Microphone input electronically balanced, discrete input configuration
Frequency response 10Hz to 55kHz, +/-3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Gain range 0dB to 44dB (MIC)
SNR (Signal to Noise Ratio) 115dB
Line input electronically balanced
Frequency response 10Hz to 55kHz, +/- 3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Sensitivity range +15dBu to -30dBu
Line input Balanced
Frequency response 10Hz to 55kHz, +/-3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Microphone input 1.4kOhm
Channel Insert return 2.5kOhm
All other inputs 10kOhm or greater
Tape out 1kOhm
All other output 120Ohm
Hi shelving +/- 15dB @12kHz
Mid bell +/- 12dB @2.5kHz
Low shelving +/- 15dB @80Hz
Low Cut filter 75Hz, 18dB/oct.
A/D and D/A converters 24 bit
DSP resolution 24 bit
Type of effects
Hall, Room, Vocal & Plate REVERBS
Mono & Stereo DELAY (max DELAY TIME 650ms)
Chorus, Flanger & Reverb
MODULATIONSREVERB+DELAY,
REVERB+CHORUS,
REVERB+FLANGER combinations
Presets 256
Controls
16-position PRESET Selector
16-position VARIATION selector
MUTE SWITCH with LED indicator
PEAK LED
Noise (Bus noise) Fader 0 dB, channels muted: -100dBr (ref.:+4dBu)
Fader 0dB, all input channels assigned and set to
UNITY gain: -90dBr (ref.:+4dBu)
Max output +22dBu balanced XLR,
'+22dBu unbalanced, 1/4"
acks
AUX Returns gain range -∞to +20dB
AUX Sends max out +22dBu
Main voltage USA/Canada 100- 120V~, 60Hz
Europe 210- 240V~, 50Hz
UK/Australia 240V ~, 50Hz
Power Consumption 17.1 watts
Dimension(W*D*H) 270mm*310mm*34/45mm(7.79''*8.95''*1.01/1.30'')
Net weight 3.0Kg(6.61 lb)
Shipping weight 3.6Kg(7.94 lb)
DSP Section (For
AMX-140FX MKII only)
Main Mix Section
Physical
Power supply (AC/AC
Adaptor)
Mono input channels
Stereo input channels
Impedances
Equalization
