LS Bedding Group VFF/CDL-BF-03 User manual

Radio remote control
VFF/CDL-BF-03
with Bluetooth-Technology
Operating Instructions

2
Foreword
Revision history
Version Date
1.0 2 8.01.2020
Change
First edition
In your own interest
Read these operation instructions and
keep them in a safe place. Observe the
safety instructions.
Foreword

3
Table of contents
Foreword 2
Revision history 2
In your own interest 2
Disclaimer 2
Manufacturer's address 2
Table of contents 3
1 General . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 How to use these instructions . . . . . . . . 4
1.2 Information about these operating
instructions. . . . . . . . . . . . . . . . . . . . . . . . 4
2 Safety instructions . . . . . . . . . . . . . . . . 4-7
2.1 Intended use. . . . . . . . . . . . . . . . . . . . . . 5
2.2 Improper use. . . . . . . . . . . . . . . . . . . . . . 5
2.3 Specific safety instructions . . . . . . . . . . 5
2.4 Information about radio operation . . . 6
2.5 Handling batteries . . . . . . . . . . . . . . . . . 7
2.6 Operating instructions of the bed
manufacturer . . . . . . . . . . . . . . . . . . . . . 7
2.7 Electronic medical equipment. . . . . . . 8
3 Commissioning / Operation. . . . . . . 9-12
3.1 The remote control . . . . . . . . . . . . . . . . 9
3.2 The double drive . . . . . . . . . . . . . . . . . . 9
3.3 Inserting the batteries . . . . . . . . . . . . . 10
3.4 Teach-in process . . . . . . . . . . . . . . . . . 10
3.5 Bed adjustment . . . . . . . . . . . . . . . . . . 11
3.6 Torch function. . . . . . . . . . . . . . . . . . . . 11
3.7 Reset to factory settings . . . . . . . . . . . 12
4 Malfunctions / troubleshooting . . . . . 13
5 Technical data . . . . . . . . . . . . . . . . . . . 13
6 Maintenance and cleaning . . . . . . . . 13
7 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Attachment . . . . . . . . . . . . . . . . . . . . . 15
8.1 Operation via a smartphone
or tablet PC. . . . . . . . . . . . . . . . . . . . . . 15
Table of contents

4
1 General
1.1 How to use these instructions
Symbols used
Indicates about a dangerous situation;
potential consequences: death or
serious injury.
Potentially dangerous situation;
potential consequences: slight or
minor injuries.
General information;
Information that is important for the
function or operation, or that will
facilitate operation or assembly.
1.2 Information about these
operating instructions
These operating instructions serve the
successful and safe use of the radio
remote control.
The operating instructions will help you
to avoid dangers, and minimise repairs
and failures.
These operating instructions were
compiled with great care. No liability
will be assumed for the accuracy and
completeness of the data, images or
drawings, unless prescribed by law.
Subject to technical amendments that
serve continuous product improve-
ment without prior announcement!
2 Safety instructions
The radio remote control can be used
by children aged 8 and upwards and
by persons with limited physical,
sensory or mental aptitude or lack of
experience and/or knowledge if they
are supervised or have received
instruction from a person responsible
for their safety as to how the radio
remote control is used and the
associated risks.
Children may not play with the radio
remote control.
Children may not clean or service the
device without supervision.
General
Warning
Caution

5
Safety instructions
2.1 Intended usage
The radio remote control is designed
for:
• operating dual drives.
• use within the home
The radio remote control is only
designed for the designated purpose.
Any other use is deemed improper
and can lead to accidents or the
destruction of the device.
This will lead to immediate invalidation
of the warranty and any warranty
claims by the end user with respect to
the manufacturer.
2.2 Improper usage
Please observe the following
information about improper usage.
The radio remote control and the
double drive may not be used
• with a medical product or installed
in a medical product,
• in an environment in which there
are inflammable or explosive gases
or vapours (e.g. anaesthetics),
• in damp environments,
• outdoors,
• in applications that are washed in
mechanical washing systems,
• for lifting and lowering of loads, in
craftsman or industrial areas or in
the household.
2.3 Specific safety instructions
The following safety instructions serve
to protect you, third parties and the
equipment, and must therefore be
adhered to strictly.
Operating environment
• The radio remote control may not
come into direct contact with damp
or water. The radio remote control is
only suitable for dry indoor rooms.
• When switching from cold to warm
environments, allow the radio
remote control time to adjust to the
Caution
Warning
Caution

