Lutron Electronics LM-81LX Installation manual

HT METE

Model : LM-81LX

Your purchase of this

LIGHT METER marks a

step forward for you into

the field of precision

measurement. Althou

this METER is a complex

and delicate instrument,

its durable structure will

allow many years of use if

proper operatin

techniques are developed.

Please read the followin

instructions carefully and

always keep this manual

within easy reach.

OPERATION MANUAL

TABLE OF CONTENTS

1. FEATURES................................................................ 1

2. SPECIFICATIONS...................................................... 1

3. FRONT PANEL DESCRIPTION..................................... 3

3-1 Power Button...................................................... 3

3-2 Hold Button........................................................

3-3 Max. / Min. Button............................................... 3

3-4 Zero Button......................................................... 3

3-5 Lux/Ft-cd button.................................................

3-6 Light Sensor........................................................ 3

3-7 LCD display......................................................... 3

3-8 Battery Compartment / Cover............................... 3

3-9 Wristlet............................................................... 3

4. MEASURING PROCEDURES........................................ 4

5. OTHER FUNCTIONS.................................................. 4

6. BATTERY REPLACEMENT........................................... 6

7. OPTIONAL CARRYING CASE.................................... 6

1. FEATURES

*Tiny bone shape with lightweight and small size case design

are suitable for handling with one hand.

*Wristlet design provides extra protection to the instrument

especially for user one hand operation.

*Exclusive photo diode and color correction filter light sensor,

spectrum meets C.I.E. photopic.

*Build in microprocessor circuit assures excellent

performance and accuracy.

*Concise and compact buttons arrangement, easy operation.

*Memorize the maximum and minimum value with recall.

*Lux/Feet-candle selectable by pressing button on the front

panel.

*Zero button design makes light meter calibration.

*Hold function to freeze the current reading value.

2. SPECIFICATIONS

2-1 General Specifications

Display 8 mm LCD display

Measurement Light ( Lux/Feet-candle)

Operating Max. 80% RH.

Humidity

Operating 0 to 50° C (32 to 122° F)

Temperature

Over Input Indication of "- - - - "

Display

Power Supply 006P DC 9V battery (Heavy duty type)

Power Approx. DC 6.2 mA

Consumption

Weight 160g (battery included)

Dimension HWD 156x60x33 mm (6.14x2.36x1.29 inch).

Standard Instruction Manual

Accessory

Optional Carrying case.

Accessory

2-2 Electrical Specification ( 23 ± 5 )

℃

Measure- Range Resolution Accureacy

ment

Lux 0 to 2,200 Lux 1 Lux

1,800 to 20,000 Lux 10 Lux ± 5% rdg ± 8 dgt

Ft-cd 0 to 204.0 Fc 0.1 Ft-cd

170 to 2,000 Fc 1 Ft-cd

Remark :

Feet-candle = Ft-cd = Fc

3. FRONT PANEL DESCRIPTION

Fig. 1

3-1 Power Button

3-2 Hold Button

3-3 Max. / Min. Button

3-4 Zero Button

3-5 Lux/Ft-cd button

3-6 Light Sensor

3-7 LCD display

3-8 Battery Compartment / Cover

3-9 Wristlet

4. MEASURING PROCEDURE

1) Power on the instrument by pressing the " Power Button "

( 3-1, Fig. 1 ).

2) Position the " Light Sensor " ( 3-6, Fig. 1 ) directly under the

light source. At the mean time the light reading value will be

displayed on the LCD display.

)

Press the " Lux/Ft-cd Button " ( 3-5, Fig. 1 ) to

select measuring unit " Lux " or " Ft-cd ".

Zero Offset Adjustment of Light Function :

*Whenever reverse the meter and blank the light sensor

with a desktop or any other flat surfaces and press the

" Zero Button (3-4, Fig 1) " to finish the zero offset

adjustment.

*Zero point might drift away because of environment

temperature change, battery power change or any other

reasons. Whenever above zero offset adjustment

procedures are recommended to be done for the most

precise measurement if the zero point drifted away

5. OTHER FUNCTIONS

5-1 Hold Function

Whenever press the "Hold Button " ( 3-2, Fig. 1 ) will freeze

the current reading value with a "HOLD" symbol on the

display.

5-2 Data Record Function

1) The Data Record function records & displays the maximum

and minimum reading values. To start the Data Record

function by pressing the " Max./Min. Button " ( 3-3, Fig. 1 )

once. There will be a " REC " symbol on the display.

2) With the REC symbol on the display :

(a) Press the " Max./Min. Button " ( 3-3, Fig. 1 ) once and the

" Max " symbol along with the maximum value will appear on

the display.

(b) Press the " Max./Min. Button " again, the " Min " symbol

along with the minimum value will appear on the display.

Button " continuously for at least 2 seconds. The display will

revert to the current reading.

(d) To clear the Max./Min. value recorded by pressing the

" Hold Button " ( 3-2, Fig. 1 ) once. Previous recorded

Max./Min. value will be given up and then revert to the

REC. function keep on recording.

5-3 Auto Power Off Disable

In order to prolong the battery life, the instrument has "Auto

Power Off " function. The meter will switch off automatically if

no buttons are pressed for around 10 minutes.

6. BATTERY REPLACEMENT

When the LCD display shows " " symbol, it's

necessary to replace a new battery. However within

specification measurement may still be made for several hours

after low battery indicator appears.

2) Open the " Battery Compartment / Cover " ( 3-8, Fig. 1) and

remove the battery.

3) Install a 9V battery (Alkaline or Heavy duty type) and then

reinstate the cover.

7. OPTIONAL CARRYING CASE

Carrying case * High quality carrying case with sash.

CA-52A * Size : 200 x 80 x 50 mm.

60210-LM-81LX

LIGHT METER

Model : LM-81LX
