Louroe Electronics APR-1- RM User manual

Contents Description
APR-1-RM listed Rack Mounted Audio Base
Station. Used for listening to live audio
from microphone, as well as
audio playback from DVR’s, VCR’s
or other audio devices.
AD-1 listed AC ADAPTER.
Supplies 12 Vdc to APR-1 and
Microphone.
Dual RCA Cable RCA cable for connection to a
DVR/VCR or other Audio devices
that accept line level input
(0dB @ 600W).
The APR-1- RM is a rack mounted single zone audio base station designed to interface
with a DVR, VCR or other recording devices that accept line level input. The APR-1
Audio Base Station contains a built-in 3” speaker and volume control for producing live
audio and audio playback. The unit has Mute switch to mute audio from the microphone
fom being heard at the speaker.
U
®
U
®2 Conductor shielded cable, 22
gauge with a 24 gauge drain
wire.
NOTE: Unshielded cable is not
satisfactory for audio
systems.
WIRING REQUIREMENTS
AUDIO BASE STATION (Rack Mounted)
INSTALLATION AND OPERATING INSTRUCTIONS
APR-1- RM
Page 1 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
APR-1-RM_inst 2/15
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: [phone] / FAX: [phone]
/ www.louroe.com[email protected]
®
DUAL RCA Cable
APR-1 Audio
Base Station
AD-1 Power Supply
APR-1 Base Station

[1] Power-Volume Turns “ON” power to the unit and controls the audio volume
through the Speaker[9].
[2] Power Indicator Lights (green) when the power is present to the unit.
[3] Mute Indicator Lights (orange) when Mute Switch[6] is pushed in. Audio is muted.
[4] Playback Indicator Lights (yellow) when Push for Playback[7] is pushed in to “ON” position.
[5] Overload Indicator Flashes (red) when there is a short in the power supply.
[6] Mute Switch Used to mute the audio on both live and playback mode.
[7] Push for playback Used for DVR/VCR playback. May also be used to listen to audio from an
external source. Press switch to listen to playback. Switch must be “OUT”
or “OFF” when monitoring and recording, otherwise live audio is muted.
[8] Headphone Jack Used for private listening. Any 3.5mm stereo headphone with 8Wto
600Wimpedance can be used.
[9] Speaker (3”) Provides live audio. Muted when a headphone is connected to
Headphone Jack [8].
DESCRIPTION
THE APR-1 IS SHOWN BELOW. ALL CONTROLS ARE LOCATED AT THE FRONT PANEL. ALL CONNECTIONS ARE
MADE AT THE REAR PANEL.
INSTALLATION AND OPERATING INSTRUCTIONS
FRONT PANEL LAYOUT OF APR-1-RM
Page 2 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
APR-1-RM_inst 2/15
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]

SENSITIVITY SWITCH OF VERIFACT A MICROPHONE
For special installations that require less microphone sensitivity or where there is background noise, a sensitivity switch is
mounted to the microphone pre-amp (PC Board) and has two positions, N and L:
N represents normal sensitivity (0dB ouput into 1kW)
L represents low sensitivity (-6dB output into 1kW)
Louroe VERIFACT microphones are always shipped with the sensitivity switch in normal (N) position. Do not change
unless necessary. To change the sensitivity setting, use a small screwdriver and move slide switch from N to L position.
The switch is mounted on the back side of the microphone housing.
NOTE REGARDING INTERFACING APR-1-RM WITH A DVR OR PC SOUNDCARD
The APR-1-RM Audio Base Station is compatible with all commercial DVR’s and PC Soundcards that accept
line level input (0dB@600W). An RCA cable is included with the kit for connecting Audio Out to Audio In of
DVR. If DVR’s audio input is a 3.5mm jack, an RCA to 3.5mm adapter (not supplied) must be attached to the
plug that connects to DVR’s Audio Input. Check with DVR’s specifications to determine if the audio input
requires a stereo or mono 3.5mm plug.
PC soundcards contain a standard 3.5mm stereo Audio Input or Line Input. Do not use Mic Input of
soundcard. Louroe microphones are line level (0dB@600W) and will overdrive the Mic Input. Use “Audio
Input” or Line Input” of the soundcard.
INSTALLATION AND OPERATING INSTRUCTIONS
N
I
E
D
U
A
S
A
M
+12 Vdc INPUT OUTPUT
AUDIO
BA C
MIC INPUT
VAN NUYS, CA
[10] [11] [12] [13]
[10] Power Jack Accepts 12Vdc power from Model AD-1 Power Supply
(included with APR-1 Audio Base Station). AD-1 has a 90°2.1mm female plug.
[11] AUDIO IN Jack (RCA) Accepts audio playback from an external source (DVR/VCR).
Audio playback is produced through the speaker. The Push for Playback[7]
must be “IN” during audio playback and “OUT” when
not used for playback.
[12] AUDIO OUT Jack (RCA) Provides audio output and connection to a DVR, VCR, etc.
[13] Audio Terminal Block A 3-pin terminal block marked A, B, C.
Accepts wiring from the remote Louroe™ Microphone.
A is 12Vdc Power
B is Audio
C is Ground
REAR PANEL LAYOUT OF APR-1
Page 3 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
®
APR-1-RM_inst 2/15

