Kraken Dock Lighting System Installation Instructions
Models: 101638
WARNING
WARNING: RISK OF ELECTRIC SHOCK
•Use only in bodies of water, ponds and small decorative fountains where persons will immerse
no more than their hands and lower arms while the product is energized.
•DO NOT use in water intended for swimming, wading, immersion, or bathing.
•All installer completed cable connections must be located outside of bodies of water, pond or
fountain.
•Low voltage circuit must be supplied by a power unit marked as suitable for supplying
submersible luminaires.
•Power unit must be supplied by a circuit protected by a ground fault circuit interrupter (GFCI).
•Maximum depth: 8 feet
•All installer completed cable connections must be located outside of bodies of water, pond or
fountain. Take careful consideration of tidal shift if connections are completed under docks, or
near waterline.
WARNING: For your safety read and understand instructions before starting installation. Before
permanently wiring to branch circuit, turn off electricity at the fuse or circuit breaker box. Before
attempting any installation check your applicable electric code. This code sets the wiring standards and
should be carefully studied before starting.
Note: All statements, technical information and recommendations contained herein are based on
information and tests we believe to be reliable. The accuracy or completeness thereof are not
guaranteed. In accordance with “Terms and Conditions of Sale”, and since conditions of use are outside
our control, the purchaser should determine the suitability of the product for his intended use and
assumes all risk and liability whatsoever in connection therewith.
IMPORTANT:
Read carefully before installing fixture. Retain for future reference.
APPLICATION: Kraken Dock Lighting Systems are designed for outdoor wet locations, where moisture,
dirt, corrosion may be present. Mantis underwater dock lights are intended for full submersion in fresh
and salt water.
Listed models of Kraken Dock Lighting System can be operated at the following voltages:
UNIVERSAL 100VAC - 300VAC 50/60Hz
Lumitec 600788

Revision C 04/2020 2
Underwater light Installation
Note: Pilings should be cleaned to remove hard growth that would prevent the light for having a stable
base to install against.
Note: Stainless Steel clamps are 60 inches long and should provide enough length to wrap around a 12
inch square or 14 inch round piling.
Note: It is helpful in tidal locations that this part of the installation be performed close to low tide.
1. Slide 1 stainless steel clamp through slot in the back of the light housing. Wrap clamp around piling
and feed free end of clamp back through clamp latch and back through slot in light housing.
2. Adjust so that light is approximately 6 inches below water line at a typical low tide for your area.
3. Tension clamp by holding light with one hand and pulling cable with the other. It may help to pull the
free end of the clamp with pliers.
4. Use a second stainless steel clamp or other if needed to secure power cable to piling. Prevent
abrasion by routing cable to side of piling away from vessel access.
Power Unit Installation
Note: This fixture is suitable for installation in wet locations.
1. Determine the mounting location of the Power Unit ensuring all underwater light cables reach the
supply and are routed to prevent abrasion from vessels or other moving components.
2. Attach the power unit to suitable structure at least 1 foot above ground level with the high and low
voltage cables pointing down. The metal plate on the back of the power unit enclosure MUST be offset a
minimum of 0.28” (7mm) for proper air-flow. NOTE: Do not energize transformer until installation of
system is complete

