DHB1700
DEMOLITION HAMMER BREAKER
DHB1700
SAFETY AND OPERATING MANUAL
O RIGINAL INSTRUCTIONS

DHB1700
TABLE OF CONTENTS
Welcome to Lumberjack!
Dear Customer, Congratulations on your purchase. Before using the
product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe all safety information in these instructions!
General Power Tool Safety Warnings………………………………….…......01
Symbols & Tech Data.............……….…………………………………….………05
Machine Details ................................……….…………………………….….06
Operation…………………………………………………………………………………..07
Maintenance .................……………………………..……………………………..08
Lumberjack Guarantee………….…………………………………………………….10
Declaration of Conformity……………………………………………………………12
Parts List…………..………………………………………………………………………...13
Parts Diagram………………………………………………………………………………15

DHB1700
01
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference. The term "power tool" in
the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power
tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with grounded surfaces,
such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.

DHB1700
02
GENERAL POWER TOOL SAFETY WARNINGS
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) If the replacement of the supply cord is
necessary, this has to be done by the
manufacturer or its agent in order to avoid a
safety hazard.

DHB1700
03
GENERAL POWER TOOL SAFETY WARNINGS
6. Safety Warnings for Rotary Hammer
a) Wear ear protectors with rotary hammers.
Exposureto noise can cause hearing loss.
b) Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.
c) Hold power tools by insulated gripping
surfaces when performing an operation where
the cutting tool may contact hidden wiring or
its own cord. Contact with a “live” wire will
make exposed metal parts ofthe tool “ live”
and shockthe operator.
d) Let bit cool before touching, changing or
adjusting it. Bits heat up dramatically while in
use, and can burn you.
e) If the drill bit jams, release the trigger
immediately; drill torque can cause injury or
break bit.
f) Maintainlabels and nameplates on the tool.
These carry important safety information. If
unreadable ormissing, Contact Lumberjack
Tools for a replacement.
g) Avoid unintentional starting. Prepare to
begin work before turning on the tool.
h) Do not lay the tool down until it has cometo
a complete stop. Moving parts can grab the
surface and pull the tool out ofyour control.
I) When using a handheld power tool, maintain
a firm grip on the tool with both hands to resist
starting torque.
J) Do not leave the tool unattended when it is
plugged into an electrical outlet. Turn off the
tool, and unplug it from its electrical outlet
before leaving.
k) This product isnot a toy. Keep it out of reach
of children.
l) People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity toheart pacemaker could cause
pacemaker interference or pacemaker failure. In
addition, people with pacemakers should:
●Avoid operating alone. ●Do not use with
power switch locked on.●Properly maintain
and inspect to avoid electrical shock. ●Any
power cord must be properly grounded. Ground
Fault Circuit Interrupter(GFCI) should also be
implemented – itprevents sustained electrical
shock.
7. Safety Warnings for Drill
a)When using the electric hammer chisel only use
bits that are configured with the correct slots for
this chuck.
b)BEFORE STARTING the operation, jog the chisel
switch to make sure the chisel bit does not wobble
or vibrate.
c)DO NOT USE fly cutters ormultiple-part hole
cutters, asthey can come apart or become
unbalanced inuse.
d)MAKE SURE the spindle hascome to a complete
stop before touching the chuck orattempting to
change the chisel bit also beware that the bit will
be hot, let it cool down before changing asitcould
burn and cause injury.
e)ALWAYS MAKE SURE THE CHISEL IS FIRMLY
SEATED INTHE HEX CHUCK before starting the job
inhand.

