LSC MANTRA LITE User manual

Version V 2.05 June 2020
Lighting Control for LEDs,
Moving Lights and Dimmers
Quick Start Guide
LSC Control Systems
[phone]
[email protected].au
www.lsccontrol.com.au
Version 2.06
October 2020

Mantra Lite
Quick Start Guide
Disclaimer
LSC Control Systems Pty Ltd has a corporate policy of continuous
improvement, covering areas such as product design and documentation. To
achieve this goal, we undertake to release software updates for all products
on a regular basis. In light of this policy, some detail contained in this manual
may not match the exact operation of your product. Information contained in
this manual is subject to change without notice.
In any event, LSC Control Systems Pty Ltd cannot be held liable for any direct,
indirect, special, incidental, or consequential damages or loss whatsoever
(including, without limitation, damages for loss of profits, business interruption,
or other pecuniary loss) arising out the use or the inability to use this product
for its intended purpose as expressed by the manufacturer and in conjunction
with this operating manual.
Servicing of this product is recommended to be carried out by LSC Control
Systems Pty Ltd or its authorized service agents. No liability will be accepted
whatsoever for any loss or damage caused by service, maintenance or repair
by unauthorized personnel.
In addition servicing by unauthorized personnel may void your warranty.
LSC Control Systems’ products must only be used for the purpose for which
they were intended.
Whilst every care is taken in the preparation of this manual, LSC takes no
responsibility for any errors or omissions.
Copyright Notices
www.lsccontrol.com.au
Copyright © 2015 LSC Control Systems Pty Ltd.
All rights reserved.
Contents of this manual, Copyright © 2015
All Trademarks referred to in this manual are the registered names of their
respective owners.
The operating software of the Mantra Lite and the contents of this manual are
copyright of LSC Control Systems Pty Ltd © 2015.
Contact Details
LSC Control Systems
ABN 21 090 801 675
65-67 Discovery Road
Dandenong South, Victoria 3175 Australia
[phone]
[email protected]
www.lsccontrol.com.au

Mantra Lite
Quick Start Guide
Contents
1Overview......................................................................4
2Help..............................................................................4
3Undo ............................................................................5
4Getting Connected .......................................................5
5Front Panel...................................................................6
6Touch Screen...............................................................7
7Controlling Fixture Intensity..........................................8
8Controlling Fixture Attributes ........................................8
9Selecting Fixtures.........................................................9
10 Controlling Colour.......................................................10
11 Controlling Position ....................................................11
12 Automatic Fixture De-select .......................................12
13 Animate Apps.............................................................13
14 Shapes App................................................................15
15 Clearing Fixtures........................................................16
16 Recording The Output................................................17
17 Playback ....................................................................18
18 Editing Memories........................................................22
19 Save/Load..................................................................24
20 Patching Fixtures........................................................24
21 Fixture Editor..............................................................26
22 Rig View.....................................................................27

Mantra Lite
Quick Start Guide
Page 4
1Overview
This “Quick Start Guide” provides basic information on patching,
controlling intensity, colour & position, creating a simple
animation plus recording and playback. Training videos plus the
“Mantra Operation Manual” containing full descriptions of all
functions are available at: mantralite.lsccontrol.com.au
Mantra comes with a “Sample” show that you can load so that
you can familiarise yourself with the controls before patching
your own fixtures.
To load the sample show from the “Home”screen touch:
Tools/Load/SampleShow.
If you don’t need the sample show and want to patch your own
fixtures now, go straight to section 20.
Mantra can control up to 24 lighting fixtures. The fixtures that
you control might be……
•A conventional lighting dimmer.
•A multi-colour LED fixture.
•A multi-colour fixture with additional controls for
position and/or beam shapes.
Each fixture is patched to a Yellow fader and button.
The Mantra Wing is an accessory for the Mantra Lite lighting
console. It can only be operated when it is connected to a
Mantra Lite console. Connecting a Mantra Wing provides
control of an additional 12 lighting fixtures (25-36) and a further
10 playbacks (11-20) (with 10 pages of memory) as well as a
second DMX512 universe (U2) output.
Connecting a second Mantra Wing provides control of an
additional 12 fixtures (37-48) and a further 10 playbacks (21-
30) (with 10 pages of memory) as well as a third DMX512
universe (U3) output.
Connecting an LSC “QX1” provides an additional DMX
universe output.
2Help
Context sensitive help is available on the touch screen for
many functions of the Mantra. Tap the button to open the
help screen. Tap to close.

