Lutool LT3IN1 User manual

12V LI-ION Power Tool Set
LT3IN1
Instruction Manual
Warning: Please make certain that the person intended to use this
equipment carefully reads and understands these instructions before
starting opertions.

Product components:
Fig. A: Cordless Drill

Fig. B: Cordless Multi Purpose Saw

Fig. C: Cordless Multi Function Tool
9

CONTENTS
1APPLICATION ..................................................................................6
2DESCRIPTION (FIG A-B-C)..............................................................6
3PACKAGE CONTENT LIST..............................................................7
4SYMBOLS.........................................................................................7
5GENERAL POWER TOOL SAFETY WARNINGS...........................8
6ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS ....................................................................................10
7ADDITIONAL SAFETY INSTRUCTIONS FOR CORDLESS DRILLS
.........................................................................................................11
8ADDITIONAL SAFETY INSTRUCTIONS FOR THE CORDLESS
MULTI PURPOSE SAWS ...............................................................11
9ADDITIONAL SAFETY INSTRUCTIONS FOR THE CORDLESS
MULTI FUNCTION TOOL ...............................................................12
10 GENERAL CHARGING INFORMATION (APPLICABLE FOR ALL 3
CORDLESS TOOL BATTERIES)...................................................13
11 OPERATION INFORMATION SPECIFIC FOR THE CORDLESS
DRILL ..............................................................................................14
12 OPERATION INFORMATION SPECIFIC FOR THE MULTI
PURPOSE SAW..............................................................................20
13 OPERATION INFORMATION SPECIFIC FOR THE MULTI
FUNCTION (OSCILLATING) TOOL ...............................................24
14 CLEANING AND MAINTENANCE .................................................29
15 TECHNICAL DETAILS....................................................................29
16 NOISE..............................................................................................30
17 RECYCLING....................................................................................30

LI-ION POWER TOOL SET 12V
1 APPLICATION
This set comes with 3 tools : A Cordless Drill
, a Multi Purpose Saw and a Multi Function Tool
.
Cordless Drill : The machine is intended to drill holes in wood, bricks or metal (when drilling in steel,
keep the machine in low speed to improve the drilling efficiency). It can also be used for driving in and
loosening screws and bolts.
Multi Purpose Saw : This tool is designed for cutting wood, iron, nonferrous metals and plastics, using a
standard saw blade.
Multi Function Tool : Depending on the accessory mounted on the tool, this machine is intended for a
variety of tasks such dry sanding small areas, sawing, scraping, polishing, rasping, cutting, separating,
etc.
These 3 tools are not designed for commercial or industrial use.
2 DESCRIPTION (FIG A-B-C)
Cordless Drill
Fig. A
Cordless Multi Purpose Saw
Fig. B
Cordless Multi Function Tool
Fig. C
1. Keyless chuck
2. 21+1 Torque setting
3. Two-speed selector
4. Forward/reverse
selector
5. ON/OFF switch trigger
6. Battery pack
7. Release latch for battery
pack
8. LED battery indicators
9. LED work-light
1. Safety guard
2. Movable saw head
3. Push button for
movable saw head
4. Soft grip
5. Lock-off button
6. ON/OFF switch trigger
7. Battery pack
8. Battery latch
9. Base plate
10. Quick-change blade
clamping holder
11. Speed control dial
1. Cut saw blade
2. ON/OFF switch button
3. LED battery indicator
4. Battery pack
5. Latch for battery pack
6. Speed controller
7. Scraper
8. Sanding base plate
9. Sanding paper
10. Hex key
WARNING! Read this manual and general safety instructions carefully
before using the appliance, for your own safety. Your power tool should
only be passed on together with these instructions.