DHB1700
04
GENERAL POWER TOOL SAFETY WARNINGS
8. Safety Warnings for Vibration safety
This tool vibrates during use. Repeated or long-
term exposure to vibration may cause
temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
a) Wear suitable gloves toreduce the vibration
effects onthe user.
b) Use tools with the lowest vibration when
there is a choice.
c) Include vibration-free periods each day of
work.
d)To reduce vibration, maintain the tool as
explained in this manual. Ifany abnormal
vibration occurs, stop useimmediately.
9. Using an Extension Cable
.
a) If an extension cable is required, use an
approved triple core extension cable suitable for
the power input of the tool.
b) Grounded tools always require a three wire
extension cable.
c) As the distance from the supply outlet
increases you must use a heavier gauge extension
cable. Using extension cables with inadequately
sized wire causes a serious drop in voltage,
resulting in loss of power and possible tool
damage.
d) The smaller the gauge number of the wire the
greater the capacity of the cord.
e) When using a cable reel, always unwind the
cable completely.

DHB1700
05
SYMBOLS AND TECH SPEC
Danger! – Read the operating
instructions to reduce the risk of
injury.
Caution! Wear safety goggles.
Caution! Wear ear defenders. The
impact of noise can cause damage
to hearing.
Caution! Wear a dust mask.
0 - 1900bpm
75J

01010101
DHB1700
06
MACHINE DETAILS
1
2a
2b
6a
6b
5
3
4
Fig. 1
a a
Fig. 2
Fig. 4
Fig. 3
1.
2a.
2b.
30MM HEX CHUCK
ON/OFF TRIGGER
LOCK-ON BUTTON
3. AUXILIARY
HANDLE
4. OIL CAP
5. POWER CABLE
6a/6b. ANTIVIBRATION CONTROL DEVICE

DHB1700 07
OPERATING INSTRUCTIONS
Intended Use
This breaker is intended for chiseling in stone, brick and
concrete.
The tool must not be modified or used for any other
purposes than the ones described in these instructions.
> Remove all packaging materials and and
transit supports where fitted.
> Check the appliance, power cord and plug
and any accessories for transport damage.
> If parts are missing or damaged, please
contact your dealer.
> Retain the packing materials as long as
possible until the end of the warranty period.
> Dispose of packing materials in accordance
with local statutory regulations.
Replacing Bits
> Before any work on the machine itself, pull
out the power plug.
> The device is fitted with a 30mm HEX
attachment system.
> Place the tool on a suitable surface, for
example a work bench.
Inserting (see Fig. 2)
> Clean tool bits and grease with a thin layer
of machine grease before fitting.
> Insert the chisel into the chuck and push it in
as far as possible.
> Pull out the locking bolt (a) as far as possible,
turn it through 180° and release it to lock the
chisel into the chuck.
Removing (see Fig. 3)
> Pull out the locking bolt (a) again, turn it through
180° and remove the chisel.
Auxiliary Handle (see Fig. 4)
> Use the machine only with the auxiliary
handle (3).
> Loosen the handle by turning anti-clockwise.
Rotate the auxiliary handle (3) to the desired working
position and re-tighten the handle firmly.
Initial Operation
> Do not drill in blind areas where there could be hidden
electric, gas or water lines. Use the appropriate
detectors to find these lines in the work area or call
the local utility company for assistance.
> Contact with an electric line may cause
fire or electric shock. Striking a gas line will
probably result in an explosion.
> Breaking into a water pipe will cause
property damage or may cause an electric shock.
Tool accessories can be very sharp and can
become very hot during use - risk of personal injury.
WARNING!

