MDW 9031/9031DCP Wireless Pocket Phone Quick Reference
503-801-165 Issue 2 February 1999 1
Quick Reference
Handset Controls
AB
234
65
MSG
212 555 1212
ON
78
CD
1
TransTalk
On/Off
Feat/P
Conf
GHI
PQRS
OPER
Trans
Hold
Redial
12
4
JKL
ABC
3
DEF
5
MNO
6
TUV
8
0
WXYZ
97
Mute
Feat/P
Exit (9031DCP Only)
(Feature/Program)
On/Off
Press to turn the
handset on.
ON
appears in handset
display. To turn off,
press again. Turn on to
make or answer a call,
and turn off to“hang
up.”
Antenna
Extend fully to
maximize the handset
range and voice
quality.
Receiver
Receives the sound
of your caller's voice,
unless a headset is
connected.
Headset On/Off
Press to turn the headset on
if the headset is plugged in.
ON appears in handset
display. To turn off, press
again. Turn on to make or
answer a call, and turn off to
“hang up.”
Lanyard Loop
Attach lanyard for
carrying handset.
Volume Control
Press "+" to increase
or "-" to decrease
volume of receiver or
alerter.
Conf (Conference)
Press to conference
in (add) another
party to your call.
Trans (Transfer)
Press to transfer
a call to another
extension.
Handset Display
Displays status of
lines and range. Also
see “Handset
Display” on next page.
Column
Use, with Select
button, to choose a
line or programmable/
intercom/drop button.
Redial
Press to redial
the last number
manually dialed from
the handset.
Mute
Press to turn the micro-
phone off for privacy .
Select
Use to move the
Selection rectangle,
and, with Column
buttons, to choose a
line or programmable/
intercom/drop button.
Also use to wake-up
the phone.
Headset Connector
Plug in the headset cord
to use the headset.
Hold
Press to put a call on
hold.
Scroll (9031DCP Only)
When the Selection
rectangle is in the top row,
press to toggle between
the first and second line of
the display.
Press the Feat/P twice
to Exit the Softkey
menu.
Press to use dial-code
features (PARTNER
systems only) or to
enter programming
mode.
®
qrtitle.book Page 1 Friday, December 18, 1998 9:52 AM

Quick Reference
MDW 9031/9031DCP Wireless Pocket Phone Quick Reference 503-801-1652 Issue 2 February 1999
Handset Display
1 Information you would see on a wired system phone’s display, (except
time), based on your communications system:
LCL:P, D, M1, or M2 = Local Mode:
communications system
WIRELESS TEST = Handset in Wireless Test Mode
VIBR = Vibrator enabled
PSEL = Line Preselection enabled
PRESELECTION:ON/OFF = Line Preselection Mode:status
CHANGE BUTTN MAP = Communications system setting is
wrong
MAP:P, D, M1, M2 = Button Mapping Mode: setting
NO LINK = Handset is not communicating with radio module
2 MSG indicates that you have a message.
3 RANGE indicates that the handset is out of range or almost out of range.
Handset also beeps.
4 ON indicates that handset was turned on by pressing O.
5 Battery icon flashes to indicate a low battery condition. Handset also
emits 2 beeps.
6 No Ring icon indicates that the alerter is disabled.
7 MUTE indicates that handset microphone was turned off by pressing
M.
1
2
8
7
6
9
543
qrtitle.book Page 2 Friday, December 18, 1998 9:52 AM

MDW 9031/9031DCP Wireless Pocket Phone Quick Reference
503-801-165
Quick Reference
Issue 2 February 1999 3
8 Line Status Indicators show the status of line or
programmable/intercom/drop buttons. See “Line Status Indicators”
below.
9 Selection rectangle indicates the active row for line or
programmable/intercom/drop button selection.
When the display is blank, the handset is either turned off or in “sleep”
mode. Activate the display by pressing Oor " .
Line Status Indicators
Each line status indicator corresponds to a specific outside line or
programmable/intercom/drop button:
PARTNER Systems
A triangle ( ) is the equivalent of a green LED on a wired phone.
A rectangle ( ) is the equivalent of a red LED on a wired phone.
All Other Systems
A triangle ( ) is the equivalent of a red LED on a wired phone.
A rectangle ( ) is the equivalent of a green LED on a wired phone.
qrtitle.book Page 3 Friday, December 18, 1998 9:52 AM

Quick Reference
MDW 9031/9031DCP Wireless Pocket Phone Quick Reference 503-801-1654 Issue 2 February 1999
Volume Adjustment
To increase or decrease the volume of the handset alerter or the receiver
(earpiece):
•Alerter: Press the “+” or the “-” button while the MDW 9031/9031DCP
is awake but turned off. If the display is dark (the phone is in “sleep”
mode), press " to wake it up, then press the “+” or the “-” button.
•Receiver: Press the “+” or the “-” button while the MDW
9031/9031DCP is turned on.
qrtitle.book Page 4 Friday, December 18, 1998 9:52 AM

