Lumiere BC100BLK User manual

  
UNIVERSAL
6 POSITION BABY CARRIER
INSTRUCTION MANUAL

12
SEAT POSITIONING ON THE WAISTBELT
Always use appropriate seat positioning before installing the waistbelt on
your hip. Make sure to use a right seat position as your baby grows.
DO NOT Mix Up Seat Positions:


 
LL HAZARD -Baby can fall through a wide leg opening or out of Carrier.
• Before each use, make sure all fasteners are secure.
• Take special care when leaning or walking.
• Never bend at waist; bend at knees.
• DO NOT USE the carrier for babies weighing less than 7 lbs (3.2 kg).
• Only use this Carrier for babies between 7 lbs (3.2 kg) and 45 lbs (20 kg).
• To prevent hazards from falling, ensure that your child is securely positioned in the carrier.
SUFFOCATION HAZARD - Babies under 4 months can suffocate in this product if face is pressed tight
against your body.
• Do not strap baby too tight against your body.
• Allow room for head movement.
• Keep baby's face free from obstructions at all times.
WARNING:
• Constantly monitor your child and ensure that the mouth and nose are unobstructed.
• For pre-term, low birthweight babies and children with medical conditions, seek advice from a health professional before using
this product.
• Ensure that your child's chin is not resting on his chest as his breathing may be restricted, which could lead to suffocation.
• Your balance may be adversely affected by your movement and that of your child.
• Take care when bending or leaning forward or sideways.
• Do not allow baby to insert his fingers into a buckle opeing.
• Never leave baby unattended in or with the carrier.
• This carrier is not suitable for use during sporting activities, eg. running, cycling, swimming and skiing.

CARE INSTRUCTIONS:
•Machine wash cold.
•Do not bleach.
•Tumble dry low.
•Do not iron.
•Do not dry clean.
WASH INSTRUCTIONS:
•Before washing, fasten all buckles and hook and loop fasteners.
•Use mild detergent when washing.
•Do not machine wash frequently.
•Do not use detergents with bleach, perfumes,chlorine, dyes, or optical brightener.

4
H O W TO A TT ACH T H E WA IST B ELT
Place waist belt around
your waist or hip.
Slide the male buckle
through elastic safety
band and connect with
female buckle. You will
hear it “click” when it
is safely engaged.
Pull remaining webbing
strap through the elastic
safety band.
The webbing should
hang outside the elastic
band to allow for
adjustments.
Tighten a bit. Roll up
excess webbing and
fold elastic loop around
strap-roll to keep it in
place.
Pull the two straps and up
and down movements until
you get a tight fit and the
lumbar support is centered
on your back with the
carrier centered on your
front.
For A Newborn Baby:
Make sure to wear the waist belt high on your waist, so baby is close enough to kiss.
Every carrying position must start with placing the waist belt around your waist.
NEWBORN CARRY
Newborn to 3 Months | Min. 7 lbs/ 3.2 kg | Min. 20 inches/ 50.8cm
Use Seat Position A
setting. Install Safety
Harness and adjust to fit
baby’s size. Place the waist
belt high on your waist.
Bring baby to your chest.
Gently slide her in the
right middle of the carrier
and guide feet to each
side.
Support baby with
your left hand; with
your right hand place
the shoulder strap over
your shoulder.
Switch hands to support
your baby; with your left
hand place the left shoul-
der strap over your shoul-
der.
Run hands along shoulder
pads and locate the con-
necting strap behind your
neck; connect the buckle
and tighten the strap.
Locate the harness
strap inside the carrier,
run strap around baby’s
waist and engage
buckles in front of
baby’s belly.
3

6
HEAD AND NEC
K SU PP ORT
<Newborn: 0-6 weeks>
<7 weeks and up - Awake> <7 weeks and up - Sleeping>
Fold the head and neck
support toward inside of
the carrier.
If your baby needs more
neck support, find a
nursing blanket and roll it
in to a “pillow”, and place
it behind your baby’s neck.
Align the top of the carrier
at the mid ear level for
proper support.
Fold the head and neck support toward
inside of the carrier. Align the top of
the carrier at the mid ear level for
proper support.
5
To bring the head and neck support
up, unbutton snaps on each side of
the carrier and connect with buckles
on shoulder straps.
IN F ANT F RONT CARR Y F ACING IN
0
3 to 9 Months | 24-28 inches/61.0 - 71.1cm
Use Seat Position B
setting. Install Safety
Harness and adjust to fit
baby’s size. Place the waist
belt on your waist (p.4).
Bring baby to your chest,
facing you. Baby’s legs
should straddle the
carrier seat.
Support baby with
your left hand; with
your right hand place
the shoulder strap over
your shoulder.
Switch hands to support
your baby; with your left
hand place the left shoul-
der strap over your shoul-
der.
Run hands along shoulder
pads and locate the con-
necting strap behind your
neck; connect the buckle
and tighten the strap.
Locate the harness
strap inside the carrier,
run strap around baby’s
waist and engage
buckles in front of
baby’s belly.
(Optional)

