LSI ENTERPRISE Series Guide

LUMINAIRE ASSEMBLY:
MAKE CERTAIN THE POWER SUPPLY IS TURNED OFF
BEFORE STARTING INSTALLATION.
MAKE CERTAIN LINE VOLTAGE CORRESPONDS WITH BALLAST
PRIMARY VOLTAGE SELECTED ON BALLAST TERMINAL BLOCK!
NOTE: PACKAGING MATERIALS SHOULD BE USED TO
PROTECT PAINT FINISH WHEN ASSEMBLING
FIXTURES & POLES ON PARKING LOT SURFACE
OR GROUND.
1. CAREFULLY FEED LUMINAIRE LEADS COILED IN SLIPFITTER INTO POLE
TOP WITH FISH TAPE. SLIDE FIXTURE SLIPFITTER ONTO 4" POLE OR TENON.
TIGHTEN SLIPFITTER SET SCREWS (6X) TO 10-12 FT/LBS TORQUE.
2. UNSCREW BALLAST ACCESS COVER BY TURNING COUNTER CLOCKWISE. THE
BALLAST ASSY IS FACTORY INSTALLED, AND SUPPLIED WITH FIXTURE SUPPLY
LEAD WIRES. INSERT FIXTURE SUPPLY LEAD WIRES INTO CORRECT VOLTAGE POSITION
ON BALLAST ASSEMBLY TERMINAL BLOCK. TIGHTEN TERMINAL SCREWS TO 4.4 IN/LBS TORQUE.
CONNECT LAMP CONNECTOR TO THE BALLAST SECONDARY CONNECTOR. REPLACE BALLAST
ACCESS COVER BY SCREWING CLOCKWISE UNTIL COVER SEATS SNUGLY AGAINST O-RING
SEAL. TO SERVICE BALLAST ASSY, DISCONNECT POWER, DISCONNECT SUPPLY LEADS &
SECONDARY CONNECTOR. REMOVE 10-24 HEX SKT CAP SCREWS (2X) & LIFT ASSY BY HANDLE
TO REMOVE.
3. FIXTURE MAY NEED TO BE ROTATED ONCE POLE IS ERECTED. LOOSEN SLIPFITTER
SET SCREWS & ROTATE FIXTURE ASSEMBLY TO PROPERLY ORIENT REFLECTOR PER
THE SITE LIGHTING PLAN. TYPE 2, 3, & FP/FT REFLECTORS HAVE BEAM DIRECTION
LABELS INDICATING DIRECTION OF REFLECTOR BEAM. ONCE FIXTURES ARE ROTATED
PROPERLY, RE-TIGHTEN SLIPFITTER SET SCREWS (6X) TO 10-12 FT/LBS TORQUE.
ASSEMBLY TOOLS REQUIRED:
3/16" HEX KEY WRENCH TORX T-25 DRIVER
5/32" HEX KEY WRENCH FISH TAPE
Ballast
Assy
BEFORE PROCEEDING, READ ALL INSTRUCTIONS CAREFULLY TO INSURE PROPER & SAFE INSTALLATION.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
WARNING:
WARNING: RISK OF FIRE OR ELECTRICAL SHOCK. DISCONNECT POWER BEFORE INSTALLING OR SERVICING.
WARNING: ALL WIRING TO BE PER NATIONAL & LOCAL ELECTRICAL CODES, BY A LICENSED QUALIFIED ELECTRICIAN.
IMPORTANT: WHEN LAMPING ALWAYS WEAR EYE PROTECTION. MAKE SURE AREA BELOW FIXTURE IS CLEAR.
NOTE:
NOTE: IF LAMP IS INSTALLED DIRTY, OPERATING HOURS & PERFORMANCE WILL SIGNIFICANTLY DECREASE.
LSI Industries Inc. 10000 Alliance Road Cincinnati, OH 45242 513-793-3200 www.lsi-industries.com Fax [phone]
PAGE 1 ENTINTLEXPTINST P/N 312658 REV 3/07
ENTERPRISE / INTREPID / LEXINGTON PT Series
INSTALLATION & ASSEMBLY INSTRUCTIONS
Slipfitter
Slipfitter
Set Screws
(6x)
Ballast Access
Cover
Turn Counter Clockwise To Remove
Turn Clockwise To Replace Cover
Ballast
Assy
(Shown
Removed)
Fixture Top
Cap (Int Shown)
Pole

LAMP & BALLAST SERVICE:
MAKE CERTAIN THE POWER SUPPLY IS TURNED OFF BEFORE STARTING SERVICE.
MAINTENANCE: This luminaire should be periodically maintained. Insects and debris should not be allowed to accumulate on the luminaire. The lens
should be cleaned periodically. If service parts are required a parts list can be obtained by contacting your local distributor or calling lsi lighting solutions
plus customer service @ 513-793-3200. Failure to follow the manufacturers instructions, or making any modifications to the product can void the warranty.
Product failures resulting from poor maintenance or abuse will not be covered by warranty. Consult warranty for full details.
1. TO RELAMP FIXTURE REMOVE FIXTURE TOP CAP (SEE FIG. 6).
2. FOR HORIZONTAL REFLECTOR : ROTATE 1/4 TURN (2X) & OPEN RELAMP DOOR AS SHOWN IN FIG. 7 & 8. REMOVE
LAMP & REPLACE WITH SAME TYPE & WATTAGE PER RELAMP MARKING LABEL. REPLACE RELAMP DOOR INTO REFLECTOR.
ROTATE 1/4 TURN FASTENERS (2X).
3. FOR VERTICAL REFLECTOR: REMOVE LAMPHOLDER/BRACKET ASSY FROM REFLECTOR BY PULLING AS INDICATED BY
ARROWS ON BRACKET (SEE FIG. 9). REMOVE LAMP & REPLACE WITH SAME TYPE & WATTAGE PER RELAMP MARKING LABEL.
REPLACE LAMPHOLDER/BRACKET ASSY INTO REFLECTOR.
4. REPLACE FIXTURE CAP & TIGHTEN 10-24 TORX SCREW (3X) TO 24 IN/LB.
Relamp Door
Lampholder
Bracket Assy
FOR SERVICING ELECTRICAL COMPONENTS REFER TO (PG 1) STEP 2 TO ACCESS ELECTRICAL WIRING & BALLAST ASSY.
ONLY REPLACE LUMINAIRE PARTS WITH IDENTICAL PARTS SUPPLIED BY LSI LIGHTING SOLUTIONS PLUS.
Reflectors:
Primary Beam
Direction
Marking Label
Primary Beam
Direction
Marking Label
Primary Beam
Direction
Marking Label
Primary Beam
Direction
Marking Label
Due To Symmetrical Beam
Type 5 Orientation Is Not Critical
Type 5 Orientation Is Not Critical
Due To Symmetrical Beam
LSI Industries Inc. 10000 Alliance Road Cincinnati, OH 45242 513-793-3200 www.lsi-industries.com Fax [phone]
PAGE 2 ENTINTLEXPTINST P/N 312658 REV 3/07
ENTERPRISE / INTREPID / LEXINGTON PT Series
INSTALLATION & ASSEMBLY INSTRUCTIONS
C Copyright 2007 LSI Industries Inc
Fig. 6 Fig. 7 Fig. 8 Fig. 9
Fixture
Top Cap
Screw 10-24
Torx (3x)
Retainer (2x)
Type 2 V
Type 2 H
Type 3 V
Type 3 H
Type FP V
Type FT H
Type 5 V
Type 5 H
Street Side Street Side Street Side
Street Side Street Side Street Side
