Lumos ISS1000Z User manual

Portable Solar Power System
— ISS1000Z —
Operation Manual
General Version
Congratulations and thank you for purchasing our portable solar power system.
Carefully read, understand and comply with all instructions before use.

Portable Solar Power System
1
Safety Instructions
1. Please read this manual thoroughly before use.
2. Please not to use high power devices beyond the permissible range of the system.
3. Ensure efficient exhaust ventilation in the working area. Keep it from exposure, damp environment and
rain.
4. Away from inflammable and explosive materials.
5. Keep out of the reach of children.
6. Overhauling shall only be taken as directed by professionals in the event of the failure of the product
instead of changing the internal wiring privately.
7. Prevent the product and solar panel from dropping and shocks. Should any damage be incurred you may
switch off the power and approach help from professionals.
8. Use soft dry cloth for cleaning after turning off the main switch. Do not use wax, benzene, thinner,
pesticide, air freshener, lube or detergent for cleaning.
9. Never connect to adapter junction box of AC house current or commercial power like house circuit.
10. If the product is not used for a long run, please full charge battery and make sure to turn off system main
switch. Please charge the battery in time while the red light of battery power red indicator is on. Otherwise
the battery will be damaged and this situation is outside the scope of free warranty.
Special Instructions:
Our company reserves the right to change the product;
The manual is subject to change with technical improvement without notice;
Base on the real product in case of any change of appearance or color.

Portable Solar Power System
2
Contents
Part I Brief introduction to portable solar power system
1.1 Basic operation principle of portable solar power system
1.2 Main characteristics of portable solar power system
Part II Main technical parameter of portable solar power system
Part III Operating instructions
3.1 Connection drawing of the system
3.2 Operating procedure of the system
Part IV Maintenance
4.1 Explanation of alarms
4.2 Daily maintenance and change of battery
Part V FAQ
Part VI Optional Accessories
6.1 Optional Accessories list
Part VII Guarantee
1.1 Product guarantee

Portable Solar Power System
3
Part I Brief introduction to portable solar power system
With the increase demand of global energy and impacts on human being environment caused by highly energy-consuming,
energy saving and emission reduction has become the major trend of global energy industry development. Photovoltaic generation
has made remarkable achievements since the first functional solar cell in 1954, which has being applied to every field. For domestic
customer, the principle advantages would be the performance of free from contamination, long service period, quiet, small cubage,
modular design, easy installation, and its portable location.
1.1 Basic operation principle of portable solar power system
1. Electric energy is generated by photoelectric converting when solar panel is in a place having access to sunshine. It is
then stored in the battery by the built-in charge controller of the product.
2. Direct current in the battery is inverted by the internal inverter when power is needed for appliances; DC is also able to
be output for DC drives to meet different requirements.
1.2 Main characteristics of portable solar power system
1. Simple in system structure, safe, reliable and portable.
2. Equipped with charge controller, inverter and batteries.
3. Internal modular design, parts of pull and plug type connection, easy installation.
4. LED indicator lights with long service period and easy to understand.
5. Direct output of AC and DC for family basic electricity demand.
6. Available to be charged by main supply in case of not being satisfied with photovoltaic charging conditions. (Main
supply charger needs to be prepared by the customer. E.g.: 12V output charger used for 12V 22Ah ~35Ah battery.)
7. If there is far more demand than the equipped battery can serve, customer can choose 12V battery, connecting to our
product, expanding capacity as well as service time.
8. The product can be used in the car to provide enduring power supply as well as charge the car batteries (with help of car
charging wires).
9. Independent switch is equipped with each AC output and system MS is also provided to realize convenience of
customers.
10. Solar panel is supplied along with bracket system for better installation and carry.
11. Battery capacity indication enables the customer to view the remaining power and charge condition.
12. The product has perfect intelligent protection system to avoid over charge, over discharge, short circuit, overload, high
temperature or under voltage.
13. Provide enduring and clean electricity for electric tools, lighting, mobile, pc, fans and so on in conditions of camping,
travel, disaster relief, power shortage areas, grazing and islanders.