3 PACKAGE CONTENT LIST
Remove all packaging materials.
Check that the package contents are complete.
Check the appliance, the power cord, the power plug and all accessories for transportation
damage.
Keep the packing materials as far as possible until the end of the warranty period. Dispose of it
into your local waste disposal system afterwards.
WARNING: Packaging materials are not toys! Children must not play with plastic
bags! There is a danger of suffocation!
Cordless Drill
Cordless Multi Purpose Saw
Cordless Multi Function Tool
1 x Cordless Drill
1 x Multi Purpose Saw
2 x Wood Blade
2 x Metal Blade
1 x Multi Function Tool
1 x Straight blade
1 x Scraping blade
1 x Sanding base plate
10x Sandpaper sheets
1 x 1 hour fast charger
1 x Battery 1300mAh
1x Allen key
1 x Instruction manual
4 SYMBOLS
The rating plate on your tool may show certain symbols.
These represent import information about the product or instructions on its use.
Denotes risk of personal injury
or damage to the tool.
"Class II - The charger is double
insulated; Earthing wire is
therefore not necessary.
To reduce the risk of injury,
user must read manual before
use.
Symbols on the battery :
Ambient temperature:
50°C max.
Only use indoors.
Do not throw the battery into
water.
Do not throw the battery into
fire.

5 GENERAL POWER TOOL SAFETY WARNINGS
WARNING：Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference!
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
5.1 Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
5.2 Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will
reduce the risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
5.3 Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a
dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
5.4 Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the
hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
5.5 Battery Tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a connection from one terminal to another.
Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
5.6 Service
a) Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.

6 ADDITIONAL SAFETY INSTRUCTIONS FOR BATTERIES AND
CHARGERS
6.1 Batteries
Never attempt to open for any reason.
Do not store in locations where the temperature may exceed 40 °C.
Charge only at ambient temperatures between 4 °C and 40 °C.
Charge only using the charger provided with the tool.
When disposing of batteries, follow the instructions given in the section “Recycling”.
Do not cause short circuits. If connection is made between the positive (+) and negative (-)
terminal directly or via accidental contact with metallic objects, the battery is short circuited and
an intense current will flow causing heat generation which may lead to casing rupture or fire.
Do not heat. If batteries are heated to above 100 °C, sealing and insulating separators and other
polymer components may be damaged resulting in electrolyte leakage and/or internal short
circuiting leading to heat generation causing rupture or file. Moreover do not dispose of the
batteries in fire, explosion and/or intense burning may result.
Under extreme conditions, battery leakage may occur. When you notice liquid on the battery,
proceed as follows:
- Carefully wipe the liquid off using a cloth. Avoid skin contact.
- In case of skin or eye contact, follow the instructions below:
Immediately rinse with water. Neutralize with a mild acid such as lemon juice or
vinegar.
In case of eye contact, rinse abundantly with clean water for at least 10 minutes.
Consult a physician.
Fire hazard! Avoid short-circuiting the contacts of a detached battery. Do not incinerate
the battery.
6.2 Charger
Use the charger provided with the tool only to charge the battery.
Never attempt to charge non-rechargeable batteries.
If the supply cord is damaged, it must be replaced by manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Do not expose to water.
Do not open the charger.
Do not probe the charger.
The charger is intended for indoor use only.
This charger is not intended for use by persons (including children) with reduced physical, sensory
or metal capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their
safety.
Children should be supervised to ensure that they do not play with the appliance.