Mantra Lite
Quick Start Guide
Page 5
3Undo
To quickly undo the last action double tap .
To undo more than one action tap once to see the list of
your actions.
Touch Undo to undo an action and step down the list. Touch
Redo to redo an action and step up the list.
Tap the [Back] button to finish.
Note: The undo list is automatically cleared whenever you save
your show, start a new show or load an existing show.
4Getting Connected
4.1 Power Input
Two models of Mantra Lite are available:
•The MANTRA/LT has an IEC mains input (90 volts to
260 volts).
•The MANTRA/LT/E has 12 volt DC power input. An
external mains power pack is supplied.
4.2 DMX 512 Output
Connect a DMX data cable from the DMX512 output (one
universe of 512 channels) to the DMX512 input of your first
fixture (dimmer, LED or Mover) and loop to the next fixture/s.
Only use specific DMX cable (never use audio cable) and
always terminate the end of the DMX line. Set the required
DMX addresses on your equipment. Patch each fixture to a
yellow fixture fader. See section 20 for more details on
patching.
4.3 Ethernet Network Connector
The RJ45 Ethernet connector can be used to output sACN and
ArtNet. These are lighting control protocols that send DMX
lighting data over a network or to a lighting visualiser program
running on a computer.
4.4 USB Connectors
The two USB connectors can be used to connect:

Mantra Lite
Quick Start Guide
Page 6
•A USB keyboard.
•A memory stick for show backup and software
upgrades.
•A USB LED desk lamp (up to 250mA).
•One or two Expansion wings.
•QX1 node. Provides an additional DMX universe.
5Front Panel
The 24 Yellow fixture faders control fixture intensity. Moving a
fixture fader automatically selects that fixture allowing its other
parameters such as colour or position to be controlled by Apps
on the touch screen. Moving a fader to zero deselects the
fixture.
The Yellow “Fixture Master” has overall intensity control of the
yellow fixture faders.
24 Fixture Faders
and Buttons
(Yellow)
10 Playback
Faders and
Buttons
(Red)
Playback
Pages
Playback
Master
(Red)
Fixture
Master
(Yellow)
Record
Output
Help
Undo
Touchscreen
Back
Select
Touch
Screen

Mantra Lite
Quick Start Guide
Page 7
The current output can be recorded into any of the Red
playbacks by tapping [Record] then tapping a Red playback
button of your choice [1-10].
Different looks can be recorded on different Red Playback
faders so that you can easily change the entire look on stage by
using the Red Playbacks.
See section 16 for more details.
6Touch Screen
If the touch screen is not on the “Home” screen, tapping the
[Back] button steps back through the screens to the
“Home” screen.
Double tapping [Back] quickly returns to the “Home” screen
from any screen.
The “Home” screen is divided into two sections:
•The top section (yellow border) has fixture icons that
show the intensity, colour and position (if applicable) of
the patched fixtures.
•The bottom section shows the contents of the red
Playbacks.
“Home” Screen
The 3 buttons below the touch screen have different functions
for different screens. Their current function is shown on the
Fixture Icons show intensity,
colour and position
Playback
Contents
Dot shows
position of
moving
fixtures
Red Playback
Page Number
Current function
of button below
Live Speed