MDW 9031/9031DCP Wireless Pocket Phone Quick Reference
503-801-165
Quick Reference
Issue 2 February 1999 5
Battery Charger LEDs
The color of the battery charger’s LEDs indicates the state of the
corresponding battery pack, as shown in the following table:
Battery
charger LED
shows...
If it is the
SPARE LED,
the battery
pack in the
Spare battery
compartment...
If it is the
HANDSET
LED, the
battery pack
in the
Handset...
If it is the
REFRESHLED,
the Refresh
button was
pressed, and
the Handset
battery pack...
Steady orange Is charging Is charging N/A
Steady green Is fully charged Is fully charged N/A
Flashing red
See Note
below.
Has one of the
following
problems...
•Is not seated
properly in the
charger
•Has dirty
contacts
•Is defective
Has one of the
following
problems...
•Is not
seated
properly in
the charger
•Has dirty
contacts
•Is defective
N/A
Steady red Is in the Discharge
portion of the
Refresh cycle.
Is in the
Discharge
portion of the
Refresh cycle.
Is in the
Discharge portion
of the Refresh
cycle.
Note: If either the SPARE LED or the HANDSET LED is flashing
red, both battery packs must be removed from the charger to
clear the flashing-red condition. Address the possible
problems for one battery pack at a time to determine whether
one is bad.
qrtitle.book Page 5 Friday, December 18, 1998 9:52 AM

Quick Reference
MDW 9031/9031DCP Wireless Pocket Phone Quick Reference 503-801-1656 Issue 2 February 1999
Help!
MDW 9031
If you need help when using your MDW 9031 with a PARTNER®,
MERLIN®, or MERLIN LEGEND®system in the continental U.S.,
call 1 800 628-2888.
MDW 9031DCP
If you need help when using your MDW 9031DCP with a DEFINITY®
system in the continental U.S., call 1 800 225-7585, or contact the Lucent
Customer Care Center at 1 800 241-2121.
For all other systems, follow the procedure you normally use to get support
for your communications system. Outside the continental U.S., contact your
Lucent Technologies Representative or local Authorized Dealer.
Making a Call
1 Press O.
2 If desired, press "
to move the Selection rectangle; then press '
corresponding to the line you want.
3 Dial the call.
4 To end the call, press O.
Answering a Call
1 Press O.
2 Speak into the handset.
3 To end the call, press O.
qrtitle.book Page 6 Friday, December 18, 1998 9:52 AM

MDW 9031/9031DCP Wireless Pocket Phone Quick Reference
503-801-165
Quick Reference
Issue 2 February 1999 7
Preselecting a Line or Button
After Line Preselection is enabled, proceed as follows:
1 If the display is blank, press "
.
2 If necessary, press "
to move the Selection rectangle.
3 Press '
corresponding to the line or button you want.
4 Press Oto access the line or button.
Accessing Certain Voice Mail Systems
with a DEFINITY System
Note: This section only applies to the MDW 9031 Pocket Phone.
After dialing into some voice mail systems (for example, Octel 200/250,
300/350), the MDW 9031 Pocket Phone may not provide touch tones in
order to access the voice mail system prompts.
If you experience this problem after dialing into your voice mail system,
press the Feat/Pbutton twice. After pressing the Feat/P button twice, your
Pocket Phone will generate touch tones and you will be able to navigate
within your voice mail system. When you end your call to your voice mail
system, or press any non-dialpad button on your Pocket Phone (that is, Conf,
Trans, Hold, Redial, Mute), your MDW 9031 will stop generating touch
tones behind the voice mail system. You will need to re-enter
Feat/Pwhenever you dial into these voice mail systems or after you have
pressed a non-dialpad button.
qrtitle.book Page 7 Friday, December 18, 1998 9:52 AM

Quick Reference
MDW 9031/9031DCP Wireless Pocket Phone Quick Reference 503-801-1658 Issue 2 February 1999
Changing Settings or Performing Tests in Local Mode
1 Make sure the handset is turned off.
2 Press and hold "
for 3 seconds.
3 While still holding "
, press O.
4 Press one of the following:
A(2) to enable or disable the alerter.
L(5) to enable or disable backlighting.
P(7) for 3 seconds, then "to enable or disable
Line Preselection.
V(8) to enable or disable the vibrator.
W(9) to enter Wireless Test Mode, then 1 for signal strength 2
for voice quality 3 for matching radio module and slot number 5
for handset power settings # to enter Local Test Mode.
5 Press Oto exit.
!CAUTION:
The MDW 9031/9031DCP handset is a radio device and, like all radio
devices, should not be placed next to a pacemaker. See “Guidelines
for Safeand Efficient Operation” in the MDW 9031/9031DCP Wireless
Pocket Phone Installation and Use guide for more information.