Revision C 04/2020 3
Electrical Connection
Note: Fixture may be switched with a timer, photodetector, or toggle switch prior to the receptacle. DO
NOT connect power unit to a dimmer. Light connected to the POCO digital control outputs can be
controlled by Bluetooth, Wi-Fi, or Network connection with the POCO controller through a mobile
device or network connected computer.
Note: Use approved outdoor (While in use) weatherproof receptacle cover to protect cord and outlet
from weather while plugged in.
Note: Supplemental grounding is highly recommended. See page (8) for surge protection.
Note: Provide electrical service according to the electric code for your specific application from a
suitable ground fault circuit interrupter (GFCI) receptacle.
1. All high voltage components in the fixture are prewired so electrical connection only needs to be
made on the secondary (24VDC low voltage) side of the power supply. NOTE: the power unit is rated for
480W max load. Do not connect more than 6 Kraken underwater lights to this supply.
2. Split low voltage cable back approximately 6 inches and strip conductors back 3/8 inch if not already
done so.
3. Insert low voltage cables into cable glands on the bottom of the power unit. Tighten cable glands until
the cables are secure.
For 2 wire “PLI” Lumitec DC lights: Connect the red (+) wires to either of the 1,2,3, or 4 Digital Control
Channel Outputs. Channel Outputs are indicated by brown and orange connectors inside the Power Unit
Enclosure. Channels 1 and 2 combined are not to exceed 10 Amps total. Channels 3 and 4 combined are
not to exceed 10 Amps total. Connect all black (-) wires to the Black Universal Ground Bus.
For 3 wire “PLI” Lumitec DC lights: Connect the red (+) wires directly to the Red 24VDC Constant Bus.
Connect all black (-) wires to the Black Ground Bus. Connect orange (remote) to either of the 1,2,3, or 4
Digital Control Channel Outputs. Channel Outputs are indicated by brown and orange connectors inside
the Power Unit Enclosure. Note: The orange wire does not draw any current and 6 Kraken light’s
orange wires can be connected to a single channel.
DC Breakers: There are 3 breakers within the Power Unit enclosure. A single 20 Amp breaker is
dedicated to the constant 24VDC (+) Bus. There are two 10 Amp breakers. One of the 10 Amp breakers
is shared between channels 1 and 2 outputs. The additional 10 Amp breaker is shared between channels
3 and 4 outputs.

Revision C 04/2020 4
DC Wiring Schematic: Shown below is a wiring schematic inside the Power Unit enclosure. Use this
schematic and the instructions listed above for proper DC device wiring.

Revision C 04/2020 5
Digital Control
Operating Lights Using POCO Digital Control
IMPORTANT: To use the supplied information provided within this quick start guide all lights installed
must be PLI compatible. For lights that are non-PLI, or a non Lumitec brand, refer to our website at
http://lumiteclighting.com/check4pli for additional installation information.
STEP 1: Plan and Install Your Digital Lighting System
CALCULATE YOUR AMP DRAW AT THE LIGHT FIXTURES
Channels 1 and 2 combined: Total Amp draw must be below 10 Amps
Channels 3 and 4 combined: Total Amp draw must be below 10 Amps
STEP 2: Connect To POCO
A. Poco can be connected to a network connected computer and/or a mobile device through
WiFi.
B. For mobile devices connect using the Lumitec Poco App available on Apple or Google Play
stores. You will be prompted to connect to Poco on launching the app.
C. To setup the Kraken system on your home network, first connect directly to the WiFi on
Kraken device you are installing. When setting up multiple units it may be helpful to keep
the power off on the remaining units until the device you are setting up has been named.
Using a laptop or mobile device, connect to the WiFi network named “Poco-XXXX” the
default password is lumitec561.
D. Open a Safari, Firefox, or Chrome web browser and type IP address: 192.168.4.1
E. Select the Gear icon in the upper right of the page to start configuring the network enter
the default password 0000. Click on the Maintenance Page.
F. Under Maintenance, Select “Configure Ethernet/WiFi”
G. Enable Station mode by selecting “Go to AP+STA mode”
H. Now connect to your home WiFi. Activate Scanning to find your network by clicking “Scan!”
I. Select network and type in the password.
J. Once connected, a Kraken command unit will appear under HTTP list in the connection
screen of the App on a mobile device. This allows for control of the Kraken lighting system
from anywhere in the house and is no longer limited to the Bluetooth range of the
command module.
Helpful Details:
- Default configuration password: 0000
- Default Wi-Fi Password: lumitec561
- Wi-Fi web access to user interface: 192.168.4.1
STEP 3: Create Light Groups
Select configuration in the setting menu (top right of screen). Assign Channel and Clan for each light
location in your landscape (underwater lights, piling lights etc.).
Examples:

Revision C 04/2020 6
Name: LG_Piling Lights
Channel: 1
Clan: 1 - Piling Lights
Output: Lumitec Spectrum
Name: LG_1,2,3 UW Lights
Channel: 2
Clan: 1 –Underwater Lights
Output: Lumitec Spectrum
Name: LG_Pathway Lights
Channel: 1
Clan: 2 –Pathway Lights
Output: Blue / White
Name: LG_4,5,6 UW Lights
Channel: 3
Clan: 4 –Underwater Lights
Output: Lumitec Spectrum
STEP 4: Create Switches
Assign a default intensity and color to each switch.
Example Simple Switch:
Name: Piling Lights
Target: LG_Piling Lights Intensity: 50% Color: Red
You can create lighting scenes by assigning multiple light groups to more than one target.
Example Scene Switch:
Name: Night Fishing
1. Target: LG_Pathway Lights Intensity: 20% Color: Red
2. Target: LG_1,2,3 UW Lights Intensity: 20% Color: Red
3. Target: LG_4,5,6 UW Lights Intensity: 100% Color: Green
STEP 5: Add Switches to Layout Pages
A. Select a location screen for your switch.
B. Select the plus (+) button symbol.
C. Select desired switch from list.
Note: Visual order of switches will be arranged by the order of the switch creation. Switches cannot be
rearranged after they have been added to a screen. Go to http://lumiteclighting.com/poco-quick-start
for more detailed information.
TROUBLESHOOTING: Check Status Indicators
POWER Indicator –
Illuminates Green if POCO is powered on, both PWR and ACC lines must have supply voltage between
10-30vDC
CH1, CH2, CH3 or CH4 Indicator –
-Illuminates Red if power is supplied to channel from fuse/breaker panel.
-Illuminates Green if power is supplied to channel input and channel is turned on inside of POCO
controller; PLI enabled lights may be OFF.

Revision C 04/2020 7
-Flashes Orange if PLI data is transmitted.
-Illuminates Orange if channel is dimmed through a PWM signal
STATUS Indicator –
-Green blinking light indicates WiFi connection status:
-0 blinks: WiFi disabled
-1 blink: WiFi enabled but not connected to any peers
-2 blinks: WiFi is connected to one or more peers
-Blue blinking light indicates Bluetooth-LE connection status:
-0 blinks: Bluetooth-LE is disabled
-1 blink: Bluetooth-LE enabled but not connected
-2 blinks: Bluetooth-LE is connected
Surge Arrestor Installation for Outdoor AC Installations
A surge protection device (SPD) has been installed in your Kraken system. Warranty claims may be
denied if an SPD has not been installed according to the recommendations in this document. Damaging
voltage fluctuations can occur from other equipment attached to the AC supply or due to induced
voltages from direct and indirect lightning strikes. Indirect lightning strikes can be especially problematic
because the voltage will be induced even at long distances from the strike location and is typically a
function of the wire length. Outdoor lighting projects typically have longer wiring and tend to be
subjected to higher induced voltages, which increases the need for SPD installation.
To prevent lightning damage to your equipment, Lumitec recommends installing a supplemental
grounding system to the one found at the service point. The grounding system directs lightning-induced
electrical current into the earth rather than allowing the surge to pass through power wires or field
wires to your equipment. The Kraken enclosure comes with a ground lug external to the enclosure.
Ground Lug

Revision C 04/2020 8
A good grounding system should maintain a resistance of 10 ohms or less to ground. Ground resistance
occurs when grounding system components, or the soil itself, oppose the flow of electricity into the
earth. The higher the ground resistance (higher ohm readings), the higher the chance the surge will
damage the equipment’s electronic components rather than be shunted to ground. If you are unable to
reach a resistance of 10 ohms or less, you can enhance the ground network with additional ground
electrodes or plates.
All grounding rods or plates must be connected with #6 AWG or larger solid copper wire. Install the
connecting wire in as straight a line as possible. If you must make a turn or bend in the wire, make the
turn in a sweeping curve with a minimum radius of 8 inches. Ground rod corrosion will increase the
ground resistance and decrease the effectiveness of the SPD. Use the correct material for your
installation environment. Copper plated, solid copper, and stainless-steel ground rods are options to
consider. Do not use galvanized grounding rods for this application.
Kraken Dock Lighting Instructions for Custom Installs
Installation with 1 controller and multiple power supplies