7 ADDITIONAL SAFETY INSTRUCTIONS FOR CORDLESS DRILLS
-Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
-Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a
“live” wire may make exposed metal parts of the power tool “live” and could give the
operator an electric shock.
-Hold power tool by insulated gripping surfaces, when performing an operation where the
fastener may contact hidden wiring. Fasteners contacting a "live" wire may make exposed
metal parts of the power tool "live" and could give the operator an electric shock.
8 ADDITIONAL SAFETY INSTRUCTIONS FOR THE
CORDLESS MULTI PURPOSE SAWS
a) Hold power tool by insulated gripping surfaces, when performing an operation where the
cutting accessory may contact hidden wiring. Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live” and could give the operator an electric shock.
b) Do not stare at the tool with the blade touching any surface. The blade action will bounce the
tool and may cause bodily injury.
c) Allow the tool to come to a complete stop before putting it down. A running tool will jerk when
the blade tip contacts any surface.
d) Always wear safety glasses or goggles, normal prescription eye or sunglasses are not safety
glasses.
e) Do not cut oversized work pieces.
f) Do not cut nails or screws unless you are using a blade specifically designed for this purpose,
inspect your material before cutting.
g) Before switching on the tool, be sure the blade is not in contact with the work piece.
h) Keep hands away from moving parts and on the top surface of the work piece. Do not place
hands below work surface while saw is operating.
i) Check your area for proper clearance before cutting. This will avoid cutting into your
workbench, the floor, etc.
8.1 Special safety precautions for cordless multi purpose saws.
Do not use for cutting pipes or cables.
Do not use cracked, blunt or damaged blades.
Do not start the saw if no blade is fitted.
Check there are no obstructions in/on the surface under the item to be cut.
Do not attempt to cut items thicker than the maximum cutting depth of the blade, or where there
is insufficient space for the blade under the item.
The saw’s metal parts may become conductive if the saw comes into contact with a live wire.
Therefore only hold the saw by its insulated handle.
Check that the ventilation slots are not blocked.
Always use a face mask if excessive amounts of dust are generated or cutting harmful materials.
Never cut asbestos materials.
Never remove dust, obstructions or the like from the work area while the blade is operating.
Never stop the saw blade by applying pressure to the saw or to the side of the blade.
Do not lift the saw from the item being cut if the blade is still running.
Never place the saw on a table or workbench if it has not stopped completely.
The saw blade will continue to run a short time after the machine has been switched off.

Do not touch the blade or metal filings until they have cooled.
9 ADDITIONAL SAFETY INSTRUCTIONS FOR THE
CORDLESS MULTI FUNCTION TOOL
Risk of injury !
Only use an undamaged plug and cable of charger.
Do not treat any materials that produce any particles that are detrimental to health (e.g.
asbestos).
Risk of damage to property/material !
Mains voltage must correspond with the voltage specifications on the charger.
Only use original accessories.
9.1 Personal protective equipment
When using this power tool wear the following protective items:
Protective glasses
Ear protection
Breathing mask
Wear gloves

10 GENERAL CHARGING INFORMATION
(APPLICABLE FOR ALL 3 CORDLESS TOOL BATTERIES)
10.1 Charging the battery pack (Fig. 3)
Fig. 3
a. Red LED light b. Green LED light c. Charger
The battery pack for this tool has been shipped in a low charge condition to prevent any possible
problems. You should charge the batteries prior to use.
NOTE: Batteries will not reach full charge the first time they are charged. Allow several cycles (working
followed by recharging) for the item to fully charge. The battery should only be charged indoors.
The battery pack will become slightly warm to the touch while charging, this is normal and does not
indicate a problem.
Do not place the charger in an area of extreme heat or cold, it will work best at normal room
temperature.
When the battery is fully charged, unplug your charger from the power supply and remove the battery
pack from the charger.
NOTE:
Allow the battery pack to cool completely before charging.
Inspect the battery pack before charging; do not charge a cracked or leaking battery pack.
Charging indication:
The charger (c) has two LED lights (Red and Green) (Refer to Fig. 3)
1. Plug the charger (c) into a suitable outlet. Do not use an extension cord. The green light (b) will
light to show the power is connected.
2. Push the battery pack to make sure contacts on battery pack engage properly with contacts in
charger (Refer to Fig. 3(A)). The red light (a) will illuminate to show the battery is charging and the
green light (b) will extinguish at the same time.

