Louroe Electronics MS-D1 User manual

Requires Cat5e or Cat6 Cabling,
(Not Included). See wiring
CONNECTIVITY on Page 2.
WIRING REQUIREMENTS
DESCRIPTION
The MS-D1 Mute Switch is an accessory for all Louroe Digifact Audio Monitoring/Audio Surveillance Systems when
microphone muting is required remotely from any Digifact hardware with a microphone. The MS-D1 contains a built-in
rocker switch with a Green L.E.D. mounted to a single gang stainless steel face plate. It is easy to setup in any
environment using 2 pairs of Cat5e or Cat6 cabling. The MS-D1 is used to mute or disable the audio feed to any
Digifact E hardware. It disables the audio stream from processing audio in the Digifact hardware, which prevents the
operator from listening in to the microphone. The MS-D1 fits into a single gang back box (not included) for mounting, on
a flat surface or in a wall.
Login to the Louroe’s Digifact Software Portal interface for the Digifact hardware you want to add Audio Muting too.
Select the following settings from the (Output Settings Tab), 1.) Select Trigger Source and set it to (Input 1), 2.)
Select Output Port, set it to (Digital Mute). When finished, disconnect the RJ45 cable to your Digifact Hardware, set
the MS-D1 switch to the OFF position. Follow the wiring Diagram 1A. on page 2 for all wiring connectivity between the
MS-D1 digital controlled mute switch and your Digifact hardware. Testing: 1.) Reconnect the RJ45 cable and wait for
the Digifact hardware to power-up, now set the MS-D1 to the on position, the Green L.E.D. should turn on indicating
the Digifact hardware audio stream is muted.
OPERATION
MODEL MS-D1
MS-D1, Part No. LE-831
Digital Controlled (Analog Audio) MUTE SWITCH
INSTALLATION AND OPERATING INSTRUCTIONS
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: [phone] / FAX: [phone]
/ www.louroe.com[email protected]
®
Page 1 of 2
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
LE-831-01272023-WB
The MS-D1 works with all DIGIFACT Hardware
R
SPECIFICATIONS OF MS-D1 MUTE SWITCH
Digital Output Voltage
UTP, Cat5e, Cat6 Distance
Switch Contact
Dimensions
Faceplate Material
5Vdc
Up to100 ft.
5A @125Vac
Weight
Shipping Weight
2.5 oz
1 lb
2 ¾ W x" 4 ½" H
303 Stainless Steel
Backbox Single gang electrical
box (not included)
Package Includes:
1 x Single Gang Stainless Steel Wall Plate with a On/Off
Rocker Switch and Green L.E.D..
2 X Stainless Steel Screws
2 X Audio Monitoring On These Premises Stickers
DIGIFACT TECHNOLOGY
R
Please Note!
All specifications are subject to change without notice.

INSTALLATION AND OPERATING INSTRUCTIONS (MS-D1), Part No.: LE-831
Page 2 of 2
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
IMPORTANT NOTICE
When this equipment is used as part
of an audio monitoring system, the
law requires that the public be given
notice of AUDIO MONITORING ON
THE PREMISES.Two decal notice
stickers are included with each MS-
D1, LE-831 units when shipped.
AUDIO
MONITORING
On
These Premises
®
WARRANTY
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within two year (24 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
®
®
®
®
®
®
10 Position Digital I/O, Power Terminal Block
available on all Digifact hardware
5VDC, Max load 100ma
Digital Output (1)
Digital Output (2)
Digital Output (3)
Digital Output (4)
Digital Input (1)
Digital Input (2)
Ground
External Power 5Vdc+
External Power Ground-
Blue Wire connects here
Orange Wire connects here
N/A
N/A
N/A
White/Blue Wire connects here
N/A
White/Orange Wire connects here
N/A
N/A
Up to 100ft. Cat5e, Cat6 Cabling,
(Not Included)
TB-1
TB-2
+
-
S1 S2
When the Green L.E.D. is ON, it means the Microphone is live
Wiring Connectivity Diagram 1A.
Orange
Blue
White/Orange
White/Blue
Please Note! This diagram uses Cat5e, Cat6 wiring
using the Orange Pair and Blue Pair Wiring.
Cat5e/Cat6
Wiring Connections Digital I/O Pinouts
MODEL MS-D1
When the TOP part of the switch is
pressed IN, the switch will illuminate
indicating the microphone
is live and active.
GREEN
When the LOWER part of switch is
pressed IN, the Green L.E.D. turns off,
indicating power to the microphone is
OFF and the microphone is disabled.
Connectivity
1.) Disconnect the RJ45 cable from the Digifact hardware. 2.) Wire the
Terminal block TB-1 and TB-2 as shown below in Diagram 1A.. 3.) Wire the
10 position Digital I/O, Power Terminal Block as shown below in Diagram 1A..
1
2
3
4
5
6
7
8
9
10
Terminals 1-10
Please Note!
Waterproof
IP67 Gland
Groumet
This cable needs to pass thru
either the digital I/O port Gland or
Groumet depending on the Digifact
hardware used.
LE-831-01272023-WB