Mantra Lite
Quick Start Guide
Page 8
screen above each button. You can tap the button or touch the
screen to operate them.
Touching anywhere in the top “fixtures section” of the “Home”
screen or touching Apps opens the “Apps” screen. Apps are
used to control the attributes of selected fixtures. Move a
yellow fader to automatically select that fixture. Use an App to
adjust the attribute. Other methods of selecting fixtures are
described in section 9.
The bottom section of the “Home” screen has Playback icons
showing the contents of each Playback (if any have been
recorded). Touch any playback icon to modify its memory. See
section 18
7Controlling Fixture Intensity
The 24 (yellow) fixture faders (under the overall control of the
yellow fixture master) control the intensity of the fixturesthat are
patched to them. To see the output of a fixture:
•Fade up the Yellow Master.
•Fade up a fixture fader to set its Intensity.
7.1 Flash
When the touch screen is on the “Home” screen, the buttons
below the yellow faders act as intensity [FLASH] buttons. You
can set the flash intensity level in the Tools/Setup screen.
If a red fader contains a single cue then its button acts as
intensity [FLASH] button.
If a red fader contains a cue-list then its button “steps” the cue-
list. See section 17.
8Controlling Fixture Attributes
Mantra uses “Apps” on the touch screen to control the attributes
of selected fixtures. From the “Home” screen, open the “Apps”
page by touching anywhere in the top half of the touch screen
or touching Apps.

Mantra Lite
Quick Start Guide
Page 9
Apps Screen
There are 4 columns (Intensity, Colour, Position, Beam/Other)
that have Apps for their type of attribute. Touch the App for the
attribute that you want to control.
9Selecting Fixtures
When you use an App, you need to select the fixtures that you
want to control with that App. Fixtures that have attributes that
can be controlled by the selected App will flash their buttons
indicating that they are available for selection. When a fixture
is selected its button is lit. Fixtures can be selected using
several methods and multiple fixtures can be selected at the
same time.
•Move a yellow fader to automatically select that fixture.
Move the fader to zero to de-select it.
•Tap the button below a yellow fader to select that
fixture. Tap again to deselect it.
•To select a range of fixtures, hold the first button and
tap the last button in the range. This works with both
low number to high number selection and high to low
number.
•Tap [Select] to re-use previous selections or to
select None.
“Clear”+“Clear All”
See section 15

Mantra Lite
Quick Start Guide
Page 10
10 Controlling Colour
10.1 Picker
From the “Home” screen, open the “Apps” page (described
above) then touch the colour Picker app icon. Fixtures that
have colour attributes will flash their buttons. Select the
fixtures (described above) then drag your finger to change the
colour. The colour is selected when you “lift”your finger from
the screen.
The side of the colour picker app shows the recently selected
colours. Touch any of the recent colours to re-use them.
10.2 Fan
When multiple fixtures are selected you can fan their colours
to create rainbow effects. Touching Fan selects “Directional”
fanning. Drag to fan the colours across the selected fixtures.
Touching Fan again selects “Symmetrical” fanning. Drag to fan
the colours with your finish colour in the centre of your fixture
selection.
Touching Fan again turns fanning off.
Your fixture selection order is used by the Fan App.
Experiment with different orders of selection to get different
colour effects.
Recently
selected
colours
Fine Control
Fan
Red Green Blue sliders
for individual control

Mantra Lite
Quick Start Guide
Page 11
Previous selections can be re-used by tapping the
[Select] button.
10.2.1 Sliders
Touching Sliders opens the “Colour Sliders” screen that
provides individual sliders for all colours. Red, Green and Blue
are located in a fixed section at the top of the window. Other
colours, White, Amber, UV and Lime, as well as Colour wheels
are located in the scrolling bottom half of the screen. Sliding
your finger vertically in the bottom half will scroll the sliders
up/down allowing access to more sliders if the selected fixture
has additional attributes.
Colour Sliders
•+and –buttons are provided for small increments.
•The decimal values of each slider is shown on the
right.
The Hexadecimal value of the last selected Red, Green, or Blue
slider is shown at the top. If you touch inside the Hex:# box you
can enter exact values using the keyboard that appears. Enter
your values (in Hex) then touch Set.
10.3 Gels
The colour Gels app is similar to the “Picker” app but has 100
commonly used colour gels to choose from.
11 Controlling Position
From the “Home” screen, open the “Apps” page then touch the
Position app icon. Fixtures that have Pan/Tilt attributes will
RGB values in
Hexadecimal