3. When the battery is loaded, the red light (b) extinguishes and green light illuminates until the
charger disconnect from the mains.
NOTE: If the battery does not fit properly, disconnect it and confirm that the battery pack is the correct
model for this charger as shown on the specification chart. Do not charge any other battery pack or any
battery pack that does not securely fit the charger.
Frequently monitor the charger and battery pack while connected.
Unplug the charger and disconnect it from the battery pack when finished.
Store the charger and battery pack indoors, out of reach of children.
NOTE: If the battery is hot after continuous use, allow it to cool down to room temperature before
charging. This will extend the life of your battery.
11 OPERATION INFORMATION SPECIFIC FOR
THE CORDLESS DRILL
11.1 Assembly - Cordless Drill
This product has been shipped completely assembled.
Carefully remove the tool and any accessories from the box. Make sure that all items listed in the
packing list are included.
WARNING: Do not use this product if it is not completely assembled or if any
parts appear to be missing or damaged. Use of a product that is not properly
and completely assembled could result in serious personal injury.
Inspect the tool carefully to make sure no breakage or damaged occurred during shipping.
Do not discard the packing material until you have carefully inspected and satisfactorily operated the
tool.
WARNING: If any parts are damaged or missing do not operate this tool until
the missing parts are replaced. Use of this product with damaged or missing
parts could result in serious personal injury.
WARNING: Do not attempt to modify this tool or create accessories not
recommended for use with this tool. Any such alteration or modification is
misuse and could result in a hazardous condition leading to possible serious
personal injury.
WARNING: To prevent accidental starting that could cause serious personal
injury, always remove the battery pack from the tool when assembling parts.
WARNING: Do not allow familiarity with tools to make you careless.
Remember that a careless fraction of a second is sufficient to inflict serious
injury.
WARNING: Do not use any attachments or accessories not recommended by
the manufacturer of this tool. The use of attachments or accessories not
recommended can result in serious personal injury.

11.2 Insertion/ removal of the battery (Fig. 4)
Fig. 4
WARNING: Before making any adjustments ensure the drill is switched off
with the forward/reverse selector (4) in the centre position.
1. Align the raised rib inside tool with groove on the battery pack (6).
2. Make sure the latches (7) on each side of the battery pack snap into place and the battery pack is
secured in the tool before beginning operation.
WARNING: Always remove the battery pack from your tool when you are assembling
parts, making adjustments, cleaning it, or when not in use. Removing the battery pack
will prevent accidental starting that could cause serious personal injury.
To remove the battery : depress the latches on each side of the battery pack to remove the battery pack
from the tool.
WARNING: Battery products are always in operating condition. Therefore,
you should keep your fingers away from the trigger when the tool is not in
use. Carrying power tools with your finger on the switch invites accidents.
11.3 Installing and removing a drill bit
1. Hold the cordless drill firmly with one hand.
2. Turn the chuck ring clockwise with the other
hand until the drill chuck opening is large
enough to accept the bit.
3. Insert the bit into the drill chuck.
4. Turn the chuck ring anticlockwise until the
tool is clamped tightly.
Remove the bit in the opposite way.
Fig. 5

11.4 Switching ON/OFF (Fig. 6 and 7)
Fig 6
Fig 7
The cordless drill starts and stops by depressing and releasing the ON/OFF switch
trigger (5).
This cordless drill is equipped with an electric brake, when the ON/OFF switch is released completely the
chuck stops immediately.
11.4.1 Switch lock
The switch trigger can be locked in the OFF position.
This helps to reduce the possibility of accidental starting when not in use.
To lock the switch trigger, place the forward/reverse selector (4) in the centre position.
11.4.2 Forward and reverse
The forward and reverse direction is controlled by the forward and reverse selector (4) located above
the switch trigger.
Clockwise rotation: To select forward rotation, release the on/off switch and push the
forward/reverse selector (4) to the right side of the tool (See Fig. 6 / 7).
Anticlockwise rotation: To select reverse rotation, push the forward/reverse selector (4) to the
left side of the tool. When the selector is in centre position, the switch trigger is locked and the machine
cannot be switched on. (See Fig. 6 / 7)

11.4.3 Variable speed
This tool has a variable speed switch that delivers higher speed and torque with increased trigger
pressure.
Speed is controlled by the amount of switch trigger depression.
11.5 LED battery indicators.
Fig. 8
There are 3 LED battery indicators (8)
positioned above the ON/OFF switch trigger.
You can check the battery capacity status by
squeezing the ON/OFF switch trigger.
Before using the drill, press the switch trigger
to check if the battery is full enough to work
properly.
The statuses of the three LED lights show the
capacity level of the battery:
-When the battery is fully charged the Green
LED L1, the yellow LED L2 and the red LED L3
are all lit.
-If the Green LED L1 and yellow LED L2 are lit
the battery has about 60% of its capacity left.
-If only the red LED L3 is lit, the battery is
almost fully discharged.
NOTE: The LED battery indicators always light during operation.
NOTE: Please charge the battery each time after use, it is necessary to charge the battery every month if
the machine is out of work.
11.6 LED work-lights
Fig. 9
There is an LED work-light (9) in front of
your cordless drill.
The LED work-light can light prior to the
motor running if you press the switch
lightly, which will keep the work area
illuminated for checking clearly at first, and
it also lights during operation.
WARNING:
-Do not stare directly at the light beam.
-Never aim the beam at any person or an
object other than the work piece.
-Do not deliberately aim the beam at
people and ensure that it is not directed
towards the eye of a person for longer than
0.25 sec.