Revision C 04/2020 9
Custom Lumitec Kraken installations that exceed the maximum current of a single power supply (PSU)
can be extended by installing additional PSUs. Lumitec provides the following wiring principals
illustrated below as guidance.
With this method of installation, the power and color of your Kraken lights can be controlled using a
toggle switch or controlled with the Lumitec Poco Digital Lighting Controller. The Kraken underwater
dock lights are powered through the Red and Black wires and controlled through the orange data wire
as shown in Figure 1.
Figure 1: Kraken wiring diagram. Basic installation.
To use a single controller for Kraken underwater lights on multiple PSUs, the control signal orange wire
(data) and black wire (ground) must be run to each light as shown in Figure 2. Lumitec strongly advises
the use of optocouplers to isolate each PSU from the others in the system. This is recommended to
lower the risk that nearby lightning strikes and electrical surges that could damage all interconnected
systems if an isolation barrier is not provided.
Figure 2 provides information on recommended components as well as the suggested wiring
configuration. Lumitec has tested and recommends using Wago optocoupler part number 859-758 for
transmitting the digital control signal without distortion. For additional details on lightning protection
see the section in this manual titled Surge Arrestor Installations.
Figure 2: Multiple Kraken Supplies controlled from a single Poco

Revision C 04/2020 10
Custom Enclosure Recommendations
Lumitec recommends installing the AC to DC power supply (PSU) within an enclosure that provides heat
dissipation. If a plastic enclosure is used, and no means for air circulation is provided, then the power
supply may go into a fault state and stop supplying power to the load until the temperature drops down
to a safe level. Typical AC to DC switching supplies are approximately 94% efficient, and 6% of the
energy is wasted as heat. As an example, a 480-Watt supply can create 29 Watts of heat when fully
loaded.
If metal enclosures are used, follow applicable NEC requirements for the grounding of dead metal.
Challenges can also occur when using metal enclosures with the Poco Digital Lighting Control unit. Be
aware that metal enclosures are not compatible with WIFI or Bluetooth connectivity.
MAINTENANCE
● The lens should be cleaned monthly to ensure continued lighting performance. To clean, brush the
lens with a stiff plastic bristled brush. Do not use a scraper, abrasive, strong alkaline, or acid cleaner.
Damage may result.
● Visually check for undue heating evidenced by discoloration of wires or other components, damaged
parts, or leakage evidenced by water or corrosion in the interior, Some small amount of water is allowed
on the interior of the power supply. Replace all worn, damaged, or malfunctioning components and
clean before putting the luminaire back into service.
● Electrically check to make sure that all connections are clean and tight.
● Mechanically check that all parts are properly assembled.
Replacement Parts
Lumitec LED underwater lights are designed to provide years of reliable lighting performance. However,
should the need for replacement parts arise, they are available through Lumitec Lighting. Contact us at
www.lumiteclighting.com .
Please refer to http://lumiteclighting.com/support/warranty/ for warranties and claims.
The product is warranted to be free from defects in workmanship and materials for a period of three (3)
years from the date of original purchase.
Lumitec is not responsible for product failure caused by abuse, neglect, improper installation, or failure
in applications other than those for which it was designed, intended, and marketed. Lumitec, Inc.
assumes no responsibility whatsoever for any damage, loss, or injury that may result from the incorrect
installation of this product, including but not limited to structural damage due to water intrusion,
electrical malfunction or vessel sinking when used in marine applications.
Should your Lumitec product prove defective during the warranty period, promptly notify Lumitec for a
return authorization number and return product with freight prepaid. Lumitec will, at its option, repair
or replace the product or defective portion without charge for parts or labor, or, at Lumitec’s option,

Revision C 04/2020 11
refund purchase price. Products repaired or replaced under this warranty shall be warranted for the
unexpired portion of the warranty applying to the original product(s). No warranty or affirmation of fact,
express or implied, other than as set forth in the limited warranty statement above is made or
authorized by Lumitec, Inc. Any liability for consequential and incidental damages is expressly
disclaimed. Lumitec liability in all events is limited to, and shall not exceed, the purchase price paid.
Any alterations, modifications or changes of any type made to the Mantis Dock Lighting System or to any
component thereof will void the warranty.
Manufacture Corporate Headquarters:
Lumitec
1405 Poinsettia Drive, Suite 10
Delray Beach, FL 33444
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.lumiteclighting.com