Mantra Lite
Quick Start Guide
Page 12
flash their buttons. Select the fixtures then drag your finger
around the touchscreen to move the beam around the stage.
You don’t have to touch the current position icon to move a
fixture, you can touch and drag anywhere on the screen and the
selected fixture(s) will follow your movements.
11.1 Flip
Touching Flip Pan or Flip Tilt reverses the direction of
movement. These settings are useful if the fixture movement is
opposite to the movement on the touch screen.
11.2 Centre
Touching Centre moves the selected fixtures to their centre
position.
11.3 Fan
When multiple fixtures are selected you can fan their positions
to create symmetrical patterns.
Touching Fan selects “Centred” fanning. Drag to fan the
positions around the centre fixture.
Touching Fan again selects “Directional” fanning. Drag to fan
the positions around the first fixture in your selection.
Touching Fan again selects “V–Shape” fanning. This pan
works best when fixtures are already fanned into a line. Drag
to pull the line of fixtures into a V shape.
Touching Fan again turns fanning off.
Your fixture selection order is used by the Fan App.
Experiment with different orders of selection to get different
shapes. Previous selections can be re-used by tapping the
[Select] button.
12 Automatic Fixture De-select
When you open an App, fixtures that have attributes that can
be controlled by hat App flash their buttons indicating that they
are available for selection. When you select fixtures their
buttons are lit. After you have used the App to change any
attribute of the selected fixtures, the buttons of the un-selected

Mantra Lite
Quick Start Guide
Page 13
fixtures stop flashing. This tells you that selecting another
fixture will cancel the previous selection and start a new
selection process. This speeds up operations because you
don’t have to de-select fixtures once you have set their
attributes.
For example: Open the Colour Picker App and fade up fixtures
1 and 2. They are automatically selected. Pick a colour. Fade
up fixture 3 and 4. This de-selects 1 and 2 and selects 3 and
4. Pick a colour for 3 and 4.
Automatic fixture de-select can be overridden by holding the
[Select] button whilst selecting additional fixtures.
13 Animate Apps
Animate Apps provides a simple and intuitive way of creating
chases and moving patterns. They work with 2 or more
selected fixtures and they shift the attribute settings (such as
colour or intensity, position or beam) from one fixture to the
next and loop the settings of the last selected fixture back to
the first. There must be at least one different setting amongst
all of the selected fixtures so that you can see the different
setting being shifted from one fixture to the next.
Example 1:
Let’s create a 2 colour animation using RGB LED fixtures 1
through 4:
•From the “Home” screen, open the “Apps” page then
touch the Colour Picker app icon.
•Fade up fixtures 1, 2 and 3. This automatically selects
them.
•Select a colour (say Red) by touching the colour picker.
•Fade up fixture 4. This automatically deselects the
previous selection and selects fixture 4.
•Select a different colour (say Blue). The output is
shown in “Step 1“ below.
•Tap [Back] once to return to the Apps screen then
open the Colour Animate app.
•Select all 4 fixtures by fading them up to full or tapping
their buttons then touch Create.

Mantra Lite
Quick Start Guide
Page 14
•The animation runs and the blue steps through the 4
fixtures.
Fixture 1
Fixture 2
Fixture 3
Fixture 4
Step 1
Step 2
Step 3
Step 4
Step 1
Example 2:
Let’s create a 4 fixture intensity animation (a chase) using
fixtures 1 to 4:
•Fade up the fixture 1 to full and fade down fixtures 2, 3
and 4 to zero (Step 1 below).
•Open the Intensity Animate app icon.
•Select fixtures 1 through 4 by holding fixture [1] button
and tapping fixture [4] button (or tap them individually).
Touch Create and the animation runs as an intensity chase.
Fixture 1
Fixture 2
Fixture 3
Fixture 4
Step 1
Step 2
Step 3
Step 4
Step 1
All animation Apps have controls for:
•Speed in BPM (Beats Per Minute).
•Crossfade: When set to “0%”, the animation snaps
from step to step. When set to “100%”, it fades from
step to step. In between settings give a proportional
crossfade and a pause.
•Direction: Forward, Reverse, Centre Out or Centre In.
Centre Out and Centre In work best with an odd
quantity of fixtures. If you select an even number of
fixtures you should start with a symmetrical pattern
(e.g. First and Last fixture).