6
Safety instructions
ambient temperature for a few hours
before use, otherwise it may suffer
damage as a result of condensation.
• Never use the remote control close
to devices that emit strong
electromagnetic fields. This could
impact on its function.
• Also avoid environments exposed to
direct sunlight, high temperatures,
cold, damp or wet.
The device
• Check first whether the housing is
damaged. If this is the case, do not
use the remote control but contact
the supplier for a replacement.
• For safety reasons, it is prohibited to
make any unauthorised changes to
the remote control. Do not open the
housing of the remote control,
except to change the batteries,
otherwise the warranty will become
void.
Operation
• The remote control only functions
correctly if it is commissioned and
used properly.
• To avoid injury, never allow children
or other vulnerable persons to use
the remote control unsupervised.
• Radio signals can pass through walls
and ceilings!. Only use the remote
control in the room in which the
adjustable bed is located!
2.4 Information about radio
operation
Please note that the transmission
range depends on the local
conditions. It may impact on other
devices operated by radio, for
instance WLANs, cordless phones or
microwave ovens.
Transmission / receiving frequency:
2.4GHz ISM band.
Devices according to the standard of
the Bluetooth SIG transmit as Short
Range Devices (SRD) in a license-free
ISM band (Industrial, Scientific and
Medical band) between 2.402 GHz
and 2.480 GHz.

7
2.5 Handling batteries
• Keep batteries out of reach of
children.
• Batteries must not be thrown into fire,
short circuited, taken apart, or
charged. Danger of explosion!
• Batteries contain harmful acids.
Replace weak batteries as soon as
possible to avoid battery leakage.
• Never use old and new batteries
together or mix batteries of different
types.
Handling leaking batteries
• Chemically resistant protective
gloves and goggles should be worn
when replacing leaking batteries!
• Avoid touching leaking batteries with
your bare hands as far as possible.
• Should you come into contact with
leaked battery components, wash
your hands thoroughly.
• Remove any electrolyte residues by
damp wiping. Wash any clothes that
come into contact with the
electrolyte.
2.6 Operating instructions of the
bed manufacturer
Also observe the safety notes in the
operating instructions of the bed
manufacturer!
Depending on the design or model of
the adjustable bed, hazards to the user
may occur that are not covered by this
manual.
These installation instructions do not
contain all information required to
safely operate the end product,
because the bed manufacturer will
carry out a risk assessment for the
adjustable bed. This will then be used
as the basis for the safety notices in its
operating instructions.
Caution
Safety instructions

8
2.7 Electronic medical devices
This product is designed and
manufactured according to the
Standard DIN EN 60335-1 (Safety of
Household and similar Electrical App-
liances) and carries the CE mark. If
you use a Medical Device such as
pacemaker you may wish to contact
your specialist to answer any
questions.
Safety instructions

9
Comissioning
3 Comissioning /
Operation
3.1 The remote control
ttt
111
222
333
sss
s Status LED Battery compartmentb
1 2 Drive up Drive down
3 t Torch function Torch LED
3.2 The double drive
bbb
111222
1 21 2 Without batteries With 2 batteries1 2 Without batteries With 2 batteries
l Teach-in button
lll

Once the batteries have been inser-
ted, close the battery compartment
lid again and the radio remote control
is operational.
3.4 Teach-in process
This teach-in process is normally
carried out by the manufacturer and
you can skip this step.
If the status LED and the keypad s
illumination are flashing, the remote
control has not yet been taught in on
the dual drive.
In the following it is assumed that this is
the case. It will be described how the
teach-in process has to be carried
out.
If the status LED and the keypad s
illumination do not flash, but a
connection between double drive and
remote control is still not established
(bed cannot be adjusted), the double
drive and remote control must be
reset to the factory settings and re-
taught. Resetting to factory settings is
explained on page 11 of this manual.
10
Commissioning
3.3 Inserting the batteries
Insert the supplied batteries (2x 1,5V
AAA LR03) into the battery compart-
ment as shown in the picture. Ensure
that the batteries are inserted in the
right direction (+/-)!

• Briefly press any button on the remote
control
The status LED and the keypad ► s
illumination flash alternately.
• Press button l on the double drive for
approx. 1 s.
The back adjustment motor moves ►
briefly up/down.
• The status LED goes off, the keypad s
illumination lights up constantly. The teach-
in process has been completed
successfully.
3.5 Bed adjustment
Before making any adjustments:
Check that neither you nor anyone
else or any pets are at risk from to the
moving parts of the adjustment
mechanics!
Use buttons and for the bed 1 2
adjustment. As long as you keep the
buttons pressed, the drives will move.
3.6 Torch function
Do not look directly into the torch LED!
• Press button for approx. 3 3
seconds.
The torch LED will switch on and t
goes off automatically after approx.
20 seconds.
• Press button again shortly will 3
switch off the torch LED.
• If you keep the button pressed, the
LED remains switched on. It then
goes off about 20 seconds after
releasing the button.
3.7 Reset to factory settings
Resetting the remote control:
• Simultaneously press and hold the
buttons , and .1 2 3
11
Operation
Caution
Caution

