven lamp ............................................................................................................. 30
6.7 Minimum setting ........................................................................................................................... 30
6.8 Spare parts .................................................................................................................................. 30
7 CLEANING.................................................................................................................................. 32
7.1 Routine cleaning.......................................................................................................................... 32

INTRODUCTION
Translation of the original instructions
3
1 INTRODUCTION
1.1 Installation drawing
FIG. 1 TP…T...
A Data Plate
C Gas connection


INTRODUCTION
Translation of the original instructions
4
FIG. 2 TP...
A Data Plate
B Gas connection
C Electrical connection

INTRODUCTION
Translation of the original instructions
5
1.2 Components
FIG. A

INTRODUCTION
Translation of the original instructions
6
FIG. B
1 Gas ring cover
2 Injector
3 Air adjustment
4 Knob
5 By-pass
6 Gas tap
7 Gas ramp
8 Power button

FIG. C
1 By-pass


INTRODUCTION
Translation of the original instructions
7
FIG. D
1 By-pass

FIG. E
Air adjustment


INTRODUCTION
Translation of the original instructions
8
FIG. F
1 Ignition spark plug
2 Injector
3 Extends drainage
4 Air adjustment


INTRODUCTION
Translation of the original instructions
9
FIG. G

INTRODUCTION
Translation of the original instructions
10
FIG. I
1 Injector
2 Pilot