Mantra Lite
Quick Start Guide
Page 15
The only limitation for animations is that there must be at least
2 fixtures selected and there must be at least one different
setting in one of the fixtures. Multiple animations can be
running simultaneously.
13.1 Recording Animations
When you record the output of the Mantra as a cue it includes
any animations that are running. Recording animations will
automatically clear the animations from the yellow faders. If
you want to keep the animations running on the output, fade
up the red playback fader on which you make the recording.
See section 16 for details on how to record cues.
14 Shapes App.
The Shapes App provides a quick and simple way of creating
continuously moving positions on fixtures that have Pan and
Tilt attributes by constantly varying those attributes.
To create a shape, from the “Home” screen, open the “Apps”
page (see section 8) then touch the “Position”Shapes app
icon.
Fade up the fixture(s) to which the shape is to be applied. This
automatically selects the fixture(s).
The Shape App has controls for:
•Ellipse (clockwise or anti-clockwise).
•Rectangle (clockwise or anti-clockwise).
•Triangle (clockwise or anti-clockwise).
Scroll down
for “Rotate”

Mantra Lite
Quick Start Guide
Page 16
•Random.
•Pan Amplitude.
•Tilt Amplitude.
•Speed (in seconds).
•Spread (in percentage). Applies when 2 or more
fixtures are selected and spreads them around the
movement shape. When set to 0%, all fixtures are
focused on the same point as they move around the
shape. When set to 100% the fixtures are evenly
spaced apart as they move around the shape. In
between values vary the spread. Does not apply to the
“Random” shape.
•Rotate (in degrees). Rotates the shape about its axis.
Does not apply to the “Random” shape.
Touch Create and the shape runs.
Multiple shapes can be created by selecting New Shape and
repeating the procedure above.
14.1 Recording Shapes
When you record the output of the Mantra as a cue it includes
any shapes that are running. Recording a shape will
automatically clear that shape from the yellow faders. If you
want to keep the shape running on the output, fade up the red
playback fader on which you make the recording. See section
16 for details on how to record cues.
15 Clearing Fixtures
If you have used any Apps to control fixture attributes such as
selecting a colour or position or created an animation(s) or
shape(s), you can clear these settings and restore the
fixture(s) to its default settings (open, white, centred beam)
and delete any animations.
From the “Apps” screen, touch Clear All or to only clear
specific items touch Clear then make your choices from the
screen.

Mantra Lite
Quick Start Guide
Page 17
Note: Recording a cue (see below) that contains an animation
or shape automatically clears that animation or shape from the
yellow faders.
16 Recording The Output
When you have adjusted the intensity and colour of your fixtures
and possibly created an animation(s) and or shapes you can
record the current output of the MANTRA onto a Red Playback
fader.
To record the current output onto a Red Playback fader,
tap [Record] then tap the button below the Red Playback
fader of your choice[1-10]. All of the attributes of any fixture with
an intensity level greater than 0% will be included and the
recording is called a cue.
To include fixtures with no intensity, after taping
[Record], tap [Select], then tap (and light) the buttons
of any fixtures with no intensity that you want to include in the
cue.
The look on stage can now be played back from the recorded
cue (see Playback below). This frees up the yellow faders ready
for you to create another lighting look and to record it into
another cue.
If you record a cue to a Red Playback that already contains a
single cue you are offered 2 choices:
•“Overwrite”. Replaces the existing cue.
•“Add”. Creates a "Cue-list" with the new cue following
the existing cue. See section 17.1
If you record a cue to a Red Playback that already contains a
Cue-list the new cue is added after the current cue in the list.
The Red "Playback Master" fader has overall intensity control of
the Red playbacks.
16.1 Pages
There are 10 red playback faders and 10 pages of memory
giving a total of 100 memories. Each memory can contain
either a single cue or a "cue-list" which can contain up to 250
cues.

