Product Manual
Models: DCT-1R Series
Version 1.6
Jan, 2022

Page | 1
Statement of Use
Each DataCartTM is designed to set a high standard in quality, ease of use, and customer satisfaction. Our
goal is to provide a product that is built to exacting standards and is ready for years of durable service.
TESTED TO COMPLY WITH:
UL Standard for Safety Medical Equipment, Part 1: General Requirements for Safety
RECOMMENDED SHIPPING AND OPERATING CONDITIONS:
Temperature Range 25°F- 120°F / Humidity Range 10% - 80%
TERMS OF USE: Removing or damaging the serial number will void all cart warranties.
For maximum stability, lower the DataCartTM completely when rolling over thresholds or other uneven
surfaces.
Warranty Information: https://data-carts.com/product-downloads/
Cart Features
Additional Options:
Vital Signs Monitor
Mount
Accessory Arm Interface
Bracket
Printer / Scanner
Shelves
Cup Holders
Scanner Holders
Sani Wipe Holder
Wire Baskets
Front Wheel Locks
on Casters
Release Handle –Raise and Lower
Work Surface
Cable Management Box
for excess cable and laptop
power supply
’ 120 VAC
Coiled
Power
Cord

DataCartTM Height Adjustment
The height adjustment handle is located on the right side of the work surface.
Adjust the height up and down by pressing the handle or paddle upwards.
DataCartTM Locking Wheels
All wheels have locks to prevent the cart from moving.
Push each lever down with your foot to engage the locks.
Push each lever up with your foot to release the locks.
Technical Specifications
Work Surface: small –” W x .” L; edium –” W x .” L; large – 30” W x ” L
Height Adjustet: .” Low x ” High
Wheelbase: ” W x ” L
Weight (Basic Cart Only): 48-58 lbs.
DataCartTM Optional Storage Drawers
Combi-Cam Lock Combination Instructions
•On the underside of the outer edge of the lock, there is a hole for the
code reset button. Rotate the face of the lock until the code reset button
comes into view.
•Push and hold this pin in with a paper clip.
•Set your personal combo by turning the dials to desired 3-digit combo.
•Release the reset button with the paperclip and your combo is set.
•Be sure to save your new combo; rotate the lock to the "Locked Position".
Rotate one or more dials after lock is closed. To open the lock, turn the
dials to your personal combination you just set.
Warnings
Important Warnings Electrical Shock Warning
The above symbols represent safety warnings that require significant attention when seen on the EMC
cart or in the user manual. Failure to do so could result in minor injury, major injury, or even death.
SERVICE AND REPLACEMENT Do not attempt to service or replace any part of the DataCartTM unless
directed to do so through DataCartTM approved documentation (i.e., this User Manual or other
instructions). If any component on the cart is missing or damaged, the cart must not be used. Contact your
Reseller or DataCartTM immediately to request service.
Page | 2

SAFE WORKING LOADS
Safe working loads labels must be abided by for all parts
MAXIMUM WEIGHTS:
Work Surface 20 lbs.
DO NOT USE THE UNIT IN OR NEAR WATER OR OTHER LIQUIDS
If the unit becomes wet, unplug it immediately, wipe away any excess liquid and allow it to
dry before use.
DO NOT TRANSPORT THE CART UP OR DOWN STAIRS
TRANSPORTING
For maximum stability, lower the DataCartTM completely when rolling over thresholds or
other uneven surfaces.
COIL CORD
Make sure the coil cord is secure prior to moving the cart
When disconnecting, pull the plug rather than the cord itself
Do not use if cord is damaged –contact Lund Industries for a replacement.