12
Operation
• The status LED starts flashing.s
• When the status LED is steady, s
release the buttons.
• The status LED goes off, the s
remote control is reset.
Resetting the double drive:
• Press button l on the double drive
for approx. 10 s (See page 9).
• The drive for the leg adjustment
moves briefly to confirm a reset to
the factory settings.
• Remove the plug from the mains
socket and wait until the green LED
on the power supply goes off.
• Then reconnect the mains plug.
• The double drive is now returned to
its default settings.
PLEASE NOTE:
After resetting the double drive to the
factory settings, the pairings of remote
controls and Apps are removed, the
pairing process has to be carried out
again.

13
4 Malfunctions /
troubleshooting
Before contacting the service office of
the furniture manufacturing company,
please try the following in the event of
a malfunction:
• Check to ensure that the dual drive
VMAT-Basic is connected to the
mains supply (power socket).
• Check (e.g. with a lamp) that the
power socket actually works (fuse).
• Replace the batteries of the radio
remote control (see page 10).
• Carry out the teach-in process
again (see page 10).
• Reset the dual drive to the default
settings (see page 12) and then
carry out the teach-in process again
(see page 10).
5 Technical data
Operating voltage . . . . . . . . . . . . 3VDC
via batteries
Power consumption
Idle. . . . . . . . . . . . . . . . . . . . . . . . typ.1µA
Operational . . . . . . . . . . . . . . . . . . . 2mA
Transmission freq. . . 2,4GHz (ISM-Band)
Transmission range . . . . . . . . . 10 - 50m
Housing material. . . . . . . . . . . . . . . . ABS
Protection grade . . . . . . . . . . . . . . . IP20
Battery type . . . 2 pcs. 1,5V AAA (LR03)
Weight (incl. batteries and
packaging). . . . . . . . . . . . . approx. 80g
6 Maintenance and
cleaning
The radio remote control is
maintenance-free, apart from the
replacement of the batteries.
Clean the housing with a slightly damp
cloth. Do not use any aggressive
detergents or scouring agents.
Malfunctions, Tech. data, Maintenance

Disposal
14
7 Disposal
The remote control and the double
drive contain electronic components,
cables, metals, plastics etc. and must
be disposed of in accordance with
the applicable environmental
regulations of the respective country.
This symbol on the product or its
packaging indicates that the product
may not be disposed of via the
household waste system.
Users have a duty to dispose of the old
equipment via the collection point for
electronic and electrical scrap.
Separate collection and correct
disposal of your old equipment helps
conserve natural resources and
guarantees recycling, which protects
human health and preserves the
environment.
Please contact your local council or
waste disposal authority to find out
where the collection points are for
your old equipment.
Disposal of the radio remote control in
Germany is subject to the Electrical
Equipment Act, internationally to the
EU Directive 2011/65/EU RoHS or the
respective national laws.
(The product is not subject to the EU
Directive 2002/96/EC (WEEE) and its
supplement EU Directive
2003/108/EC.)
Disposal of batteries in the EU is
subject to the Battery Directive
2006/66/EU, in Germany to the Battery
Act (BattG) dated 25.6.2009, and
internationally to the respective
national laws.

15
8 Attachment
8.1 Operation via a smartphone or
tablet PC
The smartphone or tablet must support
Bluetooth 4.0 (Bluetooth Smart, BLE,
Bluetooth Low Energy)!
You will need to download and install
an app to operate the dual drive via
your smartphone or tablet PC.
1)
The app is available for both Android
2)
and iOS systems.
Once the app has been installed,
please proceed as follows:
• A ctivate the Bluetooth function on
your smartphone or tablet PC. You
will usually find this in the menu
>Settings<. Please check that the
function is activated.
• Press the button l on the dual drive
for approx. 1 second (see page 8).
• Now start the connection process
on your smartphone / tablet PC.
Usually the message 'Searching for
devices' will be displayed.
• If the dual drive is still in its default
settings, the smartphone will find a
device called 'V-Mat-…', or a name
that the dual drive was previously
given.
• Now activate the connection
process (pairing; bonding) on your
smartphone. This may take a few
seconds. As soon as the connection
had been made, the app can be
used.
1) The app for Android operating systems is
available on Google Play.
2) ® ®
The app for iOS (Apple ) operating systems is
® ®
available on Apple iTunes .
Attachment

Document is subject to change without prior
announcement.
All rights reserved.
It is strictly forbidden to duplicate this
document in any form without the prior
consent of the company LS Bedding nv.
LS Bedding nv is not liable for any errors in this
document or for any ensuing damages
connected to the delivery, performance or
use of this material.