RHB1700 08
OPERATING / MAINTENANCE
Maintenance
Switch off the tool and disconnect the power
before cleaning and maintenance – risk of
electric shock and accidental start.
WARNING!
> Wipe the tool with a dry or damp cloth.
Do not use a wet cloth. Do not use detergent that
contains solvent or corrosive, abrasive
additives – risk of damaging the surface.
> Keep the ventilation openings open – risk of
overheating.
> Clear the tool vents and the SDS HEX
chuck of dust and dirt after each use. Do not clean
ventilation holes by inserting sharp objects in
them, such as screwdrivers and other similar
objects.
> Stubborn contamination in areas hard to access
can be removed with compressed air (max 3. bar).
> Regularly check all fasteners, screws and
bolts to make sure that they are tight.
Tighten any loose screws immediately –
serious injury could occur.
> If the power cord becomes damaged and
replacement is necessary, this must be carried
out by an authorised warranty agent.
WARNING!
> If the carbon brushes require replacement,
this must be performed by an authorised
warranty agent.
> After use, inspect the tool to ensure it is
in top condition. It is recommended that you
take this tool to the Authorised Service Centre
for a thorough cleaning and re-
lubrication at least once a year.
Never open the tool. The tool has no internal
parts that the user can service or repair. Never
try to repair the tool yourself. Take to an
authorised service centre.
WARNING!
On/Off Trigger (2A)
Switching on
> Press the On/Off trigger to start the tool.
Switching off
> Release the On/Off trigger to stop the tool.
Constant Speed
Activating the lock feature:
> Gradually squeeze the ON/OFF trigger (2A)
of the power switch until fully retracted.
> Press in the locking button (2B).
> Release pressure on the ON/OFF trigger. The tool
is now locked at a constant speed without having to
maintain pressure on the power switch.
To release the lock:
> Apply pressure to the ON/OFF trigger.
> The locking button will automatically release. m
Release pressure on the ON/OFF trigger. The tool
will come to a stop.
Hold electric tools by their insulated handles
whenever there is the possibility of touching
hidden wires or the tools own power cord while
using them.
Touching a “live” wire can transfer the voltage to
the exposed metal parts of the tool and give the
operator an electric shock.
Always use the correct voltage: the voltage of
the power source must agree with the values on
the rating plate of the machine.

Trouble
Probable cause
Remedy
Tool will not start
1. Cord not connected.
2. No power at outlet.
3. Tool’s thermal reset
breaker tripped(if
equipped).
4. Internal damage or
wear.(Carbon brushes or
switch, for example)
1. Check that cord is plugged in.
2. Check power at outlet. If outlet is
unpowered, turn off and check circuit
breaker. If breaker is tripped, make
sure circuit is right capacity for tool
and circuit has no other loads.
3. Turn off tool and allow to cool. Press
reset button on tool.
4. Have technician service tool.
Tool operates slowly
1. Excess pressure applied to
workpiece.
2. Power being reduced by
long or small diameter
extension cord.
1. Decrease pressure, allow tool to do
the work.
2. Eliminate use of extension cord. If an
extension cord is needed, use one
with the proper diameter for its
length and load. See Extension Cords
in GROUNDING section.
Performance decreases
over time
Carbon brushes worn or
damaged.
Have qualified technician replace
brushes.
Excessive noise or rattling
Internal damage or
wear.(Carbon brushes or
bearings, for example.)
Have technician service tool.
Overheating. GROUNDING
section.
1. Forcing tool to work too
fast.
2. Blocked motor housing
vents.
3. Motor being strained by
long or small diameter
extension cord.
1. Allow tool to work at its own rate.
2. Wear ANSI-approved safety goggles
and NIOSH-approved dust
mask/respirator while blowing dust
out of motor using compressed air.
3. Eliminate use of extension cord. If an
extension cord is needed, use one
with the proper diameter for its
length and load. See Extension Cords
in GROUNDING section.
DHB1700 09
TROUBLESHOOTING

