Lumex 6486A User manual

Installation instructions

Caution: Read before installation: This raised toilet seat is intended to fit most standard toilets. However, due to the
large variety of toilets on the market, this unit may not fit every model, or could be damaged by certain models of
toilet. If your toilet has raised or protruding points or sections on the top or inner ring of the bowl, do not use this
raised toilet seat. Certain toilet bowls require the removal of the existing toilet seat and lid for proper fit. When
properly installed, the raised toilet seat should sit flat on the top of the bowl lip and against the bowl's inner curved
section. You are ensured a safe fit if this raised toilet seat cannot be removed, even when intentionally shaken.
1. Remove raised toilet seat from carton and protective packaging.
2. Lift lid and seat of toilet.
3. Place raised toilet seat on bowl rim, hooking rear flanges under rear edge of toilet bowl. Ensure that the paddle is
back far enough to clear inner rim of toilet bowl. If not, turn knob counter-clockwise.
4. Ensure that raised toilet seat rests flat on toilet bowl rim. Straighten unit on bowl rim.
5. Totighten, rotate adjustment knob clockwise. Push unit back against rear of toilet rim while tightening knob. When
you feel resistance, turn an additional 1/8 turn to snug. If top rear of unit hits toilet seat/lid, you must remove toilet
seat and lid for proper installation.
Note: The adjustment knob head must be flush with the front of the toilet seat for proper fit. On smaller bowls, if paddle is
moved to the rear end of its travel, the knob may pop out of its original position; the knob will re-engage
automatically when you retighten.
Caution: Do not force the knob to turn. If necessary, jiggle the knob a little to start threads.
6. Raised toilet seat should now be fastened securely to toilet bowl. To ensure that you have a proper fit, intentionally
shake the raised toilet seat.
Raised Toilet Seat with Locking Clamp
Items 6486A, 6486R
With Support Arms 6487A, 6487R
Warning: This product should not be used without
proper instruction from a healthcare professional.
Warning: Lumex assumes no responsibility for any
damage or injury caused by improper installation,
assembly or use of this product.
Warning: This product has a maximum user weight
limitation of 300 lbs.
Warning: If components are damaged or missing,
contact your dealer immediately. DO NOT use
substitute parts.
6486A 6487A Paddle
Flange
Knob

Toremove raised toilet seat from toilet bowl
1. Rotate knob counter-clockwise until raised toilet seat is free.
2. Lift front of raised toilet seat, then remove from toilet bowl.
Maintenance and cleaning
Loosen, retighten, and check for secure fit of raised toilet seat weekly. To clean raised toilet seat, wash with soap and
water or a mild household detergent and rinse with clear water. To clean interior of raised toilet seat, flush with warm
soapy water, then drain and allow to air dry for several hours. Never use abrasive cleansers or scouring pads on any
part of raised toilet seat. If moisture accumulates inside raised toilet seat, do the following:
1. Remove raised toilet seat from toilet bowl (see above directions).
2. Turn raised toilet seat upside down and tilt toward drain opening.
3. Rotate until drain opening is facing downward and moisture drains.
4. Allow raised toilet seat to air dry for several hours.
Graham-Field Health Products
2935 Northeast Parkway, Atlanta, Georgia 30360
telephone: [phone]
fax: [phone]
http://www.grahamfield.com
Raised Toilet Seat with Locking Clamp
Items 6486A, 6486R
With Support Arms 6487A, 6487R
