Lucom bivias v2 User manual

Twin Cellular Module Router
Bivias v2
USER’S MANUAL
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

USED SYMBOLS
Used symbols
Danger – Information regarding user safety or potential damage to the router.
Attention – Problems that can arise in specific situations.
Information, notice – Useful tips or information of special interest.
GPL licence
Source codes under GPL licence are available free of charge by sending an email to:
[e-mail].
Advantech B+B SmartWorx s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Manual Rev. 1 released in CZ, May 6, 2016
i
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

CONTENTS
Contents
1 Safety Instruction 2
2 WEEE directive 3
3 Router Description 4
4 Contents of Package 5
5 Router Design 6
5.1 Router versions .................................... 6
5.2 Delivery identification ................................ 7
5.3 Version of module firmware ............................. 7
5.4 Order codes ...................................... 8
5.5 Basic dimensions of the router box ......................... 10
5.6 Mounting recommendations ............................. 10
5.7 Removing from the DIN rail ............................. 13
5.8 Description of the front panel ............................ 14
5.8.1 Status indication ............................... 15
5.8.2 Power connector PWR ............................ 16
5.8.3 Antenna connector ANT1, ANT2, DIV1, DIV2, GPS and WiFi ...... 17
5.8.4 SIM card reader ............................... 18
5.8.5 Ethernet Port ETH .............................. 19
5.8.6 PORT1 .................................... 20
5.8.7 PORT2 .................................... 20
5.8.8 USB Port ................................... 21
5.8.9 I/O Port .................................... 21
5.8.10 Reset ..................................... 23
6 First Use 24
6.1 Connecting the router before first use ....................... 24
6.2 Start .......................................... 25
6.3 Configuration ..................................... 25
6.3.1 Configuration over web browser ....................... 25
6.3.2 Configuration over Telnet .......................... 26
7 Technical Parameters 27
7.1 Basic parameters ................................... 27
7.2 Standards and regulations .............................. 27
ii
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

CONTENTS
7.3 Technical parameters of module .......................... 28
7.3.1 LTE module (LL, LH and LC versions) ................... 28
7.3.2 HSPA+ module (LH, HH and HC versions) ................. 28
7.3.3 CDMA module (LC and HC versions) .................... 29
7.4 Technical parameters of GPS ............................ 30
7.5 Technical parameters of processor ......................... 31
7.6 Technical parameters of I/O port .......................... 31
7.7 Technical parameters of expansion port ...................... 31
8 Recommended Literature 32
9 Troubleshooting 33
9.1 FAQ .......................................... 33
10 Customers Support 35
iii
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

LIST OF FIGURES
List of Figures
1 Contents of package ................................. 5
2 Front panels of Bivias v2 SL ............................. 6
3 Example of the router label ............................. 7
4 Basic dimensions of the router box ......................... 10
5 Space around antennas ............................... 11
6 Cable routing ..................................... 11
7 Space in front of connectors ............................. 12
8 Default position of DIN holder ............................ 13
9 Removing from the DIN rail ............................. 13
10 Front panel Bivias v2 SL ............................... 14
11 Power connector ................................... 16
12 Connection of power supply ............................. 16
13 Connecting of the antenna .............................. 17
14 Ejected SIM holder .................................. 18
15 Ethernet connector .................................. 19
16 Connection of Ethernet cable ............................ 19
17 PORT1 cable connection .............................. 20
18 PORT2 cable connection .............................. 21
19 USB connector .................................... 21
20 I/O connector ..................................... 22
21 Connection of I/O cable ............................... 22
22 Connection of input and output to the router .................... 22
23 Router reset ...................................... 23
24 Router connection .................................. 24
25 Entering the IP address of the router ........................ 25
26 Entering login information .............................. 25
27 Router web interface ................................. 26
iv
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

LIST OF TABLES
List of Tables
1 Router versions .................................... 6
2 Delivery identification ................................ 7
3 Version of firmware module ............................. 7
4 Ordering codes .................................... 9
5 Front panel description ................................ 14
6 Status indication ................................... 15
7 Connection of power connector ........................... 16
8 Connection of Ethernet connector .......................... 19
9 Connection of USB connector ............................ 21
10 Connection of I/O port ................................ 21
11 Description of reset and restart router ....................... 23
12 Basic parameters ................................... 27
13 Standards and regulations .............................. 27
14 LTE module (LL, LH and LC versions) ....................... 28
15 HSPA+ module (LH, HH and HC versions) ..................... 29
16 CDMA module (LC and HC versions) ........................ 29
17 Technical parameters of GPS ............................ 30
18 Technical parameters of processor ......................... 31
19 Technical parameters of I/O port .......................... 31
1
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