Mantra Lite
Quick Start Guide
Page 18
•Repeated taps of the [Page] button will step
through the 10 pages of memory.
•To switch directly to a page number; HOLD
[Page] and TAP a red fader button [1 to 10].
The current page number is shown in the top left corner of the
“Home” screen and the contents of the red playback faders are
shown along the bottom.
17 Playback
To playback a recorded cue, fade up the Red Playback Master
to full and fade up the Red Playback fader where you recorded
the cue (remember to select the correct page). You might want
to fade down the Yellow master (or all of the yellow fixture
faders) after you bring up the Red playback, so that you only
see the recorded look on the output.
Different looks can be recorded in different cues so that you can
easily change the entire look on stage by only using the Red
Playbacks.
Unlike the Yellow Fixture faders that only control intensity, the
Red Playback faders control all of the attributes of the fixture
that have beenrecorded in thecue. This allows you to crossfade
from one Playback to another with a smooth transition of
intensity, colour and position. See Latest Takes Precedence
(LTP) below.
17.1 Cue-lists
If a Red Playback contains a cue-list you can crossfade to the
next cue in the list by tapping its playback button (below its
fader). The crossfade uses the “fade in” and “fade out” times in
the cues. See section 18.
Every cue in a cue-list can contain a “Link Time” (0.1 seconds
to 60 minutes) or “Link Time” can be set to “None”.
•If a cue in a cue-list contains a link time, then when the
cue is played, the link time starts counting down. When
the time expires the next cue in the cue-list is
automatically played.

Mantra Lite
Quick Start Guide
Page 19
•If the Link Time is set to “None”, then the button below
the red fader must be used to manually play the next
cue
To crossfade in the reverse direction HOLD the [Back]
button whilst tapping the playback button.
The current cue has a white background. A pointer indicates
when a fade is in progress.
The cue-list can be manually played as a “list” or automatically
played as a “chase”. See section 18.
17.2 ICPB Filters
When a memory is played back it includes all of the Intensity,
Colour, Position and Beam (I C P B) attribute groups of the
fixtures recorded in the cue however for extra flexibility you can
choose which groups of attributes are included in the playback.
For example you could choose to only playback colours from
one cue list or choose to only playback positions from another
cue list. See section 18 for more details.
17.3 Latest Takes Precedence
The value for each attribute of a fixture (intensity, colour,
position, etc.) that appears on the output is determined by a
method known as LTP(Latest Takes Precedence) and by fader
position. An LTP action occurs when a red fader is raised
above zero. When this occurs, the fader will take control of its
attributes and they will fade to their levels in that fader following
the fader movement and fade times. When that fader reaches
100%, it fully overrides all other faders containing attribute
values for the same fixtures.
For example:
Touch the Playback
icon to modify the
cue-list
Playing as
a “list”
Fade in
progress

Mantra Lite
Quick Start Guide
Page 20
We have 3 cues recorded on red playback faders 1 to 3 with a
single LED fixture in each cue. In the first fader the fixture is
red, in the second it is blue and in the third it is yellow.
•Fade up fader 1 to full. The fixture fades to red.
•Fade up fader 2 to full. The fixture fades to blue.
•Fade down fader 1 and nothing happens because fader 2
is the latest (LTP) and it is at full.
•Fade up fader 3 and the fixture fades to yellow because
fader 3 is the latest.
•Fade down fader 3 and the fixture fades back to blue (the
previous latest).
Remember thatwhen the latest redfader to beraised from zero
is at full, other faders controlling the same fixtures can be faded
down without having an effect.
17.4 Live Speed
“Live Speed” allows you to override the fade times and speeds
of cues, chases, animations and shapes. The changes are
only a temporary offset applied to the settings saved in the cue
or on the live yellow faders. The settings in recorded cues are
not altered.
From the “Home” screen press Live Speed.
The “Live Speed” screen has controls to override the following
parameters:
•“Fade In/Out” times of a cue.
•“Speed” “Pause/Play” of a chase, animation or shape.
Reset