Portable Solar Power System
4
Part II Main technical parameters of the system
2.1 Technical Parameters:
Model:
ISS1000Z
System Specification:
Rated Output Power:
1000W
Solar charge controller:
24V 20A
Solar inverter:
110V/220V/1000W
Output waveform:
Pure sine wave
Battery capacity:
12V55Ah*2
AC Output ( Europe plug) :
2*220V/50Hz
DC Output (USB)
2*5V(500mA)
DC Output (DC2.1 Plug)
2*12V 3A
switching time(AC and SOLAR)
≤20ms
Peak conversion efficiency
82%
AC In connector:
CONINVERS
Solar panels connector
MC4 (16~19V)（below 15A）
AC Output Socket:
Universal \ British \ German \ French \ Australian \ American \India
Fuse Size
5 x 20 5A
Overload Protection:
Yes
Under-voltage Alarm:
Yes
Overheat Protection:
Yes
Short-circuit Protection:
Yes
Battery Power Indicator:
Yes
System charging mode
SOLAR
Mechanical Data:
Dimensions of System Box(mm):
L575*W255*H490
Net Weight of System Box(kg):
55

Portable Solar Power System
5
Part III Operating instructions
3.1 Connecting drawing of the system
Front
Back
12V DC OUT
5V USB OUT
AC OUT SOCKET
Battery Power Display
PV Charge
AC Output Light
Solar charging fault light
AC OUT
cooling fan
system main switch
Solar panels connector

Portable Solar Power System
6
3.2 Operating procedure of the system
1、Preparation before start
I. Check the output voltage and power with the technical parameter. Over value would result in damage to the product. Ensure
to connect MC4 terminal (or equivalent terminal) of solar panel. Improper unit would not be able to be connected.
II. Check the output voltage conforming to voltage on data plate, as well as ensuring no exceeding of the rated power.
III. Check the working environment. Do not use the product in wet, rainy conditions or near heat source.
IV. Check the conditions of the product. Do not use when there is any leak of colloid substance or damaged output terminals.
Never try to carry or hold the product when the screws on cover are missing or the hanging is loosened.
2、Connecting to external devices
I. Connect to solar panel
Connect the output wire of solar panel to the MC4 terminal when it is needed to charge the product.
IV. Connect to the 12V DC led bubble lights
Customer can connect the 12V bubble lights to the holder with 10M cables.
V. Connect to 5V DC devices
Use USB charger port to connect the devices of 5V 500mA need to be charged including mobile, pc and lighting. Extensional
connecting wire is also available in the optional accessories list besides self-equipped USB terminal connecting wire to connect the
product and devices.
VI. Connect to AC devices
Connect the AC devices like PC, electrical tools or lighting equipment to AC OUT socket of the product.
3、Starting-up sequence
Connect the external devices firstly like solar panel and battery charger, then turn on the Power Switch; finally connect the
appliances (turn on AC switch when using AC devices). Examples are given as follows:
I. Charging solar panel:
Connect solar panel then turn on the Power Switch (MS)
II. Charging external battery charger
Connect external battery charger then turn on the Power Switch (MS)
III. Charging solar panel simultaneously with AC appliances
Connect solar panel then turn on the Power Switch (MS), using the AC appliances and finally turn on AC switch (AC output
switch).
IV. Charging solar panel simultaneously with 5V 500mA DC appliances
Connect solar panel then turn on the Power Switch (MS), using the 5V 500mA DC appliances finally.
V. Charging external battery simultaneously with AC appliances
Connect external battery then turn on the Power Switch (MS), using the AC appliances and finally turn on AC switch (AC output

Portable Solar Power System
7
switch).
Attention:
1. The total home appliances loading power shall not exceed the total power of systems. The warranty guarantee is not valid if
the system or home appliances are damaged because of the over loading.
2. Pls use our original accessories (solar panels,fan,led bubbles,light cables). The warranty guarantee is not valid if
the system or home appliances are damaged because of using other brand accessories.
3. If connect the AC electric cable to the system, pls in strict accordance to the requirements of system (Voltage, current etc.)
4. The panels which shall be strict in accordance with the requirement of the systems. The warranty guarantee is not valid if the
system or home appliances are damaged because of mismatching panels.
5. The system shall be used under the safe environment,otherwise we don’t take any responsibility if the system have been
damaged.
Part IV Maintenance
4.1 Explanation of alarms
Alarm prompt
Explanation
bumming
under voltage of battery, close AC output
indicator: fluid twinkling
Charging by solar panel
indicator: no twinkling
System without any electric
indicator: red
low power
indicator: partly on
real electricity available, 20% for each indicator
indicator: on
connected with solar panel
indicator: on
AC output: on
indicator: on
AC output : failure
AC lights bright
The AC electric have been connect to the system