1. SAFETY INSTRUCTION
1. Safety Instruction
Please, observe the following instructions:
•The router must be used in compliance with all applicable international and national laws
and in compliance with any special restrictions regulating the utilization of the router in
prescribed applications and environments.
•To prevent possible injury and damage to appliances and to ensure compliance with
all relevant provisions, use only the original accessories. Unauthorized modifications or
the use of unapproved accessories may result in damage to the router and a breach
of applicable regulations. Unauthorized modifications or use of unapproved accessories
may void the warranty.
•The router can not be opened.
•Turn off the router and disconnect it from power supply before handling of the SIM card.
•Caution! The SIM card could be swallowed by small children.
•Input voltage must not exceed 36 V DC max.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture and high temperature.
•The router should not be used in locations where flammable and explosive materials
are present, including gas stations, chemical plants, or locations in which explosives
are used. We remind the users of the duty to observe the restrictions concerning the
utilization of radio devices at such places.
•Switch off the router when traveling by plane. Utilization of the router in a plane may
endanger the operation of the plane or interfere with the mobile telephone network, and
may be unlawful. Failure to observe these instructions may result in the suspension
or cancellation of telephone services for the respective client, or, it may result in legal
sanctions; it may also result in both eventualities.
•When using the router in the close proximity of personal medical devices, such as cardiac
pacemakers or hearing aids, you must proceed with heightened caution.
•The router may cause interference when in the close proximity of TV sets, radio receivers
or personal computers.
•It is recommended that you should create an appropriate copy or backup of all the im-
portant settings that are stored in the memory of the device.
2
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

2. WEEE DIRECTIVE
2. Product Disposal Instructions
The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been
introduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques to minimize the impact on the environment. This product contains high
quality materials and components which can be recycled. At the end of it’s life this product
MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-
tions of your supplier for disposal information.
3
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

3. ROUTER DESCRIPTION
3. Router Description
Industrial router Bivias v2 is equipped with two independent communication modules for
wireless connectivity of various equipments and devices via Ethernet interface 10/100 to the
internet or intranet. Each module can and should use the infrastructure of another cellular
service provider. This router allows customer to combine modules for different mobile tech-
nologies – LTE or HSPA+ technology on the first module position and LTE, HSPA+ or CDMA
technology on the second position. Due to high download and upload speed is this device
an ideal wireless solution for traffic and security camera systems, individual computers, LAN
networks, automatic teller machines (ATM) and other self-service terminals and machines.
As a standard, Bivias v2 router is equipped with one Ethernet 10/100, one USB Host port,
one binary Input/output (I/O) port and two SIM cards. The wide range of interface options of
this router further expands an expansion ports designated as PORT1 and PORT2 which are
mounted on the customer’s request. For PORT1 are available: Ethernet port 10/100, serial
interface ports RS232, RS485, RS422, MBUS or inputs/outputs (I/O – CNT). PORT2 may be
equipped with serial interfaces RS232, RS485, RS422, MBUS, wireless interfaces WIFI or
WMBUS, SDH expansion port or inputs/outputs (I/O – CNT). Both of ports can be fitted with
internal switch (exp. port SWITCH). This wireless router is supplied in a metal casing.
Configuration is done via web interface protected by password. The router supports cre-
ation of VPN tunnels using technologies IPsec, OpenVPN, L2TP to ensure safe communica-
tion. Web interface provides detail statistics about the router activities, signal strength, detailed
log, etc. Cellular router supports functions: DHCP, NAT, NAT-T, DynDNS, NTP, VRRP, control
by SMS and many other functions.
Other diagnostic functions ensuring continuous communication include automatic inspec-
tion of PPP connection offering an automatic restart feature – in case of connection losses, or
hardware watchdog which monitors the status of the router. With the help of a special window
(start up script window) you may insert Linux scripts for various actions. For some applications
the key option to create several different configurations for one wireless router, the so-called
profiles (maximum of 4), and the option to switch between them (for example via SMS, binary
input status, etc.) is essential. Cellular routers Bivias v2 may automatically upgrade config-
uration and firmware from server. This allows mass reconfiguration of many routers in one
time.
The router also supports additional software like R-SeeNet for permanent traffic monitoring
of routers or communication VPN server Digicluster.
Examples of possible applications
•mobile office
•fleet management
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
4
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

