THE POINTER INSTRUMENT
-- USER GUIDE --
LUNAR ARTEFACTS
LONDON
03
SPECIFICATIONS
72mm
124mm
40mm
Model : Pointer Instruments Classic (LAPI-C-MK1)
Interface : Bluetooth 5.0 | Wireless 2.4G dongle | USB-C
Sensor : Pixart PAW 3805 Optical Sensor
-Glass thickness minimum 5mm-
DPI : 800 | 1200 | 2000 | 3000
Hand Orientation : Ambidextrous
Recharge : Wireless Charging | USB-C
Dimensions : 124mm x 72mm x 40mm
Weight : Aluminium 125g | Brass 200g
Compatibility : Windows | MacOS | Linux | Android
Battery : 3.7V - 850 mAh Li-ion Rechargeable Battery
-Molex 51006 or “Losi Connector”- 9mm x 43mm x 25mm-
04
BOXCONTENTS
-1- The Pointer Instrument.
-2- Reusable frame.
-3- USB dongle.
1
4
2
3
5 6
-4- USB to USB-C cable.
-5- User guide booklet.
05
PRODUCTFEATURES
Lightly treated calf leather maximises tactile comfort and ages well.
Polished brass and aluminium allow easy maintenance and age well.
Allows customisation of materials and colour combinations.
Track on Glass sensor enables smooth performance on glass surfaces.
Carefully designed inside and out for easy repair and maintenance.
OMRON plug and play switches
NFC quick connect, customisation and plug-in accessories including
additional buttons and sizing grips. Please follow the updates on our
website: www.lunarartefacts.com
- Full-Grain French Leather Top -
- Solid Brass or Aluminium Base -
- Replaceable Top Cover -
- Triple Modes: Bluetooth 5.0 | 2.4G | Cable -
- Dual Charging : Wireless | USB-C cable -
- Track On Glass Sensor -
- Designed For Life -
- Plug and Play Switches-
- Future Updates -
06
OVERVIEW
1
2
4
6
7
5
3
8
9
10
12
14
15
16
11
13
-8- USB-C Socket
-9- Battery gauge
-10- Power switch
-11- USB Dongle
-12- DPI (Sensitivity) button
-13- Tracking sensor
-14- Connection button
-15- Wireless charging point
-16- Solid metal shell
-1- Leather top latch point
-3- Right mouse button
-4- Scroll wheel
-5- Charge indicator
-6- Battery compartment
-7- Magnetic latch
07
CONNECTIONS
3 sec
1
2
3
4
- Bluetooth Connection -
Power on the mouse. Turn the ON/OFF switch to the
ON position.
Click and hold the connection button until the
Bluetooth indicator is ON.
Press the connection button to switch to the Bluetooth
mode with the Bluetooth indicator ON.
Press and hold down the connection button for 3
seconds and then release. The LED light will start to
For Windows, navigate to Bluetooth Device Settings
and select Add Bluetooth or Other Devices, once the
For Mac, navigate to System Preferences and select
Bluetooth, once the Pointer Instrument appears, click
to Pair.
Once pairing is successful, the LED indicator will stop
now ready for use.
08
- 2.4G Dongle Connection -
1
2
3
4
1
2
3
4
Insert the USB-C into the mouse.
Connect the USB-A to the computer.
Switch the power button to the ON position.
Press the connect button until both LED lights are ON.
-The mouse will be charging while plugged in-
- Cable Connection -
Retrieve the Dongle from the base of the mouse.
Insert the Dongle into the device.
Switch the power button to the ON position.
Press the connect button to Dongle (2.4G) mode
with the Dongle indicator ON. The mouse is now
ready for use.
09
DPISETTINGS
1
2
DPI settings:
3000 DPI
2000 DPI
1200 DPI
800 DPI
Press to change DPI settings.
Top battery indicator light:
Slow breathing light - Charging
Continuously on - Fully charged
The wireless charging
point is located towards
the rear of the device.
USB cable
(approx. 2 hrs)
Wireless charging
(approx. 3 hrs)
Bottom battery indicator light:
Slow breathing light - Charging
Continuously on - Fully charged
- Battery Indicator -
CHARGING|BATTERY
- Charging -
10
Lunar Artefacts Ltd.
38 Spital Square, London, E1 6DY, United Kingdom
[email protected] www.lunarartefacts.com
©2022
HELPANDSUPPORT
Please scan the QR Code above to be taken to our Help and Support:
www.lunarartefacts.com/support
the Pointer Instrument, as well as the contact form to contact Customer Support.