Portable Solar Power System
8
4.2 Daily maintenance and change of battery
Daily maintenance：
Lead crystal battery is used for our system which asks for timely charging after discharge. Charge the product once per month in
case of unused for a long time to maintain perfect performance. Please change the battery every 500 cycling discharge (it would be
less than 500 due to improper use) or after using of more than 2 years.
How to replace the battery
(Picture just for reference)
1.Open the cover plate on both sides of the down part of the machines
2. Taking out the screw between battery and the battery fix mount.(each side 3pcs, total 6 pcs)
3. Screwing off the Screw, which is fixed on the negative and positive pole of battery and take out the cable,
4.Taping insulating tape to the negative and positive pole of battery and take out the battery from the cabinet.
5.Take another same size battery into the system cabinet and connect the system’s negative(Black one) and positive(Red one).
6.Fix the battery to the system by screw and the battery fix mount.
7.Fix the cover plate to the both side of the system cabinet.
Attention:
Pls turn off the system switch before opening the system’s cabinet.
Pls check the battery’s negative and positive pole carefully to avoid the system short circuit because of the wrong connecting.

Portable Solar Power System
9
Part V FAQ
Q：The product has been connected to solar panel, but why is the PV Charge indicator still off?
A：Ensure the solar panel has been correctly and tightly connected to the MC4 terminal. The indicator would be off when the
working condition is not satisfied or in the dark.
Q：Why there is no AC/DC output?
A：Check the indicator of battery capacity. When the product is short of power, the indicator would be off. Please charge the
product timely to avoid damaging the battery, which would shorten the service time of our product.
Q：Why is the indicator still bight when turning off the product?
A：It is normal. There is a slow discharging period lasting about 5 seconds of the inner electronic components when turning off the
product.
Q：What’s the reason for different discharging hours under same appliance ?
A：It’s normal because time of discharging is effected by the outside temperature, using time or other factors.
Q：What’s the reason for different charging hours under same solar panels?
A：The charging time listed in the technical parameter is calculated in the condition of 4.5h of sunshine heating with optimal
environment. And the real charging time is determined by the natural conditions like daily sunlight hours, sun light intensity
and temperature, which would be varied.
Q：What’s explanation of that when the electric capacity showed low power when applying high power appliances, while
using low power appliances it turned to be more electric capacity?
A：The indicator shows the current remaining power under the load power. As in the same condition, the servicing time for high
power appliances would be less than the low power ones.
Q：Why does the capacity turn to be low while it went back by switching off?
A：It is a dynamic changing during working period and the indicator shows the current remaining capacity during working
conditions. When switch off, it turns to be standby showing the actual available capacity.
Q：Why does it turn to be gradual during charging showed by the indicator when charging by battery?
A：It varies by different batteries that used, which results in various charging time due to different parameters.
Q：What’s the best time to charge the battery?
A：The battery needs to be charged when the indicator turns red and keep the product fully charged for long time storing.
Part VI Guarantee
1.1 Product guarantee:
Main machine guarantee time: 1 years limited warranty (lifetime: more 10years)
Battery guarantee time: 1 year (lifetime: 2-3years, cycle 750 times)
Solar panel guarantee time: 5 years (lifetime: around 25years, 90% output power at first 10 years, 80% output power
at second 10 years).

Portable Solar Power System
10
User File
User name
Sex
Age
Address
Telephone
Zip
Purchasing address
Retail price
Odd
Numbers
Commodity name
and specification
Model No.
Dealer
Signature
User
Signature
Guarantee Item
Keep the card for
guarantee to keep
in repair.
Guarantee
1. 1 years upon date of production, we will guarantee to keep the power box in
repair. (not including the battery and accessories.)
2. 1 year upon date of production, we will guarantee to keep the battery in repair.
3. 5 years upon date of production, we will guarantee to keep the solar module
in repair.
4. Guarantee service is subject to normally using.
5. The guarantee do not cover any normal wear and tear, misuse, or which has
been damaged through abuse, alteration, improper installation or application,
unauthorized service or modification, storage, transportation or resulting from
any power failure surges, natural disaster, or other events outside Seller’s
control.

Portable Solar Power System
11
Portable Solar Power System
— ISS1000Z —