4. CONTENTS OF PACKAGE
4. Contents of Package
Basic delivered set of router includes:
•router,
•power supply,
•crossover UTP cable,
•up to three external antennas,
•clip for the DIN rail,
•paper start guide.
Figure 1: Contents of package
Temperature range for power supply is reduced to 0 ◦C to +40 ◦C!
As optional accessories can also be supplied the following expansion ports (up to two
boards):
•RS232, RS485/422, MBUS, ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH.
•Separation columns for mounting expansion boards are included.
5
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5. Router Design
5.1 Router versions
Bivias v2 router is supplied in the following versions (see table below). All versions are
available in the metal box.
Router versions Router Box
SIM1 SIM2
I/O
USB
PORT1 PORT2
ETH
Bivias v2 LL SL Metal 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Bivias v2 LH SL Metal 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Bivias v2 LC SL Metal 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Bivias v2 HH SL Metal 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Bivias v2 HC SL Metal 1 x 1 x 1 x 1 x 1 x 1 x 1 x
Table 1: Router versions
Figure 2: Front panels of Bivias v2 SL
6
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5.2 Delivery identification
Trade name Type name Other
Bivias v2 LL SL Bivias-v2 LTE & LTE version in the metal box
Bivias v2 LH SL Bivias-v2 LTE & HSPA+ version in the metal box
Bivias v2 LC SL Bivias-v2 LTE & CDMA version in the metal box
Bivias v2 HH SL Bivias-v2 HSPA+ & HSPA+ version in the metal box
Bivias v2 HC SL Bivias-v2 HSPA+ & CDMA version in the metal box
Table 2: Delivery identification
Figure 3: Example of the router label
5.3 Version of module firmware
In the case of specifications with CDMA module applies that each operator may have a
different CDMA network, so it is necessary to generate a special firmware for each operator.
Version of the firmware is indicated by two-digit code in the name of the product.
Operator Code
Poland Orange 01
Poland Plus 02
Czech Republic O2 03
Germany Inet 04
Sweden Net.1 05
Norway Net.1 06
Russia Skylink 07
Netherlands Alliander 15
Table 3: Version of firmware module
Example of trade name: Bivias v2 HC-01 SL
7
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5.4 Order codes
For all specifications with CDMA module, order codes are given for the Polish operator
Orange. Another operator can be selected by changing two digits according to the table 3.
Expansion port Equipped port Ordering code
LTE/LTE without exp. port Bivias v2 LL SL set
LTE/LTE with Ethernet port PORT1 Bivias v2 LL ETH SL set
LTE/LTE with RS232 port PORT1 or PORT2 Bivias v2 LL RS232 SL set
LTE/LTE with RS458 port PORT1 or PORT2 Bivias v2 LL RS458 SL set
LTE/LTE with MBUS port PORT1 or PORT2 Bivias v2 LL MBUS SL set
LTE/LTE with CNT port PORT1 Bivias v2 LL CNT SL set
LTE/LTE with SWITCH port PORT1+PORT2 Bivias v2 LL SWITCH SL set
LTE/LTE with WIFI port PORT2 Bivias v2 LL WIFI SL set
LTE/LTE with WMBUS port PORT2 Bivias v2 LL WMBUS SL set
LTE/LTE with SDH port PORT2 Bivias v2 LL SDH SL set
LTE/HSPA+ without exp. port Bivias v2 LH SL set
LTE/HSPA+ with Ethernet port PORT1 Bivias v2 LH ETH SL set
LTE/HSPA+ with RS232 port PORT1 or PORT2 Bivias v2 LH RS232 SL set
LTE/HSPA+ with RS458 port PORT1 or PORT2 Bivias v2 LH RS458 SL set
LTE/HSPA+ with MBUS port PORT1 or PORT2 Bivias v2 LH MBUS SL set
LTE/HSPA+ with CNT port PORT1 Bivias v2 LH CNT SL set
LTE/HSPA+ with SWITCH port PORT1+PORT2 Bivias v2 LH SWITCH SL set
LTE/HSPA+ with WIFI port PORT2 Bivias v2 LH WIFI SL set
LTE/HSPA+ with WMBUS port PORT2 Bivias v2 LH WMBUS SL set
LTE/HSPA+ with SDH port PORT2 Bivias v2 LH SDH SL set
LTE/CDMA without exp. port Bivias v2 LC-01 SL set
LTE/CDMA with Ethernet port PORT1 Bivias v2 LC-01 ETH SL set
LTE/CDMA with RS232 port PORT1 or PORT2 Bivias v2 LC-01 RS232 SL set
LTE/CDMA with RS458 port PORT1 or PORT2 Bivias v2 LC-01 RS458 SL set
LTE/CDMA with MBUS port PORT1 or PORT2 Bivias v2 LC-01 MBUS SL set
LTE/CDMA with CNT port PORT1 Bivias v2 LC-01 CNT SL set
LTE/CDMA with SWITCH port PORT1+PORT2 Bivias v2 LC-01 SWITCH SL set
LTE/CDMA with WIFI port PORT2 Bivias v2 LC-01 WIFI SL set
LTE/CDMA with WMBUS port PORT2 Bivias v2 LC-01 WMBUS SL set
Continued on next page
8
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
Continued from previous page
Expansion port Equipped port Ordering code
LTE/CDMA with SDH port PORT2 Bivias v2 LC-01 SDH SL set
HSPA+/HSPA+ without exp. port Bivias v2 HH SL set
HSPA+/HSPA+ with Ethernet port PORT1 Bivias v2 HH ETH SL set
HSPA+/HSPA+ with RS232 port PORT1 or PORT2 Bivias v2 HH RS232 SL set
HSPA+/HSPA+ with RS458 port PORT1 or PORT2 Bivias v2 HH RS458 SL set
HSPA+/HSPA+ with MBUS port PORT1 or PORT2 Bivias v2 HH MBUS SL set
HSPA+/HSPA+ with CNT port PORT1 Bivias v2 HH CNT SL set
HSPA+/HSPA+ with SWITCH port PORT1+PORT2 Bivias v2 HH SWITCH SL set
HSPA+/HSPA+ with WIFI port PORT2 Bivias v2 HH WIFI SL set