INTERCONNECTION DIAGRAM
AUDIO OUT
AUDIO IN
N
I
E
D
U
A
S
A
M
+12 Vdc INPUT OUTPUT
AUDIO
BA C
MIC INPUT
VAN NUYS, CA
VERIFACT A MICROPHONE TO APR-1-RM BASE
STATION TO DVR, ETC.
Rear Panel of APR-1
REAR PANEL OF DVR WITH
RCA TYPE AUDIO INPUT
A B C
N
VERIFACT A
L
AD-1
AC Adapter
120V/12Vdc, 500mA
“Audio In” of APR-1
connects to “Audio Out”
of DVR or other receiving device
NOTE: If DVR’s audio input and output are 3.5mm (mini jack) type, use the appropriate adapter
at one end of RCA patch cable for connection. Check with manufacturer’s specifications
to determine if 3.5mm audio input/output is mono or stereo.
“Audio Out” of APR-1
connects to “Audio In”
of DVR or other receiving device
ABC
2 Conductor shielded cable, 22
gauge with a 24 gauge drain
wire.
NOTE: Unshielded cable is not
satisfactory for audio
systems.
WIRING REQUIREMENTS
INSTALLATION AND OPERATING INSTRUCTIONS
Terminal Block Identifier
for Microphone
(A) Red - 12Vdc power
(B) Black - Audio Output
(C) Bare - Ground
Page 4 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
®
APR-1-RM_inst 2/15

INSTALLATION TIPS
1. Use overall shielded audio cable only. West Penn 452, Belden 8451 or equivalent.
UNSHIELDED CABLE IS NOT SATISFACTORY FOR SOUND SYSTEMS.
2. When used in cashier’s booth, microphone should be installed closer to the customer rather than the
cash register, as the drawer sound may dominate the recording. It should be installed closest to the
area that needs to be monitored and documented.
3. Avoid installing microphone near air vents, air conditioner, fans and other equipment that generate
high sound and air pressure.
4. The APR-1 and microphone should have a barrier or solid wall between them in order to avoid audio
feedback, especially when they are in close proximity to each other up to 25’ (7.6 m).
6. Press “REC” on the recording device and record live audio for several minutes.
7. Press Push for Playback Switch[7] to “ON” position. Playback Indicator LED[4] will illuminate yellow.
8. Press “PLAY” on the DVR/VCR to playback recorded audio from the APR-1.
9. Press Mute Switch[6] to mute audio heard on the speaker. Mute Indicator LED[3] will light and no audio can be
heard on the speaker on both live and playback audio. When Mute Switch[6] is ON Playback Indicator LED[4] will
not light even when the Push for Playback Switch[7] is pushed in and the audio is muted.
4. Using the dual RCA cable (supplied), connect DVR/VCR’s AUDIO OUT jack to APR-1’s AUDIO IN Jack[11].
5. Connect DVR/VCR’s AUDIO IN jack to APR-1’s AUDIO OUT Jack[12].
WIRING CONNECTIONS AND TEST
Both the Verifact A Microphone and APR-1 Audio Base Station contain a 3-pin terminal block marked A, B, C.
A = 12Vdc Power Red Wire
B = Audio Black Wire
C = Ground Bare Wire
1. Starting with the microphone, connect RED wire to Pin A, BLACK wire to Pin B and BARE wire to Pin C. Connect
other end of cable to Terminal Block on back panel of APR-1 Base Station matching RED wire to Pin A, BLACK wire
to Pin B and BARE wire to Pin C. Refer to drawing on page 4.
2. Plug AD-1 power supply (AC Adapter) into the Power Jack[10] located on back panel of APR-1 first. Then connect 2-
prong block into standard 110/120 AC wall receptacle or power strip.
3. Turn “ON” power to APR-1 by rotating the Power-Volume Knob[1] clockwise. The green PWR[2] LED will illuminate.
Adjust volume of audio by rotating the knob either clockwise to increase or counterclockwise to decrease. Locate
microphone so as not to create feedback with the APR-1. The further the microphone is from the APR-1 the less
feedback it generates. System works best if there is an acoustical barrier between the microphone and the
APR-1, such as a wall or room divider. If there is no wall or barrier, microphone should be mounted at least 25 ft.
2 Conductor shielded cable, 22 gauge
with a 24 gauge drain wire.
West Penn 452 or equivalent
INSTALLATION AND OPERATING INSTRUCTIONS
Page 5 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
®
APR-1-RM_inst 2/15

NOTES
INSTALLATION AND OPERATING INSTRUCTIONS
Page 6 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
SPECIFICATIONS
Monitor output power
Audio input impedance
Freq. response
1W@8
10K
100 Hz to 10 kHz
Headphone impedance
Universal power supply
Dimensions
Weight
8 to 600
12 Vdc, 500 mA
19"L x 3 1/2”W x 8 1/4"D
2 lb 6 oz
Audio line output impedance 600Wor higher
Shipping Weight 4 lbs
APR-1-RM_inst 2/15

INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT NOTICE
When this equipment is used as part of an audio monitoring
system, the law requires that the public be given notice of
AUDIO MONITORING ON THE PREMISES. A decal notice
is included with each microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18. Crime and Criminal
Procedure, Sec 2510.
AUDIO
MONITORING
On
These Premises
Page 7 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
WARRANTY
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
®
®
®
®
®
®
®