DHB1700 10
LUMBERJACK GUARANTEE
1. Guarantee
1.1 Lumberjack guarantees that for a period of
12 months from the date of purchase the
components of qualifying products (see clauses
1.2.1 to 1.2.8) will be free from defects caused
by faulty construction or manufacture.
1.2. During this period Lumberjack, will repair or
replace free of charge any parts which are
proved to be faulty in accordance with
paragraph 1.1 providing that:
1.2.1 You follow the claims procedure set out in
clause 2
1.2.2 Lumberjack and its authorised dealers are
given reasonable opportunity after receiving
notice of the claim to examine the product
1.2.3 If asked to do so by Lumberjack or its
Authorised dealer, you return the product at
your own cost to Lumberjack’s or supplying
Authorised Dealer’s premises, for the
examination to take place clearly stating the
Returns Material Authorisation number given by
Lumberjack or an Authorised Dealer.
1.2.4 The fault in question is not caused by
industrial use, accidental damage, fair wear and
tear, wilful damage, neglect, incorrect electrical
connection, misuse, or alteration or repair of the
product without approval.
1.2.5 The product has been used in a domestic
environment only
1.2.6 The fault does not relate to consumable
items such as blades, bearings, drive belts, or
other wearing parts which can reasonably be
expected to wear at different rates depending
on usage.
1.2.7 The product has not been used for hire
purposes.
1.2.8 The product has been purchased by you as
the guarantee is not transferable from a private
sale.
2. Claims Procedure
2.1 In the first instance please contact the
Authorised Dealer who supplied the product to
you. In our experience many initial problems with
machines that are thought to be faulty due to
faulty parts are actually solved by correct setting
up or adjustment of the machine. A good
Authorised Dealer should be able to resolve the
majority of these issues much more quickly than
processing a claim under the guarantee. If a
return is requested by the Authorised Dealer or
Lumberjack, you will be provided with a Returns
Material Authorisation number which must be
clearly stated on the returned package, and any
accompanying correspondence. Failure to provide
a Returns Material Authorisation number may
result in item being refused delivery at Authorised
Dealer.
2.2 Any issues with the product resulting in a
potential claim under the guarantee must be
reported to the Authorised Dealer from which it
was purchased within 48 hours of Receipt.
2.3 If the Authorised Dealer who supplied the
product to you has been unable to satisfy your
query, any claims made under this Guarantee
should be made directly to Lumberjack. The Claim
itself should be made in a letter setting out the
date and place of purchase, giving a brief
explanation of the problem which has led to the
claim. This letter should be then sent with proof

DHB1700 11
LUMBERJACK GUARANTEE
of purchase to Lumberjack. If you include a
contact number with this it will speed your claim
up.
2.4 Please note that it is essential that the letter
of claim reaches Lumberjack on the last day of
this Guarantee at the latest. Late claims will not
be considered.
3. Limitation of Liability
3.1 We only supply products for domestic and
private use. You agree not to use the product for
any commercial, business or resale purposes and
we have no liability to you for any loss of profit,
loss of business, business interruption or loss of
business opportunity.
3.2 This Guarantee does not confer any rights
other than these expressly set out above and
does not cover any claims for consequential loss
or damage. This Guarantee is offered as an extra
benefit and does not affect your statutory rights
as a consumer.
4. Notice
This Guarantee applies to all product purchased
from an Authorised Dealer of Lumberjack within
the United Kingdom. Terms of Guarantee may
vary in other countries.

DHB1700 12
DECLARATION OF CONFORMITY
We Importer:
TOOLSAVE LTD
Unit C, Manders Ind. Est.,
Old Heat h Road, Wolverhampton,
WV1 2RP.
Declare that the product:
Designation: DEMILITION HAMMER BREAKER
Model: DHB1700
Complies with the following Directives:
2008 No. 1597 The Supply of Machinery (Safety) Regulations 2008
2016 No. 1091 The Electromagnetic Compatibility Regulations 2016
2012 No. 3032 The Restriction of the Use of Certain Hazardous Substances in
Standards & technical specifications referred to:
EN 60745-1:2009+A11 / EN 60745-2-6:2010 / EN 55014-1:2017 /
EN 55014-2:2015 / EN 61000-3-2:2014 / EN 61000-3-11:2000
Authorized Technical File Holder:Bill Evans
18/08/2023
TheDirector

DHB1700 13
Parts List

DHB1700 14
Parts List

DHB1700 15
Parts Diagram