HSPA+/HSPA+ with WMBUS port PORT2 Bivias v2 HH WMBUS SL set
HSPA+/HSPA+ with SDH port PORT2 Bivias v2 HH SDH SL set
HSPA+/CDMA without exp. port Bivias v2 HC-01 SL set
HSPA+/CDMA with Ethernet port PORT1 Bivias v2 HC-01 ETH SL set
HSPA+/CDMA with RS232 port PORT1 or PORT2 Bivias v2 HC-01 RS232 SL set
HSPA+/CDMA with RS458 port PORT1 or PORT2 Bivias v2 HC-01 RS458 SL set
HSPA+/CDMA with MBUS port PORT1 or PORT2 Bivias v2 HC-01 MBUS SL set
HSPA+/CDMA with CNT port PORT1 Bivias v2 HC-01 CNT SL set
HSPA+/CDMA with SWITCH port PORT1+PORT2 Bivias v2 HC-01 SWITCH SL set
HSPA+/CDMA with WIFI port PORT2 Bivias v2 HC-01 WIFI SL set
HSPA+/CDMA with WMBUS port PORT2 Bivias v2 HC-01 WMBUS SL set
HSPA+/CDMA with SDH port PORT2 Bivias v2 HC-01 SDH SL set
Table 4: Ordering codes
Code for the second expansion port must be written after the first port. See example below:
•Version with two LTE modules, Ethernet board and WIFI port:
Bivias v2 LL ETH WIFI SL set.
•Version with HSPA+ module, CDMA module, Ethernet board and WIFI port:
Bivias v2 HC-01 ETH WIFI SL set.
9
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5.5 Basic dimensions of the router box
Figure 4: Basic dimensions of the router box
5.6 Mounting recommendations
•possibility to be put on a work surface,
•DIN rail EN 60715 with included clip CKD2.
For the most of applications with a built-in router in a switch board it is possible to recognize
two kinds of environments:
•no public and industry environment of low voltage with high interference,
•public environment of low voltage without high interference.
For both of these environments it is possible to mount router to a switch board, the following
there is no need to have examination immunity or issues in connection with EMC according to
EN 60439-1 ed.2:00 + A1:04.
Compliance of EN 60439-1 ed.2:00 + A1:04 specification it is necessary to observe next
assembly of the router to the switch – board:
•For whip antennas we recommend to observe a distance of 6 cm from cables and metal
surfaces on every side due to the elimination of interference. While using an external
antenna except for the switch-board it is necessary to fit a lightening conductor.
10
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
•Before mounting a router on sheet-steel we recommend using a "cable" antenna.
Figure 5: Space around antennas
•For every cables we recommend to bind the bunch, we recommend for this use:
–Length of the bunch (combination of power supply and data cables) can be maxi-
mum 1.5 m. If the length of data cables exceeds 1.5 m or in the event of, the cable
leads towards the switch – board. We recommend installing over – voltage protec-
tors (surge suppressors).
–With data cables they mustn’t carry cables with reticular tension ∼230 V/50 Hz.
Figure 6: Cable routing
11
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
•Sufficient space must be left in front of individual connectors for handling of cables,
Figure 7: Space in front of connectors
•For correct function of the router we recommend to use in the switch-board earth-bonding
distribution frame for grounding of power supply of router, data cables and antenna.
12
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5.7 Removing from the DIN rail
DIN holder is suitable for DIN rail according to EN 60715 standard only. Default position
of CKD2 holder, which is used for mounting the router on a DIN rail, is shown in the following
figure:
Figure 8: Default position of DIN holder
For removing from the DIN rail it is necessary to lightly push upward the router so that the
top part of the CKD2 holder hitched to the DIN rail get out of this rail and then fold out the top
part of the router away from the DIN rail.
Figure 9: Removing from the DIN rail
13
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5.8 Description of the front panel
On the front panel is the following:
Caption Connector Description
PWR 2-pin Connector for the power supply.
ETH RJ45 Connector for connection into the local computer network.
PORT1 RJ45 Connector for expansion port ETHERNET or SWITCH.
PORT2 RJ45 Connector for expansion port WIFI or SWITCH.
ANT1 SMA Connector for main antenna (first module).
DIV1 SMA Connector for diversity antenna (first module).
ANT2 SMA Connector for main antenna (second module).
DIV2 SMA Connector for diversity antenna (second module).
GPS SMA Connector for GPS antenna. Only if the router is equipped
with a module for LTE technology!
WiFi R-SMA Connector for WIFI antenna. Available only when the
router is equipped with an expansion port WIFI.
USB USB-A Host Connector for connection of USB devices to the router. Sup-
ports devices with PL-2303 and FTDI USB/RS232 converters.
I/O 3-pin Connector for connection of the binary input and output.
SIM1 — Holder for the first SIM card.
SIM2 — Holder for the second SIM card.
Table 5: Front panel description
Figure 10: Front panel Bivias v2 SL
14
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]