7
F RONT CARR Y F ACING OUT
6 - 12 Months | 14.0 -22.0 lbs/ 6.4 - 10.0 kg
FOR BABIES WITH FULL HEAD & NECK CONTROL ONLY
Use Seat Position A
setting. Place the waist
belt on your waist (p.4).
Fold Head and Neck
Support down.
Hold your baby in front of
your body. Place baby’s
bottom close to your belly
button, “sitting” on the belt.
Guide baby’s legs to each
side of the carrier seat.
Support baby with your
right hand. With your left
hand place the left shoul-
der strap over your
shoulder. Carrier should
catch close to baby’s
crotch.
Switch hands to support
your baby; with your
right hand place the right
shoulder strap over your
shoulder.
With both shoulder straps
secure on your
shoulders; engage the
connecting strap buckle
and tighten the strap.
Adjust size of shoulder
strap by pulling down or
toward yourself. Make sure
the fit is tight and safe. On
each shoulder strap, roll
excessive webbing up and
secure with elastic band on
the end.

TODDLER F RONT CARR Y F ACING IN
9 - 24 Months | 17.2 - 44.0 lbs/ 7.8 - 20.0 kg
Use Seat Position C
setting. Place the waist
belt on your waist (p.4).
Fold Head and Neck
Support down.
Hold your baby in front of
your body. Place baby’s
bottom close to your belly
button, “sitting” on the belt.
Guide baby’s legs to each
side of the carrier seat.
Support baby with your
left hand; with your right
hand place the shoulder
strap over your shoulder.
Switch hands to support
your baby; with your left
hand place the left
shoulder strap over your
shoulder.
With both shoulder straps
secure on your shoulders;
engage the connecting
strap buckle and tighten
the strap.
Adjust size of shoulder
strap by pulling down or
toward yourself. Make sure
the fit is tight and safe. On
each sholder strap, roll
excessive webbing up and
secure with elastic band on
the end. 8

9
HI P CARR Y
6 -24 Months | 17.2 - 26.9 lbs/ 7.8 - 12.2 kg
*
SEAT POSITION: B for 6 - 9 mths , C for 9 -24 mths
*Adjust Seat Position B
or C depending on your
baby's age. Place the
waist belt on your waist
(p.4). Fold Head/Neck
Support down.
Unbuckle both shoulder
straps. Bring right shoulder
strap buckle to left side of
carrier's body and close the
buckle. Leave left shoulder
strap loose.
Put your left arm through.
Bring shoulder strap over
your head onto your right
shoulder. Adjust of
shoulder strap to create a
pouch of your baby size.
Slide carrier onto your left.
Place your baby into
carrier. Make sure your
baby is centered within
carrier on your hip.
Reach behind your back for other
shoulder strap, wrap it around your
waist and attach buckle on right
side of carrier's body
Adjust size of shoulder
strap by pulling toward
yourself. Make sure the fit
is tight and safe. Roll
excessive webbing up and
secure with elastic band on
the end.
BACK CARR Y
6 - 48 Months | 17.2 - 44.0 lbs/ 7.8 -20.0 kg
*SEAT POSITION: B for 6 - 9 mths , C for 9 - 48 mths
*Adjust Seat Position
B or C depending on
your baby's age. Place
the waist belt on your
waist (p.4). Fold Head/
Neck Support down.
Sit your baby around your waist with her legs on either
side of you. Holding baby and the carrier with one arm
bend forward and slide your baby in the carrier around
your hips toward and onto your lower back. Use your
free arm to slide waist belt around your hips more
easily.
Once your baby is centered on your
lower back, place shoulder straps on
your shoulders one at a time. Adjust
size of shoulder strap by pulling
upward.
Close chest strap in
front of you and adjust
the fit by pulling
sideways on the free
end. Chest strap
should be at collar
bone level.
Make sure all fits are
tight and safe. On each
shoulder strap, roll
excessive webbing up
and secure with elastic
band on the end.
NOTE: Practice over a bed or other
soft surface in front of a mirror first.
10

LUM IERE BABY, LLC .
 B  V  v   5   d   5 

pp 
www 
T 
p  w  d  d  d 
 TMF  -  d  N  -  5
Designed in the USA, made responsibly in China