11.7 Adjusting the torque
The torque is adjusted by rotating the torque setting (2), the torque is greater when the torque setting is
set on a higher position. The torque is less when the torque setting is set on a low position“1”denote
lowest and “ ” denote highest.
Torque is set by means of a torque setting according to different screw types and different materials. If
the screw is long and the material is hard, you can adjust to a higher torque setting as follows:
1 - 5
For driving small screws
6 - 10
For driving screws into soft material
11 - 16
For driving screws into soft and hard material
17 - 21
For driving screws into hard wood
For heavy drilling
11.8 Speed selector (Fig. 10)
Low speed Position
High speed Position
Fig. 10
NOTE : Mark “1”is the Low speed position, mark “2”is the High speed position. It is moulded into the
button of two speed selector (3).
The drill has a two-speed gear train designed for drilling at 1 (LOW) or 2 (HIGH) speed.
A gear selector is located on top of the drill to select either low or high speed. When you push the
button (3) forward and select low speed range, the speed will decrease but will provide more power and
torque.
When using the cordless drill in the high speed range, the speed will increase but will provide less power
and torque.
Use low speed for high power and torque application and high speed for fast drilling applications.
IMPORTANT: To avoid damage NEVER adjust this two speed selector（3）whilst the
drill is running. Always let it come to a complete stop first.

11.9 Drilling
Before drilling, the torque setting should be set on drill position “ ”.
When drilling hard smooth surface, use a centre punch to mark the desired hole location. This will
prevent the drill bit from slipping off centre as the hole is started. Hold the tool firmly and place the tip
of the drill or bit into the work piece, applying only enough pressure to keep the bit cutting. Do not force
or apply side pressure to elongate a hole.
11.9.1 Wood Drilling
For maximum performance, use high speed steel drill bits for wood drilling, turn the torque setting on
the drill position“ ”. Begin drilling at a very low speed to prevent the bit from slipping off the starting
point. Increase the speed as the drill bit bites into the material. When drilling through holes, place a
block or wood behind the work piece to prevent ragged or edges on the back side of the hole.
11.9.2 Metal drilling
For maximum performance, use high speed steel bits for metal or steel drilling. Turn the torque setting
on the drill position“ ”. Begin drilling at a very low speed to prevent the bit from slipping off the
starting point. Maintain a speed and pressure which allows cutting without overheating the bit. Applying
too much pressure will overheat the drill; wear the bearings, bend or burn bits, produce off-centre or
irregular shaped holes.
When drilling large holes in metal, it is recommended that you drill with a small bit at first, then finish
with a large bit, also lubricate the bit with oil to improve drilling action and increase bit life.

12 OPERATION INFORMATION SPECIFIC FOR THE
MULTI PURPOSE SAW
12.1 Installing/replacement of the blade.
Warning: Always remove the battery pack before making any adjustment or attaching
any accessories.
Select the saw blade best suitable for your application. Wood blades have a coarser tooth pitch; metal
blades have a finer tooth pitch. Use each blade only for its specified material.
Fig. 11
1. Push and hold the lever of the quick-change blade clamping holder (10).
2. Slide the saw blade into the locating groove with the teeth pointing forward for the jig saw
function (refer to Fig. 11) or downward for the reciprocating saw function (refer to Fig. 12).
3. Make sure that the saw blade fits into the blade clamping holder firmly and then release the lever.
Fig. 12