5. ROUTER DESIGN
5.8.1 Status indication
About router status inform eight LED indicators on the front panel. ETH port, PORT1 and
PORT2 have two additional LEDs that provide information about port status.
Caption Color State Description
M1 Green /
Orange
On Indicates the activity of the first module (green color).
In the case of "HC" version with two HSPA+ SIM cards,
this LED diode indicates the operation of the first SIM
card with green color and operation of the second SIM
card with orange color.
M2 Orange On Indicates the activity of the second module
PWR Green Blinking
On
Fast blinking
Router is ready
Starting of the router
Updating firmware
DAT Red Blinking Communication in progress on radio channel
WAN Yellow 1x flash per sec.
2x flash per sec.
3x flash per sec.
Signal strength is from –50 dBm to –69 dBm
Signal strength is from –70 dBm to –89 dBm or differ-
ence between neighbours cells is exactly 3 dBm
Signal strength is from –90 dBm to –113 dBm or differ-
ence between neighbours cells is smaller than 3 dBm
USR Yellow Function of this LED diode can be selected by user
OUT Green On Binary output active
IN Green On Binary input active
ETH Green On
Off
Selected 100 Mbit/s
Selected 10 Mbit/s
ETH Yellow On
Blinking
Off
The network cable is connected
Data transmission
The network cable is not connected
PORT Green Depends on the expansion port (see user’s manual for used port)
PORT Yellow Depends on the expansion port (see user’s manual for used port)
Table 6: Status indication
State indication of WAN LED is updated every 10 seconds.
15
23-05-16
LUCOM GmbH * Ansbacher Str. 2a * 90513 Zirndorf * Tel. [phone] * Fax. [phone] * www.lucom.de
www.lucom.de [e-mail]
